Universal Remote Control Total Control MRX-8 User manual

wner’s Manual
MRX-8
System Controller

Total Control MRX-8 Owner’s Manual ©2015 Universal Remote Control, Inc.
The information in this owner’s manual is copyright protected. No part of this
manual may be copied or reproduced in any form without prior written consent
from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR
O ERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN
THIS MANUAL.
The information in this owner’s manual may be subject to change without prior
notice.
Total Control is a registered trademark of Universal Remote Control, Inc.
URC - Control the Experience is a registered trademark of Universal Remote
Control, Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
Universal Remote Control,Inc.
500 Mamaroneck Avenue, Harrison, NY 10528
hone: [phone] Fax: [phone]

TABLE FCNTENTS
ntroduction 1
Features and Benefits 1
Parts Guide 1
Front Panel Descriptions 2
Rear Panel Descriptions 3
nstalling the MRX-8 4
Specifications 8
Limited Warranty Statement 9
End User Agreement 11
Federal Communication Commission
nterference Statement 12
Declaration of Conformity 13

Page 1
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Introduction
Congratulations on purchasing the Total Control MRX-8 System
Controller for automation and control. Using the Total Control line
of interfaces provides you full access and control for every
compatible device using R, P, RS-232, and Relays. This network
based control is also compatible with URC sensors, like audio
sensor and video sensor, which detects the status of a device and
provides automation triggers.
The MRX-8 makes it easy to turn on multiple devices at once such
as a TV and Blu-Ray, even lights with one button press. Enjoy
controlling your space!
Features and Benefits
Stores and issues commands and macros for all P, R,
RS-232, Relay to compatible devices and other Total Control
series base stations in the system.
Provides two-way communication with Total Control
interfaces. (TRC-780 remote requires optional UZ-1 to be
compatible with MRX-8)
Can be programmed offsite via the internet, after initial
programming is completed onsite, and project is registered
with URC's Offsite Programming portal.
Parts Guide
The MRX-8 System Controller includes:
1 - System Controller
1 - Sleeved Emitter for RFTX-1 port
1 - Wall Mount and 4 Screws
1 - AC Power Adapter
5 - Standard Emitters/Flashers
1 - Adjustment Tool
1 - nstallation Manual

Page 2
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Front Panel Descriptions
The front panel consists of two indicator lights which illuminate
when in use.
Power LED: ndicates that the MRX-8 is powered on when lit.
Ethernet LED: ndicates the network connectivity status:
● On = Connected
●Off = Not connected
●Blinking = Attempting to connect.
Power LED Ethernet LED

Page 3
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Rear Panel Descriptions
The rear panel ports are:
DC 12V Power: Attach the included 12V power supply here.
LAN Connection: RJ45 standard Ethernet connection to the
local network.
Relays (N , NC, C M): Programmable relay to be normally
opened (NO), normally closed (NC) or momentary contact. An
application shall require less than 30V/.5A.
RS-232: Two RS-232 ports support Tx(Transmit), Rx(Receive) and
GND(Ground) connections for two-way communication.
Compatible with URC cables RS232F and RS232M.
Sensors: Two sensor ports allow programming of state dependent
and triggered automation macros. Compatible with URC Video
(SEN-V D), Voltage (SEN-VOLT), Audio (SEN-AUD), Current (SEN-
CMF), Light (SEN-L TE), and Contact Closure (SEN-CCLS) sensors.
IR utputs: Six standard 3.5mm R emitter ports with individual
output level adjustment screws. Always use the supplied sleeved
emitter with pink connector, in port #6. lugging a regular emitter to
this port may cause it to damage the unit and prevent it from
operating correctly.
RFTX-1 Port: Connect the included 3.5mm stereo to 3.5mm stereo
to the optional RFTX-1 transmitter and control URC Lighting
products via 418MHz or 433.92MHz wireless RF.
Reset: Press and release to reboot. Pressing and holding for 15
seconds factory defaults the unit.
DC 12V
Power
Relay: N ,
NC, C M
RFTX-1
Reset
RS-232 Ports
Sensors
IR utputs: #1-6
LAN

Installing the MRX-8
Physical Installation of the MRX-8 and Accessories
The MRX-8 System Controller can be installed anywhere in the
home or office network. Once installed, program it to operate all
local equipment using P/Network, R, RS-232, or Relays. As well as
query the status of a device using Sensors. All cables are plugged
into their respective ports in the rear of the unit.
Network Installation
1. Connect an Ethernet cable (RJ45) to the rear of the MRX-8 and
onto the network.
2. Plug flashers into any of the six R outputs on the rear of the MRX-8.
(Make sure the 3.5mm pink connector cable is reserved for port
#6.)
Page 4
TTAL CNTR L MRX-8 SYSTEM CNTR LLER

Page 5
ptimizing IR Flasher Levels
Test a few commands for each device before fixing the flasher in
place on the front panel of a device. Since Satellite Receivers and
Cable Boxes are extremely sensitive to R overload or saturation, you
should test them thoroughly. Put up the cable or satellite
on-screen guide and test the navigation arrows. Compare operation
via RF to the original remote control. Operation should be identical.
f operation is inconsistent or sluggish, lower the R line output
and/or reposition the flasher.
f you still have sluggish operation, check that the remote control is
set to a particular L NE OUT, rather than ALL. When R commands
are sent to all the flashers in a cabinet, you can have difficulty
adjusting the R Output. Reprogram the remote control to send R
commands only via a specific (1-6) Line Output, then readjust the R
Line Output level.
1. Connect an IR emitter to each R output and run the emitter wire
to the front panel of each component. DO NOT STICK the emitter
in place. Adjust the level first.
2. Adjust each of the IR utput levels with the included adjustment
tool for best operation. f the component operates best at minimum
level, but is still operating sluggishly or intermittently, move the
emitter farther away from the component’s R sensor.
RS-232 Connection
The MRX-8 can operate equipment via RS-232 communication. This
allows discrete serial commands to be triggered from a Total Control
remote to a MRX-8. The signal is then sent to the device over
proprietary URC RS-232 cables. These use either male or female
DB-9 connections with standard pin-outs.
TTAL CNTR L MRX-8 SYSTEM CNTR LLER

Page 6
Using Sensors with the MRX-8
The MRX-8 uses sensors to detect audio, light, video, voltage, current
and contact closures to determine the equipment status, query the state
of a device or other automation triggers for the equipment it controls.
For example, using a video sensor cable with the MRX-8 can detect a
video signal from a composite or component video output.
TTAL CNTR L MRX-8 SYSTEM CNTR LLER

Page 7
Wiring to the Relay on the MRX-8
The MRX-8 has a Relay with three contacts, NO, NC, and COM. These
can be used as dry contacts or to an electrical switch or motor for use
with screens, blinds, curtains, etc. The Relay can be programmed as
either a latching or a momentary contact.
Using an RFTX-1 for URC ne-Way Lighting products
The MRX-8 can use an RFTX-1, via the available RFTX-1 port. t
controls URC One-Way Lighting products at 418 or 433.92 MHz.
Use the included 3.5mm to 3.5mm to connect to the RFTX-1 and
plug the other end into the RFTX-1 port (#6).
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
RFTX-1

Page 8
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Specifications
Network: One 10/100 Ethernet port
Relay: One relay configurable to be NO, NC or Momentary
Sensor: Two Sensors support Video (SEN-V D), Voltage (SEN-VOLT),
Audio (SEN-AUD), Current (SEN-CMF), Light (SEN-L TE), and
Contact Closure (SEN-CCLS) sensors.
RS-232: Two RS-232 ports support TX, RX and GND two-way
communication via URC cables.
IR: Six adjustable R ports enable the included URC emitters to
control R devices Note: 6th IR Output requires the included
sleeved emitter (identified by a pink connector), since it can
optionally be used to connect an RFTX-1.
Weight: 10.5 oz.
Size: 9.76” X 4.72” X 1.10”
Power: 12V External Power Supply

Page 9
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Limited Warranty Statement
1. LIMITED WARRANTY AND DISCLAIMERS
Universal Remote Control, nc. (“URC”) warrants that URC
equipment purchased directly from URC or from an authorized
URC dealer or distributor shall be free from defects in material and
workmanship under normal usage for a period of one (1) year from
the date of purchase of the product by the end-user, but no longer
than thirty-six (36) months from the date of shipment of the URC
equipment by URC to an authorized URC dealer or distributor,
except that with respect to Total Control® whole-house products,
the warranty extends for two (2) years from the date of purchase by
the end-user, but no longer than forty-eight (48) months from the
date of shipment of the URC equipment by URC to an authorized
URC dealer or distributor.
This limited warranty is valid only in the United States of America.
URC equipment purchased from other than an authorized URC
dealer or distributor is without warranty.
URC warrants that the software will substantially conform in any
material respect to its functional specifications at the time of
delivery. URC SHALL NOT BE L ABLE FOR OPERAT ONAL,
TECHN CAL OR ED TOR AL ERRORS AND/OR OM SS ONS
MADE N THE URC DOCUMENTAT ON. URC DOES NOT
WARRANT THAT THE URC SOFTWARE S BUG-FREE OR ERROR
FREE OR THAT THERE ARE NO ERRORS/BUGS N THE URC
SOFTWARE.
URC warrants that at the time of purchase the URC equipment and
the URC software complied with all applicable regulations and
policies of the Federal Communications Commission ("FCC")
regarding electromagnetic interference caused by
electronic/computing devices and to the extent that the URC
equipment and/or the URC software fails to so comply, URC shall,
at its own expense, take all reasonable measures to promptly cause
such to comply.
TH S L M TED WARRANTY DOES NOT COVER TECHN CAL
ASS STANCE FOR HARDWARE OR SOFTWARE USAGE EXCEPT
AS EXPRESSLY PROV DED FOR HERE N.
CERTA N MPL ED WARRANT ES, NCLUD NG AN MPL ED
WARRANTY OF MERCHANTAB L TY AND F TNESS FOR A
PART CULAR PURPOSE, MAY BE AVA LABLE W TH RESPECT TO
URC EQU PMENT. MPL ED WARRANT ES VARY FROM STATE
TO STATE. URC EXPRESSLY L M TS THESE MPL ED
WARRANT ES, TO THE EXTENT ALLOWABLE BY LAW, TO THE
T ME PER ODS COVERED BY THE EXPRESS WR TTEN
WARRANT ES PROV DED HERE N. OTHERW SE AND EXCEPT AS
PROV DED FOR HERE N, URC EXPRESSLY D SCLA MS ALL
WARRANT ES, EXPRESS, STATUTORY OR MPL ED, AND MAKES
NO REPRESENTAT ONS REGARD NG THE USE OF, OR THE
RESULTS OF THE USE OF, THE EQU PMENT, SOFTWARE OR
DOCUMENTAT ON N TERMS OF CORRECTNESS, ACCURACY,
REL AB L TY OR OTHERW SE.

Page 10
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
EXCEPT AS EXPRESSLY PROV DED FOR HERE N, TECHN CAL
SERV CES ARE SUPPL ED "AS S", W THOUT ANY WARRANTY,
EXPRESS, STATUTORY OR MPL ED, OF ANY K ND. TO THE
MAX MUM EXTENT PERM TTED BY APPL CABLE LAW, URC
EXPRESSLY D SCLA MS ALL WARRANT ES RELAT NG TO
TECHN CAL SERV CES, EXPRESS, STATUTORY OR MPL ED,
NCLUD NG BUT NOT L M TED TO THE WARRANT ES OF
QUAL TY OR REASONABLE SK LL AND CARE, OR OUTCOME
OR RESULTS.
W THOUT N ANY WAY L M T NG THE GENERAL TY OF THE
OTHER PROV S ONS HERE N, TH S L M TED WARRANTY DOES
NOT COVER: ( ) DAMAGE FROM M SUSE, NEGLECT OR ACTS
OF NATURE, ( ) MOD F CAT ONS, ( ) NTEGRAT ON W TH
TH RD PARTY CONTENT, OR ( V) BEYOND THE WARRANTY
PER OD AND/ OR FA LURE TO FOLLOW URC WARRANTY
CLA M PROCEDURE.
The warranty limitations and warranty disclaimers may not apply to
end user in whole or in part, where such are restricted or excluded
by applicable law, and such shall apply to the maximum extent
permitted by applicable law.
n the event of any warranty claim, URC will, at its sole option,
repair the URC equipment using new or comparable rebuilt parts,
or exchange the URC equipment for new or rebuilt equipment. In
the event of a defect, these are the end user's exclusive remedies.
All the URC equipment returned for service, exchange or repair
require an RGA number. To obtain an RGA number, you must
complete a Return Request Form which you may obtain by calling
[phone] or contacting URC at
[email protected]. To obtain warranty service,
end user must deliver the URC equipment, freight prepaid, in its
original packaging or packaging affording adequate protection to
URC at 420 Columbus Avenue, Valhalla, NY 10595. t is end user's
responsibility to backup any macro programming, artwork, software
or other materials that may have been programmed into the unit. t
is likely that such data, software, or other materials will be lost
during service and URC will not be responsible for any such
damage or loss. A dated purchase receipt, bill of sale, installation
contract or other verifiable proof of purchase is required. For the
URC equipment support and other important information, please
visit URC's website available at www.universalremote.com or call
the Customer Service Center at [phone].
This limited warranty only covers the URC equipment issues
caused by defects in material or workmanship during ordinary
consumer use. t does not cover product issues caused by any other
reason, including but not limited to product issues due to
commercial use, acts of God, third-party installation, misuse,
limitations of technology, or modification of or to any part of the
URC equipment. This limited warranty does not cover the URC
equipment sold as used, as is, refurbished, so called "B stock" or
consumables (such as batteries). This limited warranty is invalid if
the factory applied serial number has been altered or removed from
the URC equipment. This limited warranty specifically excludes

Page 11
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
the URC equipment sold by unauthorized resellers.
With the exception of URC's R-only, broad-based consumer
remotes, none of URC's PC programmable remotes or any of our
Total Control® whole-house equipment are authorized for online
internet sales. Buying URC's PC programmable remotes or any of
our Total Control® whole-house equipment online means buying
equipment that does not have URC's limited warranty. Such
equipment is not eligible for URC tech support or software support,
either.
2. URC'S LIMITATI NS F LIABILITY
N NO EVENT SHALL URC BE L ABLE FOR ND RECT, SPEC AL,
NC DENTAL, EXEMPLARY, PUN T VE OR CONSEQUENT AL DAMAGES
OF ANY K ND OR LOSS OF PROF TS OR BUS NESS OPPORTUN TY,
EVEN F URC S ADV SED OF THE POSS B L TY OF SUCH DAMAGES.
N NO EVENT SHALL URC BE L ABLE FOR LOSS OF OR DAMAGE TO
DATA, COMPUTER SYSTEMS OR COMPUTER PROGRAMS.
URC'S L AB L TY, F ANY, FOR D RECT DAMAGES OF ANY FORM
SHALL BE L M TED TO ACTUAL DAMAGES, NOT N EXCESS OF
AMOUNTS PA D BY END USER FOR THE URC EQU PMENT.
N NO EVENT SHALL URC BE L ABLE FOR ANY EVENTS BEYOND TS
CONTROL, NCLUD NG ANY NSTANCE OF FORCE MAJEURE.
N NO EVENT SHALL URC BE L ABLE FOR THE ACTS OR OM SS ONS
OF END USER OR ANY TH RD PARTY.
THE L M TAT ONS OF L AB L TY MAY NOT APPLY TO END USER N
WHOLE OR N PART, WHERE SUCH ARE RESTR CTED L M TED OR
EXCLUDED BY APPL CABLE LAW AND SUCH SHALL APPLY TO THE
MAX MUM EXTENT PERM TTED BY APPL CABLE LAW.
URC SHALL NOT BE HELD RESPONS BLE FOR THE STATEMENTS MADE
BY OTHERS.
SOME STATES OR JUR SD CT ONS DO NOT ALLOW THE EXCLUS ON
OR L M TAT ON OF NC DENTAL OR CONSEQUENT AL DAMAGES, OR
ALLOW L M TAT ONS ON HOW LONG AN MPL ED WARRANTY
LASTS, SO THE ABOVE L M TAT ONS OR EXCLUS ONS MAY NOT
APPLY TO END USER. TH S L M TED WARRANTY G VES END USER
SPEC F C LEGAL R GHTS AND END USER MAY HAVE OTHER R GHTS
WH CH VARY FROM STATE TO STATE OR JUR SD CT ON TO
JUR SD CT ON.
End User Agreement
The terms and conditions of the End User Agreement is available at
www.universalremote.com/eua.php shall apply.

Page 12
TTAL CNTR L MRX-8 SYSTEM CNTR LLER
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. f this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one more of
the following measures:
Reorient or relocate the receiving antenna.
ncrease the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Warning!
Changes or modifications not expressly approved by the manufacturer could void
the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

Page 13
Declaration of Conformity
Company Name : OH SUNG ELECTRONICS CO., LTD.
Company Address : #181 GONG DAN-DONG, GUMI, GYEONG BUK,
REPUBLIC OF KOREA
Contact Information : Phone: [phone], Fax: [phone]
Brand Name : UNIVERSAL remote control
Product Name : System Controller
Model Name : MRX-8
This product herewith complies with the requirements of EMC Directive(2004/108/EC)
issued by the Commission of the European Community
Compliance with these directives implies conformity to the following European Community
 EMC Directive
 EN 55022
 EN 55024
 EN 61000-3-2
 EN 61000-3-3
List of test reports and/or certificate verified compliance with the standards above
Date of issue :
Name and signature of authorized person :
 EMC Directive
 Report No.
 Testing Laboratory : Gumi College EMC Center
OH SUNG ELECTRONICS CO., LTD.
TTAL CNTR L MRX-8 SYSTEM CNTR LLER

Page 14
NTE

Page 15
NTE

OCE-0073k Rev 02_RH
500 Mamaroneck Avenue, Harrison, NY 10528
hone: [phone] Fax: [phone]
www.universalremote.com
