V-Chip Microsystems VT-CC1110-433M User manual

VT-CC1110-433M Wireless Module
User Guide
V-Chip Microsystems, Inc
Add：6 floor, Longtang Building, Nan Shan Cloud Valley Innovation Industrial
Park, No.1183, Liuxian Road, Nanshan District, Shenzhen city
Tel：[phone]
Fax：[phone]
E-mail：[email protected]
ZIP：518055
Web：www.digiRF.com

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
General Description
VT-CC1110-433M is based on RF Transceiver CC1110 of TI Chipcon，it’s a small size and ultra low power UHF
wireless module. combines the excellent performance of the state-of-the-art RF transceiver CC1101 with an
industry-standard enhanced 8051 MCU. The circuit is mainly intended for the ISM (Industrial, Scientific and
Medical) and SRD (Short Range Device) frequency bands at 315, 433, 470,868 and 915 MHz, The MAX RF
output power can be set as high as +10dBm, with data rate as high as 500Kbps. The module integrated many RF
functions thus you can use it conveniently and reducing your development time.
Features
High performance and low power 8051 microcontroller core.
Programmable output power up to 10 dBm, and the communication
disstance up tp 200m.
Application in 433MHz transceiver, Frequency range :391~464MHz
Programmable baseband modulator with GFSK/2-FSK/ASK/OOK/MSK
Programmable data rate 1.2～500Kbps
Hardware support CSMA/CA function.
Battery detector and temperature sensor.
7 - 12 bitADC with up to eight inputs
Two USARTs , 16-bit timer with DSM mode, Three 8-bit timers
128-bit AES security coprocessor
Applications
Logistics Tracking System, Warehouse patrol, Electronic label.
Replace RS232 and RS485 in data transmission
Industrial monitoring and control in data acquisition
AMR –Automatic Meter Reading
Home and building automation
Consumer Electronics products of wireless control
Wireless alarm and security systems
Wireless sensor networks

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
General Characteristics
Test operating conditions：Ta=25°C，VCC=3.3V if nothing else stated.
Parameter
Type
Condition/Note
Operating supply voltage
DC2.0～3.6V
Central frequency
433MHz
Can be programmable to other frequency in
bands 391~464MHz
Frequency accuracy
±10KHz
Modulation format
GFSK/2-FSK/ASK/OOK/MSK
Programmable
Transmit power
-30～+10dBm
Programmable
Receiver sensitivity
-110dBm
2.4Kbps
TX current consumption
<35mA
Po=10dBm
RX current consumption
<22mA
Sleep State current consumption
0.5uA
Power Mode 3
Data rate
1.2～500Kbps
Programmable
Communication distance
>200m
2-FSK modulation, 2.4kBaud data rata,
+10dBm output power.
Flash
32KB
RAM
4KB
Operating temperature
-20～+85 °C
Storage temperature range
-50～+125°C
Antenna Impedance
50ohm
Dimension
24.0×25.9×2.4mm
See more in PCB description
Note：
1．The module transmission data rate will affect transmission distance and receiving sensitivity, the higher the data
rate , the closer the distance, and the lower the receiving sensitivity.
2．The supply voltage to the module will affect TX power, in the operating supply voltage range, the lower the
voltage, the lower the TX power.
3．The module central frequency will change as the operating temperature change, use it under suggest temperature,
the module can work well.
4．The antenna will strongly affect the communication distance, please select matched antenna and connect it
correctly.
5．The module mount will affect the communication distance.

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
PCB Description
Pin Configuration
Pin Name
Pin Type
Description
VCC
Power
DC 2.0-3.6V power supply connection
GND
Ground
RESET
DI
CC1110 RESET
P2_0
D I/O
CC1110 P2_0
P2_1
D I/O
CC1110 P2_1
P2_2
D I/O
CC1110 P2_2
P0_0
D I/O
CC1110 P0_0
P0_2
D I/O
CC1110 P0_2
P0_3
D I/O
CC1110 P0_3
P0_4
D I/O
CC1110 P0_4
P0_5
D I/O
CC1110 P0_5
P0_6
D I/O
CC1110 P0_6
P0_7
D I/O
CC1110 P0_7
P1_1
D I/O
CC1110 P1_1
P1_2
D I/O
CC1110 P1_2
P1_3
D I/O
CC1110 P1_3
P1_4
D I/O
CC1110 P1_4
P1_5
D I/O
CC1110 P1_5
P1_6
D I/O
CC1110 P1_6
P1_7
D I/O
CC1110 P1_7
ANT
RF I/O
Antenna Impedance 50ohm

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
Special character pin
1. EEPROM control pin(optional)
The module integrated 2~64KB EEPROM, the interface is I2C, and CC1110’s pin P2.1 and P2.2 are used as
EEPROM’s clock(SCL) pin and data(SDA) pin. These two pins are also debug pins, so the EEPROM doesn’t
support IAR.
If you purchase the module integrated EEPROM, we will provide the read/write code.
2. Simulation debugging interface(DEBUG)
CC1110 integrated 8051 microcontroller core support IAR, the debugging interface include clock pin
P2.2(DCLK) and data pin(DDA), you can connect these two pins to the simulator interface on the programming,
detail information refer to CC1110 datasheet.
3. Strong driver pins
CC1110’s port P1.0 and P1.1 can supply 20mA current to drive LED directly, detail information refer to CC1110
datasheet.
4. Status output pin
CC1110’s port P1.5, P1.6 and P1.7 are configurable pins that can output internal status information useful for
control software. More details refer to CC1110 datasheet.

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
Operation States
CC1110’s operation states contain: Sleep State, Idle State, Active State，Sleep State is the lowest power mode.
After wake up from Sleep State, the module get into Idle State. Except the Sleep State, each state can be switch by
SPI interface, also programmed to auto-switch. CC1110’s radio control state diagram is shown as below, for detail
information in the CC1110 datasheet.

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
Data Transmission
The CC1110 contains a 64 byte FIFO for data to be transmitted, built-in hardware support for packet oriented
radio protocols, e.g. Preamble bytes, Synchronization Word, Whitening the data, CRC checksum, Interleave and
Forward Error Code, Address checksum. The SPI interface is used for sending commend control and writing to
the TX FIFO.
The format of the data packet can be configured and consists of the following figure：
In addition, CC1110 supports fixed packet length protocols, variable packet length protocols and infinite packet
length. Details refer to the CC1110 datasheet.
Configuration Registers
The configuration of CC1110 can be done with software SmartRF Studio7. Complete descriptions of the registers
are given in the CC1110 datasheet. We can provide evaluation board and demo code to the customer to develop
and evaluate the module’s capability.
Dimension
24mm
1mm
1.6mm
R0.25mm
R0.35mm
R0.5mm
R0.35mm
ANT
1mm
12.65mm
19mm
25.9mm
0.9mm
12.75mm
24.5mm
1.67mm
1.27mm
P1_0
RESET
GND
GND
P1_5
P1_3
P1_4
P1_7
P1_6
P1_2
P0_2
P0_3 P0_4
P0_5
P1_1
P2_0
P2_1
P2_2
P0_0
ANT
VCC
VCC
P0_6
P0_7
0.9mm
0.75mm
21.55mm
5.6mm
2.54mm
R0.8mm
R0.425mm
R0.29mm
R0.6mm
1.6mm
6.68mm
1.6mm

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
Antenna
We can provide antenna match to the module. And if there is some special requirements to satisfy, we can
coordinate with you to select antenna, match antenna to the module in order to make the product work well.
Some recommend antennas as the table below.
Spring antenna（Standard）
Characteristic: small size, low cost, embedded
conveniently.
SMArubber antenna（Optional）
Characteristic: medium-scale, low cost, high gain
Magnetic MountAntenna（Optional）
Characteristic: high gain, Magnetic Mount ，
suitable for mount on iron box.
Note: Standard is for free, optional need another payment and the cost refer to the antenna price.

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
VT-CC1110-433M
Questions and Answers
Description
Reason and Solution
Can’t
communication
1．The power supply connect not well, check the module VCC whether it is out of maximum
rating.
2．The signal line connect not well, check the module SPI interface.
3．The settings of the transmitter module and receiver module are not the same. Check these
modules’ register configuration.
4．Signal block. If the transmitter work with a high TX power, and the receiver was put at a short
distance(<0.5m), maybe there is a signal block to make no communication.
Communication
distance is too
short
1．The application environment is too bad or the antenna is shield. Put the antenna to a better place
outside or higher throw a coaxial line , replace it with a higher gain antenna.
2．The work space contains a same frequency interference source, or a strong magnetic field
interference, power source disturbance. Try to change the carrier frequency or get far away from
the source of the disturbance.
3．The power supply is not strong. Check the voltage and the current whether it is enough.
High data error
1．The power supply ripple is too big, Change the power supply.
2．Check the module register configuration, it is recommended to set as the CC1110-datasheet.
3．There is a carrier frequency interference, change the channel.
4．The antenna unmatched to the module RF interface, change another matched antenna.
Development Package:
1. CC1110 datasheet（CC1110.pdf）
2. CC1110 register configuration tool（SmartRF Studio 7 v1.4.9.zip）
3. CC1110 demo code (CC1110 Demo Code.rar）
4. Hard ware tools（TI Chipcon Evaluation Board）
Note：
1．You can get the development package above from the salesman when you order the module.
2．As version update，please refer to our latest development materials.

COPYRIGHT @ 2012 Shenzhen V-CHIP MICROSYSTEMS Co. Ltd VERSION: VT-CC1110-APR-2012
