Unova Intermec EasyCoder 501 User manual

EasyCoder 501/601
Dual Serial Interface Kit
P/N 1-960345-02
Edition 2
September 1998
Installation Instructions
All manuals and user guides at all-guides.com
all-guides.com

EasyCoder 501/601 – Installation Instructions
1
DUAL SERIAL INTERFACE KIT
The Serial Interface Board adds two serial communication ports
("uart2:" and "uart3:") to the standard serial communication port
("uart1:").
The printer's software detects when a Serial Interface Board is
installed and adds communication and buffer setup options for the
two additional communication ports.
When a Serial Interface Board is fitted, the following types of
interfaces become available:
"uart1:" Fittedonprinter'sCPUboard.
RS232C Standard.
RS422or20mACL Option.Additionalcircuits required.
"uart2:" Fittedon Serial Interface Board.
RS232C
"uart3:" Fittedon Serial Interface Board.
RS232C or 20 mA CL Selectedby means of strap.
The Dual Serial Interface Kit consists of:
• 1 Serial interface board assy.
• 2 Screws MRX-Z 3 ×6 FZB (not intended for EasyCoder 501/
601)
• Installation Instructions
Introduction
"uart1:"
"uart3:"
"uart2:"
230V
0
Note:
Illustrations show an EasyCoder 501.
The principles for fitting this optional
equipment in an EasyCoder 601 are
exactly the same.
EasyCoder 501/601
Dual Serial Interface Kit
Installation Instructions
Edition 2, September 1998
Part No. 1-960345-02
All manuals and user guides at all-guides.com

EasyCoder 501/601 – Installation Instructions
2
Continued!
DUAL SERIAL INTERFACE KIT, cont'd.
Step-by-Step Installation
Instructions
Communication
Port "uart1:"
Cover Plate
Power
Switch
Power Cord
Receptacle
The only tool required is a Torx #T10 screwdriver.
❑Turn off the power and remove the power cord.
❑Remove the communication cable from communication port
"uart1:".
❑Open the right-hand door.
❑Remove the eight Torx screws that hold the cover over the left
part of the printer (see illustration below).
❑Remove the cover.
Screws (4x)
Cover
0
230V
Screws (4x)
All manuals and user guides at all-guides.com

EasyCoder 501/601 – Installation Instructions
3
❑Remove the existing cover plate.
❑Make sure that the CPU board is strapped and equipped for the
desired type of communication on "uart1:" (see the EasyCoder
501 or EasyCoder 601 Technical Manual). Once the interface
boardhasbeenfitted,itwillbedifficulttoaccesstherearpartof
the CPU board.
❑FittherequiredstrapsontheSerialInterfaceBoardasdescribed
on page 5.
❑Connect the cable from the interface board to connector P-4 at
the bottom rear corner of the CPU board. Be careful so the
interface board and the CPU board do not come in contact with
eachother,whichpossiblymaycausedamageorshort-circuiting.
❑Fit the interface board assembly to the printer's rear plate from
theinsideasillustratedbelowusingthesamescrewsthatheldthe
removed cover plate.
DUAL SERIAL INTERFACE KIT, cont'd.
Step-by-Step Installation
Instructions, cont'd.
Continued!
1
P3
2 3
P6
Connect to P-4
on CPU Board
Rear Plate Serial
Interface Board
"uart3:"
(male DB25
connector)
"uart2:"
(female DB25
connector)
Screw
Screw
All manuals and user guides at all-guides.com

EasyCoder 501/601 – Installation Instructions
4
DUAL SERIAL INTERFACE KIT, cont'd.
Continued!
Step-by-Step Installation
Instructions, cont'd. ❑Reassemble the printer in reverse order.
❑Connect the communication cables to their respective connec-
tors. Please refer to page 6 for pinout descriptions.
❑Connect the power cord and turn on the power.
"uart1:"
"uart3:"
Serial Interface
Board Assy.
"uart2:"
230V
0
All manuals and user guides at all-guides.com

EasyCoder 501/601 – Installation Instructions
5
1
P3
2 3
P6
DUAL SERIAL INTERFACE KIT, cont'd.
Straps
Thefollowing strapsareusedto set upthedesired type ofinterface
on the communication ports "uart2:" and "uart3:".
Communication Port "uart2:"
There are no straps for controlling the RS 232C interface on
"uart2:".
Communication Port "uart3:"
RS 232C:
StrapfittedonP-3betweenpin1–2(rightandmiddlepins)selects
RS 232C.
20 mA Current Loop:
Strap fitted on P-3 between pin 2 – 3 (middle and left pins) selects
20 mA current loop.
External +5V:
External +5V (max. 200 mA) can be made available on pin 16 by
fitting a strap on P-6.
Be careful not to enable this option unintentionally, which may
cause harm to the connected terminal, computer or other device.
"uart3:"
"uart2:"
P-3
P-6
All manuals and user guides at all-guides.com
all-guides.com

EasyCoder 501/601 – Installation Instructions
6
DUAL SERIAL INTERFACE KIT, cont'd.
Informationinthismanualissubjecttochangewithoutpriornoticeanddoesnotrepresentacommitment
on the part of Intermec Printer AB.
© Copyright Intermec PTC AB, 1998. All rights reserved. Published in Sweden.
EasyCoder is a registered trademark of Intermec Technologies Corp.
Torx is a registered trademark of Camcar Division of Textron Inc.
"uart2:" is a DB25 female connector.
"uart3:" is a DB25 male connector.
The mounting holes are connected to chassis ground.
Connector Configuration
Pin "uart2:" "uart3:" Used for: Remarks
DB25female DB25male "uart2:" "uart3:"
1 GNDC GNDC RS232C RS 232C Cableshield
2 TXDA TXDB RS 232C RS232C Transmitted data fromprinter
3 RXDA RXDB RS232C RS232C Receiveddata toprinter
4 RTSA RTSB RS232C RS 232C RTSfromprinter
5 CTSA CTSB RS232C RS 232C CTStoprinter
6 DSRA DSRB RS232C RS232C DSRtoprinter
7 GNDI GNDI RS232 C RS 232C Signalground
8 – – – – not used
9 – +20M1 – Currentloop + 20 mA
10 – –20M1 – Currentloop - 20 mA
11 – +TXD – Currentloop TXD +
12 – –TXD – Currentloop TXD –
13 – +20M2 – Currentloop + 20 mA *
14 – –20M2 – Currentloop – 20 mA *
15 – – – – not used
16 – +5VEXT – RS232C/CL + 5V max 200 mA.(if strap fitted on P-6)
17 – – – – not used
18 – +RXD – Currentloop RXD +
19 – – – – not used
20 DTRA DTRB RS 232C RS232C DTRpermanently high
21 – – – – not used
22 – – – – not used
23 – – – – not used
24 – – – – not used
25 – –RXD – Currentloop RXD –
*/.In case of printer beingactivereceiver.
