Welcome…
Welcome to a new era of aviation navigation. Once again,
UPS Aviation Technologies, Inc. has set new standards in
features and ease of use for the general aviation public.
The Apollo MX20 Multi-Function Display provides a
focal point for integrating many of your navigation needs
in an easy to use and convenient package.
The MX20 presents a wealth of information on its
six-inch diagonal, 640x480 pixel, color display. The many
features are organized as distinct functions and are
designed to closely mimic the traditional instruments used
in the standard cockpit. Each function allows varying
degrees of customization. The custom map function is
customizable so you can create a display for almost any
configuration you require. The other functions provide
more limited levels of customization so that they retain
the look and feel of the instruments they reflect.
The MX20 is capable of creating powerful overlay views
where information from a variety of sources can be
presented simultaneously in proper relationship to each
other, thus greatly increasing situational awareness for the
pilot.
You can be confident in knowing that you are the owner
of the state-of-the-art in aviation and navigation. The
MX20 architecture is designed to support full expansion
for both software and hardware enhancements. This
flexibility protects your investment and allows for the ease
of adding new features. Our products are built to last and
to allow the flexibility to meet your needs as they change
in the future.
iii

About This Manual
This manual may be used as a summary, a reference, and
a learning tool. Information is provided about all of the
functions available to the MX20. Your specific installation
may not include all of these functions.
Take a few moments to familiarize yourself with the
various sections in this manual. The Getting Started
section gives an introduction to the controls, basic
operation, and organization of the functions in your
MX20. Be sure to read the Getting Started section to learn
the rules for using the MX20. The Detailed Operation
section is the reference for each of the functions in the
MX20. Refer to the Detailed Operation section when you
want to get into the details on every function and option
along with step-by-step instructions.
Not every function is available in all software versions or
installations. Check your Approved Flight Manual
Supplement to verify the features that are available.
iv
