URBANGLIDE Quad 4.0 User manual

1
Quad 4.0
USER MANUAL
ENGLISH

2
Security and precautions p.3
Before using p.5
Assembly p.6
Before driving p.8
Maintenanceand reparation p.9
Troubleshooting p.12
Component of the quad p.13
TABLE OF CONTENTS

3
CAUTION:Drivingan electricquadmaybe dangerous, sobe careful when using it. Misuse of the
productdoes not affectthe manufacturer,please pay attention tothe tips andsafety that youwill
find inthis manual. This quad can cause loss of control, a fall or a dangerous situation. If any of these
things happen, you risk losing yourlife, pleaseuse the safety equipmentand be careful aroundyou.
You drive at yourrisk used your common sense.
Thismanual containsmany warningsandtips forusingyourquad, please readthemcarefullyand
pay attention tothem. If a serious accident iscaused tooccur, it is not the responsibility of the
company.
•Equipementsforprotection
Always wearthe followingsafetyequipment:
-Helmetapprovedandcertifiedaccordingto yourlocation
-Knee pads and elbow patches
-Long-sleevedT-shirtandlongpants
-Gloves
-Shoeswith rubbersoles, neverdrive barefootorsandal. Checktomake the lacesmade, and
keep themas far as possible fromthe wheels andthe internal system.
•Driver advice and parental supervision
The drivershould notexceed54kg, the size and weightdo not fully certify thatthe driverwill have
full control of the vehicle. Thismanual contains valuableinformation, warningsand advice, anditis
your responsibilityto ensure thatall usersare aware of the risks. The recommended minimumage
for quaduse is 8 years old. Itis yourresponsibilitytoputa youngerchild, takingintoaccounttheir
skills, maturity andabilityto follow the rules. Donottouch the engine orthe brakesduringor
immediately afterusingthe vehicle, these partsmaybe extremely hot.Keepthe quadawayfrom
children, and ensure thatthe person using the vehiclehasreadthe instructions inthismanual.
•Proceduresand driving conditions
Please checklocal laws andrules before usingthe quad. Alwayslook around when driving, and pay
attention to all possible hazards. Always respectthe rights and properties of everyone. Do not
engage the throttle withoutbeing on the quadand safe. Please do not tryto figure or cascade with
the electricquad.This productis not designed tomake jumps, skids etc.
SECURITY AND PRECAUTIONS

4
To avoid any risk of accident, parental supervision is necessary. Neverdrive nearvehicles, stairs, hills,
swimming poolsorotherstreams. Hold the handlebarswith bothhands. Neverride more thanone
person on the quad.Keep yourfingersandall otherpartsof yourbody away fromthe chain, engine
or brakes. Neverdrive with a smartphone by hand or with an mp3 player. Neverhang anything on
the quad to pull it. Neverput the quadin contact withwater,electrical components can be damaged
and create a dangerous situation. Roll only on flat, solid surfaces. Avoidsurfaces withgravel, holes
and icecan leadto loss of control and accidents.
Do not drive atnightor in areas where visibility isreduced. Donot drive indoorswhere carpetsand
carpets can interfere.
Before eachuse, checkthat eachpiece is in its place andis in good condition.
People who have medical follow-up or treatment such as: cardiac people, pregnant women, people
not responsible, people with aprobleminthe backor neckshouldnot use the quad.
Maximum speed of the quad: 11 km / h
Before eachuse, checkthe following:
-The brakes are in good workingorder.
-All components are ingoodconditionandintheirplace.
-The parts that showedanomaliesduringthe lastuse have been repaired orchanged
accordingto the manufacturer'sconditions.
•Usingthe charger
The charger must be inperfect condition with eachuse, check the wires, the condition ofthe tips etc.
if the quad doesnotcharge, itmay be that the charger is defective, you will needtochange it.
Use only the supplied charger. The chargeris nota toyand shouldbe used byan adult. Never
connectthe charger near flammable productsorliquids. Always unplugthe chargerfromboth sides
whennotcharging.
SECURITY AND PRECAUTIONS

5
WARNING:Take out all the componentspresent in the box before startingyourquad. Make sure the
quad is off before startingassembly.
The quad mustbe assembledby an adult.
15 min of estimated assembly time, not including the initial charging time of 14h.
BEFORE USING
Button on/off
Charge port
Accelerator
Charger included
Necessary tools
10mm/8mm
Key (included)
5mm
Hex key (included)
6mm
Hex key (Not included)
Pressure pump
(Notincluded)
Screwdriver

6
Note:The gap betweenthe A & B parts must be the same on bothsides of the handlebar.
Transportation andthe time between manufacture andfirstuse may have slightly deflatedthe tires.
Use a pressure pumpto inflate yourtires.Itis not recommended touse astationinflator,whichis
thought to inflate totally different wheels.
•Inflating
Remove the capon the wheel, inflatethe tire, and replace the cap.
PSI : 30 Max
Bar : 2.07 Max
ASSEMBLY
Handlebar assembly
1. Align the handlebars vertically
and horizontally with the clip (A &
B). Screw the 4 screws (C) on the
fixed part(D).
2.Tighten the screws with the 5mm
hex wrench (E), hold with the
10mm wrench (F).
3. Check that the handlebar is
securely attached by pressing
on it. He should notmove.
Inflating tires
CAUTION: Regularly check the tire pressure, it
ensures yourcomfortandsafety with each use.

7
•Firstcharge required: 14 hours
•Nextrecharge: about 10 hours
•If the quadhas been damaged, the battery may needto be rechargedmonthlytomaximize
itsperformance.
Note:This equipment has beentested toensure yoursafety and is designedto workwith Class B
digital devices, in accordance with Part15 of the FCC Rules. This type of equipmentcangenerate
radio frequency energy.If the instructions are notfollowedcorrectly, these frequencies may be
harmful forradiocommunications.In addition, there isnoguarantee thatinterference will notharm
otherequipment.
If these interferencesinterfere withyourtelephoneorTV communication, you are advised toturnoff
and on yourequipment. If interference persists, follow these steps:
-Shift or reorientyourantenna - Move the charger away fromyour antenna.
-Connect yourcharger to a socket that is part of anotherelectrical circuit.
-Contact the technical supportof yourTV / Phone.
Warning:Do not use the product without charging your battery for the14 hours required,
otherwise you will damage your product and have the warranty void.Do not leavethe battery in
extreme temperatures. (Above 21 ° C - below0 ° C). The battery needs to be charged at least once
a month, evenif the quad isnot used.
ASSEMBLY
Charging the battery
CAUTION:The battery must be fully charged before eachuse.
1. Make sure the quad is off before inserting the
charger. Insert the charger intothe proper port (A) on
the right side of the battery.
2. Insert the charger into a socket, a light shouldappear
on the charger. A red light indicates that the battery is
charging, it turns green when the batteryis charged.

8
•Brakes
Checkthe brakes before each use. Forthis, without gettingon the quad, exertaslight
acceleration, then press the brake, the quad is supposed to stop.
•Frame and handlebars
Checkthat everythingis well assembledandthatall the cablesare well connectedand in
theirplace. Make a habitof checkingbefore eachuse.
•Tires
Checkthe tires of the quadregularly.
•Accelerator
Checkthat the throttle isin good workingorderandthat youare in an openarea.
•Security equipment
It is importantto always wearprotective gear(helmet/ elbow pads/knee pads). Sports
shoes(with arubbersole). Neverdrive barefootorsandal and be sure to keep yourlaces
away fromthe engine andthe ATV brakes.
•Battery
Checkthat the quad is turnedoff when youhave finishedusingit.Donot store the quadin
cold temperatures, asthis maydamage the battery.
BEFORE DRIVING
CAUTION:Alwayscheckthatyou are in an open area with a flat, dry, even surface.
Always keep bothhandsonthe handlebars, donottry to figure orjumpwiththe quad.

9
Maintenance and reparation
CAUTION:Turn off the quad before handlingthe followingparts.
Adjust the brakes (10min)
Loosen
Tighten
1. To adjust the brake cable,
unscrew the small black portion on
the brake until you reach the
desiredfit.
2. If you have trouble screwing or
unscrewing, you can use the 10mm
wrench. Make sure the nut is tight
once the adjustment is made.
3. Check that the brake is properly
adjusted without friction. You can adjust
the brake concentration by turning the
nut as shown in the picture.
CAUTION:If the brakes are notproperlyinstalled,theymayblockordamage your wheelsandtires.
Always checkbefore usingthe quad, thatthe brakes donot rub on anything.
Practice in an openarea to use your brakes, tofamiliarizeyourself withstoppingyourquad.

10
Maintenance and reparation
CAUTION:Turn off the quad before handlingthe followingparts.
Replace the chain (15min)
1. Remove the bolt from the right rear
wheel with the 6mm hex wrench.
2. Remove the nut on the wheel axle
using the 5mm hex wrench and the
10mm wrench.
3. With the screwdriver, unscrew the 3
screws on the protective casing of the
chain.
4. Remove the part holding the chain
(A) and slide it to remove the chain
completely.
5. Remove the part holding the chain
and slide it to remove the chain
completely.
6. Screw on the protective housing
using the 3 screws.
7. Retighten the nut on the wheel axle
using the 5mm hex wrench and the
10mm wrench.
8. Tighten the bolt on the middleof the
wheel with the 6mm hex key.

11
Do not leave yourbattery in extreme temperatures. Above 21° C and below 0 ° C.
Thisquad containsacid in the battery, whichmustbe recycled
according to your local laws and regulations. Please readthe
followinginstructionscarefully.
Recycle the deadbatteryresponsibly. The battery contains lead/
acid (electrolyte) andmustbe disposed of properly and in
accordance with currentlegislation. In most countries, it is illegal to incinerate batteries or disposeof
them in a landfill. Take them toan approved lead / acid battery recycling company, such as the
nearestcar batterydealer. Do not dispose of the batterywithhousehold waste.
Maintenance and reparation
Battery disposal and security
CAUTION:Rememberto washyourhands after handlingthe battery.
Do not mix oldandnew batteries, anddo not mix standardand rechargeable
batteries.

12
Problem
Possible Cause
Solution
The quad does not
work
The batteryis discharged.
Charge the battery, 14h may be
necessary.
Connections orcables are disconnected.
Checkthat the batteryis firmly seated in
the quad.
The quad does not
work long
The batteryneedsto be charged.
Charge the battery, 14h may be
necessary. Check that the battery is fully
engagedinthe quad.
The batterydoes not charge fully.
Make sure the powerflow is well
connected.
The batterymay need tobe changed.
The brakes are not properly adjusted
Follow the instructions onpage 9.
Tiresare notproperly inflated
Follow the instructions onpage 6.
The quad suddenly
stoppedworking
Overload, cut-off
Overloadingcanleadtosystem
shutdown. Turn off the quad, wait 15
seconds, then turnit on again.
Grilled fuse
Overloadingcan burn fuses, so you have
to change them. For this, contact the
after-sales service. Check beforethe
statusof all connectorsand cables.
The quad makes
strange noises when
the engine is running
The chain is struggling towork
Apply lubricantto the chain.
The quad moves
slowly
The brakes are not properly adjusted
Follow the instructions onpage 9.
The quad has overloaded
Make sure the personon itweighsless
than 54kg.
Checkthat there are no objects
obstructingthe properoperation of the
quad.
Bad drivingcondition
Make sure you are on flat, dry, and
constantground.
Tiresare notproperly inflated
Follow the instructions onpage 6.
Troubleshooting

13
1
Accelerator
16
Chain
31
Control device
2
Handlebar
17
Gearing
32
Guide wheel
3
Handlebar attachment
18
Gear nut
33
Tensioningsupport
4
Hand brake
19
Chainprotection box (int.)
34
Engine
5
Left handle
20
Batterysafety
35
Leftside protection
6
Seat
21
Battery
36
Leftfootrest
7
Corp
22
Rear fork
37
Front wheel
8
Above
23
Chassis
38
Front wheel centersupport
9
On / off button
24
Shockabsorber
39
Front axle (right)
10
On / off box
25
Brake callipers
40
Steeringrod
11
Rod attachment
26
Brake disc
41
Steeringtube
12
Stem
27
Axis
42
Front axle (left)
13
Tire
28
Rightfootrest
43
Fuse
14
Tire central support
29
Loadingport
15
Chainprotection box (ext.)
30
Rightside protection
Component of the quad

14
DECLARATION OF CONFORMITY
We undersignedPACTINFORMATIQUE hereby declare that the product.
Model : URBANGLIDE QUAD 4.0 CLASSIC
Type : Quad
Function: Electric quad
Product description: Small-scale modelofelectricquad for child, works witha rechargeable battery
Meets allstandards andtechnicaldirectives below:
DIRECTIVES
2009/125/EC
2006/66/EC
2013/56/EU
TESTS STANDARD
EN 61056-1:2012
EN 50563:2011+A1:2013
EN 55014-1:2006+A1:2009+A2:2011
EN 61056-2:2012
EN 50564:2011
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55014-2:1997+A1:2001+A2:2008
EN55014+A22011
IEC 62321-2:2013
IEC 62321-4:2013
IEC 62321-5:2013
CERTIFICATES/REPORTS
GJW2017-0099
HSO170103001ARM
150728098GZU-002
GJW2017-1062
150728101GZU-018
All radioemissiontests were carriedoutby the laboratories mentionedbelow:
Intertek Testing Sevices Shenzhen Ltd. Guangzhou Branch
Block E, NO. 7-2 GuangDong Software Science Park, CaipinRoad,
Guangzhou Sience City, GETDD Guangzhou, China
Tel/Fax : [phone]
Contact details of the manufacturer or agent:
PACT Informatique
33 ruedu ballon
93160Noisyle Grand –France
Contact details of the person authorized to edit the technical document:
Michael Barreira
33 ruedu ballon
93160Noisyle Grand - France
This declarationshall be issued undertheresponsibilityof the manufacturer and,where appropriate,of his
representative
05/11/2018
Representative of the company:
PACT INFORMATIQUE
33 rue du ballon –
Noisy le Grand - France
Maurice Bodokh
CEO
Shenzhen HSO. Test Technology Co., Ltd.
4F, Building 6,SamsungIndustrialZoneBlock2
Fuhai Avenue East, Fuyong Street, Bao’an District,
Shenzhen, China

15
QUAD 4.0
MANUEL D’UTILISATION
FRANÇAIS

16
Sécurité et précautions p.17
Avant de commencer p.19
Assemblage p.20
Avant de conduire p.22
Entretien et réparation p.23
Dépannage p.26
Composants du quad p.27
SOMMAIRE

17
ATTENTION : Conduire unquadélectriquepeutreprésenterun danger, veillezàfaire attentionlors
de son utilisation. Lamauvaise utilisation duproduitne metpas en cause le fabricant,merci de
prêterattentionaux conseils et sécurité que voustrouverezdansce manuel. Ce quadpeutune
entraînerperte de contrôle, une chute ouune situation dangereuse. Si une de ces choses se produit,
vousrisquezde perdre lavie, veuillezutiliserles équipementsde sécuritéetfaire attention autourde
vous. Vous conduisez à vos risques utilisévotre bon sens.
Ce manuel contient beaucoup d’avertissements et de conseils concernant l’utilisation de votre quad,
merci de bien les lire et d’y prêter attention. Si un accident grave est amené à se produire, il n’est pas
de la responsabilité de l’entreprise.
•Equipementsde protection
Veillezàtoujoursporter les équipements de sécurité suivant :
-Casque approuvé etcertifié en fonction de votre localisation
-Genouillèresetcoudières
-Tee-shirtàmancheslonguesetpantalon long
-Gants
-Chaussures avecdes semelles en caoutchouc, ne jamais conduirepieds-nus ou en sandale.
Vérifiez d’avoir les lacets faits, et de les maintenir le plus loin possible des roues et du
système interne.
•Conseil conducteuret surveillance parentale
Le conducteurne doitpas faire plus de 54kg, la taille etle poids ne certifientpas pleinement que le
conducteuraura une entière maîtrise du véhicule. Ce manuel contientdes informations, des
avertissementset desconseilstrès précieux, il estde votre responsabilitéde vousassurerque
l’ensemble des utilisateurs ont bien conscience des risques. L’âge minimum recommandé pour
l’utilisation du quad est 8 ans. Il est de votre responsabilité de mettre un enfant plus jeune, en
prenanten compte sescompétences, samaturité etsacapacité à suivre les règles. Ne touchezpasle
moteurou les freins pendant ou juste après l’utilisation du véhicule, ces parties peuvent être
extrêmementchaudes. Gardez le quadloin des enfants, etveillez àce que la personne qui uti lise le
véhicule ait pris connaissance des instructionsprésentes dans ce manuel.
•Procédures et conditionsde conduite
Veuillez vérifier les lois et les règles locales avant d’utiliser le quad. Regardez toujours autour de vous
lorsque vous conduisez, et prêtez attention àtous les risques éventuels. Respectez toujours les droits
et les propriétés de chacun. N’enclenchez pas l’accélérateur sans être sur le quad et en sécurité.
Veuillezne pastenterde figure oude cascade avecle quad électrique. Ce produit n’est pas conçu
pour faire des sauts, des dérapages etc…
SECURITE ET PRECAUTIONS

18
Pourévitertout risque d’accident, la surveillance des parents est nécessaire. Ne conduisez jamais
près de véhicules, d’escaliers, de collines, de piscine ou d’autre cours d’eau.
Maintenez le guidon avec les deux mains. Ne montez jamais à plus d’une personnesurle quad.
Gardez vos doigtset toutesles autresparties de votre corpsloin de la chaîne, du moteurou des
freins. Ne jamais conduire avecunsmartphone àlamain, ni avec un lecteurmp3.
Ne jamaisrienaccrocher au quad pour le tirer. Ne mettez jamais le quad en contact avec de l’eau, les
composants électriques peuvent s’endommager et créer une situation dangereuse.
Roulez uniquement surdes surfaces plates, solides. Evitez les surfaces avecdu gravier, les trous et la
glace peuvententraînerdes pertes de contrôle etdesaccidents. Ne roulezpaslanuit oùdans des
zones oula visibilité estréduite.
Ne roulezpasnon plus enintérieur, dans desendroits oùlamoquette etles tapis peuventvous
gêner.
Avantchaque utilisation, vérifiezque chaque pièce estbien àsaplace et esten bon état.
Les personnes qui disposent d’un suivi médical ou d’un traitement tels que : les personnes
cardiaques, les femmesenceintes, les personnes non-responsables, lespersonnes qui ont un
problème audosou au cou ne doivent pas se servirduquad.
Vitesse maximumdu quad :11 km/h
Avant chaque utilisation, vérifiez les points suivants :
-Les freins sonten bonétatde fonctionnement.
-Tous les composantssonten bonétat etbienà leurplace.
-Les pièces ayantprésenté des anomalies lorsde ladernièreutilisation ontbien été réparées
ou changées selon les conditionsdufabricant.
•Utilisationduchargeur
Le chargeurdoitêtre en parfaitétatà chaque utilisation,vérifiezles fils, l’état des embouts etc… si le
quadne charge pas, il se peutque le chargeur soitdéfectueux, il vous faudraalorsle changer.
Utilisezuniquementle chargeurfourni. Le chargeur n’est pas un jouet et doit être utilisé par un
adulte. Ne branchez jamaisle chargeurprès de produits inflammables oude liquide.
Débranchez toujours le chargeur des deux côtés lorsqu’il ne charge pas.
SECURITE ET PRECAUTIONS

19
ATTENTION : Sortez tousles composants présentsdanslaboîte avant de démarrervotre quad.
Assurez-vous que le quad est bien éteint avant de commencer l’assemblage.
Le quaddoitêtre assemblé parunadulte.
15 minde temps de montage estimé, sanscompterle temps de charge initialde 14h.
AVANT DE COMMENCER
Bouton on/off
Port de charge
Accélérateur
Chargeur inclus
Outils nécessaires
10mm/8mm
Clé (inclus)
5mm
Clé hexagonale (incluse)
6mm
Clé hexagonale (Non-incluse)
Pompe
pression
(Non-incluse)
Tournevis

20
Note : L’écart entre les pièces A&B doit être identique des deux côtés duguidon.
Il se peut que le transportet le temps entre lafabrication etlapremière utilisation aientlégèrement
dégonflé lespneus. Utiliserune pompe àpressionpourgonflervos pneus. Il n’est pas recommandé
d’utiliser un gonfleur de station, qui estpensépourgonflerdes roues totalementdiffèrentes.
•Gonflage
Enlevez le bouchonprésentsurlaroue, gonflez le pneu, puis remettezle bouchon.
PSI : 30 Max
Bar : 2.07 Max
ASSEMBLAGE
Assemblage du guidon
1.Alignez le guidon verticalement et
horizontalement avec l’attache (A&B).
Vissez les 4 vis (C) sur la partiefixe(D).
2. Serrez les vis avec la cléhexagonale
de 5mm (E), maintenez avec la clé
10mm (F).
3. Vérifiez que le guidon est bien
attaché en exerçant une pression
dessus.Il ne devraitpas bouger.
Gonflage des pneus
ATTENTION : Vérifiez régulièrement la pression
des pneus, elle assure votre confort et votre
sécurité àchaque utilisation.
