upcom UC-16MX User manual

TRANSPORT STREAM
MULTIPLEXER
User Manual
www.upcom.com

Operations Manual UC-MX16
© 2007-2010 UPCOM TECHNOLOGIES, INC
This document is property of UPCOM TECHNOLOGIES, INC and is delivered on the express
condition that it not be disclosed, reproduced in whole or in part, or used for the manufacture for
anyone other than UPCOM without written consent, and that right is granted to disclose or so use
any information on said document.
Notice
The information in this document was believed to be correct at the time of publication, and every
effort was made to ensure that the most current information was shipped with each machine. If
subsequent modifications were made to your unit, and you need information on these, please
contact the UPCOM documentation department.
If you have technical or editorial comments concerning this manual, please write them on
photocopies of the relevant pages and send them to the documentation department or contact
the Customer Service Department. This assistance will be greatly appreciated
Manual Applicability and Symbols
This is the general operating manual for UPCOM Receivers Please make sure that the correct
manual is being used by verifying part number and serial number with UPCOM technical support
team or your local distributor.
Be prepared to furnish:
Serial Number
Exact Model Number
Symbols
The following warning and caution symbols are used throughout this manual:
Warning: A hazard exists that may result in personal injury or loss of life.
Caution: Failure to follow the procedures given may result in damage to the
equipment.

WARNING
This equipment operates at potentially lethal voltages. Only trained, qualified personnel should
operate, maintain, or service it. Only technicians thoroughly familiar with the equipment must
perform Service work.
This equipment is rated for 85 to 265V. Proper power cords should be used for the country where
the equipment will be operated. Power consumption should not exceed 50W.
The UC-16MX should not be operated where the unit is exposed to extremes of temperature
outside the ambient range, ( 0ºC to +45ºC ), precipitation, condensation or humid atmospheres
above 75%.
This equipment should not be operated around excessive dust, vibration, flammable gases,
corrosive or explosive atmospheres.

CONTENT
1.#Before#Getting#Started............................................................................................................. 1!
2.Introduction ................................................................................................................................ 2!
2.1#Working#principle.............................................................................................................................2!
2.2#Function................................................................................................................................................3!
2.3#Technique#parameter ......................................................................................................................3!
2.4#Use#surrounding ................................................................................................................................3!
3#Structure....................................................................................................................................... 4!
3.1#Front#Panel#&#Dimensions .............................................................................................................4!
3.2#Rear#Panel............................................................................................................................................5!
4#Operation...................................................................................................................................... 6!
4.1 Front Panel............................................................................................................................................6!
4.2#UCJ16MX#Operation#Flow ...............................................................................................................6!
4.3#Menu#Structure ..................................................................................................................................7!
4.3.1!Setting!the!network!address ....................................................................................................................9!
4.3.3!Output!number............................................................................................................................................ 11!
4.3.4!Test!mode...................................................................................................................................................... 12!
4.3.5!Keyboard!Lock ............................................................................................................................................ 13!
4.3.6!Modify!password........................................................................................................................................ 14!
4.3.7!Master!Reset................................................................................................................................................. 15!
4.3.8!Version!Info .................................................................................................................................................. 16!
Appendix#A.#Alarm#information ............................................................................................ 17!
Appendix#B.#Noun#Abbreviations.......................................................................................... 18!

UC-16MX
- 1 -
UC-16MX
Transport Stream Multiplexer
1. Before Getting Started
If you need help UPCOM and its distributors stand by every product sold. If you need help
please contact your local distributor or UPCOM directly at:
+1.408.329.4158
or
by e-mail:
[email protected]
Manual Updates
From time to time, new versions of software may require slight changes to the material
presented in this document. Check inside the back cover for supplementary pages that may
have been added to keep the manual up to date
Unpacking and Inspection
Before installing the equipment. Please check the box for integrity. After unpacking, look
for any missing items or damage to the equipment. If there is damage, please contact customer
support immediately. Do not proceed installing the equipment if there is visible or perceived
physical damage.
Warranty and RMA
UPCOM guarantees this equipment against defects in material and workmanship for a
period of 3 years from date of shipment. During this period UPCOM will repair or replace
products that are under warranty.
For all equipment under warranty the owner is responsible for freight to UPCOM and all
related customs, tariffs, insurance, etc. UPCOM is responsible for the freight of the equipment
from the factory to the owner under the same method the equipment was returned to UPCOM.
Equipment shipped back to UPCOM without a previously accepted RMA will be returned
to owner at owner’s expense.
The warranty does not cover: products with defaced serial number, damage during
shipping, damage caused by lightning, power surge or installation services.

UC-16MX
- 2 -
2.Introduction
The UC-16MX is a DVB Standard Transport Stream Multiplexer supports real-time video
stream multiplexing and re-multiplexing.The UC-16MX can handle 16 inport ASI SPTS or
MPTS and send the out through 1 or two MPTS streams.
It is compatible with the ISO/IEC-13818 standard with DVB ASI output interface.
2.1 Working principle
[Principle figure]
#
Figure2-1
[Working principle explanation]
(1) The multiplexer supports 16 MPEG-2 SPTS or MPTS inputs and two MPEG-2 transport
stream (MPTS) outputs. It filters out the empty packetsor the unneeded packets, and
changesthe PID (packet identity).
(2) Obtainsthe PSI (Program Specific Information) and SI (Service Information) and
integratesthem with local data.
(3) The UC-16MX can connect with a network management software through TCP/IP
protocol.

UC-16MX
- 3 -
2.2 Function
Multiplexing to SPTS (single program transport streams) or multiplexing to MPTS (multi
program transport streams), MPTS supports all-chosen or part-chosen.
Supportstwo different outport.
Low time delay. The delay for MPEG-2 Video program is less than 100ms.
Providing PCR check
SupportsDVB data broadcast.
Supportsremote upgrade of the software.
Real time monitor input status.
Port PID monitor function, you can customize monitoring time and port.
2.3 Technique parameter
PCR：< 100 ns
Input interface: ASI Interface, BNC
Input interface impedance: 75Ω
Input interface bit rate（max）： 180Mbps
Input select PID num（max）： 120
Input program num(max)：100
Input packet length: 188or 204byte
Output interface ：ASI Interface, BNC
Output interface impedance：75Ω
Output packed length: 188 or204byte
Total output rate（max）： 180Mbps
Power supply: 220VAC±10%,50Hz
Power: 30W
Weight: 4Kg
Dimension: 450*430*44（deep*wide*high）mm
2.4 Use surrounding
Working temperature: 0～45
Working humidity: 5～80%
Storage temperature：-20～70
Storage humidity: 5～90%

UC-16MX
- 4 -
3 Structure
3.1 Front Panel & Dimensions
Each equipment is designed for 1U（44mm）space, machine dimensionsof equipment is shown
as figure3-1.
#
Figure 3-1

UC-16MX
- 5 -
3.2 Rear Panel
Figure3-2
Figure3-2 showsrear-panel map of equipment, port describe is shown:
(1) ASI input channel（from1 to 16）, input SPTS or MPTS with DVB standard, 75ΩBNC.
(2) ASI output 1, multiplex output, 75ΩBNC.
(3) ASI output 2, multiplex output, 75ΩBNC.
(4) The same as to ASI output 2.
(5) The same as to ASI output1.
(6) RJ-45 port, network control. The customer can manage the multiplexer via any PC in
the LAN or WAN.
(7) RS232 port, it is used upgrade and test locally.
(8) ASI ring outport.
(9) Power switch.
(10)Power supply.
(11)GND.
Note: output1 is different or same with output 2

UC-16MX
- 6 -
4Operation
4.1 Front Panel
Figure 4-1
Power：power supply work indicator light, when green the system is normal.
channel indicator light：Display channel status. These status is shown as appendix A
Display screen：Display the system state and menu setting.
select key： ,  keyisusedtoswitchup/downmenuandadd/decreasenumber,
 key is used to change numbers.
MENUkey：enter or exit operation.
OKkey：make sure the operation.
4.2 UC-16MX Operation Flow
Step
Appliance
First
Second
Third
Fourth
Fifth
Installation
Setting
network
address
Initialization
Logon
Reading
information
Program
multiplexing
Changeinput
port transport
streams
Initialization
Logon
Reading
information
Program
multiplexing
Change output
program
parameters
Logon
Reading
information
Modify
parameters
Status monitor
Logon
Reading
information
Table 4-1 UC-16MX basic operation flow
Channel indicator lights
Power light
Display screen
OK key
MENU key
Select keys
