USSC Ambiance B9945L User manual

Propane (LPG) Model
B9945L
Natural Gas Model
B9945N
UNITED STATES STOVE COMPANY
227 Industrial Park Road • P.O. Box 151 • South Pittsburg, TN 37380 • [phone]
VENT-FREE PEDESTAL GAS HEATER
INSTALLATION AND OPERATION INSTRUCTIONS
This is an unvented gas-fired
heater. It uses air (oxygen) from
the room in which it is installed.
Provisions for adequate combus-
tion and ventilation air must be
provided. Refer to "Adequate
Combustion And Ventilation Air"
on page(s) 6 of this manual.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury, or loss of
life.
~Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
~WHATTO DO IFYOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
~Installation and service must be performed by a
qualified installer, service agency, or the gas supplier.
WARNING:
Do not use a blower insert,
heat exchanger insert or other
accessories not approved
for use with this heater.
Save this manual for
future reference.
This appliance may be installed in an aftermarket* manufactured (mobile) home,
where not prohibited by state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with other gases.
851369B 6/00

TABLE OF CONTENTS
TC
NOTICE
Installationandrepairmustbedonebyaqualifiedserviceperson.Theapplianceshouldbeinspected
beforeuseandatleastannuallybyaprofessionalserviceperson.Morefrequentcleaningmaybe
requiredduetoexcessivelintfromcarpeting,beddingmaterial,etc. Itisimperativethatcontrol
compartments,burnersandcirculatingairpassagewaysoftheappliancebekeptclean.
IMPORTANT SAFETY INFORMATION............................................................3-4
PRODUCT FEATURES..........................................................................................4
SPECIFICATIONS...................................................................................................5
CONTENTS..............................................................................................................5
ITEMS REQUIRED FOR INSTALLATION..........................................................6
INSTALLATION........................................................................................................7
MANTELCLEARANCES........................................................................................8
GAS CONNECTION..........................................................................................9-10
GAS PRESSURE CHECK....................................................................................10
FLAMEAPPEARANCE........................................................................................11
LOG ASSEMBLY...................................................................................................11
OPERATING INSTRUCTIONS........................................................................12-14
CLEANING/SERVICING................................................................................14-15
FLAME APPEARANCE.......................................................................................15
PARTS LIST FOR HEATER ASSEMBLY......................................................16-17
PARTS LIST FOR BURNER& LOG ASSEMBLY.......................................18-19
TROUBLE SHOOTING..................................................................................20-21
OPTIONAL EQUIPMENT................................................................................22-23
WIRINGDIAGRAMS.......................................................................................23-25
NOTES....................................................................................................................26
LIMITEDWARRANTY POLICY.........................................................................27

CARBON MONOXIDE POISONING: Earlysignsofcarbonmonoxidepoisoningaresimilartothe
fluwithheadaches,dizzinessand/ornausea.Ifyouhavethesesigns,obtainfreshairimmediately.
Have the heater serviced as it may not be operating properly.
The installation must conform with local codes or, in the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1.
The 9945N/9945L vent-free gas heater system cannot be installed in a bedroom.
Do not install the heaters in a bathroom.
WARNING:Improperinstallation,adjustment,alteration,serviceormaintenancecancauseinjury
orpropertydamage. Referto this owner'smanual. Installationandservice must beperformedby
a qualified installer; service agency or the gas supplier.
Topreventmalfunctionand/orsooting,anunventedgasheatershouldbecleanedatleastannually
byaprofessionalserviceperson.Morefrequentcleaningmayberequiredduetoexcessivelintfrom
carpeting,etc.Itisimperativethatcontrolcompartments,burnersandcirculatingairpassageways
be kept clean.
Correct placement of the ceramic fiber logs is necessary to avoid problems with sooting. Sooting
cansettle onsurfacesoutsidetheheater andcausediscoloration.Seetheappropriatesections of
this manual for instructions.
WARNING: Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner
flame patterns. Do not place a blower inside burn area of firebox. Ceiling fans may create drafts
that alter burner flame patterns. Sooting and improper burning will occur.
This is an vent-free gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to installation
guidelines.
Children and adults should be alerted to the hazard of high surface temperature and should stay
away to avoid burns or clothing ignition.
IMPORTANT SAFETY INFORMATION
3
INSTALLER: Please leave these instructions with the owner.
OWNER: Please retain these instructions for future reference.
IMPORTANT: Read these instructions carefully before installing or trying to operate this heater.
WARNING: Any change to this heater or its controls can be dangerous.
Improper installation or use of the heater can cause serious injury or
death from fire, burns, explosion or carbon monoxide poisoning.
WARNING
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Young children should be carefully supervised when they are in the room with the appliance.

PRODUCT FEATURES
IMPORTANT SAFETY INFORMATION
Do not place clothing or other flammable material near the appliance.
Keep appliance area clear and free from combustible materials, gasoline and other flammable
vapors and liquids.
Any safety screen or guard removed for servicing must be replaced prior to operating the heater.
Thisvent-freegasheater is intended tobesmokeless.Iflogs appear to smoke,turnoffthe heater
andcallaqualifiedserviceperson.Initialburnoffmaycauseslightsmokeandodorduringthefirst
four hours of operation.
Input ratings are shown in BTU per hour and are for elevations up to 2,000 feet. For elevations
above 2,000 feet, input ratings should be reduced 4 percent for each 1,000 feet above sea level.
Refer to the National Fuel Gas Code.
Theapplianceanditsappliancemaingasvalve must be disconnected from the gas supply piping
systemduringanypressuretestingofthatsystemattestpressuresinexcessof1/2psig(3.5kPa).
Theappliancemustbeisolatedfromthegassupplypipingsystembyclosingitsequipmentshutoff
valveduringanypressuretestingofthegassupplypipingsystemattestpressuresequaltoorless
than 1/2 psig (3.5 kPa).
Do not use this room heater if any part has been under water. Immediately call a qualified service
technician to inspect the room heater and to replace any part of the control system and any gas
control which has been under water.
4
12.
13.
14.
15.
16.
17.
18.
19.
FIGURE1.9945Vent-FreePedestal
GasHeater.
Features:
• Heating Efficiency - 99.9%
• Wide BTU Range: 27,000 - 39,900.
• Safe Operation - Oxygen Depletion Sensor (ODS).
• No Electricity Required.
• Fiber Ceramic Logs.
• Push-Button Piezo Ignitor.
• Clean Operation.
• Wide Bay Front.
• Easy Operation.
• Heats up to 1,200 square feet.

SPECIFICATIONS
NaturalGas
ManifoldPressureSetting4"w.c.
GasInletPressure Maximum10-1/2"w.c.
Minimum5"w.c. GasRate Number
Model Number Type Max BTU/Hr Min BTU/Hr ofBurners
9945N Manual 39,900 27,000 1
Propane/LPG
Note:Anexternalregulatorisrequiredtoreducesupplypressuretoamaximumof13"w.c.
ManifoldPressureSetting10"w.c.
GasInletPressure Maximum13"w.c.
Minimum11"w.c. GasRate Number
Model Number Type Max BTU/Hr Min BTU/Hr ofBurners
9945L Manual 39,900 27,000 1
5
GLOVES ARE RECOMMENDEDWHEN HANDLING CERAMIC FIBER LOGS
TO PREVENT SKIN IRRITATION FROM LOOSE FIBERS. LOGS ARE
FRAGILE, HANDLE WITH CARE.
Carefullyinspectthecontentsforshippingdamageandimmediatelyinformyourdealerifanydamageisfound.
CAUTION
9945Land9945NUnventedGasHeaters
1. PacketcontainingHomeowners/Installationinstructions.
2. Three(3)individuallywrappedfiberceramiclogs,refertoinstallationinstructions.
3. Unventedgasheater.
CHECKTHATALLLISTED PARTSHAVEBEENRECEIVED
CONTENTS
Controls-Maincontrolhas4positions:
1. OFF-Allgastotheburnerisshutoffatthecontrol
2. IGN-Piezoignitorallowsignitionofthepilotwithouttheuseofmatchesorbatteries
3. PILOT-Valve positionto light/maintaina standingpilot
4. ON-Gasflowtocompletesystem.
HIGH / LOW Control - Infinite control :
RotateknobclockwisetoLOW,counterclockwisetoHIGH.

Thisheatershallnotbeinstalledinaconfinedspaceorunusuallytightconstructionunlessprovisionsare
provided for adequate combustion and ventilation air.
Unusually tight construction is defined as construction where:
(a) Wallsandceilingsexposedtotheoutsideatmospherehaveacontinuouswatervaporretarder
with a rating
of 1 perm (6 x 10 kg per pa-sec-m²) or less with openings gasketed or sealed, and
(b) Weather stripping has been added on openable windows and doors, and
(c) Caulking or sealants are applied to areas such as joints around window and door frames,
between sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations
for plumbing, electrical, and gas lines, and at other openings.
The National Fuel Gas Code defines a confined space as a space whose volume is less than 50 cubic
feet per 1,000 BTU per hour (4.8m per kw) of the aggregate input rating of all appliances installed in that
space and an unconfined space is defined as a space whose volume is not less than 50 cubic feet per
1,000 BTU per hour (4.8m per kw) of the aggregate input rating of all appliances installed in that space.
Roomscommunicatingdirectlywiththespaceinwhichtheappliancesareinstalled,throughopeningsnot
furnished with doors, are considered a part of the unconfined space.
6
ADEQUATE COMBUSTION AND VENTILATION AIR
ITEMS REQUIRED FOR INSTALLATION
ITEMS REQUIRED FOR INSTALLATION
Ensurethatthefollowingitemsareavailablebeforeproceedingwithinstallation:
•Externalregulator(forpropane/LPGonly) •Manualshutoffvalve
•Pipingwhichcomplieswithlocalcodes •Sedimenttrap
•Pipesealantapprovedforusewith •Pipewrench
propane/LPG(resistanttosulfurcompounds)
CODES
Adheretoalllocalcodesorintheirabsence,thelatesteditionofTHENATIONALFUELGASCODEANSIZ223.1
orNFPA54whichcanbeobtainedfrom:
AmericanNationalStandardsInstitute,Inc. NationalFireProtectionAssociation,Inc.
1430Broadway or BatterymarchPark
NewYork,NY10018 Quincy,MA02269
WARNING
3
Duetohightemperatures,donotinstalltheheater:
• Wherecurtains,furniture,clothingorotherflammableobjectsarelessthan42"
fromthefrontoftheheater.
• Inhightrafficareas.
• Inwindyordraftyareas.
DO NOT PLACE CLOTHING OR OTHER FLAMMABLE MATERIAL ON OR NEAR THE
APPLIANCE.

INSTALLATION
Thefollowingformulacanbeusedtodeterminethemaximum
heaterratingperthedefinitionofunconfinedspace:
BTU/HR=(L1+L2)Ft x (W)Ftx(H)Ft x 1000
50
Considertwoconnectingroomswithanopenareabetween,
withthefollowingdimensions:(SeeFig.2,Example)
L1=15-1/2Ft.,L2=12Ft.,W=12ft.,H=8Ft
50
=52800BTU/HR
Iftherewereadoorbetweenthetworoomsthecalculation
wouldbebasedonlyontheroomwiththeheater.
BTU/HR=(15-1/2)x(12)x(8)x1000
50
=29760BTU/HR
7
FIGURE 2.
Wheninstallingtheappliancedirectlyoncarpeting,tileorothercombustible
material,otherthanwoodflooring,theappliancemustbeinstalledonametalor
woodpanelextendingthefullwidthanddepthoftheappliance.
WARNING
Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasan
unconfinedspaceorifthebuildingisofunusuallytightconstruction,provide
adequatecombustionandventilationairbyoneofthemethodsdescribedinthe
NationalFuelGasCode,ANSIZ223.1,Section5.3,orapplicablelocalcodes.
L2 (12')
L1 (15-1/2') W (12')
H (8')
Minimumclearancestocombustibles:
Topofheater....................................36"
Sidesofheater....................................8"
Frontofheater..................................42"
Rearofheater.....................................4"
FIGURE3.MinimumClearances
36"
8"
8"
4"
42"
Ensure the minimum clearances shown in FIGURE 3 are maintained for
accessibilityforpurposesofservicingandproperoperation.Leftandright
clearancesaredeterminedwhenfacingthefrontoftheheater.
WARNING WARNING
Maintaintheseclearancesto
ensure adequate space
around air opening for
properoperation.

8
MANTEL CLEARANCES
Ifplacingacustommantelabovetheheater,youmustmeetminimumclearancesbetweenmantel
shelfandthetopoftheheater.
Ifyourinstallationdoesnotmeetthebelowminimumclearances,youmust:
•Raisethemanteltoanacceptableheight,OR
•Removethemantel.
ALL MINIMUM
DISTANCESARE
ININCHES
TOPOFHEATER
DISTANCETO
UNDERSIDEOF
MANTEL
UNDERSIDEOF
MANTEL SHELF
MANTEL SHELF
BACK WALL
FLOOR MINIMUM CLEARANCE
TO BACK WALL

GAS CONNECTION
NOTICE
CAUTION
IMPORTANT:Loosenthepipeadapter
on the flex tube before installing to the
systempiping.
FIGURE5.GasConnection
CHECKGASTYPE:Thegassupplymustbethesameasstatedonheater'sratingplate.Ifthegassupplyis
different,DONOTINSTALLtheheater.Contactyourdealerforthecorrectmodel.
Connectingdirectlytoanunregulatedpropane/LPGtankcancauseanexplosion.
9
Aqualifiedgasapplianceinstallermustconnectthefireplacetothegassupply.
Consultalllocalcodes.
WARNING
TO HEATER
CONTROL VALVE STAINLESS
FLEXIBLE TUBE
PIPE
COUPLING
PIPE
MANUAL
SHUTOFF VALVE
TEE JOINT
PIPE NIPPLE
CAP
SEDIMENT TRAP
Usenewblackironorsteelpipeonly.Internallytinnedcoppertubingcanbeusedinsomeareas
whenpermittedbylocalcodes.Onlyusepipeof1/2"orgreaterdiametertoallowfullgas
volumetoheater.Excessivepressurelosswilloccurifthepipeistoosmall.
Amanualshutoffvalve,unionandplugged1/8"NPTpressuretappingpointmustbeinstalled
upstreamoftheheater(FIGURE4).
Asedimenttrapmustbeinstalledupstreamoftheheatertopreventmoistureandcontaminants
frompassingthroughthepipetotheheatercontrolsandburners.Failuretodosocould
preventtheheaterfromoperatingreliably(FIGURE4).

10
GAS CONNECTION
GASPRESSURECHECK
FIGURE6.RearViewof9945Vent-FreeGasHeater
The gasinletconnectionis3/8"NPT,madeat
thesideofthemaincontrolthroughtheareaat
therearofthepedestal.
Testallgasjointsfromthegasmetertothe
heaterforleaksusingsoapandwatersolution
aftercompletingconnection.DONOTUSE
ANOPENFLAME.
Theheaterregulatorcontrolstheburnerpressurewhichshouldbecheckedatthepressuretestpointlocatedonthe
frontofthemaincontrolandisaccessiblethroughthefrontoftheheater.(seeFIGURE6).
Thepressureshouldbecheckedwiththeheaterburningandthecontrolsettohigh(HI).
Thepressureregulatorispresetandlockedtoavoidtampering.IfthepressureisnotasspecifiedinProduct
Specifications(Page5),contactyourdealerandreplacetheregulator.
FIGURE7.PressureTestPointLocation
GasInletConnection(3/8"NPT)

1)Removethetwo(2)screwsandliftthefrontscreenslightlyup.(Fig.7A) Thentiltthebottomofthescreen
inward and downward. (Fig. 7B) 2) Lean the top of the screen toward you slightly (Fig. 7B) and then
proceedtocarefullybringthescreenstraightback(Fig.7C). NOTE:Toreinstallthefrontscreen,reverse
steps 1 & 2.
11
REMOVING FRONT SCREEN
WARNING
Thepositioningofthelogsiscriticaltothesafeandcleanoperationofthisheater.
Sootingandotherproblemsmayresultifthelogsarenotproperlyandfirmly
situatedintheappliance.Neveraddadditionallogsorembellishmentssuchas
pinecones,vermiculiteorrockwooltotheheater.
LOG POSITIONING
Donothandletheselogswithyourbarehands! Alwayswearglovestopreventskinirritationfromceramicfibers.
Afterhandlinglogs,washyourhandsgentlywithsoapandwatertoremoveanytracesoffibers.
PROPER INSTALLATION SEQUENCE:
LOG ASSEMBLY
FIG 7CFIG 7B
FIG 7A
FIGURE8.LogSetAssembly
WARNING: Failure to position the
partsinaccordancewiththesedia-
grams or failure to use only parts
specificallyapprovedwiththisheater
may result in property damage or
personalinjury.

12
OPERATING INSTRUCTIONS
Avoidanydraftsthataltertheburnerflamepatterns.Donotallowfanstoblowdirectlyintotheheater.Donotplace
ablowerinsideburnareaoffirebox.Ceilingfansmaycreatedraftsthatalterburnerflamepatterns.Sootingand
improperburningwilloccur.
Thisvent-freegasheaterisintendedtobesmokeless.Iflogsappeartosmoke,turnofftheheaterandcallaqualified
serviceperson.Initialburnoffmaycauseslightsmokeandodorduringthefirstfourhoursofoperation.
WARNING:Ifyoudonotfollowtheseinstructionsexactly,afireorexplosionmay
resultcausingpropertydamage,personalinjuryorlossoflife.
Thisapplianceisequippedwithanignitiondevice(Piezo)whichautomaticallylightsthepilot. IfPiezofails,
thenlightthepilotusingmatches. Refertomatchlightinginstructions(page14). Whenlightingthepilot,
followtheseinstructionsexactly.
BEFORELIGHTINGsmellallaroundtheapplianceareaforgas.Besuretosmellnexttothefloorbecause
somegasisheavierthanairandwillsettleonthefloor.
WHAT TO DO IF YOU SMELL GAS
•Donotattempttolightanyappliance.
•Donottouchanyelectricswitch;donotuseanyphoneinyourbuilding.
•Immediatelycallyourgassupplierfromaneighbor'sphone.Followthegassupplier'sinstructions.
•Ifyoucannotreachyourgassupplier,callthefiredepartment.
Useonlyyourhandtopushinorturnthegascontrolknob.Neverusetools.Iftheknobwillnotpushinor
turnbyhand,don'ttrytorepairit,callaqualifiedservicetechnician.Forceorattemptedrepairmayresult
inafireorexplosion.
Donotusethisapplianceifanyparthasbeenunderwater.Immediatelycallaqualifiedservicetechnician
toinspecttheapplianceandtoreplaceanypartofthecontrolsystemandanygascontrolwhichhasbeenunder
water.
A.
WARNING
FOR YOUR SAFETY READ BEFORE LIGHTING
Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityofthisoranyother
appliance.
FOR YOUR SAFETY
B.
C.
D.

1. STOP! Read the safety information on the
previous page.
2. Set the thermostat to lowest setting.
3. Turn off all electrical power and open the
access door.
4. Push in gas control (B) slightly and turn clock
wise to "OFF".
5. Push "ON / OFF" switch to "OFF" position.
NOTE: Knob cannot be turned from "PILOT" to
"OFF" unless knob is pushed in slightly. Do not
force.
6. Waitfive(5)minutestoclearoutanygas.Then
smell for gas, including near the floor. If you
smell gas, STOP! Follow "B" in the safety
information on the previous page. If you don't
smell gas, go on to the next step.
7. Depressknob(B)andturngascontrolknob
counterclockwise to "Pilot".
8. Push in knob (B) all the way and hold in.
Immediatelylightthe pilotbypushingin onthe
piezo button (A). Continue to hold the control
knob in for about one(1) minute after the pilot
islit. Releaseknobanditwillpopbackup. Pilot
shouldremainlit. Ifitgoesout,repeatsteps4
through8.
Ifthepilotdoesnotpopupwhenreleased,stop
and immediately call your service technician
or gas supplier. If the pilot will not stay lit after
several tries, turn control knob to "OFF" and
call your gas supplier.
9. Turn valve knob clockwise to "ON".
10. Waitaboutoneminutethenturn burnerswitch
(D) to "ON". It will take a few minutes for the
thermopile located on top of the pilot to heat
up.
NOTE: If unit is equipped with remote "on-off" wall
switch,switchmustbein"on"positionforburnerto
light.
11. Adjustflameheightwiththehigh-lowknob(C).
12. Turn on all electrical power to the appliance.
13. Close access door.
NOTE: It is normal for the new heater to give off
some odor the first time it is burned. This is due to
the curing of the paint and any undetected oil from
the manufacturing process.
Itisrecommendedthatyouburnyournewheaterfor
at least two(2) hours the first time you use it. If
optionalfankitisinstalled,leaveitturnedoffforthe
break in period.
13
OPERATING INSTRUCTIONS
LIGHTING INSTRUCTIONS
TOP VIEW OF BURNER ASSEMBLY
A
B
C
D
1. Open access door.
2. Turn switch (D) to "OFF"
3. Unplug all electric power (optional blower) if service is to be performed.
4. Push in gas control knob slightly and turn clockwise to the "OFF" position.
5. Close access door.
TURN OFF GAS TO APPLIANCE

Annualinspectionandcleaning byyour dealeror qualifiedservice technicianis recommendedto prevent
malfunction and/or sooting.
Removefrontscreen,(seepage11).Carefullyliftscreenfromlocatingstubsandsetasideduringcleaning.
Refer to instructions on page 11 for installation of screen. Do not operate the unit with the screen
removed.
Removelogs, handlingcarefullybyholdinggentlyateachend.Glovesarerecommendedtoprevent skin
irritationfromceramic.Iftheskinbecomesirritated,washgentlywithsoapandwater.Refertomanualfor
correct log placement. 14
OPERATING INSTRUCTIONS
Wait30secondsbeforereadjustingtheheaterwhenthecontrolhasbeenturned
downtoalowersetting.
WARNING
PILOT FLAME
Thepilotflameshouldalwaysbepresentwhenthe
heaterisinoperationandshouldjusttouchthetopof
thethermocoupletip(FIGURE9).
Ifthepilotflamedoesnottouchthethermocouple,
thenthemainburnerisunlikelytofunctionreliably
(FIGURE10).
WARNING Turnoffheaterandallowtocoolbeforecleaning.
CLEANING / SERVICING
FIGURE9.PilotFlame FIGURE10.IncorrectShapeofPilotFlame
MATCH LIGHTING INSTRUCTIONS
Ifthepilotwillnotlightusingthepiezoignitor,youcanlightthepilotwithamatch. First,locatethepilot. Thepilot
islocatedbetweentheburnertubeontherightend(facingtheunit),insidethefirebox. Tolightpilotwithamatch,
movethegascontrol(knobB,pg.13)tothepilotpositionandholddown. Lightmatchandplacenearpilot. Once
pilotislit,continuetoholdtheknobforabouttenseconds. Thenfollowsteps9thru13onpage13.
CHECKING FLAME APPEARANCE
Flamesfromthepilotandburnershouldbevisuallycheckedwhentheheaterisinstalled. Inaddition,aperiodic
checkoftheflamesshouldbemade.

FIGURE 11. Flames - Natural Gas and LP Gas
15
CLEANING / SERVICING
Periodic Cleaning
• Do not use cleaning fluid to clean logs or any part of heater.
• Logs - Brush with soft bristle brush or vacuum with brush attachment.
• Vacuum loose particles and dust from the front and rear burner, control, and piezo.
• Inspect burner's and air intake hole. Remove lint or particles with vacuum.
• External case should be dusted and wiped with a wet soapy cloth.
Annual Cleaning/Inspection
• Inspect and clean burner air intake holes.
• Inspect and clean all burner ports.
• Inspect ODS pilot for operation and accumulation of lint at air intake holes.
• Verify flame pattern and log placement for proper operation.
FLAME APPEARANCE
• Verify smooth and responsive ignition of main burner and rear burner.
In normal operation at full rate after 15 minutes the following flame appearance should be observed.
FLAMES
The flames behind log #1, and in between log #2, should be yellow with a blue base. (See Below,
#1
#2
Figure 11)

14
16
HEATER ASSEMBLY REPLACEMENT PARTS
5
3
9
7
6
18
10
4
17
15
16
8
12
11
13
2
1
20
19

KEY PART # DESCRIPTION QTY.
1 B24767 BASE 1
2 B69198 PEDESTALWELDMENT 1
3 24891 FIREBOX BOTTOM (NATURAL) 1
4 24768 FIREBOXBOTTOM(L.P.PROPANE) 1
5 24772 FIREBOXWRAPPER 1
6 B24769 CABINETWRAPPER 1
7 24771 FIREBOXTOP 1
8 24770 FRONT 1
9 B24773 CABINETTOP 1
10 24774 LOUVERFRAME 1
11 B24457 CONTROLDOOR 1
12 89899 BRASSKNOB 1
13 83323 8-32x3/8MACHINESCREW 1
14 24800 WINDOWFRAMEBRACKET(BOTTOM) 2
15 24799 WINDOWFRAMEBRACKET(TOP) 2
16 69236 WINDOW FRAMEASSEMBLY 1
17 89916 EXTRUDEDLOUVER(LONG) 2
18 89917 EXTRUDEDLOUVER(SHORT) 4
N/S 89824 MAGNETIC LATCH 1
N/S 83343 #10x1/2HXHDSCREWS 86
19 24892 HEAT SHIELD 2
20 24886 ROCKERSWITCHBRACKET 1
PARTS LIST FOR HEATER ASSEMBLY
17
N/S = NOT SHOWN

BURNER & LOG ASSEMBLY
18
11
1
17
15
16
14
3
2
8
7
9
10
6
4
5
12
13

19
PARTS LIST FOR GENERATOR AND LOG ASSEMBLY
KEY PART # DESCRIPTION QTY.
1 24777 BURNERPLATE 1
2 24881 CONTROLBRACKET 2
3 81198 CONTROL VALVE (NATURAL) 1
- 81202 CONTROLVALVE(LIQUID PROPANE) 1
4 83464 10-32x3/8PHHDMACHINESCREW 4
5 89937 BURNERGASLINE(#31ORIFICE-NAT.) 1
- 89938 BURNERGASLINE(#49ORIFICE-L.P.) 1
N/S 83172 #10Ax1/2HXHDSCREW(2toMOUNTPILOT) 11
6 89921 "O.P. AMERICA" NAT. PILOT 1
- 89922 "O.P. AMERICA"L.P. PILOT 1
7 89855 PILOTTUBE (11") 1
8 89856 3/16" LOXIT FITTING 1
9 89841 3/16"COMPRESSIONNUT 1
10 89842 3/16"COMPRESSIONSLEEVE 1
11 89920 BURNER 1
12 C42373 ROCKERSWITCH 1
13 80376 WIRE ASSEMBLY 1
14 24888 LOGSUPPORT 2
15 89939 REARUNILOG 1
16 89940 FRONTLOG 1
17 89941 CROSSLOG 1
N/S=NOTSHOWN

20
TROUBLESHOOTING
Turnoffandletcoolbeforeservicing.Onlyaqualifiedservicepersonshould
serviceandrepairheater.
NOTE:Alltroubleshootingitemsarelistedinorderofoperation.
REMEDYPOSSIBLECAUSE
OBSERVEDPROBLEM
Whenignitorbuttonispressed,thereis
nosparkatODS/Pilot.
•Ignitorelectrodepositionedwrong
•Ignitorelectrodeisbroken
•Ignitorelectrodenotconnectedto ignitor
cable.
•Ignitorcablepinchedorwetkeepignitor
cabledry.
•Brokenignitorcable
•Badpiezoignitor
•Replace ignitor.
•Replace ignitor.
• Reconnect ignitor cable.
• Free ignitor cable if pinched by any
metalor tubing.
• Replace ignitor cable.
• Replace piezo ignitor.
•Ventilateroom.Stopusingodor-caus-
ingproductswhileheateris running.
• Locate and correct all leaks.
•Applianceburningvaporsfrompaint,hair
spray,glues,etc.
•Gasleak.
Applianceproducesunwantedodors.
•NotenoughfreshairisavailableforODS/
Pilottooperate.
•Lowlinepressure.
•ODS/Pilotispartiallyclogged.
•Openwindowand/ordoorventilation
• Contact local gas company.
• Clean ODS/Pilot.
Applianceshutsoffinuse.
•Gasleak.
•Controlvalvedefective.
• Locate and correct all leaks.
• Replace control valve.
Gasodorevenwhencontrolknobisin
OFFposition.
•Gassupplyturnedofformanualshutoffvalve
closed.
•ControlknobnotinPILOTposition.
• Control knob not pressed in while in Pilot
position
•Airingaslineswheninstalled.
•ODS/Pilotisclogged.
•Gasregulatorsettingisnotcorrect.
•Turnongassupplyoropenmanualshutoff
valve.
• Turn control knob while in PILOT position.
• Press in control knob while in PILOT posi-
tion.
• Continue holding down control knob.
Repeat igniting operation until air is re-
moved
• Replace ODS/pilot assembly or get it
serviced
Whenignitorbuttonispressed,thereis
sparkatODS/Pilot,butnoignition.
•Controlknobnotfullypressedin.
•Controlknobnotpressedinlongenough.
•Manualshutoffvalvenotfullyopen.
• Replace gas regulator.
• Press in control knob fully.
• After ODS/pilot lights, keep control
knob pressed in 30 seconds.
• Fully open manual shutoff valve.
ODS/Pilot lights, but flame goes out
whencontrolknobisreleased.
WARNING
