USBGEAR USBG-BREC304 User manual

User Manual
USB 3.2 Gen 1 Charging & Super
Speed Mountable Hubs
Model Numbers: USBG-BREC304, USBG-BREC307, USBG-BREC3010
Product Manual Version: 1 Date 2023-10-04

BREC Hubs – Product Manual
2
Table of Contents
1. Introduction 2
2. Connector Layout 3
3. Hardware Installation 4
4. Checking the Installation 5
5. Restore to Factory Settings 7
6. Environmental Specifications 7
Revision History
Revision
Date
Comments
1.0
2023-10-04
First Release
1. Introduction
Thank you for purchasing one of our 4, 7, or 10 port hubs. This User Manual covers the
USBG-BREC304, USBG-BREC307, and USBG-BREC3010 hubs. Housed in a compact steel chassis,
these hubs are perfect for discreet installations in offices, labs, warehouses, heavy machinery,
automation equipment, and other industrial applications.
Features:
✔Compliant with USB 3.2 Gen 1 Specifications
✔Upstream and Downstream ports support Super-Speed (SS), High-Speed (HS) and Full-Speed
(FS) traffic
✔Backward compatible to USB specification Revision 2.0/1.1
✔Includes a charging function to power each port up to 900mA, enough for normal charging
✔Compliant with Fast Charging for international Battery Charging 1.2 Standard Protocol and
Smart Control
✔Transfer data and charge connected devices simultaneously
✔Support included for Plug-and-Play and hot swapping. No driver installation needed
✔Bus-Powered with Limit current protection
✔Compatible with all operating systems
✔Power Adapter Included in all models
Need help? Visit: usbgear.com/support

BREC Hubs – Product Manual
3
2. Connector Layout
USBG-BREC304
USBG-BREC307
USBG-BREC3010
1
Downstream Device Charging Ports
4, 7, or 10x USB 3.2 Gen 1 Female Type-A
2
Upstream Host Port
1x USB 3.2 Gen 1 Female Type-B
3
Power Connector
DC Barrel Jack
4
Surface Mounting Bracket
Fixed Non-Removable
Need help? Visit: usbgear.com/support

BREC Hubs – Product Manual
4
3. Hardware Installation
1. Use static electricity discharge precautions. Remove possible static discharge potential
from any objects that the hub may come in contact with before installation. This can be
accomplished by touching a bare metal chassis rail after you have turned off the power.
2. Apply DC power via the DC Barrel Jack. Attach the included DC Barrel Power Supply.
3. Connect USB Host cable: The host cable is a standard A-to-B USB 3.2 Gen 1 cable. Please
connect the Type-A end connector of the cable to your USB Host or PC, then connect the
Type-B end connector to this hub. Since the USB hub is plug-and-play, you don’t have to
turn off your host computer when installing the hub.
4. Connect USB devices to the downstream ports of this hub.
5. (OPTIONAL) Mount your hub on the wall / surface.
3.1 Surface Mounting
1. Mount your hub where needed via the integrated surface mounting flanges. *Screws for
surface mounting not included
