Universal Tool UT8769 User manual

PLEASE READ AND FOLLOW ALL WARNINGS
Read Operating Instructions
Always become familiar with all the
instructions and warnings before operating
any power tool.
Always Wear Approved
Eye Protection
Impact resistant eye protection should
meet or exceed the standards as set forth
in the United States ANSI Z87.1,
Occupational and Educational Eye and
Face Protection. Look for the marking
Z87.1 on your eye protection to insure that
it is an approved style. For further
information, ANSI Z87.1, Occupational and
Educational Eye and Face Protection, is
available from the American National
Standards Institute, Inc., 11 West 42nd
Street, New York, NY 10036.
Hearing Protection is
Recommended
Hearing protection should be used when the
noise level exposure equals or exceeds an
8 hour time-weighted average sound level
of 85 dBA. Process noise, reflective
surfaces, other tools being operated
nearby, all add to the noise level present in
your work area. If you are unable to
determine your noise level exposure, we
recommend the use of hearing protection.
Avoid Prolonged Exposure to
Vibration
PnuematicTools can vibrate during use.
Prolonged exposure to vibration or very
repetitive hand and arm movements, can
cause injury. Stop using any tool if
discomfort, tingling feeling or pain occurs.
You should consult your physician before
resuming use of the tool.
90 PSIG Maximum
This tool is designed to operate at an air
pressure of 90 pounds per square inch
gauge pressure (90 PSIG) maximum, at the
tool. Use of higher air pressure can, and
may cause injury. Also, the use of higher
air pressure places the internal components
under loads and stresses they were not
designed for, causing premature
Universal Tool
A Division of Florida Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter, Florida 33458
Toll Free 1-800-327-9403
Read these instructions carefully before attempting to install, operate or
service this Florida Pneumatic product. Failure to comply with the instruc-
tions could result in personal injury and/or property damage! Retain these
instructions for future reference.
Safety Instructions
The following instructions are furnished as
general guidelines for use of your pneu-
matic tool. They cannot comprehensively
cover all possible or conceivable uses of
the subject tool. For additional information
on the safe use of air tools, we advise you
to obtain a copy of ANSI B186.1 Safety
Code for Portable Air Tools, available from
the following source:
American National Standards
Institute, Inc.
11 West 42nd Street
New York, NY 10036.
The use of the word “shall” in the following
instructions, indicates that adherence to
the particular requirement is necessary to
conform to ANSI B186.1.
Tool Application and Usage
Pneumatic tools shall be used only for the
purposes intended in their design and
within the capacity for which they were
FPMC
WARNING:
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth
defects or reproductive harm. Some examples of
these chemicals are:
•
Lead from lead-based paints
•
Crystalline silica from bricks, cement and
other masonry products
•
Arsenic and chromium from chemically
treated lumber
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals, work in a well-
ventilated area and work with approved safety
equipment such as those dust masks that are
specially designed to filter out microscopic
particles.
MODEL NO. UT8769
9” VERTICAL GRINDER
intended and rated. It shall be the tool owner’s
and/or employer’s responsibility to instruct
each operator in the safe use of the tool.
Tools shall not be used without guards and
safety devices as furnished by the manufac-
turer. Where an air tool is modified or altered,
the modifier shall provide the safeguards to
enable it to be safely used in the operations
intended and to comply with any applicable
provisions as contained in ANSI B186.1.
Tool Installation
Pressure regulators shall be used to limit air
pressure to the rated pressure where the
supply pressure exceeds the tool’s rated
pressure. Air hoses and lines shall be
relieved of compressed air before being
disconnected or disjointed, unless there is
automatic valve closing protection at the joint
being separated. Synthetic lubricants which
can cause deterioration of elastomer seals
shall not be used in air systems of air tools.
Tool Maintenance
It shall be the tool owner.s and/or
employer.s responsibility to assure that
tools are maintained in a safe operating
condition. Tool maintenance and repair
shall be performed by authorized,
trained, competent personnel. Tools
shall be disconnected from their
compressed air supply before repairs
are attempted. Repairs shall be
consistent with the manufacturer.s
recommended procedures.
Tool, hoses and fittings shall be
replaced if unsuitable for safe operation.
It shall be the tool owner.s and/or
employer.s responsibility to keep
required rating markings and warnings
on the tool in legible condition.
.
Features: 2.0 HP Motor prevents stall under load. Safety lock-off throttle.
Governor controlled to maintain speed for optimum material removal
Double bearing spindle design for durability. Built-in exhaust silencer system
Best for continuous heavy duty grinding
Always use accessories with an
RPM rating that meets or exceeds
the tool RPM rating.

Replacement Parts
Limited Warranty
Universal Tool warrants its tools to be free from defects in material and workmanship for one year from the date of
purchase. This warranty does not apply to tools which have been abused, misused, modified or repaired by
someone other than Universal Tool or its authorized service centers. If a Universal Tool proves defective in
material of workmanship within one year after purchase, return it to any authorized service center or to Universal
Tool, freight prepaid. Please enclose your name, address and adequate proof of purchase date with a brief
description of the defect. Universal Tool will, at its option, repair or replace defective tools, free of charge. Repairs
or replacements are warranted as described above for the remainder of the warranty period. Universal Tool's sole
liability and your exclusive remedy under this warranty is limited to repair or replacement of the defective tool.
There are no other warranties expressed or implied and Universal Tool shall not be liable for incidental, consequential
or special damages, or any other damages, costs or expense of repair or replacement as described above.
Specifications:
MODEL NO. UT8769
9” VERTICAL GRINDER
MODEL NO. UT8769
9” VERTICAL GRINDER
Motor HP .................................................................................................................. 2.0
Max. Wheel Diameter ................................................................................... 9” Type 27
Exhaust .................................................................................................................. Side
Spindle Size ..................................................................................................... 5/8” - 11
RPM ...................................................................................................................... 7,000
Weight ................................................................................................................. 7.2 lbs
Length ................................................................................................................... 12.5”
Air Inlet .............................................................................................................1/2” NPT
Rec Hose ................................................................................................................ 3/8”
NYT’QNOITPIRCSEDONTRAP.O
1 988001 1GNISUOH
2 9OB-04 1)4.1*5.3(GNIR-O
3 988003 VALVE 1METS
4 988004 1GNIHSUB
5 988005 2GNIR-O
6 988006 1REHSAW
1EVLAV8007897
8 988008 1GNIRPS
9 988009 1GNIHSUBTELNI
10 988010 1REVEL
1NIP23407911
12 988012 1WERCS
13 980528 3)6X5M(WERCS
14 988014 1ELFFABTSUAHXE
15 988015 NOISE ELIMINATION POLY FIBER 1
16 988016 1REVOC
17 987020 1REDLOHGNIRPS
18 987021 1)T5.0*5.9*41(
REHSAW
19 987022 1)5.61*T2.1*7.9(GNIRPS
20 987024 1)L8.11*2(NIP
21 987023 1EVLAVRONREVOG
22 987027 GO 1EGACRONREV
23 987025 GOVERNOR WE 2THGI
24 987026 2NIPRONREVOG
25 987028 1REHSAW
26 987029 1)ZZ1026(GNIRAEB
27 988027 1ETALPRAER
28 981326 3)L8*3(NIP
29 988029 1REDNILYC
30 988030 4EDALBROTOR
31 988031 1ROTOR
32 988032 1ETALPTNORF
33 988033 2)ZZ3006(GNIRAEB
34 988034 1RECNALABTFAHSROTOM
1YEK53088953
36 988036 1REHSAW
37 988037 1REHSAW
39 988039 5)L02*6M(WERCS
40-1 988040-1 1)"9(REVOCCSID
41 988041 F 1ETALPECA
42 988042 1TUNCSID
43 988043 1TUNCSID
44 988044 1WERCS
45 988045 STOP SP 1)MM52(RENNA
46 987057 1RENNAPSCSID
47 960929 1)MM4(XEH
48 988048 1ELDNAH
49 988049 1)L02*01M(WERCS
50 987056 STOP SP 1)MM91(RENNA
