CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
`
Preface
CradlePoint reserves the right to revise this publication and to make changes in the content thereof without obligation to
notify any person or organization of any revisions or changes.
Manual Revisions
Revision
Date
Description
Author
1.0
Sept. 13, 2011
Initial release for Firmware version 3.3.0
Jeremy Cramer
1.1
May 4, 2012
Updated for Firmware version 3.5.1
Jeremy Cramer
1.2
June 6, 2012
Updated for Firmware version 3.6.1
Jeremy Cramer
1.3
July 23, 2012
Updated for Firmware version 3.6.3; updated module
information for HSPA+, LTE/HSPA+
Jeremy Cramer
2.0
Sept. 19, 2012
Updated for Firmware version 4.0.2
Jeremy Cramer
2.1
Jan. 15, 2013
Updated for Firmware version 4.1.1
Jeremy Cramer
2.2
Feb. 26, 2013
Updated for Firmware version 4.2.0
Jeremy Cramer
2.3
Aug. 21, 2013
Updated for Firmware version 4.4.0 and hardware version 1.3
Jeremy Cramer
3.0
Sept. 22, 2013
Updated for Firmware version 5.0
Jeremy Cramer
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
`
Trademarks
CradlePoint and the CradlePoint logo are registered trademarks of CradlePoint, Inc. in the United States and other
countries. All other company or product names mentioned herein are trademarks or registered trademarks of their
respective companies.
Copyright © 2013 by CradlePoint, Inc.
All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written consent by
CradlePoint, Inc.
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
`
Table of Contents
1!INTRODUCTION*.................................................................*3!
1.1! PACKAGE!CONTENTS!.............................................................!3!
1.2! SYSTEM!REQUIREMENTS!........................................................!3!
1.3! IBR600/IBR650!OVERVIEW!.................................................!3!
2!HARDWARE*OVERVIEW*.....................................................*8!
2.1! PORTS,!LEDS,!AND!SWITCHES!................................................!9!
2.2! MOUNTING!BRACKET!.........................................................!13!
3!QUICK*START*...................................................................*16!
3.1! BASIC!SETUP!.....................................................................!16!
3.2! CONNECT!TO!A!COMPUTER!OR!OTHER!DEVICE!..........................!17!
3.3! COMMON!PROBLEMS!.........................................................!20!
4!WEB*INTERFACE*–*ESSENTIALS*.........................................*21!
4.1! ADMINISTRATOR!LOGIN!.......................................................!22!
4.2! GETTING!STARTED!–!FIRST!TIME!SETUP!..................................!24!
4.3! QUICK!LINKS!.....................................................................!29!
4.4! CONFIGURATION!PAGES!......................................................!30!
4.5! ENTERPRISE!CLOUD!MANAGER!REGISTRATION!.........................!32!
4.6! IP!PASSTHROUGH!SETUP!.....................................................!33!
5!STATUS*............................................................................*34!
5.1! CLIENT!LIST!.......................................................................!35!
5.2!CP!CONNECT!....................................................................!37!
5.3! DASHBOARD!.....................................................................!38!
5.4!GPS!................................................................................!41!
5.5! GRE!TUNNELS!...................................................................!42!
5.6! HOTSPOT!CLIENTS!(IBR600)!...............................................!43!
5.7! INTERNET!CONNECTIONS!.....................................................!44!
5.8! ROUTING!..........................................................................!54!
5.9! STATISTICS!........................................................................!55!
5.10! SYSTEM!LOGS!..................................................................!58!
5.11!VPN!TUNNELS!................................................................!59!
5.12! WIPIPE!QOS!..................................................................!60!
6!NETWORK*SETTINGS*........................................................*61!
6.1! CONTENT!FILTERING!...........................................................!62!
6.2! DHCP!SERVER!..................................................................!68!
6.3!DNS!...............................................................................!69!
6.4! FIREWALL!.........................................................................!72!
6.5! MAC!FILTER!/!LOGGING!.....................................................!80!
6.6! ROUTING!..........................................................................!82!
6.7! ROUTING!PROTOCOLS!.........................................................!83!
6.8! WIFI!/!LOCAL!NETWORKS!....................................................!92!
6.9! WIPIPE!QOS!...................................................................!116!
7!INTERNET*......................................................................*123!
7.1! CONNECTION!MANAGER!...................................................!124!
7.2!CP!CONNECT!(BETA)!........................................................!151!
7.3! CLIENT!DATA!USAGE!........................................................!152!
7.4! DATA!USAGE!..................................................................!153!
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 2
7.5! GRE!TUNNELS!................................................................!157!
7.6!L2TP!TUNNELS!...............................................................!160!
7.7! NETWORK!MOBILITY!(NEMO)!...........................................!163!
7.8! NHRP!CONFIGURATION!....................................................!165!
7.9!VPN!TUNNELS!................................................................!167!
7.10! WIFI!AS!WAN!/!BRIDGE!(IBR600)!...................................!179!
7.11!WAN!AFFINITY!/!LOAD!BALANCING!..................................!184!
8!SYSTEM*SETTINGS*..........................................................*188!
8.1! ADMINISTRATION!.............................................................!189!
8.2! DEVICE!ALERTS!................................................................!208!
8.3! GPIO!CONNECTOR!..........................................................!211!
8.4! ENTERPRISE!CLOUD!MANAGER!...........................................!213!
8.5! FEATURE!LICENSES!...........................................................!215!
8.6! HOTSPOT!SERVICES!(IBR600)!............................................!216!
8.7! SERIAL!REDIRECTOR!..........................................................!220!
8.8! SNMP!CONFIGURATION!...................................................!222!
8.9! SYSTEM!CONTROL!............................................................!225!
8.10! SYSTEM!SOFTWARE!........................................................!226!
9!GLOSSARY*.....................................................................*228!
10!APPENDIX*....................................................................*242!
10.1! PRODUCT!INFORMATION!AND!SAFETY!GUIDE!.......................!242!
10.2! SPECIFICATIONS!.............................................................!245!
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 3
1 INTRODUCTION
1.1 Package Contents
•CradlePoint COR Integrated Broadband Router: IBR600 (includes WiFi) or IBR650 (no WiFi) with embedded
high-speed modem (4G LTE / 3G EVDO rev A, EVDO rev A, WiMAX, LTE/HSPA+, HSPA+). Models with no
integrated modem (NM) are also available for use with an external USB modem.
•AC power adapter (12V, 1.5A)
•Two external modem antennas
•Two 2.4 GHz High Performance 802.11n WiFi Antennas (IBR600 only)
•Mounting Hardware
•Quick Start Guide
1.2 System Requirements
•At least one Internet source: an active subscription for the embedded modem; an external USB modem; an
Ethernet-based modem; or WiFi as WAN
•Windows 2000/XP/7, Mac OS X, or Linux computer (with WiFi adapter for IBR600 WiFi functionality)
•Internet Explorer v6.0 or higher, Firefox v2.0 or higher, Safari v1.0 or higher
1.3 IBR600/IBR650 Overview
The CradlePoint COR is a highly featured, compact, and robust router designed for deployment in critical business and
enterprise applications that require 24x7 connectivity via Ethernet and/or WiFi. The router features a built-in high-speed
modem (4G LTE, 3G EVDO, WiMAX, HSPA+, LTE/HSPA+) modem as well as support for wired networks such as DSL or
Cable. With its compact size, sleek metal case and mounting bracket, and external Cellular antennas, CradlePoint COR is
ideal for use in high-availability portable or fixed applications (ATM, kiosk, surveillance, vehicle). With failover/failback
capability, COR supports both wired and wireless Internet.
The router increases Internet availability and business continuity by detecting network failures and seamlessly switching
over to the other network(s). It is also ideal for deployment as a primary connection solution where wired Internet is not
available. The IBR600/IBR650 provides secure and reliable VPN functionality, allowing users to create, manage, and
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 4
terminate up to 5 concurrent IPSec VPN sessions. It allows for secure access to company networks for enterprise
applications and provides a secure way to transmit sensitive data to and from a remote site.
COR: THE HEART OF YOUR M2M NETWORK
•For use in business critical high-availability installations such as ATMs, Kiosks, Surveillance, Vehicles, etc. that
require 24x7 connectivity
•Increase your network availability with WiPipe™-powered automatic failover/failback internal functionality
•Supports both wireless and wired Internet connections (two Ethernet ports for either LAN/LAN or WAN/LAN)
•Secure IPsec VPN (5 concurrent sessions maximum)
•Centralize the administration and monitoring of distributed routers using CradlePoint Enterprise Cloud Manager
ENHANCED WIFI (IBR600)
•500+ feet of WiFi Range
•Wireless “N” WiFi (802.11n, legacy 802.11b/g, external 2x2 MIMO antenna system)
•2.4 GHz WiFi broadcast
•Maximum security with both Public and Private networks
•Dual SSIDs
•Create a customized Hotspot with our captive portal feature (include Terms of Service, advertisements, etc.)
•Enhanced performance around walls and other obstructions
ADDITIONAL FEATURES
•Standardized platform and cloud-based management with CradlePoint Enterprise Cloud Manager (subscription
required)
•Built-in GPS including NMEA GGA, VTG, and/or RMC sentences (depending on your modem type)
•IP Passthrough
•Up to 5 concurrent VPN endpoint sessions
•Compatible with Cisco, Juniper, SonicWall, and other VPN termination systems
•Establish continuous uptime with optimum total cost of ownership for broad deployment
•Simple to install, configure and maintain with minimal impact on IT
•Virtual LAN capabilities
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 5
•Data Usage section that allows users to track and manage modem use
•NAT-less routing
•VPN NAT traversal
•IPv6 support
•SMS support
•Multicast Proxy support
LICENSABLE FEATURES – REQUIRE EXTENDED ENTERPRISE LICENSE (and hardware version 2.0)
•OSPF; BGP; RIPv1, RIPv2, and RIPng; VRRP; and STP
•Site-to-site dynamic VPN with NHRP
•Layer 2 Tunneling Protocol (L2TP)
•NEMO (Network Mobility) / DMNR (Dynamic Mobile Network Routing for Verizon)
See http://www.cradlepoint.com/eel for more information about the Extended Enterprise License.
1.3.1 Active GPS Support on -PWD Models
The following -PWD models include an active GPS connection at 3.3 V and 100 mA max:
•COR IBR600LE-PWD (Verizon)
•COR IBR600LP-AT-PWD (AT&T)
•COR IBR600LP2-EU-PWD (Europe)1
•COR IBR600LP-PWD2 (Canada)1
1 Requires minimum order quantity (MOQ)
To enable, purchase and connect an active GPS antenna (SMA adapter included). The -PWD models include only one
WiFi antenna for operation in 1x1 WiFi mode.
1.3.2 CradlePoint Enterprise Cloud Manager
Rapidly deploy and dynamically manage networks at geographically distributed stores and branch locations with
Enterprise Cloud Manager, CradlePoint’s next generation management and application platform. Enterprise Cloud
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 6
Manager integrates cloud management with your CradlePoint devices to improve productivity, increase reliability, reduce
costs, and enhance the intelligence of your network and business operations. Learn more at http://cradlepoint.com/ecm.
1.3.3 CradleCare – Access the Experts 24/7
CradlePoint understands how important and critical network uptime is to your business. We have a knowledgeable
enterprise technical support staff that is available anytime via phone, chat, or email to protect your investment. Our
experts will expedite issue resolution and provide flexible device-by-device solutions to help maximize operational
efficiency. This allows you to dedicate more time to what’s important: your business.
Support
•CradleCare Support Agreement: 24/7 technical support, software upgrades, and advanced hardware exchange –
1, 3, and 5 year options
•CradleCare Extended Warranty: extends the standard warranty to 3 or 5 years
On-Site Services
•CradleCare Standard 3G/4G Site Survey: Comprehensive carrier analysis for optimal performance
•CradleCare Standard Installation: Deploy the experts to ensure a successful installation
Learn more at http://www.cradlepoint.com/products/cradlecare.
1.3.4 Captive Portal (IBR600)
The captive portal solution provided by CradlePoint routers enables businesses to provide their customers with a public
WiFi hotspot with access controls. The controls can be as simple as requiring acceptance of a terms of service
agreement, while advanced features allow administrators to control and monitor usage, require login, direct users to
specific web pages, provide revenue through service fees or paid advertising, and more.
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 7
1.3.5 CradlePoint COR Models
CradlePoint
COR models
Modem
Technology
Carrier /
Location
Antenna
Symbol
IBR600 (WiFi)
IBR650 (no WiFi)
LE-VZ
LTE/EVDO
Verizon
✔1
✔
LP-AT
LTE/HSPA+
AT&T
✔1
✔
LP
LTE/HSPA+
Canada
✔1
✔2
LP2-EU
LTE/HSPA+
Europe
✔1
✔2
P
HSPA+
Generic
✔
✔
P-INTL
HSPA+
International
✔
✔
P-AT
HSPA+
AT&T
✔2
✔
W
WiMAX
CLEAR
✔
E-VZ
EVDO
Verizon
✔
✔
E-SP
EVDO
Sprint
✔
✔
NM (no modem)
-
-
-
✔
✔
1 -PWD version available (IBR600LE-VZ-PWD, IBR600LP-AT-PWD, IBR600LP2-EU-PWD, IBR600LP-PWD2) that comes with an active GPS
connection at 3.3 V and 100 mA max; IBR600LP2-EU-PWD, IBR600LP-PWD2 versions require MOQ
2 Requires minimum order quantity (MOQ)
CradlePoint products with the -EU and -INTL SKUs enable and disable WiFi channels to comply with EU law. The -EU
and -INTL SKUs are not legal for use in North America. The -EU and -INTL versions also come with an adapter kit for
non-USA/Canada power outlets (includes US, EU, and UK options).
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 8
2 HARDWARE OVERVIEW
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 9
2.1 Ports, LEDs, and Switches
Power 12VDC: The power connector includes two pins for power and two pins for GPIO
(General Purpose Input/Output) functionality. The included power adapter, however, only
connects to the power pins. You will need a separate adapter for GPIO functionality.
Reset: You can return your router to factory default settings by pressing and holding the
Reset button. This button is recessed, so it requires a pointed object such as a paper clip
to press. Press and hold for 10 seconds to initiate reset.
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 10
Ethernet Ports: By default, the IBR600/IBR650 has one WAN (Wide Area Network—your Internet source) port and one
LAN (Local Area Network) port. Each of these ports can be reconfigured, however, if you need two LAN or two WAN
Ethernet ports.
Ethernet LED:
•Solid Green – connected
•Blinking Green – data transfer activity
USB Port (Standard-A): This port can be used for an external USB modem or to attach a direct firmware upgrade to
enable manual firmware upgrades if necessary. (Hardware version 1.3 changed from a micro USB port to a full-size
Standard-A USB port.)
WiFi Antennas (IBR600 only): The IBR600 comes with two 2.4 GHz WiFi antennas (Reverse SMA). These antennas are
simple to attach and adjust for maximum WiFi broadcast.
The antenna position shown is not allowed: neither WiFi nor modem antennas
should lie on top of each other.
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 11
Modem Antennas: The CradlePoint COR comes with two modem antennas to enhance reception for the embedded
modem. These antennas are simple to attach and adjust.
Power On/Off:
•I = On
•O = Off
Power LED:
•Blue = On
•No light = Off
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 12
WiFi LED:
•Green = On and operating normally
•No light = Off
Modem LED:
•Green = On and operating normally
•Blinking Green = Connecting
•Amber = Not available (idle, for example)
•Blinking Amber = Cellular data connection error
•No light = Off
Additional LED Indications:
Factory reset button detected
WiFi and modem LEDs blink amber
twice
Error during USB firmware
upgrade
WiFi and modem LEDs blink red
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 13
2.2 Mounting Bracket
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 14
2.2.1 Attaching the COR to the Mounting Bracket
1) Attach the bracket to the wall or other surface with screws.
NOTE: Screws are not provided because the type of screw required
depends on the mounting surface.
2) Place the router’s edge
against the bottom of the
bracket.
3) Press the router down
firmly, then push it inside
the bracket. It should
latch.
CRADLEPOINT COR | USER MANUAL Firmware ver. 5.0.0
© 2013 CRADLEPOINT, INC. PLEASE VISIT HTTP://KNOWLEDGEBASE.CRADLEPOINT.COM/ FOR MORE HELP AND RESOURCES PAGE 15
2.2.2 Removing the COR from the Mounting Bracket
From the top of the bracket, press down firmly on the router using your thumb(s) and pull the device out.
This manual suits for next models
1
Table of contents
