English
User manual
Portable Electric Air Compressor

3
Portable electric air compressor
Thank you for purchasing mini electric air pump. Please read
this user manual carefully before using the product and keep it
properly for reference.
Hose storage
Hose connector
LED lighting
Measured pressure
Preset pressure
Mode
Unit
Battery indicator
Preset +
Button for LED lighting
Power on/o
Preset -
Unit switching
Mode switching
Type-C input
Attention
1. Do not leave away from the product during inating.
2. Keep away from combustible and explosives.
3. Avoid moisture, sand and prevent from falling.
4. Do not store the product in a place that is too cold or hot.
5. Since the inator is equipped with lithium battery, do not put
it into re or discard casually.
6. Keep it away from children.

4
Packing list
1x Mini electric air pump
1x Storage bag for mini electric air pump
1x Presta adapter valve
1x Type-C cable
1x Schrader valve
1x Inating needle
Specication
Product name Portable Electric Air
Compressor
Product model UP-AC-220014
Dimension 137*55*55mm
Weight 360g
Pressure range 0-150PSI/0-10.3BAR
Working temperature -10/45°C
Battery capacity 850mAh x2/7.4V
Charging input 5V=1.5A
Instruction
1. Turn on/o
Turn on Turn o Press and hold the on/o
button for 3 seconds, as
shown in the picture.
Turn on successfully
Press and hold the on/o
button for 3 seconds, as
shown in the gure. Turn
o successfully.
In the power-on state,
short press the start-stop
button to start the
ination and automatically
stop the ination when
the preset air pressure
value is reached.
The pump will
automatically shut down
after no operation in 3
minutes. When the battery
is low, the automatic
protection shutdown.

5
4 bars of battery and are
constant on: 100%
3 bars of battery and are
constant on: 60%
2 bars of battery and are
constant on: 30% 1 bar of
battery left and ashes
anxiously: 5% (Battery
is low and need to be
charged)
Battery
indicator
2. Battery indicator
The hose can be stored
in the product storage
hole, as shown on the left.
Insert the threaded side of
hose into the storage hole.
3. Hose storage
Hose
To charge, please connect
the Type-C charging cable
(included) to a power
adapter (not included) of
about 5V/1,5A.
State of battery indicator:
Flashes: charging
Continuous light: full.
Note: the air pump cannot
be used during charging.
4. Charging method
Mountain cycling,
electrical bike, motorbike,
and car, are equipped with
Schrader valve. Ination:
connect Schrader valve
with the connector to start
ination.
Deation: press the inner
needle of valve with
proper tool, such as Allen
wrench.
5. Connection Shrader valve
Valve Connector

6
Road cycling and mountain
cycling may need to use
the adapter for Presta
valve.
Ination:
1. Connect Presta valve to
the adapter.
2. Unscrew the Presta
valve of tire.
3. Connect Presta valve
with the adapter to start
ination.
Presta adapter valve
Valve Connector
Deation: Unscrew the screw of Presta valve and press the
valve to start deation.
Basketball and football
need to use inating
needle for ination.
Ination: connect inating
needle with Shrader valve
and insert the needle into
the valve of ball.
Inating needle
Valve Connector
6. Measuring pressure
When the air pump is on, connect the
hose with an object and the measured
pressure will display on screens.
Measuring pressure
Preset pressure

7
7. Mode switching
Press to select dierent modes:
Scene mode Reference
value Adjustable range
Bicycle mode 38PSI 0~150PSI/0~10.3BAR
Custom mode 100PSI 0~150PSI/0~10.3BAR
Ball mode 8PSI 0~150PSI
8. Unit switching
Long press to select dierent units. The unit formula is
shown below:
1BAR = 14.5PSI
9. Preset pressure
Press: adjust the preset measure value.
Long press: quickly adjust the preset pressure value.
Note: the mode and preset pressure value are automatically
saved by the inator. You only need to switch the mode for the
next use, and the preset pressure will be automatically set.
10. LED lighting
Press to turn on LED light. Press it again to turn o.
11. Reset pressure value
Turn the power on, when the measured pressure value is not
zero, long press for 3 seconds to enter automatically
reset.
Do not connect the product to any inatables when resetting.
Note: The product has been calibrated from the factory. When
the dierence in altitude or the sensor tolerance shows that
the measured pressure is not zero, manual reset can improve
the accuracy of pressure detection. It is not recommended to
do reset in a high temperature.

8
1. The electric air pump
can only be used for
replenishing car tires in a
emergency. Do not use it
for a long time ination.
2. The mini pump doesn’t
auto. stop when inating
balloon or toy ball of which
the air pressure value is too
small to be sensored.
Warm tips:
12. Look up the pressure value of object
To guarantee safe operation, please look up the pressure value
of the object you want to inate, preventing from explosion
accident caused by excessive ination.
The pressure range of
bicycle tire is marked in
its side.
The load weight is related
to ination pressure.
For more details, please
check out user manual for
your bike.
Bicycle tire
The pressure range of balls
is marked inside of ination
port. The load weight
is related to ination
pressure. For more details,
please check out user
manual for your balls.
Balls

9
Caution
The hose will be overheated after working for a long time. Do
not touch the hose and the connector by hands immediately.
Hot
Pressure value of common inatables
Tyre Category Pressure
Range
Bike
Kids bike 18~30PSI
10-16 inch tires 30~45PSI
20-30 inch tires 38~55PSI
Road bike 100~120PSI
Ninebot Self-balancing
Scooter of MI 40~60PSI
Sheelchair/Electrical ride 30~45PSI
Motorcycles Motorcycles Electric vehicles 1.8~3.0BAR
Vehicles Cars 2.2~2.8BAR
Balls
Balls for kid 3~6PSI
Basketball 7~9PSI
Football 10~12PSI
Volleyball 4~6PSI
Rugby 10~14PSI
