UTTERN D70 User manual
D70 Owner’s Manual
Welcome
iii
Congratulaons on becoming a new owner of a Uern boat. This Owner’s Packet will provide important
informaon about the features of your boat and should be, at all mes, kept aboard your boat. Take me
to carefully review the informaon in this packet to really get to know your boat.
The Owner’s Packet will contain the following:
Model Specic Owner’s Manual
The model specic manual contains informaon vital to understanding the operaon of your
boat.
Original Equipment Manufacturer (OEM) Informaon
The OEM informaon contains manuals provided by the individual system manufacturers of
the equipment installed on your boat. These include items such as engine controls, electronics,
and stereos, just to name a few. The Owner’s Manual will oen refer to informaon provided
by the manufacturers of specic systems.
Please keep this manual in a secure place, and transfer to the new owner when you sell the cra.
Informaon and assistance is also available via our website, www.uern.com.
iv
Informaon in this publicaon is based upon the latest producon specicaons available at prinng.
Uern reserves the right to make changes at any me, without noce, in the colors, equipment,
specicaons, materials and prices of all models, or to disconnue models. Should changes in producon
models be made, Uern is not obligated to make similar changes or modicaons to models sold prior to
the date of such changes.
UTTERN A BRUNSWICK COMPANY
# INT 2231804
UTTERN D70
June 2016
Table of Contents
v
Introducon
1. Owner’s Manual ............................................ vi
2. Your Responsibilies ..................................... vi
3. Safety / Warning Labels................................. vi
4. Dealer Responsibilies ................................. vii
5. Cra Idencaon Number (CIN) ................ vii
6. Warranty Informaon .................................. vii
General Informaon
1. Basic Boat Dimensions & Specicaons......... 1
2. Vessel Stability................................................ 2
3. Load Capacity ................................................. 2
4. Passenger Locaons ....................................... 3
5. Design Categories........................................... 3
6. Safety Label Locaons .................................... 4
7. Deck Layout (standard equipment)................ 6
8. Deck Layout (oponal equipment)................. 7
9. Cockpit Storage .............................................. 8
10. Thru Hull Locaons......................................... 9
11. Interior Liner Layout..................................... 10
12. Dash Layout .................................................. 11
13. Navigaon Lights .......................................... 12
14. Engine ........................................................... 13
15. Trailering....................................................... 13
16. Strong Points ................................................ 14
System & Component Overview and Operaon
1. Fuel System ..................................................15
2. Fresh Water System (oponal).....................17
3. Black Water System......................................19
4. Grey Water System (oponal)......................21
5. Bilge Pumps ..................................................22
6. Fire Prevenon .............................................23
7. Carbon Monoxide Monitor...........................24
8. Stove & Heater (oponal) ............................26
9. Bow Anchor Windlass (oponal)..................27
10. Stern Anchor Windlass (oponal) ................28
11. Steering.........................................................29
12. Engine Controls ............................................ 31
13. Emergency Engine Shutdown Switch........... 32
14. Smartcra® Gauges...................................... 32
15. Trim Tabs (oponal)..................................... 32
16. Diesel Heat (oponal) .................................. 33
17. Stereo (oponal) .......................................... 34
18. Windshield Wipers....................................... 34
19. Reclining A Cockpit Seat (oponal) ........... 35
20. Cockpit Table................................................ 36
21. Sun Lounge (oponal).................................. 36
22. Ski Pole (oponal) ........................................ 37
23. Canvas .......................................................... 37
Electrical Systems
1. DC Electrical ................................................. 39
2. Baeries ....................................................... 39
3. Baery Boxes ............................................... 39
4. Baery Selector Switches ............................ 39
5. Fuses and Breakers ...................................... 40
6. Electrical Schemacs.................................... 41
Maintenance
1. Maintenance ................................................ 44
2. Hull & Deck Surfaces .................................... 44
3. Component Maintenance ............................ 45
Introducon
vi
DANGER—Immediate hazards which will result in severe
personal injury or death if the warning is ignored.
WARNING—Hazards or unsafe pracces which MAY result
in severe personal injury or death if the warning is ignored.
CAUTION—Hazards or unsafe pracces which could result
in minor injury, product or property damage if the warning
is ignored.
NOTICE—Informaon which is important to proper
operaon or maintenance, but is not hazard related.
1. Owner’s Manual
The material here and the rest of the Owner’s manual packet:
Gives you basic safety informaon
Describes the fundamentals of boat use
Describes the features of your boat
Describes the equipment on your boat
Contains service and maintenance informaon
You must learn to safely operate this boat as well as read, understand and use the informaon
contained in this package.
What this manual does not give you is a course in boang safety, or how to navigate, anchor or dock
your boat. Operang a power boat safely requires more skills, knowledge and awareness than is
necessary for a car or truck.
2. Your Responsibilies
For your safety, the safety of your passengers, other boaters and people in the water, you must take a
boang safety course and get instrucon in the safe and proper handling of your boat. Understand
and follow the “Rules of the Road” and learn how to navigate.
Do not forget that a boang license is mandatory in many countries for vessels above a certain engine
power. These regulaons can vary depending on the country or region that you are located in.
Finally, your boat must be registered with the proper navigaon authories. A Declaraon of
Conformity is part of the documents that you receive with the boat and it must be kept aboard with
other ocial documents at all mes. The Declaraon of Conformity is mandatory when registering
the boat.
3. Explanaon of Safety Labels
The most important aspect of boang is safety. Although every eort is made to address the
numerous issues regarding the safe usage of your boat, it is strongly recommended that you avail
yourself of the training and knowledge available through boang safety courses, etc.
Safety Precauons
Mounted at key locaons throughout your boat and duplicated in this manual are labels which advise
the owner/operator of imperave safety precauons to follow when operang or servicing
equipment. Learn to recognize the degree of precauon and understand the explanaons of safety
prior to reading this manual. These precauons are not all-inclusive. Always use common sense in the
operaon of your boat.
Do not remove or obstruct any safety label.
Replace any label which becomes illegible. Replacement safety labels can be obtained by
calling your dealer
Introducon
vii
4. Dealer Responsibilies
In addion to a pre-delivery check and service of the boat, your dealer is to provide:
A descripon and demonstraon of the safety systems, features, instruments and controls on
your boat
An orientaon in the general operaon of your boat
A review of all warranty informaon and how to obtain warranty service
The Owner Informaon Package
If you do not receive all of these materials, or have any quesons, contact your dealer.
5. Cra Idencaon Number (CIN)
The Cra Idencaon Number is located either on the starboard side of the transom, or on the a
starboard side of the hull under the gunwale if the boat has an oponal swim plaorm, and is your
boat’s most important idenfying factor. The CIN must be included in all correspondence related to
the vessel. Also of vital importance is the engine serial number(s) and part number(s) when ordering
parts for your engine.
6. Warranty
You will nd informaon regarding the Uern warranty following the introducon. A warranty
informaon card is also included in the owner informaon packet. If for some reason this informaon
is missing, contact your Uern dealer.
Registraon
Contact your dealer or the distributor in your country, or the Brunswick Marine in EMEA Center
closest to you.
Transfer of Warranty
Contact the distributor in your country, or the Brunswick Marine in EMEA Center closest to you.
CIN Locaons
Introducon
viii
The Uern Division of Brunswick Marine in EMEA (Uern) provides the following Limited Warranty to the original retail
owner of its Uern boat, if purchased from an authorized dealer and operated under normal, subject to remedies, exclusions,
and limitaons set out in this Limited Warranty.
Europe and Confederaon of Independent States
WHAT IS COVERED: Brunswick Marine in EMEA warrants its new products to be free of defects in material and workmanship
during the period described below.
DURATION OF COVERAGE: This Limited Warranty provides coverage for two (2) years from the date the product is rst sold
to a recreaonal use retail purchaser, or the date on which the product is rst put into service, whichever occurs rst.
Commercial users of these products receive warranty coverage of one (1) year from the date of rst retail sale, or one (1)
year from the date in which the product was rst put into service, whichever occurs rst.
Commercial use is dened as any work or employment related use of the product, or any use of the product which generates
income, for any part of the warranty period, even if the product is occasionally used for such purposes.
The repair or replacement of parts, or the performance of service under this warranty, does not extend the life of this
warranty beyond its original expiraon date. Unexpired warranty coverage can be transferred from one recreaonal use
customer to a subsequent recreaonal use customer upon proper registraon of the product. Unexpired warranty coverage
may be terminated for use or repossessed product; or product purchased at aucon, form a salvage yard, or from an
insurance company.
CONDITIONS THAT MUST BE MET IN ORDER TO OBTAIN WARRANTY COVERAGE: Warranty coverage is available to only to
retail customers that purchase from a Dealer authorized by Brunswick Marine in EMEA to distribute the product in the
country in which the sale occurred, and then only aer the Brunswick Marine in EMEA specied predelivery inspecon
process is completed and documented. Warranty coverage becomes available upon proper registraon of the product by the
authorized dealer. Roune maintenance outlined in the Operaon and Maintenance Manual must be mely performed in
order to maintain warranty coverage. Brunswick Marine in EMEA reserves the right to make future warranty coverage
conngent on proof of proper maintenance.
WHAT BRUNSWICK MARINE IN EMEA WILL DO: Brunswick Marine in EMEA’s sole and exclusive obligaon under this
warranty is limited to, at our opon, repairing a defecve part, replacing such part or parts with new or Brunswick Marine in
EMEA cered remanufactured parts, or refunding the purchase price of the Brunswick Marine in EMEA product. Brunswick
Marine in EMEA reserves the right to improve or modify products from me to me without assuming an obligaon to
modify products previously manufactured.
HOW TO OBTAIN WARRANTY COVERAGE: The customer must provide Brunswick Marine in EMEA with a reasonable
opportunity to repair, and reasonable access to the product for warranty service. Warranty claims shall be made by
delivering the product for inspecon to a Brunswick Marine in EMEA authorized dealer to service the product. If purchaser
cannot deliver the product to such a dealer, wrien noce must be given to Brunswick Marine in EMEA. We will then arrange
for the inspecon and any covered repair. Purchaser in that case shall pay for all related transportaon charges and/or travel
me. If the service provided is not covered by this warranty, purchaser shall pay for all related labor and material, and any
other expenses associated with that service. Purchaser shall not, unless requested by Brunswick Marine in EMEA, ship the
product or parts of the product directly to Brunswick Marine in EMEA. Proof of registered ownership must be presented to
the dealer at the me warranty service is requested in order to obtain coverage.
WHAT IS NOT COVERED: As expressly set out herein, all warranes provided by the manufacturers and distributors of
components, equipment, and parts (“Component Manufacturer”) on the boat are hereby assigned to the owner, to the
extent permied by the Component Manufacturer, as the owner’s sole and exclusive remedy with respect to such items. Any
assistance by Brunswick Marine in EMEA and/or its authorized dealers with regard to component warranes shall not
constute an adopon of the responsibilies of a component manufacturer with regard to its component warranes. This
Limited Warranty does not apply to any Uern which has been salvaged or declared a total loss or a construcve total loss for
any reasons not covered in this Limited Warranty. This Limited Warranty also does not apply to the following items:
1. Engines, drivetrains, controls, propellers, baeries, other equipment or accessories that carry their own
individual warranes, or equipment and accessories which are not installed by Uern
2. Window damage or breakage
About Your Limited Warranty
Introducon
ix
3. Rainwater leakage, including rainwater leakage through converble tops
4. Damage or deterioraon of cosmec surface nishes, including cracking, crazing, discoloraon, air voids, fading or
oxidaon of gel coat, wood nishers (varnishes, stains, and paints), fabrics, vinyls, plascs, trim tape, plated or
painted metal, stainless steel nishes, an-fouling boom paint, or zinc anodes
5. Any Uern which has been altered or modied from Brunswick Marine in EMEA factory specicaons
6. Any Uern inially sold at retail by a party other than an authorized Brunswick Marine in EMEA dealer
7. Any Uern which has been used for racing or military purposes, or which has been overpowered according to
Brunswick Marine in EMEA factory specicaons for such Uern
8. Any Uern used for Commercial Purposes. Commercial Purposes, as used herein, means a vessel with more than
50% usage for business or revenue-producing purposes.
9. Any failure or defect caused by an accident, product abuse or misuse, failure of the owner to use, maintain, or
store the Uern as specied in Brunswick Marine in EMEA owner’s manual(s), and any other failure to provide
reasonable care and maintenance.
10. Any transportaon, haul out, or other expenses incurred in returning the Uern to the selling dealer or to the
Brunswick Marine in EMEA factory for warranty service.
11. Any representaon or implicaon relang to speed, range, fuel consumpon or esmated performance
characteriscs.
12. Damage, shrinkage, or deterioraon of carpet, upholstery, and exterior canvas tops, enclosures, and weather
covers (including rainwater leakage)
13. Any failure or defect caused by an act of nature resulng in damage, cost, or expense
14. Any transportaon
15. Any failure or defect arising from a previous repair made by a non-authorized service provider
16. Any item exceeding the expressed coverage limits specied in any Brunswick Marine in EMEA Limited Warranty
17. Any defect or repair requiring redesign of the Uern, except pursuant to the recall provisions of the United States
Federal Boat Safety Act of 1971, or the recall laws of any other foreign jurisdicon.
SOLE REMEDY: The remedy of repair or replacement of parts that are found to be defecve in factory materials or
workmanship covered by the Limited Warranty shall constute the owner’s sole and exclusive remedy against Brunswick
Marine in EMEA for any claims whatsoever of economic loss resulng from product failure.
In keeping with environmental policies and pracces, Brunswick Marine in EMEA reserves the right to ulize recondioned,
refurbished, repaired or remanufactured products or parts in the warranty repair or replacement process. Such products and
parts will be comparable in funcon and performance to an original product or part and warranted for the remainder of the
original warranty period. In no event shall any repair or replacement under this Limited Warranty exceed the fair market value
of the product as of the date of the owner’s claim. Acceptance of any product retuned or any refund provided by Brunswick
Marine in EMEA shall not be deemed an admission that the product is defecve. Products that are replaced become the
property of Brunswick Marine in EMEA.
OTHER LIMITATIONS: Except as set forth herein or on any other wrien Limited Warranes by Brunswick Marine in EMEA,
there are no other warranes, expressed or implied provided by Brunswick Marine in EMEA, on this Uern. All other
warranes, expressed or implied are expressly excluded. Brunswick Marine in EMEA further disclaims any liability for
economic loss arising from claims of product failure, negligence, defecve design, manufacturing defect , failure to warn and/
or instruct, lack of seaworthiness, and any other theory of liability not expressly covered under the terms of this Limited
Warranty.
Any implied warranty of merchantability or tness for a parcular purpose is disclaimed. To the extent the implied warranty
cannot be disclaimed, it is limited to the shorter of one (1) year from the date of delivery to the rst retail owner or the
duraon of the respecve Limited Warranes stated herein. To the extent required by law and implied warranty of
merchantability is limited for the duraon of the respect Limited Warranes stated. To the extent allowed by law neither
Brunswick Marine in EMEA, not the selling dealer shall have any responsibility of the loss of use of the Uern, loss of me,
inconvenience, commercial loss or consequenal damages.
Some countries, states or regions do not allow limitaons on how long an implied warranty lasts, so the above limitaons may
not be applicable. Some countries, states or regions do not allow the exclusion or limitaons of incidental or consequenal
damages, so the above limitaons or exclusions may not be applicable. This warranty gives the owner specic legal rights, and
the owner may also have other rights, which vary country to country, state to state, or region to region.
Retail customers in the European Economic area (EEA) may have legal rights under the applicable naonal legislaon regarding
the sale of consumer goods which are not aected by this Limited Warranty. The retail customer’s legal rights under any
applicable naonal legislaon regarding the sale of consumer goods shall not be aected. Informaon on authorized EEA
dealers and EEA Privacy be obtained at www.uern.com.
Introducon
x
STATUTE OF LIMITATIONS: Any acon for rescission or revocaons against Brunswick Marine in EMEA shall be barred unless it
is commenced within one (1) year from the date of accrual of such cause of acon. This provision does not grant any consumer
a right of rescission or revocaon against Brunswick Marine in EMEA, where such does not otherwise exist under applicable
law. Some country, state, or region may not allow the applicable statute of limitaons for rescission or revocaon to be
reduced, so this provision may not apply to each retail owner.
OWNER’S OBLIGATIONS: Contact the selling Brunswick Marine in EMEA dealer to set up an appointment for warranty repairs.
All warranty work or repairs must be referred to the selling dealer for authorizaon as a condion precedent to Limited
Warranty coverage. Brunswick Marine in EMEA must receive wrien noce of any remaining warranty claims form the owner
prior to the expiraon of the owner’s Limited Warranty, and the owner must nofy Brunswick Marine in EMEA of any Uern
being repaired by an authorized Brunswick Marine in EMEA dealer which has been at the dealership for een (15) days, or of
any claimed defect which was not corrected aer one (1) repair aempt.
MODIFICATIONS & SEVERABILITY: The terms and condions contained herein, as well as those of any documents prepared in
conjuncon with the sale of this vessel may not be modied, altered, or waived by any acon, inacon, or representaons,
whether oral or in wring, except upon the expressed, wrien authority of a management level employee of Brunswick Marine
in EMEA. The invalidity or unenforceability of any one or more of the provisions herein shall not aect the validity and
enforceability of the other provisions.
Africa and Middle East
WHAT IS COVERED: Brunswick Marine in EMEA warrants its new products to be free of defects in material and workmanship
during the period described below.
DURATION OF COVERAGE: This Limited Warranty provides coverage for one (1) years from the date the product is rst sold to
a recreaonal use retail purchaser, or the date on which the product is rst put into service, whichever occurs rst.
Commercial users of these products receive warranty coverage of one (1) year from the date of rst retail sale, or one (1) year
from the date in which the product was rst put into service, whichever occurs rst.
Commercial use is dened as any work or employment related use of the product, or any use of the product which generates
income, for any part of the warranty period, even if the product is occasionally used for such purposes.
The repair or replacement of parts, or the performance of service under this warranty, does not extend the life of this warranty
beyond its original expiraon date. Unexpired warranty coverage can be transferred from one recreaonal use customer to a
subsequent recreaonal use customer upon proper registraon of the product. Unexpired warranty coverage may be
terminated for use or repossessed product; or product purchased at aucon, form a salvage yard, or from an insurance
company.
CONDITIONS THAT MUST BE MET IN ORDER TO OBTAIN WARRANTY COVERAGE: Warranty coverage is available to only to
retail customers that purchase from a Dealer authorized by Brunswick Marine in EMEA to distribute the product in the country
in which the sale occurred, and then only aer the Brunswick Marine in EMEA specied predelivery inspecon process is
completed and documented. Warranty coverage becomes available upon proper registraon of the product by the authorized
dealer. Roune maintenance outlined in the Operaon and Maintenance Manual must be mely performed in order to
maintain warranty coverage. Brunswick Marine in EMEA reserves the right to make future warranty coverage conngent on
proof of proper maintenance.
WHAT BRUNSWICK MARINE IN EMEA WILL DO: Brunswick Marine in EMEA’s sole and exclusive obligaon under this warranty
is limited to, at our opon, repairing a defecve part, replacing such part or parts with new or Brunswick Marine in EMEA
cered remanufactured parts, or refunding the purchase price of the Brunswick Marine in EMEA product. Brunswick Marine
in EMEA reserves the right to improve or modify products from me to me without assuming an obligaon to modify
products previously manufactured.
HOW TO OBTAIN WARRANTY COVERAGE: The customer must provide Brunswick Marine in EMEA with a reasonable
opportunity to repair, and reasonable access to the product for warranty service. Warranty claims shall be made by delivering
the product for inspecon to a Brunswick Marine in EMEA authorized dealer to service the product. If purchaser cannot
deliver the product to such a dealer, wrien noce must be given to Brunswick Marine in EMEA. We will then arrange for the
inspecon and any covered repair. Purchaser in that case shall pay for all related transportaon charges and/or travel me. If
the service provided is not covered by this warranty, purchaser shall pay for all related labor and material, and any other
expenses associated with that service. Purchaser shall not, unless requested by Brunswick Marine in EMEA, ship the product
or parts of the product directly to Brunswick Marine in EMEA. Proof of registered ownership must be presented to the dealer
at the me warranty service is requested in order to obtain coverage.
Introducon
xi
WHAT IS NOT COVERED: As expressly set out herein, all warranes provided by the manufacturers and distributors of
components, equipment, and parts (“Component Manufacturer”) on the boat are hereby assigned to the owner, to the extent
permied by the Component Manufacturer, as the owner’s sole and exclusive remedy with respect to such items. Any
assistance by Brunswick Marine in EMEA and/or its authorized dealers with regard to component warranes shall not
constute an adopon of the responsibilies of a component manufacturer with regard to its component warranes. This
Limited Warranty does not apply to any Uern which has been salvaged or declared a total loss or a construcve total loss for
any reasons not covered in this Limited Warranty. This Limited Warranty also does not apply to the following items:
1. Engines, drivetrains, controls, propellers, baeries, other equipment or accessories that carry their own individual
warranes, or equipment and accessories which are not installed by Uern
2. Window damage or breakage
3. Rainwater leakage, including rainwater leakage through converble tops
4. Damage or deterioraon of cosmec surface nishes, including cracking, crazing, discoloraon, air voids, fading or
oxidaon of gel coat, wood nishers (varnishes, stains, and paints), fabrics, vinyls, plascs, trim tape, plated or
painted metal, stainless steel nishes, an-fouling boom paint, or zinc anodes
5. Any Uern which has been altered or modied from Brunswick Marine in EMEA factory specicaons
6. Any Uern inially sold at retail by a party other than an authorized Brunswick Marine in EMEA dealer
7. Any Uern which has been used for racing or military purposes, or which has been overpowered according to
Brunswick Marine in EMEA factory specicaons for such Uern
8. Any Uern used for Commercial Purposes. Commercial Purposes, as used herein, means a vessel with more than
50% usage for business or revenue-producing purposes.
9. Any failure or defect caused by an accident, product abuse or misuse, failure of the owner to use, maintain, or
store the Uern as specied in Brunswick Marine in EMEA owner’s manual(s), and any other failure to provide
reasonable care and maintenance.
10. Any transportaon, haul out, or other expenses incurred in returning the Uern to the selling dealer or to the
Brunswick Marine in EMEA factory for warranty service.
11. Any representaon or implicaon relang to speed, range, fuel consumpon or esmated performance
characteriscs.
12. Damage, shrinkage, or deterioraon of carpet, upholstery, and exterior canvas tops, enclosures, and weather
covers (including rainwater leakage)
13. Any failure or defect caused by an act of nature resulng in damage, cost, or expense
14. Any transportaon
15. Any failure or defect arising from a previous repair made by a non-authorized service provider
16. Any item exceeding the expressed coverage limits specied in any Brunswick Marine in EMEA Limited Warranty
17. Any defect or repair requiring redesign of the Uern, except pursuant to the recall provisions of the United States
Federal Boat Safety Act of 1971, or the recall laws of any other foreign jurisdicon.
SOLE REMEDY: The remedy of repair or replacement of parts that are found to be defecve in factory materials or
workmanship covered by the Limited Warranty shall constute the owner’s sole and exclusive remedy against Brunswick
Marine in EMEA for any claims whatsoever of economic loss resulng from product failure.
In keeping with environmental policies and pracces, Brunswick Marine in EMEA reserves the right to ulize recondioned,
refurbished, repaired or remanufactured products or parts in the warranty repair or replacement process. Such products and
parts will be comparable in funcon and performance to an original product or part and warranted for the remainder of the
original warranty period. In no event shall any repair or replacement under this Limited Warranty exceed the fair market value
of the product as of the date of the owner’s claim. Acceptance of any product retuned or any refund provided by Brunswick
Marine in EMEA shall not be deemed an admission that the product is defecve. Products that are replaced become the
property of Brunswick Marine in EMEA.
OTHER LIMITATIONS: Except as set forth herein or on any other wrien Limited Warranes by Brunswick Marine in EMEA,
there are no other warranes, expressed or implied provided by Brunswick Marine in EMEA, on this Uern. All other
warranes, expressed or implied are expressly excluded. Brunswick Marine in EMEA further disclaims any liability for
economic loss arising from claims of product failure, negligence, defecve design, manufacturing defect , failure to warn and/
or instruct, lack of seaworthiness, and any other theory of liability not expressly covered under the terms of this Limited
Warranty.
Any implied warranty of merchantability or tness for a parcular purpose is disclaimed. To the extent the implied warranty
cannot be disclaimed, it is limited to the shorter of one (1) year from the date of delivery to the rst retail owner or the
duraon of the respecve Limited Warranes stated herein. To the extent required by law and implied warranty of
merchantability is limited for the duraon of the respect Limited Warranes stated. To the extent allowed by law neither
Brunswick Marine in EMEA, not the selling dealer shall have any responsibility of the loss of use of the Uern, loss of me,
inconvenience, commercial loss or consequenal damages.
Introducon
xii
Some countries, states or regions do not allow limitaons on how long an implied warranty lasts, so the above limitaons may
not be applicable. Some countries, states or regions do not allow the exclusion or limitaons of incidental or consequenal
damages, so the above limitaons or exclusions may not be applicable. This warranty gives the owner specic legal rights, and
the owner may also have other rights, which vary country to country, state to state, or region to region.
Retail customers in the European Economic area (EEA) may have legal rights under the applicable naonal legislaon regarding
the sale of consumer goods which are not aected by this Limited Warranty. The retail customer’s legal rights under any
applicable naonal legislaon regarding the sale of consumer goods shall not be aected. Informaon on authorized EEA
dealers and EEA Privacy be obtained at www.uern.com.
STATUTE OF LIMITATIONS: Any acon for rescission or revocaons against Brunswick Marine in EMEA shall be barred unless it
is commenced within one (1) year from the date of accrual of such cause of acon. This provision does not grant any consumer
a right of rescission or revocaon against Brunswick Marine in EMEA, where such does not otherwise exist under applicable
law. Some country, state, or region may not allow the applicable statute of limitaons for rescission or revocaon to be
reduced, so this provision may not apply to each retail owner.
OWNER’S OBLIGATIONS: Contact the selling Brunswick Marine in EMEA dealer to set up an appointment for warranty repairs.
All warranty work or repairs must be referred to the selling dealer for authorizaon as a condion precedent to Limited
Warranty coverage. Brunswick Marine in EMEA must receive wrien noce of any remaining warranty claims form the owner
prior to the expiraon of the owner’s Limited Warranty, and the owner must nofy Brunswick Marine in EMEA of any Uern
being repaired by an authorized Brunswick Marine in EMEA dealer which has been at the dealership for een (15) days, or of
any claimed defect which was not corrected aer one (1) repair aempt.
MODIFICATIONS & SEVERABILITY: The terms and condions contained herein, as well as those of any documents prepared in
conjuncon with the sale of this vessel may not be modied, altered, or waived by any acon, inacon, or representaons,
whether oral or in wring, except upon the expressed, wrien authority of a management level employee of Brunswick Marine
in EMEA. The invalidity or unenforceability of any one or more of the provisions herein shall not aect the validity and
enforceability of the other provisions.
Uern D70— General Informaon
1
1. Basic Boat Dimensions & Specicaons
LMAX
LH
BHBMAX
Manufacturer: Brunswick Marine in EMEA
Model: Uern D70
Design Category: C
TH
TMAX
Ha
LMAX OPTIONS
Length of Hull (LH):6.91m
Length Overall (LMAX): 6.99m
Length Overall (LMAX OPTION): 7.37m
Beam of Hull (BH): 2.49m
Beam Max (BMAX): 2.55m
Dra of Hull (TH): 0.55m
Dra Max (TMAX): 0.97m
Overall Height (Ha): 2.03m
Light Cra Mass (mLCC): 2155kg
Maximum Load (mMTL): 1043kg
Fully Loaded Mass (mLDM): 3198kg
Trailerable Mass (mT): 2429kg
Fuel Tank Capacity: 280L
Water Tank Capacity: 80L
Waste Tank Capacity: 27.8L
Grey Water Tank Capacity 80L
Uern D70 — General Informaon
2
2. Vessel Stability
The following maximum load has been used for assessing the stability and buoyancy comprising
Manufacturer’s maximum recommended load per ISO 14946 1043kg
Fuel, fresh water, other uids to maximum capacity of xed tanks 411kg
This assessment has been made assuming that
The boat in the empty cra condion has a mass of 1550kg
The boat in the light cra condion has a mass of 2155kg
The maximum recommended engine outboard mass is 294kg
All standard equipment is aboard.
Your boat was manufactured to specic stability and otaon standards for the capacity shown on the
cercaon plate. Maximum recommended load included the weight of all persons aboard, all
provisions and personal eects, cargo (if any) and all consumable liquids (water, fuel, etc). Any increase
from the recommended load capacies will put your boat in jeopardy of capsizing, swamping and/or
sinking. In addion, any changes to the masses aboard may signicantly aect the stability, trim, and
performance of the cra. Stability can be considerably aected by loose uids or weight within the
vessel. Keep the bilge area as dry as possible, and in rough weather or at planing speeds, keep all
openings, hatches, lockers, doorways, and windows closed to minimize ooding. Breaking waves are a
serious stability hazard. Finally, stability can be compromised when towing or liing heavy weights
using a davit or boom.
3. Load Capacity
The capacity plate, located near the helm, indicates the maximum weight and number of persons
your boat can handle under calm sea condions. Do not exceed the load capacies stated. A full
explanaon of this informaon can be found in the relevant secons of this manual.
The informaon present on the cercaon plate does not relieve the operator of responsibility. Use
common sense and sound judgment when placing equipment and/or passengers in your boat.
Uern D70 Capacity Plate
Do not exceed the maximum recommended number of
persons. Regardless of the number of persons on board,
the total weight of persons and equipment must never
exceed the maximum recommended load. Always use the
seats/seang spaces provided.
When loading the cra, never exceed the maximum
recommended load. Always load the cra carefully and
distribute loads appropriately to maintain design trim
(approximately level), and secure loose equipment when
underway. Avoid placing heavy weights high up.
Uern D70— General Informaon
3
When people are on the working deck area for anchoring, mooring, or in emergencies, they must be
holding on and be posioned as to prevent falling overboard.
5. Design Categories
There are four design categories of boats based upon their ability to withstand wind and water
condions:
Category A – Designed for winds that may exceed wind force 8 (Beaufort scale – 40 knots) and a
signicant wave height of 4m and above.
Category B -- Designed for winds that include up to wind force 8 (Beaufort scale – 40 knots) and
signicant wave height up to and including 4m.
Category C – Designed for winds that include up to a wind force 6 (Beaufort scale – 27 knots) and
a signicant wave height up to and including 2m.
Category D – Designed for winds that include up to a wind force 4 (Beaufort scale – 16 knots) and
a signicant wave height up to and including 0.3m, with occasional waves of 0.5m maximum
height.
Refer to your product capacity plate for the design category of your boat.
Gelcoat surfaces are slippery when wet. Use extreme
cauon when walking on wet surfaces.
Never occupy the working decks while the boat is
underway.
Be aware of your foong while the boat is underway.
Slipping or falling could result in serious injury or death,
especially if the boat is in moon or in rough seas. Keep the
accommodaon clean, so if movement is necessary, it will
be free of obstrucon.
Do not aempt to boat in severe weather condions.
Death or serious injury can occur. Get to shore before the
weather turns bad.
Area to be used during normal operaon
Area to be used during anchoring, mooring and emergency operaon
4. Passenger Locaons
Uern D70 — General Informaon
4
6. Safety Label Locaons — Cockpit & Exterior
Uern D70— General Informaon
5
6. Safety Label Locaons — Interior
6. Safety Label Locaons — Helm
Uern D70 — General Informaon
6
7. Deck Layout (Standard Boat)
Anchor locker hatch
Secure eye
Bow cleat (P&S)
Navigaon lights (P&S)
Bow rail (P&S)
Foredeck window (P&S)
Windshield
Center windshield walkthrough door
Companionway door
Port console storage
Midship cleat (P&S)
Port reversible seat
Fuel tank access hatch
A cockpit access hatch
A cockpit seat cushion (Port)
A cockpit seat cushion (A)
A cockpit seat backrest
Flag holder
A cleat (P&S)
Access plate
Port swim plaorm cover
Ladder cover
Fuel ll
Canvas hatch
All around light
Sunlounge ller cushion
Forward cockpit oor hatch
Starboard windshield wiper w/washer
Horn
Transom access hatch
Center motorwell access
Engine rigging tube
Waste pumpout deck plate
Transom ladder
Uern D70— General Informaon
7
Port swim plaorm extension
Starboard swim plaorm extension
Transom ladder
Ski pole
Transom shower
8. Deck Layout (Oponal Equipment)
7. Deck Layout (Standard Boat)
Teak table
Table leg
Table base
12V receptacle
Cup holder
12V cooler
Hand rail
Port windshield wiper w/washer
Stereo
Stern windlass
Stern windlass roller
Stern windlass anchor
Cockpit sink
Entertainment center
Stove/heater
Refrigerator
Uern D70 — General Informaon
8
9. Cockpit Storage
Anchor locker
Port forward seat storage
Port L-lounge seat storage
A L-lounge seat storage
Canvas storage
A cockpit oor storage
Forward cockpit oor storage Uern recommends that the lifera store in the cockpit
oor storage or cabin interior.
Do not store any equipment containing petrol (outboard
engines, portable petrol tanks, etc.) in the cockpit seat
storage. These compartments were not designed to store
petrol and do not have adequate venlaon.
Bow windlass w/pivot bow roller
Freshwater ll deck plate
Trim tabs (P&S)
Grey water pumpout deck plate
8. Deck Layout (Oponal Equipment)
Table of contents
