unovita RH300 User manual

Red Light
Therapy Panel
User Manual

Red Light Therapy Panel
P- 01
Product model
Dimensions
Power Consumption
LEDs
Lens Beam Angle
Cooling Fans
Weight
Warranty
Lifespan
Best For
Pulse
EMF
RH300
322*220*71
91W
70
30 Degree
1
4.2
3 years
50000 Hours
Half body
73Hz-146Hz-293Hz-587Hz
0 ut. at 3 inches
RH1000
880*220*71
273W
210
2
8.6
Full body
RH2400
1159*419*71
728W
560
4
18.5
Full body
RH3600
1717*419*71
1092W
840
8
32
Full body
RH1500
880*280*71
390W
300
2
11.8
Full body
Technical Specification
Product model
6in
12in
18in
24in
RH300
136mw/cm²
15.8*12in
125mw/cm²
19*15in
110mw/cm²
22.1*18.2in
92mw/cm²
25.2*21.3in
RH1000
146mw/cm²
37.8*12in
129mw/cm²
41*15in
116mw/cm²
44.1*18.2in
98mw/cm²
47.2*21.3in
RH2400
146mw/cm²
48.78*19.84in
129mw/cm²
52*22.84in
116mw/cm²
55.1*26in
98mw/cm²
58.2*29.1in
RH3600
156mw/cm²
70.7*19.8in
140mw/cm²
74*22.84in
132mw/cm²
77.1*26in
103mw/cm²
80.2*29.1in
RH1500
156mw/cm²
37.8*14.2in
140mw/cm²
41*17.3in
132mw/cm²
44.1*20.5in
103mw/cm²
47.2*23.6in
Irradiance

Timer Control:
Red Light Therapy Panel
P- 02
Step1
Press the"R/NIR"button,both red light and nir light
are working. Both light indicater of RED and NIR light
will light up to be green.
Press the"R/NIR"button again to use red light only.
The light indicator of RED will up to be green only.
Press the"R/NIR"button one more time to use NIR
light only. The light indicator of NIR will up to be green
only. But you can't see any light cause NIR is invisible
to naked human eyes.
Press the"R/NIR"button one more time to turn off
the device.
( Note: NIR is invisible to naked human eyes. )
The remote control function is enabled by default if you want to disable the
remote control function press and hold the"R/NIR"button for 6 seconds.
The available battery for the remote control is 23A 12V.

Red Light Therapy Panel
P- 03
Step2
Timing is not set by default.
To set a specific treatment time press the"T"button on
the control panel. Press the button once, the device
will work according to the 5-minute timing,each time
the button is pressed the device will increase the timing
by 5 minutes, up to 30 minutes.
If you need to leave temporarily during treatment press
and hold the " T " button for two seconds to pause the
device and then press and hold the button for two
seconds the device will continue to work according to
the set time.
Step3
Start working/ pause/, after you preset time,
click the " " button to start countdown/stop
countdown.

Red Light Therapy Panel
P- 04
Step4
Pulse is not activated by default.
If pulses are to be used, press the button to
enable pulse mode.Each time the button is pressed,
it will switch according to the following pulse modes.
73/146/293/587Hz
73Hz
Hormone Balance : Resonates with the sub-corticalor lower regions of the brain.
including the thalamus and hypothalamustwo major control centers for body
functions. May also help with muscle spasms, facial pain, headaches and
depression. Has been used for non-healing bone fractures and to help balance
hormones. Veterinary experience: Improves circulation.
146Hz
Brain activation intelligent tissue : Used for memory, psychological disorders,
nervousness and worry. Resonates with the cerebral cortex of the brain involved
with thinking, imagining and creating. Veterinary experience: Reduces inflammation
and scar tissue on tendons and ligaments, reduces edema and improves gums.
293Hz
It has a stimulating effect on the tissue of ectodermal origin the central and the
peripheral nervous system,the sensory epitheliathe epidermis with hair nails
cutaneous glands, the pituitary glandthe epiphysisIt facilitates recovery following
surgical procedures, restores the skin and the mucous membrane(wounds wrinkles
ulcers).Helps with migraines.This frequency is used as the universal frequency for
acupuncture points. Assists wound healing skin and nerve repairand reduces scar
tissue,inflammation and tumors.

Red Light Therapy Panel
P- 05
587Hz
Autonomic nerve balance : Resonates with Endoderm (innermost tissue) that
forms the lining of the intestinal tract, the lungs, the bladder, the urethra, and the
auditory tube. It also forms the thyroid, thymus, liver, gall bladder and pancreas.
Improves nutritional assimilation, allergy problems and balances the parasympa-
thetic nervous system. Used for circulatory problems, edema, and lymph problems.
The remote control fits for 23A 12V battery;
Remote control
23A 12V
23A 12V

Red Light Therapy Panel
P- 06
Introduction
Thank you for purchasing light therapy device!You've
chosen the only device that was purposefully designed to provide the most
optimal light therapy experience possible.
The device delivers clinical-grade irradiance at both 630nm 660 nm visible red
light 810nm 830nm 850 nm nonvisible near infrared light or a combination of both.
These light wavelengths have been scientifically proven to provide therapeutic
effects.
How Works
works by emitting red and near infrared light within a certain range of therapeutic
wavelengths and intensity these treatments penetrate your body tc generate a
number of health benefits following.
Many of these benefits happen because red and near infrared light activates
various metabolic pathways, leading to increased production of ATP(adenosine
triphosphate enhanced cellular signaling,and elevated protein synthesis. Red
and near infrared light therapy has been proven to be effective for a wide range
of health issues including but not limited to the following.
Product features
Red Light at 630nm 660nm
Most of red light absorbed by your skin,
leading to increase collagen production and
optimal skin health
Near Infrared light at 810nm
830nm 850nm
Near Infrared light penetrates deeper within
your body enhancing muscle recovery and
reducing joint pain

Red Light Therapy Panel
P- 07
The light energy emitted by Uno Vita should be used on bare skin for best results.
FDA Indication
Uno Vita is indicated for the relief of muscle spasms minor muscle & joint aches,
as well as pain&stiffness associated with arthritis
Getting Started with Uno Vita
Your Uno Vita comes with everything you need to access the amazing health
benefits of light therapy.For the best results, please read this manual completely
before using the device.
Light Sensitivity
Prior to using your Uno Vita please check for photosensitivity.To do this, expose
an area of your forearm 6inches away from the device for 3 minutes. If you exp-
erience any redness or discomfort you might be photosensitive and we recomm-
end consulting with your doctor or healthcare provider prior to using your Uno Vita.
Treatment Instructions
Uno Vita delivers medical-grade power also called irradiance of red and near
infrared liaht. For optimal results we recommend positioning your unovita
approximately 4 to 6inches from the area on your body you intend to treat.There
commended default treatment time is 10 minutes per area which will result in a
clinically proven dose of energy for both superficial and deep tissues.
Consistencyis Key
It's important to be consistent with your light therapy treatments.
That's why we recommend using your Uno Vita every day or at least 5 times per
week. For additional health benefits,including pain relief from aches and strains,
up to 3 treatments per day can be helpful. Photobiomodulation(PBM), or light the-
rapy, is like food for your cells. Unfortunately, most people do not get the proper
amount of healthy light their bodies need for optimal wellbeing. Because of this
their bodies may respond with detox-like symptoms.So if you're experiencing
these types of effects we recommend starting out with1-2 minute treatments per
area slowly working up to a10minute sessions over the course of 2-3 weeks as
your body acclimates to the therapy. As always, if you have any concerns regar-
ding the use of photobiomodulation,we recommend consulting with your trusted
healthcare provider.

Red Light Therapy Panel
P- 08
Results and Expectations
The amount of time required to see benefits and improvements depends on your
health goals.The cellular health benefits of light therapy have been thoroughly
proven across hundreds of clinical studies, so trust that your body is benefiting
from every therapy session. But there are many factors that may affect how
quickly you experience improvements in your symptoms.Some people will see
benefits within a matter of days.But overall improvements in health or skin related
issues can take 8-12 weeks of consistent use. By using your Uno Vita on a daily
basis,you can maximize your body’s rate of healing.

Red Light Therapy Panel
P- 09
Door Mounted Setup Guides
Step1
Place the RH1000 or RH 1500 face
down on a scratch-free surface.
Install the accessories on the back
of the panel with four screws as
shown in the picture.
Step2
Hang the included custom hook on
any standardsized door.
Step3
Attach the tripod to the clip
attached to the height adjustment
pulley. Then connect the snap on
the other end directly to the hook.

Red Light Therapy Panel
P- 10
Step4
To raise your RH1000 or RH 1500 to
your desired height pull down on the
loose cable while supporting the
device with your opposite hand.
Be sure to adequately support the
device while raising and lowering it
with the height-adjusting system.
Step4
To lower your RH1000 or RH1500,
push up on the lever on the height-
ad- justing pulley while supporting
the device with your opposite hand.
Be sure to adequately support the
device while raising and lowering it
with the height-adjusting system.
Step5
Plug the power cord into the
device and plug the other end into
a wall outlet. Next turn on the power
switch.
The display will appear "OFF" .

Warnings
Do not stare directly into the diodes or its reflection in a mirror
because it can cause temporary irritation of the eyes.
Do not let children use the devices unsupervised
This device is an electrical device to avoid electric shock adhere to the following.
Do not drop your device in water or liquids because you may get an electric
shock.
Do not wash electrical parts with water or liquids.
Do not directly touch the device or touch the plugs or switches with wet hands.
Do not apply or touch the device to wet or damp skin
Do not pull, carryor lift the device by its cord.If the cord is damaged do not use
the device because you could get an electric shock
Do not use the device if it has been dropped left outside or has encountered
water or liquids.
Do not use on or near heated surfaces
Do not operate this device in areas where it could be exposed to
flammable or combustible productsor where vapours may be pres ent.Explosion
of fire may occur.
This device is not to be used by sleeping or unconscious persons.
Do not use the device on open wounds as heat may increase circulation and
cause bleeding.
Do not use this device in combination with liniments and balms that contain
heat-producing ingredients as a skin burn could result.
Use of this device in any way other than described in this manual voids the
warranty and could result in serious injury.
Maintenance
The Uno Vita does not require maintenance other than routine cleaning.
Cleaning
Turn off your device by switching off the power switch to the off position on the
back of the device.
Unplug the power adaptor at the power wall outlet.
Clean the surface of device with a slightly damp cloth, making sure the device is
dry before using
Avoid the use of any harsh cleaners or bleaches as this may damage your device.
Red Light Therapy Panel
P- 11
WARNINGS AND CAUTIONS
MAINTENANCE CLEANING DISPOSAL GUIDELINES

Warranty:
We warrant this device will function and perform within its specification for 3
years from the date of delivery.
What does this warranty cover?
This limited warranty covers any defects in material or workmanship under
normal use during the warranty period. During the warranty period,our company
will repair or replace,at no charge.Products or parts of products those prove
defective because of improper material or workmanship under normal use and
maintenance.
What does this not cover?
The limited warranty does not cover any problem that is caused by damand result
in a from negligence improper maintenance or modification,demand by natural
causes like liahtnina floods or other natural disasters theft or loss of the product.
Red Light Therapy Panel
P- 12
Warranty Regulations
