The “BREAK-SAFE®”
PORTABLE LOADBREAK & LOAD PICKUP JUMPER
CLAMP
USBS-15-1-PS
USBS-15-2-PS
USBS-27-1-PS
USBS-27-2-PS
USBS-46-1-PS
USBS-46-2-PS
Operation Manual
B-00125 USBS Manual Rev. 2.2 (9-23-19)

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
2!
!#
Contact!with!high!voltage!will!cause!death!or!grievous!personal!injury!to!the!
operator.!!Only!use!this!device!in!conjunction!with!safe!operating!practices!
around!energized!lines!and!equipment.!
!
DANGER#
!#
!#
!#
Always!wear!appropriately!rated!rubber!gloves!and!personnel!protective!gear!
when!utilizing!this!product!to!prevent!electrocution.!
!
DANGER#
!#
!#
Carefully!read!and!fully!understand!this!manual!prior!to!operating,!
maintaining!or!testing!this!device.!!Improper!operation,!handling!or!
maintenance!of!this!device!can!result!in!death,!grievous!personal!injury!and!
or!equipment!damage.!!!
!
WARNING#
!#
!#
The!BREAK-SAFE®!tool!is!a!portable!switch!designed!to!perform!the!following!three!
functions:!loadbreak,!load!pickup!and!continuous!current!duty.!!It!is!intended!for!
temporary!connecting!and!transferring!of!load!and!should!not!be!used!in!a!
permanent!capacity!under!any!circumstance.!!!The!BREAK-SAFE®!is!designed!to!be!
installed!using!appropriate!rubber!gloves!and!personal!protective!equipment.!!The!
tool!is!operated!using!an!insulated!hotstick.!
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
!
!
!
!
!
!
!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
3!
!#
Follow!safe!work!procedures!and!practices!when!utilizing!this!product.!!
Failure!to!use!this!tool!in!a!safe!manner!can!result!in!death,!grievous!personal!
injury!and!or!equipment!damage.!
!
WARNING#
!#
!#
!#
These!instructions!are!not!intended!to!replace!or!be!a!substitute!for!proper!
safety!training!procedures.!!Failure!to!select!the!proper!tool!in!regards!to!
minimum!system!requirements!can!result!in!death,!grievous!personal!injury!
and!or!equipment!damage.!
!
WARNING#
!#
!#
!#
Only!trained!and!qualified!personnel!should!operate,!inspect!and!maintain!
this!equipment.!!!
!
WARNING#
!#
!#
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
4!
BREAK-SAFE®CIRCUIT#RESTRICTIONS#
BREAK-SAFE®!devices!should!not!be!used!in!situations!where!the!maximum!voltage!
and/or!amperage!rating!of!the!tool!can!be!exceeded.!!BREAK-SAFE®!tools!are!rated!
by!maximum!amperage!(A)!and!voltage!(V).!!TABLE!1!details!the!specific!ratings!of!
the!various!BREAK-SAFE®!models.!
!
Cat.!#!
Maximum!
Current!
Rating!
Maximum!
System!
Voltage!
Minimum!
Conductor!Size!
Maximum!
Conductor!Size!
USBS-15-1-PS!
300!A!
15!kV!
#6!Copper!
954!ACSR!
USBS-15-2-PS!
300!A!
15!kV!
#6!Copper!
954!ACSR!
USBS-27-1-PS!
300!A!
27!kV!
#6!Copper!
954!ACSR!
USBS-27-2-PS!
300!A!
27!kV!
#6!Copper!
954!ACSR!
USBS-46-1-PS!
200!A!
46!kV!
#6!Copper!
954!ACSR!
USBS-46-2-PS!
200!A!
46!kV!
#6!Copper!
954!ACSR!
TABLE!1:!Model!Ratings!
!
Outlined!below!are!some!circuit!restrictions!known!to!exist:!
!
•Do!not!utilize!the!BREAK-SAFE®!tool!in!situations!where!ferroresonance!can!
produce!overvoltage!situations.!!An!example!of!this!involves!switching!
unloaded!transformers!that!are!delta-connected!three!phase!and!wye-
connected!three!phase!with!primary!neutral!ungrounded.!
!
•Do!not!utilize!the!BREAK-SAFE®!to!switch!unloaded!transformers.!
!
•Do!not!utilize!the!BREAK-SAFE®!to!switch!capacitor!banks.!!Capacitor!
switching!can!cause!large!over!voltage!situations!that!are!likely!to!cause!
flashover!of!the!tool.!!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
5!
!#
Do!not!utilize!the!BREAK-SAFE®!in!phase-to-phase!or!grounding!circuits.!
!
WARNING#
!#
!#
!#
The!BREAK-SAFE®!is!to!be!used!in!a!temporary!capacity!only.!!Do!not!utilize!
the!tool!in!a!permanent!capacity!or!for!extended!periods!of!time.!!
!
!
WARNING#
!#
!#
!#
The!BREAK-SAFE®!is!not!waterproof.!!Do!not!use!the!BREAK-SAFE®!in!wet!
conditions.!
!
!
WARNING#
!#
!#
!
!!!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

!
"#$$%&'!()")!*%+,!-./0!12.34,56/!74/849! !
\!
:6/@8;,63!`66S!
:94G2!`4/@9.!
K/,.3/49!a.996<!
L8I.!
Y64@![5;S82!
L35>>.3!
a.996<!K/@5;4,63!"4/@!
[email protected]!M5/>!
:6/@8;,63!"43!
VT.RWE'RH.X#<5#;/.#[email protected]#@?'<;<?5##
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
#
#
#
)4D.,B![5/!:633.;,9B!
K/+,499.@!5/!,=.!12./!
[6+5,56/C!

!
"#$$%&'!()")!*%+,!-./0!12.34,56/!74/849! !
^!
:6/@8;,63!`66S!
:94G2!`4/@9.!
NV,.3/49!"34++!
:6/,4;,+!
Y64@![5;S82!
L35>>.3!
[email protected]!M5/>!
:6/@8;,63!"43!
VT.RWE'RH.X#<5#;/.#6=?'.*#@?'<;<?5
)4D.,B![5/!:633.;,9B!
K/+,499.@!5/!,=.!:96+.@!
[6+5,56/C!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
8!
Do!not!use!the!BREAK-SAFE®!if!the!clear!body!of!the!tool!exhibits!cracking!
(cracks!larger!than!¼”!length).!!Cracks!larger!than!¼”!are!an!indicator!that!
the!tool!was!either!dropped!or!was!cleaned!/!exposed!to!solvents.!!The!
BREAK-SAFE®!should!only!be!cleaned!with!soap!and!water.!!Also!any!thread!
lock!material!utilized!on!the!tool!must!be!dry!and!solventless.!!Contact!Utility!
Solutions!for!a!list!of!approved!thread!lock!materials.!!
WARNING#
!#
!#
•Do!not!use!the!BREAK-SAFE®!if!the!internal!yellow!tube!exhibits!signs!
of!a!flashover.!!Internal!flashover!can!be!attributed!to!the!following!
situations:!!!
•The!tool!was!used!in!the!rain.!
•The!tool!was!used!to!open!capacitor!banks.!
•The!tool!was!not!reset!properly!prior!to!performing!a!loadbreak!
operation.!
•The!tool!had!accumulated!soot!/!debris!from!prior!loadbreak!
operations!that!deteriorated!the!overall!dielectric!strength!of!the!tool.!!!
!
The#yellow#tube#needs#to#be#cleaned#on#a#routine#basis#to#prevent#
the#buildup#of#loadbreak#deposits.##
WARNING#
!#
!#
Do!not!use!the!BREAK-SAFE®!if!the!tool!exhibits!pitting!and!or!charring!
around!the!external!brass!contacts.!!Pitting!and!or!charring!are!the!result!of!a!
tool!that!was!not!properly!reset!prior!to!performing!a!loadbreak!operation.!
WARNING#
!#
!#
##
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#
#

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
9!
!#
When!working!with!the!BREAK-SAFE®!always!assume!the!tool!is!energized!at!
all!times.!!Never!consider!the!tool!body!as!rated!insulation.!!
!
!
WARNING#
!#
!#
!#
When!working!with!the!BREAK-SAFE®!always!assume!the!tool!is!energized!at!
all!times.!!Never!consider!the!tool!body!as!rated!insulation.!!
!
!
WARNING#
!#
!#
BREAK-SAFE®#LINE#AND#TOOL#PREPARATION#
!
BREAK-SAFE®#FIELD#INSPECTION#PROCEDURE#(PRIOR#TO#OPERATION)#
Reference!the!accompanying!laminated!BREAK-SAFE®!Inspection!Procedure.!
#
1. Do!not!exceed!the!rated!voltage!of!the!tool!(TABLE!1).!!!
!
2. Do!not!exceed!the!rated!amperage!of!the!tool!(TABLE!1).!!!
! !!
3. Insulate!the!pole!and!conductor!as!required!by!the!supervising!utility!safety!
practices.!
!
4. Clean!the!conductor!at!each!location!where!the!BREAK-SAFE®!jumper!clamp!
system!will!be!attached.!
!
5. If!the!BREAK-SAFE®!is!equipped!with!a!duckbill!head!(USBS-**-2-PS)!ensure!
that!all!attachment!fasteners!are!tight!and!secure.!
!
!
!
BREAK-SAFE®#OPERATIONAL#INSTRUCTIONS#
The!following!procedures,!as!described,!are!intended!to!overview!a!typical!circuit!
bypass!application!and!circuit!re-energizing!application!using!the!BREAK-SAFE®!
Portable!Switch.!!Always!follow!supervising!utility!installation!and!use!procedures!
for!the!BREAK-SAFE®!jumper!clamp!system.!!!
!
CIRCUIT#BREAK#APPLICATION#
1. Prior!to!securing!the!BREAK-SAFE®!to!the!line,!pull!the!Loadbreak!Ring!on!
the!BREAK-SAFE®!Black!Pull!Strap!until!the!tool!locks!in!the!open!tool!
position!(the!internal!yellow!tube!is!visible).!!!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
10!
2. Insert!the!Safety!Locking!Pin!into!the!hole!labeled!“LOCK!OPEN”!and!verify!
the!Safety!Locking!Pin!secures!the!tool!in!the!fully!open!position.!!!
!
The!Safety!Locking!Pin!secures!the!tool!in!the!open!position!and!prevents!an!
accidental!load!pickup!operation.!!
!
If!the!Safety!Locking!Pin!cannot!be!inserted!into!the!“LOCK!OPEN”!hole!it!
alerts!the!operator!the!tool!has!not!been!fully!extended!in!the!open!position.!!
If!necessary!pull!down!on!the!Black!Pull!Strap!Assembly!with!enough!force!so!
the!Safety!Locking!Pin!fully!seats!in!a!smooth!and!easy!manner.!!!!!!
!
3. Verify!the!BREAK-SAFE®!is!in!the!open!position!with!the!Safety!Locking!Pin!
securely!fastened!to!prevent!accidental!tool!operation.!
!
4. Securely!attach!the!BREAK-SAFE®!jumper!head!to!the!“SOURCE!SIDE”!or!
“LINE!POWER!SIDE“!(FIGURE!1)!using!standard!utility!safety!practices!and!
procedures.!!!
!
Attaching!the!BREAK-SAFE®!to!the!“SOURCE!SIDE”!or!“LINE!POWER!SIDE”!
ensures!that!after!the!loadbreak!operation!has!been!preformed!in!STEP!(12)!
the!jumper!cable!is!entirely!de-energized.!!!
!
5. Securely!attach!one!end!of!a!jumper!cable!to!the!“LOAD!SIDE”!of!the!circuit!
(FIGURE!1)!using!standard!utility!safety!practices!and!procedures.!
!
6. Securely!attach!the!opposite!end!of!a!jumper!cable!to!the!Conductor!Bar!
located!at!the!base!of!the!BREAK-SAFE®.!!Do!not!allow!the!jumper!cable!to!
pull!sideways!on!the!BREAK-SAFE®.!!The!jumper!cable!should!have!enough!
slack!to!hang!straight!down.!
!
7. Prior!to!performing!the!load!pickup!operation!remove!the!Safety!Locking!Pin!
from!the!“LOCK!OPEN”!position.!!!!
!
8. To!pickup!load,!exert!a!steady!downward!movement!on!the!Load!Pickup!
Trigger!using!an!insulated!hotstick.!!The!Black!Pull!Strap!Assembly!should!
retract!forcefully!into!the!Clear!Tube!Assembly.!!!
!
When!load!pickup!has!been!properly!performed!the!yellow!indicator!band!
(either!yellow!paint!or!yellow!tape!on!older!models)!on!the!Black!Pull!Strap!
Assembly!should!not!be!visible.!!!
!
If!the!yellow!indicator!band!is!visible!on!the!Black!Pull!Strap!Assembly!the!
tool!has!not!properly!closed!and!the!operator!should!push!the!Loadbreak!
Ring!upward!until!the!yellow!indicator!band!is!no!longer!visible!to!ensure!the!
tool!has!fully!reset.!!!!!!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
11!
The!BREAK-SAFE®!when!in!the!“OPEN!POSITION”!does!not!constitute!being!
rated!insulation!nor!does!it!provide!a!visible!gap.!!This!is!why!the!use!of!the!
Utility!Solutions!“Jumper-T”!(USJT-001)!or!equivalent!as!a!parking!stand!is!
suggested.!!
!
!
WARNING#
!#
!#
9. Insert!the!Safety!Locking!Pin!into!the!hole!labeled!“LOCK!CLOSED”!and!verify!
the!Safety!Locking!Pin!secures!the!tool!in!the!fully!closed!position.!!The!Safety!
Locking!Pin!secures!the!tool!in!the!closed!position!and!prevents!an!accidental!
loadbreak!operation.!!!!!!
!!
10. Following!standard!safety!practices!and!procedures!the!permanent!circuit!
can!now!be!cut!and!both!ends!isolated!and!insulated.!!
!
11. Prior!to!performing!the!loadbreak!operation!remove!the!Safety!Locking!Pin!
from!the!“LOCK!CLOSED”!position.!!!
!
12. With!one!steady!motion,!pull!down!firmly!on!the!Load!Break!Ring!using!an!
approved!insulated!hot!stick!until!the!tool!locks!in!the!open!position.!Do!not!
stop!or!hesitate!while!pulling.!!
!
13. Insert!the!Safety!Locking!Pin!into!the!hole!labeled!“LOCK!OPEN”!and!verify!
the!Safety!Locking!Pin!secures!the!tool!in!the!fully!open!position.!!!
!
The!Safety!Locking!Pin!secures!the!tool!in!the!open!position!and!prevents!an!
accidental!load!pickup!operation.!!
!
If!the!Safety!Locking!Pin!cannot!be!inserted!into!the!“LOCK!OPEN”!hole!it!
alerts!the!operator!the!tool!has!not!been!fully!extended!in!the!open!position.!!
If!necessary!pull!down!on!the!Black!Pull!Strap!Assembly!with!enough!force!so!
the!Safety!Locking!Pin!fully!seats!in!a!smooth!and!easy!manner.!!!!!!
!
14. Verify!there!is!NO!VOLTAGE!AND/OR!NO!AMPERAGE!present!on!the!“LOAD!
SIDE”!prior!to!removing!the!jumper!cable!end!attached!to!the!“LOAD!SIDE”!
line.!!!
!
15. Place!the!unattached!“LOAD!SIDE”!jumper!cable!end!on!an!insulated!Utility!
Solutions!“Jumper-T”!(USJT-001)!or!equivalent!device!(FIGURE!2).!!This!
separation!constitutes!a!visible!gap!for!safety.!
!
!
!
!
!
! !
! ! !
!
!
!
16. Following!standard!safety!practices!and!procedures,!work!can!be!performed!
on!the!de-energized!line.!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
12!
!
!
CIRCUIT#MAKE#APPLICATION#
1. Prior!to!securing!the!BREAK-SAFE®!to!the!line,!pull!the!Loadbreak!Ring!on!
the!BREAK-SAFE®!Black!Pull!Strap!until!the!tool!locks!in!the!open!tool!
position!!(the!internal!yellow!tube!is!visible).!!!
!
2. Insert!the!Safety!Locking!Pin!completely!through!the!hole!labeled!“LOCK!
OPEN”!and!verify!the!safety!pin!secures!the!tool!in!the!fully!open!position.!!
!
The!Safety!Locking!Pin!secures!the!tool!in!the!open!position!and!prevents!an!
accidental!load!pickup!operation.!!
!
If!the!Safety!Locking!Pin!cannot!be!inserted!into!the!“LOCK!OPEN”!hole!it!
alerts!the!operator!the!tool!has!not!been!fully!extended!in!the!open!position.!!
If!necessary!pull!down!on!the!Black!Pull!Strap!Assembly!with!enough!force!so!
the!Safety!Locking!Pin!fully!seats!in!a!smooth!and!easy!manner.!!!!!!
!
3. Verify!the!BREAK-SAFE®!is!in!the!open!position!with!the!Safety!Locking!Pin!
securely!fastened!to!prevent!accidental!tool!operation.!
!
4. Securely!attach!the!BREAK-SAFE®!jumper!head!to!the!“SOURCE!SIDE”!or!
“LINE!POWER!SIDE“!(FIGURE!1)!using!standard!utility!safety!practices!and!
procedures.!!!
!
Attaching!the!BREAK-SAFE®!to!the!“SOURCE!SIDE”!or!“LINE!POWER!SIDE”!
ensures!that!after!the!loadbreak!operation!has!been!preformed!in!STEP!(13)!
the!jumper!cable!is!entirely!de-energized.!!!
!
5. Securely!attach!the!first!end!of!a!jumper!cable!to!the!non-energized!“LOAD!
SIDE”!of!the!circuit!!(FIGURE!2)!using!standard!utility!safety!practices!and!
procedures.!
!
6. Securely!attach!the!opposite!end!of!a!jumper!cable!to!the!Conductor!Bar!
located!at!the!base!of!the!BREAK-SAFE®.!!Do!not!allow!the!jumper!cable!to!
pull!sideways!on!the!BREAK-SAFE®.!!The!jumper!cable!should!have!enough!
slack!to!hang!straight!down.!
!
7. Prior!to!performing!the!load!pickup!operation!remove!the!Safety!Locking!Pin!
from!the!“LOCK!OPEN”!position.!!!
!
8. To!pickup!load!exert!a!steady!downward!movement!on!the!Load!Pickup!
Trigger!using!an!insulated!hotstick.!!The!Black!Pull!Strap!Assembly!should!
retract!forcefully!into!the!Clear!Tube!Assembly.!!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
13!
When!load!pickup!has!been!properly!performed!the!yellow!indicator!band!
(either!yellow!paint!or!yellow!tape!on!older!models)!on!the!Black!Pull!Strap!
Assembly!should!not!be!visible.!!!
!
If!the!yellow!indicator!band!is!visible!on!the!Black!Pull!Strap!Assembly!the!
tool!has!not!properly!closed!and!the!operator!should!push!the!Loadbreak!
Ring!upward!until!the!yellow!indicator!band!is!no!longer!visible!to!ensure!the!
tool!has!fully!reset.!
!
9. Insert!the!Safety!Locking!Pin!into!the!hole!labeled!“LOCK!OPEN”!and!verify!
the!Safety!Locking!Pin!secures!the!tool!in!the!fully!open!position.!!!
!
The!Safety!Locking!Pin!secures!the!tool!in!the!open!position!and!prevents!an!
accidental!load!pickup!operation.!!
!
10. Verify!VOLTAGE!AND!AMPERAGE!are!present!on!the!“LOAD!SIDE”.!
!!
11. Following!standard!safety!practices!and!procedures,!uncover!the!permanent!
jumpers!and!reconnect!or!create!permanent!connections!!
!
12. Prior!to!performing!the!loadbreak!operation!remove!the!Safety!Locking!Pin!
from!the!“LOCK!CLOSED”!position.!!!
!
13. With!one!steady!motion,!pull!down!firmly!on!the!Load!Break!Ring!using!an!
approved!insulated!hot!stick!until!the!tool!locks!in!the!open!position.!Do!not!
stop!or!hesitate!while!pulling.!!
!
14. Insert!the!Safety!Locking!Pin!into!the!hole!labeled!“LOCK!OPEN”!and!verify!
the!Safety!Locking!Pin!secures!the!tool!in!the!fully!open!position.!!!
!
The!Safety!Locking!Pin!secures!the!tool!in!the!open!position!and!prevents!an!
accidental!load!pickup!operation.!!
!
If!the!Safety!Locking!Pin!cannot!be!inserted!into!the!“LOCK!OPEN”!hole!it!
alerts!the!operator!the!tool!has!not!been!fully!extended!in!the!open!position.!!
If!necessary!pull!down!on!the!Black!Pull!Strap!Assembly!with!enough!force!so!
the!Safety!Locking!Pin!fully!seats!in!a!smooth!and!easy!manner.!!!!!!
!
15. Verify!there!is!NO!AMPERAGE!present!along!the!jumper!cable.!
!
16. Remove!the!jumper!cable!end!attached!to!the!“LOAD!SIDE”!line.!!!
!
17. Remove!the!jumper!cable!end!attached!to!the!BREAK-SAFE®.!
!
18. Remove!the!BREAK-SAFE®.!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
14!
FIGURE!1:!BREAK-SAFE®!Installation!Schematic!
!
“SOURCE“!
OR!
“LINE!POWER!SIDE”!
!
“LOAD!SIDE”!
!
USJT-001!
“Jumper-T”!
!
“SOURCE“!
OR!
“LINE!POWER!SIDE”!
!
“LOAD!SIDE”!
!
FIGURE!2:!USJT-001!Visible!Gap!/!Rated!Insulation!Configuration!for!
BREAK-SAFE®!
!
USJT-001!
“Jumper-T”!
!
!
!
!
!

!
B-00125!USBS!(1st!Gen)!Operation!Manual! !
15!
Resistance#Test
An!optional!Resistance!Test!may!be!performed!in!between!scheduled!maintenance.!
This!test!DOES!NOT!replace!scheduled!maintenance!or!extend!the!time!between!
scheduled!maintenance.!
!
This!test!is!performed!using!the!Utility!Solutions!USGT-600!Grounds!Tester!w/!
REACH!Technology!or!equivalent!device.!Refer!to!the!testers’!instruction!manual!for!
proper!set-up!procedures.!
!
1. The! BREAK-SAFE®! should! be! in! the! closed! position! and! RESET! with! the!
external!brass!contacts!fully!seated.!
2. Connect!the!BREAK-SAFE®!Conductor!Hook!to!a!Current!Output!Post!on!the!
Grounds!Tester.!Position!and!support!the!BREAK-SAFE®!so!the!weight!of!the!
tool!does!not!apply!sideways!force!on!the!Current!Output!post!(a!small!block!
of!wood!should!suffice).!
3. Connect! a! standard! Mechanical! Jumper! (minimum! 6! feet,! 1/0! AWG,! 300!
AMP)! to! the! other! Current! Output! Posts! of! the! Grounds! Tester! and! the!
conductor!bar!of!the!BREAK-SAFE®.!
4. Put!the!Grounds!Tester!in!REACH!mode.!
5. Turn!on!the!Grounds!Tester!and!adjust!the!Current!Control!Knob!to!energize!
to!300!AMPS.!
6. Using! the! red! and! black! Jumper! Leads! on! the! Grounds! Tester,! measure! the!
voltage!on!the!BREAK-SAFE®!between!the!lower!jaw!of!the!Conductor!Hook!
and!the!Parking!Stand.!!
7. Voltage!drop!should!not!exceed!0.220!volts.!If!the!voltage!displayed!exceeds!
0.220!volts!the!tool!should!be!removed!from!service.!Maintenance!should!be!
performed!by!the!factory!or!by!trained!and!certified!personnel.!
