UVAIRx Ux 210 Series User manual

MadeintheUSAUVAIRx,Inc.
4833 Front Street Unit B-508
CastleRock,Colorado80104
303‐579‐4865
www.UVAIRx.com
Ux210&Ux520Series
ActivePhotocatalyticOxidation
(PCO)
In‐DuctTechnology
USER’SGUIDE
CAUTION:Readmanualcarefullyforproperproceduresandoperation.
IntendedtobeinstalledbyaprofessionalHVACtechnicianonly.

CONGRATULATIONS
onyourpurchaseofaUVAIRxUx210orUx510AirPurification
EnhancementSystem.TheUx210isdesignedtobeinstalledintoan
existingHVACsystemandusedasavirtuallymaintenancefree
enhancementtocurrentairpurificationtechnology.TheUx510is
designedtobehungfromtheceiling.
Pleasereadandfollowallserviceproceduresoutlinedinthis
manual.
RECORDS
PleaserecordthenameandphonenumberofyourDealer
Name:________________________________________________
Phone#:_______________________________________________
PleaserecordtheserialnumberofyourUVAIRxUx210orUx510
Serial#________________________________________________
1
FURTHERLIMITATIONSANDEXCLUSIONSAREASFOLLOWS
Anywarrantythatmaybeimpliedinconnectionwithyourpurchase
oruseoftheProduct,includinganywarrantyofmerchantabilityor
anywarrantyforFitnessForAParticularPurposeislimitedtothe
durationofthiswarranty.Somestatesdonotallowtheexclusionor
limitationofincidentalorconsequentialdamages,sotheabove
limitationorexclusionmaynotapplytoyou.
ThisWarrantygivesyouspecificlegalrightsandyoumayalsohave
otherrightswhichvaryfromstatetostate.
REGISTRATION
PleaseregisteryourProductwithin10daysofpurchasebyfilling
outandreturningtheenclosedwarrantyregistrationcard.
RegisteringyournewUVAIRxUx210entitlesyoutothemostup‐to‐
dateUVAIRxUx210warrantyandpromotionalinformation.

14
PRODUCTCONTENTS
INSTALLATIONHARDWARE
(8) Self‐TappingScrews
(4) BrassThumbNuts
REPLACEMENTPARTS
ThePCOCellistheonlyreplacementpartavailablefortheUVAIRx
210. Pleasecontactyourdistributorforyournewcellreplacements.
PCOCellPartNumber:CELL‐HV‐14‐03‐GT
3
CHANGINGTHEPCOCELL(continued)
4. ExchangetheOldPCOCells
withtheNewPCOCellsand
replacethe(4)Screwsthat
holdthemintoplace.
5. ReplacetheUnitCoverand
PCOCellsintheductand
securewiththe(4)Brass
ThumbNuts.
6. PlacetheUnitPowerCableback
intothereceptacleandrepower
yourunit.

12
LIMITEDWARRANTYINFORMATION
YourUVAIRxmodel(Product)iswarrantedtobefreefromall
defectsinmaterialandworkmanshipinnormalhouseholdusefora
periodof2Yearsfromdateofpurchase.Thewarrantyisgrantedto
onlytheoriginalpurchaser.Thewarrantyissubjecttothefollowing
provisions:
Anydamagesormalfunctionscausedbynegligence,abuseoruse
notinaccordancewiththeProductOwner’sManualarenot
coveredbythiswarranty.Likewise,anydefectsordamagescaused
byunauthorizedserviceortheuseofotherthanGenuineUVAIRx
Ux210orUx510Partsarenotcovered.
UVAIRxwill,atitsoption,repairorreplaceadefectiveProductor
part(s)fortheProductthatis/arecoveredbythiswarranty.Asa
matterofwarrantypolicy,UVAIRxwillnotrefundthecustomer’s
purchaseprice
.
OBTAININGWARRANTYSERVICE
Toobtainwarrantyserviceyoumustreturnthedefectiveproduct
alongwithproofofpurchasetotheUVAIRxAuthorizedService
Center.Allshippingcostssubmittedunderthiswarrantyshallbe
bornebypurchaser.UnlessthiswarrantythisWarrantyisexpressly
renewedorextendedbyUVAIRx,anyrepairedorreplacedpartof
theunitshallbewarrantedtotheoriginalpurchaseronlyforthe
lengthoftheoriginalwarranty.
Beforeanyproductissenttoservice,thecustomershouldcontact
theUVAIRxServiceCentertoobtainaReturnMerchandise
Authorization(RMA)Number.TheRMANumbershouldbeclearly
writtenontheboxbeforeshipping.
13
CONTENTS
ProductContents…………………………………………………………..3
InstallationHardware…………………………………………………….3
ReplacementParts…………………………………………………………3
AboutUVAIRxUx210andUx510………………………………….4
Specifications…………………………………………………………………4
RecommendedInstallationTools…………………………………..5
InstallationRequirements……………………………………………..6
Installation…………………………………………………………………….6
Maintenance/UVLampIndicator…………………………………10
ChangingthePCOCell…………………………………………………..11
LimitedWarrantyInformation……………………………………...13

2
CHANGINGTHEPCOCELL
WARNING:UVLightinoperation.Disconnecttheunitfrompowersupply
beforeservicing.Failuretofollowwarningsmayresultinsevereye
damage.
1. RemovetheUnitPowerCable
fromthereceptacleorensure
theunitisn’tpowered.
2. Removethe(4)BrassThumb
NutsfromtheUnitCoverand
removetheUnitCoverand
PCOCells.
3. Removethe(4)Screws
holdingthePCOCellsinplace
andremovethePCOCellsfromtheUnitCover.
11
ABOUTUVAIRxINDUCTTECHNOLOGY
UVAIRxmodelsaredesignedtoimproveindoorairqualityby
dealingwithpollutantsinaproactiveway.UVAIRxUx210isinstalled
intheductsystemandprovidesaggressiveionizedoxidizersthatare
distributedthroughoutthehomeoroffice.Theseoxidizersdestroy
pollutantswhichincludemold,bacteria,viruses,odorsandvolatile
organiccompounds(VOCs)attheirsourceintheairandon
surfaces.WhilethesePCOoxidizersareveryaggressivein
destroyingpollutants,theyareentirelysafeforhumanlivingspaces.
Familyand/oremployeeswillenjoyfresh,cleanairknowingthat
theyareprotectedfromtheharmfulgerms,bacteriaandother
pollutantsthatcancausediscomfortandillness.TheUx510works
thesamewaybutishungfromtheceiling.
MainFeatures
PCO(Photo‐CatalyticOxidationAttacksandDestroysVOCs,
Odors,Mold,BacteriaandViruses
SafeforHumansandAnimals
DistributesOxidationEvenlythroughouttheEnvironment
UsingDucts
KeepsDuctSystemsFreefromMoldandBacteria
AttacksPollutantsintheAirandonSurfaces
Applications
UVAIRxUx210isIdealforOffices,Schools,DayCareFacilities,
NursingHomes,Hospitals,VeterinaryClinicsandMuchMore!
SPECIFICATIONS

Model:Ux210,Ux510
Coverage:80,000CubicFeet;160,000CubicFeet
Electrical:38Watts,120‐277Volt,50/60Hz
Dimensions:11”Wx10”Hx17”D(includingmountingplate),
4.1lbs.
4
RECOMMENDEDINSTALLATIONTOOLS
A–3.5”HoleSawBit D–UtilityKnife
B–3/8”DrillBit E–TinSnips
C–Drill/PowerDriver F–PhillipsHeadScrewDriver
INSTALLATIONREQUIREMENTS
1. Unitshouldbeinstalleddownstreamoftheairhandlerin
theHVACsystem.
2. Theductworkaroundtheinstallationareashouldbeclean
anddrytoinsureproperadhesionofthegasketmaterials
andanytapeused.
3. Twocircularopenings,measuringapproximately3.5”
(8.89cm)each,willneedtobecutintotheexistingduct
worktoinstalltheunitproperly.
5
MAINTENANCE/UVLAMPINDICATOR
YourUVAIRxunitrequiresnoperiodicmaintenancebeyond
replacementofthePCOcellevery3years.
Note:Foroptimalperformance,we
recommendthereplaceofthePCOcellevery
3years,eveniftheUVlampappearstobe
operatingnormally.
TheUVlampoperationindicator
onthefaceoftheunitwillglow
whentheUVlampisinuse.Ifthe
indicatordoesnotglowandthe
unithaspower,thePCOCell
shouldbereplaced.
DISPOSALOFTHEPCOCELL.
PleasedonotthrowausedPCOCellinthe
garbage.ThespecialgermicidalUVXbulb
usedintheUx210andUx510containavery
smallamountofmercury.Contactyourlocal

WasteManagementCenterforproperdisposalprocedure.
10
ALTERNATIVECUTTINGMETHOD
1. UsingtheAdhesiveGasketPlate,
tracetheholelocationsontothe
duct.
2. Drillholesaroundtheoutside
edgesofthepreviouslymarked
holesbutinsidetheouterholesof
theAdhesiveGasketPlate.
3. UsetheTinSnipstocutoutthespace
aroundthemarkedholes.
9
ELECTRICALREQUIREMENTS
Tousethe120Vplug,besuretolocatetheunitwithin6ft.ofa
standard120Vgroundedoutlet.Longtermuseofanextensioncord
isnotrecommendedduetosafetyconsiderations.
HARDWAREREQUIREMENTS
PermanentwiringoftheunitintoyourHVAC
systemorinstallationsusinga220Vplug(not
included)shouldbedonebyalicensedHVAC
InstallerorElectricalContractoronly.
For110Vand220VApplications:Black=L1,
White=Neutral,Green=Ground
ForInternationalApplications:Brown=L1,
Blue=L2,Green/YellowStripe=Ground
Ux510INSTALLATION
1. HangtheUx510fromtheceilingusingchainorhangerthat
willsupport39pounds.Useholesinbaseofunitfor
hanging.
2. Electricalrequirementsare:120VAC,60Hzor220VAC,50
Hz
3. Airflowis262cfm.

6
Ux210INSTALLATION
1. Findasuitablelocationtomount
yourInductUnit
2. Ifnecessary,cutawayinsulation
foryourplatetoadheretothe
duct.
3. UsingtheAdhesiveGasketPlate,
tracetheholelocationsonthe
duct.
4. UsetheHoleSawandDrilltocutoutthemarkedholes.
7
Ux210INSTALLATION(continued)
4. Removetheplasticbackingon
yourAdhesiveGasketPlate.
5. PresstheAdhesiveGasketPlate
ontotheduct.Securewiththe(8)
Self‐Tappingscrews.
Note:ForFiberglassducts,securetheGasketPlateusing
theToggleBoltAnchors(notsupplied)insteadofSelf‐
TappingScrews
6. PlacetheUnitandCellsthroughthe
openingsandsecurewiththe(4)
BrassThumbNuts.
7. PlugtheUnitPowerCableintothe
receptacleofhaveaLicensed
ElectricianorHVACInstallerto

hardwiretheUnitdirectlyintotheHVACsystem.
8
