Universal Tool UT8840R User manual

1/2" REVERSIBLE DRILL
PLEASE READ AND FOLLOW ALL WARNINGS
Read Operating Instructions
Always become familiar with all the
instructions and warnings before
operating any power tool.
Always Wear Approved
Eye Protection
Impact resistant eye protection
should meet or exceed the
standards as set forth in the United
States ANSI Z87.1, Occupational
and Educational Eye and Face
Protection. Look for the marking
Z87.1 on your eye protection to
insure that it is an approved style.
For further information, ANSI Z87.1,
Occupational and Educational Eye
and Face Protection, is available
from the American National
Standards Institute, Inc., 11 West
42nd Street, New York, NY 10036.
Hearing Protection is
Recommended
Hearing protection should be used
when the noise level exposure
equals or exceeds an 8 hour time-
weighted average sound level of 85
dBA. Process noise, reflective
surfaces, other tools being
operated nearby, all add to the
noise level present in your work
area. If you are unable to determine
your noise level exposure, we
recommend the use of hearing
protection.
Avoid Prolonged Exposure to
Vibration
Tools can vibrate during use.
Prolonged exposure to vibration or
very repetitive hand and arm
movements, can cause injury.
Stop using any tool if discomfort,
tingling feeling or pain occurs. You
should consult your physician
before resuming use of the tool.
90 PSIG Maximum
This tool is designed to operate at
an air pressure of 90 pounds per
square inch gauge pressure (90
PSIG) maximum, at the tool. Use of
higher air pressure can, and may
cause injury. Also, the use of
higher air pressure places the
internal components under loads
and stresses they were not
designed for, causing premature
failure. The air supply should be
clean and dry, preferably
lubricated. For best results, drain
the moisture from your compressor
daily.
Universal Tool
A Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter, Florida 33458
Toll Free 1-800-327-9403
Read these instructions carefully before attempting to install, operate
or service this Florida Pneumatic product. Failure to comply with the
instructions could result in personal injury and/or property damage!
Retain these instructions for future reference.
devices as furnished by the manufac-
turer. Where an air tool is modified or
altered, the modifier shall provide the
safeguards to enable it to be safely used
in the operations intended and to comply
with any applicable provisions as
contained in ANSI B186.1.
Tool Installation
Pressure regulators shall be used to limit
air pressure to the rated pressure where
the supply pressure exceeds the tool’s
rated pressure. Air hoses and lines shall
be relieved of compressed air before
being disconnected or disjointed, unless
there is automatic valve closing protec-
tion at the joint being separated. Syn-
thetic lubricants which can cause
deterioration of elastomer seals shall not
be used in air systems of air tools.
Tool Maintenance
It shall be the tool owner’s and/or
employer’s responsibility to assure that
tools are maintained in a safe operating
condition. Tool maintenance and repair
shall be performed by authorized,
trained, competent personnel. Tools shall
be disconnected from their compressed
air supply before repairs are attempted.
Repairs shall be consistent with the
manufacturer’s recommended proce-
dures. Tool, hoses and fittings shall be
replaced if unsuitable for safe operation.
It shall be the tool owner’s and/or
employer’s responsibility to keep required
rating markings and warnings on the tool
in legible condition.
FPMC
WARNING:
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals
known to cause cancer, birth defects or
reproductive harm. Some examples of
these chemicals are:
•Lead from lead-based paints
•Crystalline silica from bricks, cement
and other masonry products
•Arsenic and chromium from chemi-
cally treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to
these chemicals, work in a well-ventilated
area and work with approved safety
equipment such as those dust masks that
are specially designed to filter out
microscopic particles.
PL0253
UT8840R
Safety Instructions
The following instructions are furnished
as general guidelines for use of your
pneumatic tool. They cannot compre-
hensively cover all possible or conceiv-
able uses of the subject tool. For
additional information on the safe use
of air tools, we advise you to obtain a
copy of ANSI B186.1 Safety Code for
Portable Air Tools, available from the
following source:
American National Standards
Institute, Inc.
11 West 42nd Street
NewYork,NY10036.
The use of the word “shall” in the
following instructions, indicates that
adherence to the particular require-
ment is necessary to conform to ANSI
B186.1.
Tool Application and Usage
Portable tools shall be used only for
the purposes intended in their design
and within the capacity for which they
were intended and rated. It shall be
the tool owner’s and/or employer’s
responsibility to instruct each operator
in the safe use of the tool. Tools shall
not be used without guards and safety
Description
Universal Tool model UT8840R 1/2" Heavy Duty Reversible Drill is designed for
general drilling and cutting operations that require extra power in a compact tool,
including honing, reaming and wire brushing. Durable and easy to use this drill
features a convenient trigger mounted reverse valve, a lightweight aluminum
housing to reduce fatigue, through handle exhaust to direct air away from work and
an auxiliary handle for more control.

Parts Breakdown for UT8840R
Ref. Description Part # Ref. Description Part #
Replacement Parts for UT8840R
UT8840R UT8840R
1/2" REVERSIBLE DRILL 1/2" REVERSIBLE DRILL
Limited Warranty
Universal Tool warrants its tools to be free from defects in material and workmanship for one year
from the date of purchase. This warranty does not apply to tools which have been abused,
misused, modified or repaired by someone other than Universal Tool or its authorized service
centers. If a Universal Tool proves defective in material of workmanship within one year after
purchase, return it to any authorized service center or to Universal Tool, freight prepaid. Please
enclose your name, address and adequate proof of purchase date with a brief description of the
defect. Universal Tool will, at its option, repair or replace defective tools, free of charge. Repairs or
replacements are warranted as described above for the remainder of the warranty period. Univer-
sal Tool's sole liability and your exclusive remedy under this warranty is limited to repair or replace-
ment of the defective tool. There are no other warranties expressed or implied and Universal Tool
shall not be liable for incidental, consequential or special damages, or any other damages, costs or
expense of repair or replacement as described above.
Specifications
Chuckcapacity................................................................................................................1/2"
Freespeed.............................................................................................................800RPM
Spindlethread.........................................................................................................3/8"-24
Weight........................................................................................................................31/4lbs.
Length.............................................................................................................................81/2”
Averageair consumption........................................................................................4CFM
Recommendedhose size......................................................................................3/8"I.D.
Inletsize.................................................................................................................1/4"NPT
Maximumoperating pressure................................................................................90PSI
22 Valve stem 8900106
23 O-Ring 81008173
24 O-Ring 8900107
25 Reverse lever 8900108
26 Reverse bushing 8900109
27 O-Ring 8900110
28 Pin 8900111
29 Motor housing 8900112
30 Motor gasket 8900113
31 Exhaust diffuser 8731922
32 Screw (2) 8731921
33 Air inlet 8731920
34 Screen 81005726
35 Valve spring 8731925
36 Rubber cushion 8900276
37 Steel ball 8732435
38 Work spindle 8900277
39 Idler gear (6) 8900278
40 Reduction spindle 8900279
41 Pinion gear 8900280
1 Chuck spacer 8730229
2 Drill chuck w/key 5975
3 Clamp nut 8900272
4 Outer collar 8900273
5 Inner collar 8900274
6 Clamp ring 8900275
7 Dead handle 8729974
8 Chuck screw 8900100
9 Ball bearing (2) 81000894
10 Washer 8730231
11 Internal gear (2) 8732078
12 Spacer 8900101
13 Ball bearing (2) 8729012
14 End plate (2) 8900102
15 Rotor 8900103
16 Rotor blade (5) 8729709
17 Cylinder 8900104
18 Pin 8900105
19 Retaining ring 8729180
20 Set screw 8731928
21 Trigger 8731929
