Universal UNV84600 User manual
SPECIFICATIONSOPERATION
Hot Lamination
1. Place the machine on a flat, sturdy surface and Set the Laminator to 'Hot'. Press the power button 'ON'
2. The machine will take approximately 3-5 minutes to warm- up, When 'ready' the Green "Ready" light turns on.
3. Place the item to be laminated into the laminating pouch.
4. The document or photo will then automatically feed out the through the back of the machine.
Cold Lamination
Note:
If the machine was previously used in hot setting, allow approximately 25minutes for the machine to cool down.
1. Place the machine on a flat, sturdy surface. Set the Laminator to 'Cold'. Press the power button 'ON'.
2. The green ready light will turn on.
TROUBLESHOOTING
Symptom Solution
Motor does not work. Check to make sure machine is plugged in. Check to make sure the
power button is turned on.
The pouch is jammed. Please slide the Release and pull out the pouch from the front of
the machine
UNV84600
LAMINATOR
Owner's Manual
SAFETY INSTRUCTIONS
NOTE: READ ALL SAFETY INSTRUCTIONS BEFORE USE
The safety recommendations outlined in this section should be read and understood before operating this machine.
When using this machine follow these basic safety precautions to reduce risk of fire, electric shock or injury. Keep this
information for future reference.
1. To prevent the possibility of a fire or injury, do not allow foreign articles inside the machine.
2. Do not attempt to laminate items that exceed total recommended material thickness.
3. To prevent the possibility of electric shock, do not immerse the laminator in water or permit liquids inside the machine.
4. Because the laminator creates heat, keep out of the reach of children.
5. Do not cut pouches before inserting them into the laminator. This will cause the laminator to jam.
6. Do not laminate leaves, flowers, clothes etc.
7. Do not use the machine if the cord is damaged. This may result in electric shock, fire, or other hazards.
How to load a laminating pouch.
The laminating pouch is sealed along one side. Open the pouch and place the item to be laminated centrally and as close
to the sealed edge as possible. The sealed edge is then placed into the entry slot to start the laminating process.
Release Button
Should the pouch become jammed during the laminating process turn the machine off and press and hold the 'release'
button and remove the item.
CONTROLS
WARRANTY
Essendant Co. (Essendant) warrants this product against defects in materials and workmanship under normal consumer
use for a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser ("Warranty
Period"). If this product does not satisfy the warranty, the original end-user purchaser may retum it to the place of
purchase during the Warranty Period and the product will be replaced or the purchase price refunded,at the retailer's
option. A replacement product assumes the remaining warranty of the original product or ninety (90) days from the
date of replacement, whichever provides longer coverage to you. Essendant does not warrant that the operation of the
product will be uninterrupted or error-free. Essendant is not responsible for damage arising from failure to follow
instructions relating to the product's use.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS. AS PERMITTED BY APPLICABLE LAW, ESSENDANT
SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIESOF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST HIDDEN OR
LATENT DEFECTS. IF ESSENDANT CANNOT LAWFULLY DISCLAIM STATUTORY OR IMPLIED WARRANTIES THEN TO THE
EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF THIS
EXPRESS WARRANTY AND TO REPLACEMENT OR REFUND AS DETERMINED BY ESSENDANT IN ITS SOLE DISCRETION. No
Essendant reseller, agent, or employee is authorized to make any modification,extension,or addition this warranty.
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE EXTENT PERMITTED BY LAW, ESSENDANT IS NOT RESPONSIBLE
FOR DIRECT,SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION,OR UNDER ANY OTHER LEGAL THEORY,INCLUDING BUT NOT LIMITED TO LOSS OF USE; LOSS OF REVENUE;
LOSS OF ACTUAL OR ANTICIPATED PROFITS (INCLUDING LOSS OF PROFITS ON CONTRACTS); OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED. THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR
PERSONAL INJURY CLAIMS.
CONSUMER PROTECTION LAWS.
Some countries, states and provinces do not allow the exclusion or limitation of incidentalor consequential damages or
exclusions or limitations on the duration of implied warranties or conditions, so the above limitations or exclusions may
not apply to you. This warranty gives you specific legalrights, and you may also have other rights that vary by country,
state or province.This Limited Warranty is governed by and construed under the laws of the country in whi ch the product
purchase took place, The address of Essendant, the warrantor under this Limited Warranty, is
One Parkway North Boulevard, Suite 100, Deerfield, Illinois 60015 USA
SAVE THESE INSTRUCTIONS
Manufactured for Universal®/ Essendant Co.
One Parkway North Deerfield, IL 60015 ©2017 Essendant Co.
Made in China
Ready indicator (Green)
Power Light (Red)
Feed in
Feed out
Release button
Hot/Cold Setting ON / OFF Switch
Important: sealed laminate
end must go in first
Model Name
UNV84600
Power Supply Voltage 120V 60Hz
Power Consumption (W)
265W
# of Rollers
2
Min pouch size
Credit card size - 2.1" x 3.3" (54 x 86mm)
Speed 9.8" (250mm)
Maximum Entry Width
9" (230mm)
Warm-up Time (Min) 3-5 mins
Lamination Hot and Cold
Unit Dimensions
(W x D x H)
13.8" x 5.7" x 2.9"
(350 x 145 x 74 mm)
Unit Weight 2.5 lbs (1.15kg)
08-017/1
