Universal Tool UT100S-18 Manual

FLORIDA-PNEUMATIC.COM
Pleasecontact1-800-356-3392forfurtherassistance.
Universal Tool
™
GRINDERS & CUT-OFF TOOLS
General Safety Information & Replacement Parts
WARNING: Risk of injury to persons. Read and
understand operation instructions. Always become familiar
with all the instructions and warnings before operating any
pneumatic tool.
WARNING: DO NOT REMOVE GUARD. NEVER OPERATE
THETOOLWITHOUTTHE GUARD FITTED.
TABLE OF CONTENTS
General Safety Information ...........................2
Air Compressor and Air Tool Safety...................2-3
Tool Specifications ..................................3
Installation ........................................4
Maintenance / Lubrication............................4
Troubleshooting ....................................5
Warranty ..........................................5
Service Parts.....................................6-7
UT100S-18
1HP HORIZONTAL GRINDER

U niversal Tool a Division of Florida Pneumatic Manufacturing Corporation
7.2.2.3 GENERAL SAFETY RULES
• Multiple hazards. Read and understand the safety instructions before
installing, operating, repairing, maintaining, changing accessories on,
or working near the power tool. Failure to do so can result in serious
bodily injury.
• Onlyqualiedandtrainedoperatorsshouldinstall,adjustorusethe
power tool.
• Donotmodifythispowertool.Modicationsmayreducetheeffec-
tiveness of safety measures and increase the risks to the operator.
• Do not discard the safety instructions – give them to the operator.
• Do not use a tool if the tool has been damaged.
• Warningsshallbegivenagainsttheriskofexplosionorreduetothe
material being processed;
• Warnings shall be given against the risk of cutting.
7.2.2.4 PROJECTILE HAZARDS
• Failure of the work piece, of accessories, or even of the tool itself may
generate high velocity projectiles.
• Always wear impact-resistant eye protection during operation of the
tool. The grade of protection required should be assessed for each
use.
7.2.2.5 ENTANGLEMENT HAZARDS
• Entanglement hazard - choking, scalping and/or lacerations can occur
if neck ware, hair or gloves are not kept away from tool and acces-
sories.
7.2.2.6 OPERATING HAZARDS
• Use of the tool may expose the operator’s hands to hazards including
crushing, impacts, cuts and abrasions and heat. Wear suitable gloves
to protect hands.
• Operators and maintenance personnel must be physically able to
handle the bulk, weight and power of the tool.
• Hold the tool correctly: be ready to counteract normal or sudden
movements – have both hands available.
• Maintain a balanced body position and secure footing.
• Keep hands away from rotating or reciprocation accessories, spindles
or other moving parts.
• Release the start and stop device in the case of an interruption of the
energy supply
• Use only lubricants recommended by the manufacturer.
7.2.2.7 REPETITIVE MOTIONS HAZARDS
• When using a power tool, you may experience discomfort in your
hands, arms, shoulders, neck, or other parts of your body.
• While using a power tool, position your body in a comfortable
posture. Maintain secure footing and avoid awkward or off-balanced
postures. Changing your posture during extended tasks may help
avoid discomfort and fatigue.
• If you experience symptoms such as persistent or recurring discom-
fort, pain, throbbing, aching, tingling, numbness, burning sensation,
or stiffness, do not ignore these warning signs. Promptly tell your
employerandconsultaqualiedhealthprofessional.
7.2.2.8 ACCESSORY HAZARDS
• Only use sizes and types of accessories and consumables that are
recommended by the power tool manufacturer.
7.2.2.9 WORKPLACE HAZARDS
• Slips, trips and falls are major causes of workplace injury. Be aware
of slippery surfaces caused by use of the tool and also of trip hazards
caused by the air line or hydraulic hose.
• Proceed with care in unfamiliar surroundings. Hidden hazards may
exist, such as electricity or other utility lines.
• This power tool is not intended for use in potentially explosive atmo-
spheres and is not insulated from coming into contact with electric
power.
• Make sure there are no electrical cables, gas pipes etc. that could
cause a hazard if damaged by use of the tool.
7.2.2.10 DUST AND FUME HAZARDS
• Dust from some work processes can cause cancer, birth defects or
other respiratory diseases. Risk assessment of these hazards and
implementation of appropriate controls is essential.
• Ifthepneumatictoolisusedinadustlledenvironmentexhaust
air can cause a dust hazard
• Dusts and fumes generated when using power tools can cause
ill health (for example: cancer, birth defects, asthma and/or der-
matitis); risk assessment of these hazards and implementation of
appropriate controls of is essential.
• Risk assessment should include dust created by the use of the tool
and the potential for disturbing existing dust.
• Operate and maintain the power tool as recommended in these
instructions, to minimize dust or fume emissions
• Direct the exhaust so as to minimized disturbance of dust in a dust
lledenvironment
• Where dusts or fumes are created, the priority shall be to control
them at the point of emission.
• All integral features or accessories for the collection, extraction or
suppression of airborne dust or fumes should be correctly used
and maintained in accordance with the manufacturer’s instructions.
• Select, maintain and replace the consumable/inserted tool as
recommended in these instructions, to prevent an unnecessary
increase in dust or fumes
• Use respiratory protection as instructed by your employer or as
required by occupational health and safety regulations;
7.2.2.11 NOISE HAZARDS
• Unprotected exposure to high noise levels can cause permanent,
disabling, hearing loss and other problems such as tinnitus (ring-
ing, buzzing, whistling or humming in the ears);
• Risk assessment of these hazards and implementation of appropri-
ate controls of is essential.
• Appropriate controls to reduce the risk may include actions such as
damping materials to prevent work pieces from ‘ringing’
• Use hearing protection as instructed by your employer or as
required by occupational health and safety regulations;
• Operate and maintain the power tool as recommended in these
instructions, to prevent an unnecessary increase in noise levels;
• Select, maintain and replace the consumable/inserted tool as
recommended in these instructions, to prevent an unnecessary
increase in noise.
7.2.2.12 VIBRATION HAZARDS
• Exposure to vibration can cause disabling damage to the nerves
and blood supply of the hands and arms;
• Wear warm clothing when working in cold conditions and keep
your hands warm and dry;
• If you experience numbness, tingling, pain or whitening of the skin
inyourngersorhands,stopusingthepowertool,andtellyour
employer.Youshouldalsoseekmedicaladvicefromaqualied
occupational health professional.
• Operate and maintain the power tool as recommended in these
instructions, to prevent an unnecessary increase in vibration;
• Select, maintain and replace the consumable/inserted tool as
recommended in these instructions, to prevent an unnecessary
increase in vibration levels;
• Support the weight of the tool in a stand, tensioner or balancer,
because the operator can then use a lighter grip to support the tool.
• Hold the tool with a light but safe grip taking account of the
required hand reaction forces, because the risk from vibration is
generally greater when the grip force is higher.
7.2.3 ADDITIONAL SAFETY INSTRUCTIONS FOR PNEUMATIC
POWER TOOLS - AIR SUPPLY & CONNECTION HAZARDS
• Air under pressure can cause severe injury.
• Always shut off air supply, drain hose of air pressure and discon-
nect tool from air supply when not in use, before changing acces-
sories or when making repairs.
• Never direct air at yourself or anyone else.
• Whipping hoses can cause severe injury. Always check for dam-
agedorloosehosesandttings.
• Whenever universal twist couplings (claw couplings) are used, lock
pins must be installed.
• Do not exceed the maximum air pressure stated on the tool.
• Use whip check safety cables to safeguard against possible hose to
tool and hose to hose connection failure.
• Never carry an air tool by the hose.
Safety Information

FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Safety Information (continued)
AIR COMPRESSOR AND AIR TOOL SAFETY
1. Risk of Bursting. Do not adjust the regulator to result in output
pressure greater than the marked maximum pressure of this air
tool.
2. Ensure the hose is free of obstructions or snags. Entangled or
snarled hoses can cause loss of balance or footing and may
become damaged.
3. Never leave a tool unattended with the air hose attached.
4. Do not operate this tool if it does not contain a legible warning
label.
5. Do not continue to use a tool or hose that leaks air or does not
function properly.
6. Never direct a jet of compressed air toward people or animals.
7. Protect your lungs.Wear a face or dust mask if the operation is
dusty.
Important Warnings - Grinders & Cut-Off Tools
Specications
1. The stopping time, if longer than 5 seconds,shall be stated,and it shall be recommended to put the grinder in a stable position.
2. When cutting-off, the workpiece shall be so supported that the slot is kept at constant or increasing width during the whole operation.
3. If the abrasive product gets jammed in a cut slot,shut off the grinder and ease the wheel free. Check that the wheel is still correctly secured and not
damaged before continuing the operation.
4. Grinding wheels and cut-off wheels shall not be used for side grinding. (Exception:grinding wheels designed for side grinding.) Grinders should not
be used over the maximum rated speed of an abrasive product.
5. The operator shall pay attention that no bystanders are in the vicinity.
6. The personal protective equipment such as gloves,apron and helmet shall be used.
7. Do not remove guard. Never operate the grinder without the original guard supplied by the grinder manufacturer correctly fitted to the grinder.
8. Only use the wheel mounting anges supplied by the grinder manufacturer.
9. Only use grinding wheels and cut-of wheels and wire brushes that meetANSI standards,ISO standards or both-this will be shown on the wheel
manufacturers label.
10. Only use grinding wheels and cut-off wheels and wire brushes that have the correct center mounting hole or correct threaded insert center to match
the spindle thread on the grinder.
11. Never adjust the grinder, adjust the guard or change the wheel unless the air supply and air hose is disconnected from the grinder.
12. Only personnel trained in the correct methods to adjust guards and change grinding wheels or cut-off wheels or wire brushes should conduct these
operations.
13. Always ensure that you are aware of the direction of the sparks being created by the grinding operation and ensure that the sparks are not directed
to the operator or other persons in the area.
14. Never use a grinder close to any explosive or ammable materials or air conditions.
15. Only use the type of wheel that the grinder manufacturer species that the grinder is designed for use with.
16. Never attempt to modify or adapt a grinder or cut-off tool to accept a grinding wheel or cut-off wheel or wire brush that the grinder was not designed
for use with.
17. Eye protection,hearing protection,safety gloves and safety aprons must always we worn when operating a grinder.
Vibration Level (m/sec2):1.4 Noise Level (dBA): 82
Motor Motor Max. Wheel Speed Spindle Guard Weight Weight Length Length Rec. Air Inlet Rec. Hose Air Cons Av. Air Cons
Model (HP) (kW) Dia. (in) (RPM) Exhaust Size Type (lb) (Kg) (in) (mm) Pressure (NPT) (I.D. in) (cfm) (cfm)
UT100S-18 1.0 .75 3” 18,000 Rear 3/8 -24 Type 1 3.25 1.47 13.35 796 90 psi-6.2 bar 3/8" 1/2" 13 10

Universal Tool a Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
Installation
1 Cleaning the air hose
□A 3/8" air hose is required,with a maximum length of 25 ft.
□Clean the air hose of accumulated dust and moisture
before connecting it to the air supply.
NOTE: If a longer air hose is required,connect a 1/2" air
hose to the 3/8" air hose to ensure the angle grinder has
the necessary air supply.
Ensure the air line is shut-off and drained of air before removing this tool for service or changing sockets.This will prevent the tool from
operating if the throttle is accidentally engaged.
LUBRICATION
□An in-line lter-regulator-lubricator is recommended as it increases tool life and keeps the tool in sustained operation.
□Regularly check and ll the in-line lubricator with air tool oil.Avoid using excessive amounts of oil.
□Adjust the in-line lubricator by placing a sheet of paper next to the tool’s exhaust ports and holding the throttle open approximately 30
seconds.The lubricator is properly set when a light stain of oil collects on the paper.
□If it is necessary to store the tool for an extended period of time (overnight, weekend,etc.),generously lubricate the tool through the air
inlet. Run the tool for approximately 30 seconds to ensure the oil is evenly distributed throughout the tool. Store the tool in a clean and
dry environment.
□Recommended lubricants:Air tool oil or any other high grade turbine oil containing moisture absorbent,rust inhibitors,metal wetting
agents,and an EP (extreme pressure) additive.
Maintenance
Recommended Air Line Set-Up
Part Description
AAirTool
B Quick Plug
C Quick Coupler
D Air Hose
E In-line Regulator
F In-line Lubricator
G In-line Filter
H Air Compressor

FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Troubleshooting
Problem Possible Cause Solution
The tool runs slowly or will not
operate. There is grit or gum in the tool. □Flush the tool with air tool oil or gum solvent.
The tool is out of oil. □Lubricate the tool according to the lubrication
instructions in this manual.
The air pressure is low. □Adjust the regulator on the tool to the
maximum setting.
□Adjust the compressor regulator to the tool’s
maximum setting of 90 psi.
The air hose leaks. □Tighten and seal the hose ttings with pipe
thread tape if leaks are found.
The air pressure drops. □Ensure the hose is the proper size. Long
hoses or tools using large volumes of air may
require a hose with an I.D. of ½" or larger
depending on the total length of the hose.
□Do not use a multiple number of hoses
connected together with a quick connect
tting.This causes additional pressure drops
and reduces the tool power. Directly connect
the hoses together.
There is a worn rotor blade in the motor. □Replace the rotor blade.
There is a worn ball bearing in the motor. □Remove and inspect the bearing for rust,dirt,
and grit. Replace or clean and grease the
bearing with bearing grease.
There is moisture blowing out
of the tool’s exhaust. There is water in the tank. □Drain the tank. (See the air compressor manual for instructions.) Lubricate the tool
and run it until water is not evident. Lubricate
the tool again and run for 1-2 seconds.
Warranty
LimitedWarranty:Universal Tool warrants its tools to be free from defects in material and workmanship for one year from the date of
purchase.This warranty does not apply to tools which have been abused,misused, modied or repaired by someone other than Universal
Tool or its authorized service centers. If a UT tool proves defective in material or workmanship within one year after purchase,return
it to any authorized service center or Universal Tool freight prepaid. Please enclose your name,address and adequate proof of date of
purchase and a short description of the defect. UniversalTool will,at its option, repair or replace defective tools free of charge. Repairs or
replacements are warranted as described above for the remainder of the original warranty period. UniversalTool's sole liability and your
exclusive remedy under this warranty is limited to repair or replacement of the defective tool.
There are no other warranties expressed or implied and UniversalTool shall not be liable for incidental, consequential or special damages,
or any other damages,costs or expenses excepting only the cost or expense of repair or replacement as described above.

U niversal Tool a Division of Florida Pneumatic Manufacturing Corporation
Service Parts / Exploded View Drawing

FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Service Parts / Exploded View Drawing
Ref
#Part Number Description Qty Ref #Part Number Description Qty.
1 9ST40001 AIR INLET 1 18 9ST40023 ROTOR BLADE 4
2 9ST40002 EXHAUST SLEEVE 1 19 9ST40024 ROTOR 1
3 9ST40003 CONE MUFFLER 1 20 9ST40025AS CYLINDER SET 1
4 9ST40004 SPRING 1 21 9ST40026AS FRONT PLATE SET 1
5 9ST40005 STEEL BALL 1 22 970048A BEARING 1
6 9ST40006AS VALVE BUSHING SET 1 23 9ST40029 COUPLING NUT 1
7 9ST40008 O-RING 1 24 9ST290L29 COUPLING 1
8 9ST40009 BACK COVER 1 25 9ST40031 BUSHING 1
9 9ST40010 PROTECTING RUBBER 1 26 9ST40032 SPINDLE 1
10 9ST40011AS VALVE STEM SET 1 27 9ST40033 CLAMP NUT 1
11 9ST40015 HOUSING 1 28 9ST40034 SPINDLE HOUSING 1
12 9ST40016 SAFETYTHROTTLE 1 29 9ST40035 SHAFT 1
13 9ST40017 PIN 1 30 9ST40036 DISCWASHER 1
14 9ST40021AS VALVE CASE SET 1 31 9ST27037 NUT 1
15 9ST-91521 GOVERNOR SET (0.6mm) 1 32 9ST40039AS GUARD SET 1
16 9ST15418 BEARING 1 33 9BT25457 STOP SPANNER (14mm) 1
17 9ST40022 REAR PLATE 1 34 9BT88045 STOP SPANNER (25.4mm) 1

Universal Tool a Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
Universal Tool a Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
