Crestron PSPHD User manual

Crestron PSPHD
PROCISE®7.3 High-Definition
Professional Surround Sound Processor
Operations Guide

Important Safety Instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•
Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
•Only use attachments/accessories specified by the
manufacturer.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED
ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSONNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product's enclosure t hat may be of sufficient magnitude
to constitute a risk of electric shock to persons.
•Use only with the cart, stand, tripod, bracket or
table specified by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/app
aratus combination to
avoid injury from tip-over.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
IMPORTANT:
This device can be used with Class 2 output wiring.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have f
allen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Disconnect power prior to connecting or disconnecting
equipment.
•Do not install in direct sunlight.
•The apparatus must be installe
d in a way that the power cord
can be removed either from the wall outlet or from the
device itself in order to disconnect the mains power.
•
Prevent foreign objects from entering the device.

The specific patents that cover Crestron products are listed at patents.crestron.com.
Products are manufactured under license from Audyssey Laboratories; under license from Dolby Laboratories; and under license from DTS (under
U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567).
Crestron, the Crestron logo, Cresnet, Crestron Control, Crestron Studio, Crestron Toolbox, DigitalMedia, PROCISE,QuickSwitch HD, and
SystemBuilder are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Audyssey
Dynamic EQ, Audyssey Dynamic Volume, Audyssey Laboratories, and Audyssey MultEQ XT are either trademarks or registered trademarks of
Audyssey Laboratories in the United States and/or other countries. Blu-ray Disc is a either trademark or registered trademark of the Blu-ray Disc
Association (BDA) in the United States and/or other countries. Cisco is either a trademark or registered trademark of Cisco Systems, Inc. in the United
States and/or other countries. Dolby, Dolby Digital, and the double-D symbol are either trademarks or registered trademarks of Dolby Laboratories in
the United States and/or other countries. DTS, DTS-HD, DTS-HD Master Audio, and the DTS logos are either trademarks or registered trademarks of
DTS, Inc. in the United States and/or other countries. HDMI, the HDMI logo and High Definition Multimedia Interface are either trademarks or
registered trademarks of HDMI Licensing LLC in the United States and/or other countries. Other trademarks, registered trademarks and trade names
may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest
in the marks and names of others. Crestron is not responsible for errors in typography or photography.
This document was written by the Technical Publications department at Crestron.
©2013 Crestron Electronics, Inc.
Regulatory Compliance
As of the date of manufacture, the PSPHD has been tested and found to comply with specifications for CE
marking and standards per EMC and Radiocommunications Compliance Labelling.
Federal Communications Commission (FCC) Compliance Statement
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C Contents •i
Contents
PROCISE 7.3 High Definition Professional Surround Sound Processor: PSPHD 1
Introduction ............................................................................................................................... 1
Features and Functions ................................................................................................1
Features and Functions ................................................................................................2
Applications................................................................................................................. 3
Internal Block Diagram ............................................................................................. 11
Specifications ............................................................................................................ 12
Physical Description.................................................................................................. 17
Setup ........................................................................................................................................ 24
Network Wiring......................................................................................................... 24
Identity Code ............................................................................................................. 24
Installation ................................................................................................................. 25
Hardware Hookup ..................................................................................................... 26
Configuration........................................................................................................................... 30
Open the “INSTALLER MENU”.............................................................................. 30
Navigating the “INSTALLER MENU”..................................................................... 30
Audio Setup ............................................................................................................... 31
Network Setup ........................................................................................................... 35
Control Setup............................................................................................................. 43
About......................................................................................................................... 47
Exit “INSTALLER MENU” ..................................................................................... 47
Uploading and Upgrading........................................................................................................ 48
Establishing Communication..................................................................................... 48
Programs and Firmware ............................................................................................ 49
Program Checks ........................................................................................................ 50
Operation ................................................................................................................................. 51
Turn on the PSPHD ................................................................................................... 51
Standby...................................................................................................................... 51
Home ......................................................................................................................... 51
Display Brightness .................................................................................................... 51
Volume Control......................................................................................................... 51
Mute .......................................................................................................................... 51
Select a Source .......................................................................................................... 51
Surround Sound Decoding Mode Selection .............................................................. 52
Setup.......................................................................................................................... 52
Information................................................................................................................ 57
VU Meter................................................................................................................... 57
Spectrum Analyzer .................................................................................................... 57
Level Settings ............................................................................................................ 57
Amplifier Status ........................................................................................................ 57
Problem Solving ...................................................................................................................... 58
Troubleshooting......................................................................................................... 58
Check Network Wiring.............................................................................................. 58
Reference Documents................................................................................................ 59
Further Inquiries ........................................................................................................ 59

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
ii •Contents Operations Guide – DOC. 6837C
Future Updates .......................................................................................................... 60
Appendix: Audyssey Laboratories, Inc.................................................................................... 61
Return and Warranty Policies .................................................................................................. 62
Merchandise Returns / Repair Service ...................................................................... 62
Crestron Limited Warranty........................................................................................ 62

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •1
•7.3 HD surround sound processing delivers a multichannel experience
with enveloping surround sound and uniform deep bass coverage
employing multiple subwoofers
•Audyssey MultEQ®XT1,2 precision automatic room compensation
maximizes a speaker system’s performance within an acoustical space
•HDMI®connectivity provides the essential transport for 7.1 surround
sound, HD 1080p and 3D video
•Three floating-point DSPs and 24-bit 96 kHz A-D/D-As achieve
articulate, life-like sound with extreme dynamic range and ultra low
noise down to 125 dB S/NR
•Dolby®TrueHD, Dolby Digital®Plus, and DTS-HD Master Audio™
support the latest 7.1 surround sound audio formats to get the most
from Blu-ray Disc®and other high-definition media
•Audyssey Dynamic EQ®assures consistent bass response, tonal
balance and soundstage at any volume
PROCISE 7.3 High Definition
Professional Surround Sound
Processor: PSPHD
Introduction
The PROCISE®PSPHD from Crestron®brings world-class cinema audio to any
room, be it a custom home theater, luxury living room, high-tech auditorium or
executive boardroom. With its proprietary combination of advanced features and
innovative new technologies, the PSPHD fulfills all the design challenges and
performance expectations of the high-end custom market
Features and Functions
(Continued on following page)
1. Manufactured under license from Audyssey Laboratories™. U.S. and foreign patents pending.
MultEQ XT is a registered trademark of Audyssey Laboratories.
2. Setup of MultEQ XT is highly recommended for optimum system performance. Requires CSSTK
Professional Surround Sound Tuning Kit for setup (sold separately).

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
2•PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
•Audyssey Dynamic Volume®1 solves the problem of spikes in volume
level between television programs and commercials, and between the
soft and loud passages of movies
•Pure mode bypasses all signal processing to provide a pure signal path
for critical listening of analog sources
•QuickSwitch HD®digital switching achieves fast, fluid switching of
HDMI* audio and video
•Smart HDCP management ensures the reliable handling of digital HD
content, and compatibility with a wide range of devices
•Copious connectivity furnishes 30 inputs including HDMI, AES/EBU,
S/PDIF optical and coaxial; plus mono, stereo, and multichannel analog
•XLR balanced inputs/outputs ensures a quieter, more reliable analog
interface to professional-grade amplifiers, powered subwoofers, and
source components
•PROAMP automatic amplifier pairing allows integration between
preamp and amplifier for seamless control and monitoring
•Discrete output channel signal processing affords independent fine
adjustment of every individual speaker and subwoofer
•2-channel signal steering routes stereo audio to the surround, rear, or all
speakers for better background or party music
•Downmix outputs provide independent mono and stereo output signals
to feed additional listening zones, and for interfacing with all kinds of
commercial audio equipment
•Integrated line mixer enables straight-forward integration with
microphone mixers and codecs, eliminating the need for extra outboard
gear in a commercial multimedia presentation or teleconferencing
application. Also affords flexibility for interfacing with doorbells and
phone ringers, paging and karaoke equipment
•Dedicated speech processing incorporates programmable compression,
gating, 4-band EQ and notch filtering into each of the three mixer
inputs
•Sophisticated signal routing allows flexible distribution of each mixer
input to feed any of the front, surround, rear, and downmix outputs
•Native Crestron Control®enables customization for real-time touch
screen control and automation as part of a complete Crestron control
system
•Crestron PROCISE Tools software affords extensive configuration and
fine adjustment via USB or Ethernet
•DigitalMedia™ system integration melds seamlessly into a Crestron
DigitalMedia distribution system via HDMI and Ethernet
•High-end appearance features a stunning milled aluminum front panel
with clean, uncomplicated controls and selectable visual feedback for a
look befitting the finest showcase theater or luxury conference room
Features and Functions
(Continued)
* HDMI requires an appropriate adapter or interface cable to accommodate a DVI or DisplayPort
Multimode signal. CBL-HD-DVI and CBL-DP-HD interface cables available separately.

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •3
Applications
The following diagrams show 3-D and 2-D views of a PSPHD in residential and
commercial applications.
PSPHD in a Residential Home Theater Application

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
4•PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
PSPHD in a Residential Home Theater Application, 2-D View
LCD Display
Game Console
HDMI Out
Blu-Ray Disc Player
HDMI Out
HD Cable Box
HDMI Out
PROAMP-7X400
Amplifier
Amplified Out 1
Amplified Out 2
Amplified Out 3
Amplified Out 4
Amplified Out 5
Amplified Out 6
Amplified Out 7
Balanced Input 1
Balanced Input 2
Balanced Input 3
Balanced Input 4
Balanced Input 5
Balanced Input 6
Balanced Input 7
Cresnet
Ethernet
Left Right S Left S Right B Left B Right Center
To Audio
Distribution
To Control System
LAN
Powered
Sub 1
Powered
Sub 2
Powered
Sub 3
PSPHD
Processor
Digital
HDMI In 1
HDMI In 2
HDMI In 3
HDMI In 4
HDMI In 5
HDMI In 6
Optical In 1
Optical In 2
Optical In 3
Optical In 4
Optical In 5
Optical In 6
SPDIF In 1
SPDIF In 2
SPDIF In 3
SPDIF In 4
SPDIF In 5
SPDIF In 6
Analog
Audio L 1
Audio R 1
AES/EBU In
Audio L 2
Audio R 2
Audio L 3
Audio R 3
Audio L 4
Audio R 4
Audio L 5
Audio R 5
Audio L 6
Audio R 6
Audio L 7
Audio R 7
Audio L 8
Audio R 8
Balanced L
Balanced R
Multi-Ch L
Multi-Ch R
Multi-Ch SL
Multi-Ch SR
Multi-Ch BL
Multi-Ch BR
Multi-Ch C
Multi-Ch Sub
Mixer
Mixer Input 1
Mixer Input 2
Mixer Input 3
HDMI Out
L Balanced Out
R Balanced Out
SL Balanced Out
SR Balanced Out
BL Balanced Out
BR Balanced Out
C Balanced Out
L Bal. Down Out
R Bal. Down Out
Mono Bal. Down Out
Cresnet
Ethernet
L Audio Out
R Audio Out
SL Audio Out
SR Audio Out
BL Audio Out
BR Audio Out
C Audio Out
Sub 1 Balanced Out
Sub 2 Balanced Out
Sub 3 Balanced Out
Sub 1 Out
Sub 2 Out
Sub 3 Out
L Downmix Out
R Downmix Out
Mono Downmix Out

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •5
PSPHD in a Conferencing Boardroom with Audio and Video Conferencing

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
6•PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
PSPHD in a Conferencing Boardroom with Audio and Video Conferencing, 2-D View
Blu-Ray Disc Player
HDMI Out
5-Channel 8Ω
Amplifier
Laptop
DVI Out
PSPHD
Processor
Digital
HDMI In 1
HDMI In 2
HDMI In 3
HDMI In 4
HDMI In 5
HDMI In 6
Optical In 1
Optical In 2
Optical In 3
Optical In 4
Optical In 5
Optical In 6
SPDIF In 1
SPDIF In 2
SPDIF In 3
SPDIF In 4
SPDIF In 5
SPDIF In 6
Analog
Audio L 1
Audio R 1
AES/EBU In
Audio L 2
Audio R 2
Audio L 3
Audio R 3
Audio L 4
Audio R 4
Audio L 5
Audio R 5
Audio L 6
Audio R 6
Audio L 7
Audio R 7
Audio L 8
Audio R 8
Balanced L
Balanced R
Multi-Ch L
Multi-Ch R
Multi-Ch SL
Multi-Ch SR
Multi-Ch BL
Multi-Ch BR
Multi-Ch C
Multi-Ch Sub
Mixer
Mixer Input 1
Mixer Input 2
Mixer Input 3
HDMI Out
L Balanced Out
R Balanced Out
BL Balanced Out
BR Balanced Out
C Balanced Out
L Bal. Down Out
R Bal. Down Out
Mono Bal. Down Out
Cresnet
Ethernet
L Audio Out
R Audio Out
SL Audio Out
SR Audio Out
BL Audio Out
BR Audio Out
C Audio Out
Sub 1 Balanced Out
Sub 2 Balanced Out
Sub 3 Balanced Out
Sub 1 Out
Sub 2 Out
Sub 3 Out
L Downmix Out
R Downmix Out
Mono Downmix Out
DSS Receiver
HDMI Out
Video Conference Unit
From Far End
To Far End
In Wall Speakers
SL Balanced Out
SR Balanced Out
2-Channel 70V
Amplifier
Ceiling Speakers
Mic Mixer w/Audio Conferencing
Speech Only Audio
From AC Far-End
From VC Far-End
From VC
Program Audio (Stereo)
Program Audio (Mono)
To VC
Lectern Mic
Table Mic
Table Mic

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •7
PSPHD in a Boardroom without Conferencing

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
8•PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
PSPHD in a Boardroom without Conferencing, 2-D View
LCD Display
Blu-Ray Disc Player
HDMI Out
PROAMP-7X400
Amplifier
Amplified Out 1
Amplified Out 2
Amplified Out 3
Amplified Out 4
Amplified Out 5
Amplified Out 6
Amplified Out 7
Balanced Input 1
Balanced Input 2
Balanced Input 3
Balanced Input 4
Balanced Input 5
Balanced Input 6
Balanced Input 7
Cresnet
Ethernet
Left Right S Left S Right B Left B Right Center
Laptop
DVI Out
HD Cable Box
HDMI Out
B
A
Telco Line In
Audio Conferencing
Audio Output 1
Audio Output 2
Audio Output 3
Audio Output 4
Audio Output 5
Audio Output 6
Audio Output 7
Audio Output 8
Audio Input 1
Audio Input 2
Audio Input 3
Audio Input 4
Audio Input 5
Audio Input 6
Audio Input 7
Audio Input 8
Telco Line
PSPHD
Processor
Digital
HDMI In 1
HDMI In 2
HDMI In 3
HDMI In 4
HDMI In 5
HDMI In 6
Optical In 1
Optical In 2
Optical In 3
Optical In 4
Optical In 5
Optical In 6
SPDIF In 1
SPDIF In 2
SPDIF In 3
SPDIF In 4
SPDIF In 5
SPDIF In 6
Analog
Audio L 1
Audio R 1
AES/EBU In
Audio L 2
Audio R 2
Audio L 3
Audio R 3
Audio L 4
Audio R 4
Audio L 5
Audio R 5
Audio L 6
Audio R 6
Audio L 7
Audio R 7
Audio L 8
Audio R 8
Balanced L
Balanced R
Multi-Ch L
Multi-Ch R
Multi-Ch SL
Multi-Ch SR
Multi-Ch BL
Multi-Ch BR
Multi-Ch C
Multi-Ch Sub
Mixer
Mixer Input 1
Mixer Input 2
Mixer Input 3
HDMI Out
L Balanced Out
R Balanced Out
SL Balanced Out
SR Balanced Out
BL Balanced Out
BR Balanced Out
C Balanced Out
L Bal. Down Out
R Bal. Down Out
Mono Bal. Down Out
Cresnet
Ethernet
L Audio Out
R Audio Out
SL Audio Out
SR Audio Out
BL Audio Out
BR Audio Out
C Audio Out
Sub 1 Balanced Out
Sub 2 Balanced Out
Sub 3 Balanced Out
Sub 1 Out
Sub 2 Out
Sub 3 Out
L Downmix Out
R Downmix Out
Mono Downmix Out
70 V Speakers
(Speech)
70V Amplifier
70 V Output
Audio Input
Assisted Listening
Audio Input L
Audio Input R
Audio Recorder
Audio Input L
Audio Input R
To Control System
LAN
A
B

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •9
PSPHD in an Auditorium

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
10 •PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
PSPHD in an Auditorium, 2-D View
Blu-Ray Disc Player
HDMI Out
PROAMP-7X400
Amplifier
Amplified Out 1
Amplified Out 2
Amplified Out 3
Amplified Out 4
Amplified Out 5
Amplified Out 6
Amplified Out 7
Balanced Input 1
Balanced Input 2
Balanced Input 3
Balanced Input 4
Balanced Input 5
Balanced Input 6
Balanced Input 7
Cresnet
Ethernet
Laptop
DVI Out
B
A
PSPHD
Processor
Digital
HDMI In 1
HDMI In 2
HDMI In 3
HDMI In 4
HDMI In 5
HDMI In 6
Optical In 1
Optical In 2
Optical In 3
Optical In 4
Optical In 5
Optical In 6
SPDIF In 1
SPDIF In 2
SPDIF In 3
SPDIF In 4
SPDIF In 5
SPDIF In 6
Analog
Audio L 1
Audio R 1
AES/EBU In
Audio L 2
Audio R 2
Audio L 3
Audio R 3
Audio L 4
Audio R 4
Audio L 5
Audio R 5
Audio L 6
Audio R 6
Audio L 7
Audio R 7
Audio L 8
Audio R 8
Balanced L
Balanced R
Multi-Ch L
Multi-Ch R
Multi-Ch SL
Multi-Ch SR
Multi-Ch BL
Multi-Ch BR
Multi-Ch C
Multi-Ch Sub
Mixer
Mixer Input 1
Mixer Input 2
Mixer Input 3
HDMI Out
L Balanced Out
R Balanced Out
SL Balanced Out
SR Balanced Out
BL Balanced Out
BR Balanced Out
C Balanced Out
L Bal. Down Out
R Bal. Down Out
Mono Bal. Down Out
Cresnet
Ethernet
L Audio Out
R Audio Out
SL Audio Out
SR Audio Out
BL Audio Out
BR Audio Out
C Audio Out
Sub 1 Balanced Out
Sub 2 Balanced Out
Sub 3 Balanced Out
Sub 1 Out
Sub 2 Out
Sub 3 Out
L Downmix Out
R Downmix Out
Mono Downmix Out
Audio Recorder
Audio Input L
Audio Input R
DSS Receiver
HDMI Out
Microphone Mixer
Audio Output 1
Audio Output 2
Audio Output 3
Audio Output 4
Audio Output 5
Audio Output 6
Audio Output 7
Audio Output 8
Audio Input 1
Audio Input 2
Audio Input 3
Audio Input 4
Audio Input 5
Audio Input 6
Audio Input 7
Audio Input 8
Mic 1
Mic 2
Mic 3
Mic 4
Mic 5
Mic 6
Mic 7
Mic 8
Projector
Composite
S-Video
Y/P
b
/P
r
HDMI
Left Right S Left S Right Center
To Control System
LAN
A
B

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •11
Internal Block Diagram
The following diagram represents the abilities of the PSPHD.
Internal Block Diagram of the PSPHD
10 x 1
Analog
Audio
Switch
Stereo Audio
1
2
3
4
5
Stereo Audio
Stereo Audio
Stereo Audio
Stereo Audio
6
7
8
9
Stereo Audio
Stereo Audio
Stereo Audio
Balanced
Multi-Channel
Analog
10
12 x 1
Digital
Audio
Switch
Digital Coax
1
6
1
4
1
Digital Coax
Digital TosLink
Digital TosLink
AES/EBU
6 x 1
HDMI
Switch
HDMI
1
2
3
4
5
HDMI
HDMI
HDMI
HDMI
6HDMI
DIGITAL AUDIO
Signal
Decoding and
Processing
MIX 1 BALANCED MONO
MIX 3 BALANCED MONO
MIX 2 BALANCED MONO
7.3 Program Audio
Input Processing
Input Processing
Input Processing
1:10 Split with CB (Channel Balance)
1:10 Split with CB (Channel Balance)
1:10 Split with CB (Channel Balance)
Output
Mixing
Stage
7.3 Mixed
Downmix Mixed
Mono Mixed
Downmix L
Downmix R
Mono
Tone
Control
Tone
Control
Tone
Control
Volume
Control
Volume
Control
Volume
Control
Main Out 7.3
Stereo
Mono
2 Notch
L
C
R
SR
SL
SBR
SBL
L
C
R
1:10 Split with CB (Channel Balance)
Gate
2 Shelving &
2 Peaking
Compressor
VU
VU
VU
Input Processing
A/D
D/A
D/A
D/A
Output Mixing Stage
(Mixers for 7.3, Downmix & Mono)
MIX 1
MIX 2
MIX 3
Program Audio
Faders
Mixed
Output
HDMI
DIGITAL AUDIO
DIGITAL VIDEO
HDMI Audio
Multiplexer
DOWNMIX AUDIO

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
12 •PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
Specifications
Specifications for the PSPHD are listed in the following table.
PSPHD Specifications
SPECIFICATION DETAILS
Audio – General
Features 27 selectable source inputs plus built-in
noise generator, 7.1 Dolby Digital/DTS®
surround sound decoder, 7.3 multichannel
signal processing and steering, Audyssey
MultEQ XT, Audyssey Dynamic Volume,
Audyssey Dynamic EQ, 6-band graphic or
parametric EQ, 100 ms lip-sync/speaker
delay, unprocessed Pure mode (analog
sources only), Direct mode (HDMI only),
independent mono and stereo downmix
outputs, 3-channel line mixer (post
surround decoder/processor) with
independent speech-optimized signal
processing, HDCP management, Crestron
QuickSwitch HD
Input Signal Types HDMI supporting HD lossless multichannel
up to 7.1 with HDCP, DisplayPort
Multimode1, S/PDIF (coaxial and optical),
AES/EBU, analog 2-channel (balanced and
unbalanced), analog 8-channel
(unbalanced), analog mono (balanced or
unbalanced)
Output Signal Types Analog 7.3 channel (balanced and
unbalanced), analog 2-channel downmix
(balanced and unbalanced), analog mono
downmix (balanced and unbalanced), HDMI
with 2-channel downmix
Processor Three floating-point DSPs
Analog-To-Digital Conversion 24-bit 96 kHz
Digital-To-Analog Conversion 24-bit 96 kHz (192 kHz in Direct mode)
Frequency Response 20 Hz to 20 kHz ±0.2 dB
Total Harmonic Distortion
(THD) + Noise
0.002% digital in to analog out,
0.003% analog in to analog out
Signal-to-Noise Ratio
(S/N Ratio)
125 dB AES/EBU in to balanced out
122 dB SPDIF/HDMI in to balanced out,
118 dB AES/EBU in to unbalanced out
114 dB SPDIF/HDMI in to unbalanced out
109 dB unbalanced in to unbalanced out
(Continued on following page)

Crestron PSPHD PROCISE 7.3 Surround Sound Processor
Operations Guide – DOC. 6837C PROCISE 7.3 Surround Sound Processor: PSPHD •13
PSPHD Specifications (Continued)
SPECIFICATION DETAILS
Audio – Surround Sound
Decoding Modes None, Stereo, Dolby Pro Logic IIx Movie,
Dolby Pro Logic IIx Music, DTS Neo:6
Cinema, DTS Neo:6 Music, Two Channel
Steering – Surround, Two Channel Steering
– Rear, Multichannel Stereo (Party),
Cathedral, Hall, Stadium, Jazz Club, Dolby
Digital, Dolby Digital EX, Dolby Digital Plus,
Dolby TrueHD, DTS, DTS-ES Matrix,
DTS-ES Discrete, DTS 96/24, DTS-HD
Master Audio, PCM Multichannel,
Multichannel Input
Master Volume Level -80 to +20 dB, adjustable from 0% to 100%,
plus mute
Speaker Levels ±12.0 dB per output (Front L/R, Surround
L/R, Back L/R, Center, Sub 1-3)
Low Frequency Effects (LFE) -10.0 to +0.0 dB
Decoding Mode Speaker
Levels
±12.0 dB per output
Decoding Mode LFE Level -10.0 to +0.0 dB
Input Compensation ±10.0 dB per input
Bass Control ±12.0 dB
Treble Control ±12.0 dB
EQ Modes Audyssey MultEQ XT, 6-band graphic
(global), or 6-band parametric (per output)
GEQ Center Frequencies 63, 250, 1k, 4k, 10k, 20k Hz
GEQ Gain ±12.0 dB per band
GEQ Presets 1 thru 5
PEQ Center Frequency 25 to 20,000 Hz per band
PEQ Gain ±12.0 dB per band
PEQ Bandwidth 0.0 to 3.0 octaves per band
PEQ Presets 1 thru 5
Crossover Frequency Large (full range) or 40 to 200 Hz, adjustable
in 10 Hz steps, per output (excluding subs)
Delay 0 to 100 ms lip-sync (global), 0 to 20 ms
speaker distance compensation (per output);
adjustable in milliseconds, feet, or meters;
NOTE: 100 ms max per output lip-sync and
speaker delay combined.
Compression Off, Audyssey Dynamic Volume (Heavy,
Medium, Light), Dolby/DTS DRC (Heavy,
Medium, Light), Dolby TrueHD Auto
Loudness Compensation None or Audyssey Dynamic EQ (available
only with MultEQ®XT active)
(Continued on following page)

PROCISE 7.3 Surround Sound Processor Crestron PSPHD
14 •PROCISE 7.3 Surround Sound Processor: PSPHD Operations Guide – DOC. 6837C
PSPHD Specifications (Continued)
SPECIFICATION DETAILS
Audio – Surround Sound
(continued)
DTS Neo:6 Music Settings CGain 0.0 to 1.0, Standard or Wide mode
Dolby Pro Logic IIx Music
Settings
Dimension ±7, Center Width 0 to 7, Standard
or Panorama
Audio – Downmix
L/R Output Level -80 dB to +20 dB, adjustable from 0% to
100%, plus mute
Mono Output Level -80 dB to +20 dB, adjustable from 0% to
100%, plus mute
Bass Control ±12.0 dB per output
Treble Control ±12.0 dB per output
Audio – 3-Channel Input Mixer
Mix Level -80.0 to 0.0 dB per channel (Mix 1-3), per
output (Front L/R, Surround L/R, Back L/R,
Center, Stereo Downmix, Mono Downmix)
Input Compensation ±10.0 dB per input
EQ Mode 4-band graphic plus 2 notch filters (per input)
GEQ Center Frequencies 160, 500, 1.2k, 3k Hz
GEQ Gain ±12.0 dB per band
Notch Filter Frequency 20 to 20,200 Hz per filter
Notch Filter Width 0.020 to 3.500 octaves per filter
Dynamics Processing Gating and compression (per input)
Dynamics Pre-Process Level ±12.0 dB
Gating Level (Threshold) 0-100%
Gating Depth (Attenuation) -80.0 to 0.0 dB
Gating Attack 0 to 100 ms
Gating Decay 0 to 5000 ms
Compression Level
(Threshold)
-80.0 to +20.0 dB
Compression Ratio 1.0:1 to 10.0:1
Compression Attack 0.1 to 300.0 ms
Compression Release 1 to 1000 ms
Compression Curve Hard or soft knee
Dynamics Post-Process Level ±12.0 dB
Mixer Input Presets 1 thru 30
(Continued on following page)
