Prebena SLIDER 4C-Z50 Quick start guide

170619 97544702_EN
Operating note for the telescopic arms
for device types:
Slider 4C-Z50, 4C-L50, 5C-Z75, 5C-Q67 oder 5C-L67:
ATTENTION! Separate the slider from the compressed air supply during
the following settings to avoid unintentional shots.
Pan telescopic arm:
Keep the red button on the locking pin (1) pushed and
pull back the black part. Now it is unlocked. While the
locking pin is pulled back you could choose the position
of the telescopic arm (positions Fig .3-5). Then release
the locking pin. Now it is locked when the red butten
juts out.
ATTENTION! The locking pin only locks properly in the
shown positions (Fig.3-5).
Set length:
Turn the tension lever (2) anticlockwise for two turns to
open it. Then you can adjust the length of the telescopic
arm as desired by pulling or pushing on the handle. To fix
the telescopic arm, tighten the tension lever (2) clockwise.
Fig. 1
Fig. 2
Positions:
Fig. 3
Fig. 4
Fig. 5
30°

010218 97521203 EN
Installation instruction for attaching the handle
to the devices: Slider 4C-Z50, 4C-L50, 5C-Z75 oder 5C-Q67:
Equipment:
A
1 pcs
handle, complete
E.T.: 98016803
B
4 pcs
screw M6x40
E.T.: 99307202
2. Opperating position:
Rotate the star handle fully clockwise.
Assembly-/Disassemblyposition:
Rotate the star handle fully
counterclockwise.
3. Pull out the locking bolt and
turn it 90 °. The locking bolt is
now unlocked. Insert the pipe
ends of the handle into both
holes of the handle unit. Then
turn the locking bolt 90 °
again. The locking bolt locks.
To remove the handle,
proceed in reverse order.
4. Pull the trigger up for a
distance controlled fire.
1. Unscrew the screws (Pos. 156 E.T.:
99303208) from the slider and replace
them with the supplied screws B. Fix the
handle unit with this screws. Make sure
that the wheels are positioned like on
the picture.
