V-tech CS1500 User manual

CS1500
CS1501
CS1502
CS1503
CS1550
CS1551
CS1552
CS1553
Scan the QR code for
support information
Quick Start Guide
Specifications are subject to change without notice.
©2022 VTech Telecommunications Ltd.
All rights reserved. 05/22. CS150X_CS155X_UK_QSG_V1
Connect the base Install the battery Charge the battery
Technical Specifications
Frequency control Crystal controlled PLL synthesizer
Transmit frequency 1.88 GHz to 1.9GHz
Channels 10
Nominal effective
range
Actual operating range may vary according to
environment conditions at the time of use.
Power
requirement
Handset battery
1) Yi Yang Corun Battery Co.,Ltd.;
Ni-MH AAA400mAh 1.2V.
2) GPI International Ltd.;
VT40AAAHC.
Base/charger
Adapter:
VTPL: VT05EEU06045 (EU plug)
VTPL: VT05EUK06045 (UK plug)
Input 100-240V AC 50/60Hz 0.15A;
Output 6VDC 0.45A 2.7W
RF power <250mW
Important safety instructions
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink, swimming
pool).
5. Do not expose the telephone to direct sunlight or extreme cold environment. Do not put
the telephone close to heating sources such as radiators, cookers, etc.
6. Do not overload wall outlets and extension cords as this can result in the risk of fire or
electric shock.
7. Unplug this product from the wall outlet and refer servicing to VTech/distributor under
the following conditions:
- When the power supply cord or plug is damaged or frayed.
- If the product does not operate normally by following the operating instructions.
- If the product has been dropped and the cabinet has been damaged.
- If the product exhibits a distinct change in performance.
8. Avoid using a telephone (other than a cordless type) during an electrical storm. There may
be a remote risk of electric shock from lightning.
9. Do not use the telephone to report a gas leak in the vicinity of the leak.
10. Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation periods for
the handsets are only applicable with the default battery capacities.
11. The use of other battery types or non-rechargeable batteries/primary cells can be
dangerous. These may cause interference and/or unit damages. The manufacturer will not
be held liable for damage arising from such non-compliance.
12. Do not use third party charging bays. The batteries may be damaged.
13. Please note the correct polarity while inserting the batteries.
14. Battery should not be exposed to excessive heat such as bright sunshine or fire and
immersed in water.
15. Use only adaptors and battery listed below; Use only the provided external
power supply:VTech Telecommunications Limited. Model: VT05EEU06045 | VT05EUK06045.
Use only the supplied batteries: Yi Yang Corun Battery Co., Ltd. Model: Ni-MH AAA400mAh
1.2V; GPI International Ltd. Model: VT40AAAHC.
Disposal of Old Equipment and Batteries (WEEE)
Only for European Union and countries with recycling systems
These symbols (a, b) on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and batteries must
not be mixed with general household waste. For proper treatment, recovery and
recycling of old products and batteries, please take them to applicable collection
points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and
prevent any potential negative effects on human health and the environment.
For more information about collection and recycling, please contact your local municipality.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
Product disposal instructions for business users
If you wish to discard electrical and electronic equipment, please contact your dealer or
supplier for further information.
Information on Disposal in other countries outside the European Union
These symbols (a, b) are only valid in the European Union. If you wish to discard these items,
please contact your local authorities or dealer and ask for the correct method of disposal.
Note for the battery symbol
This symbol (b) might be used in combination with a chemical symbol. In this case it complies
with the requirement set by the Directive for the chemical involved.
Recycle your device (WEEE directive 2012/19/EU)
The WEEE logo appears on the product to indicate that this product must not be disposed
off or dumped with your other household wastes. You are liable to dispose of all your
electronic or electrical waste equipment by relocating over to the specified collection point
for recycling of such hazardous waste.
Approval and conformity
This product is intended for use within Europe and the UK. This equipment complies with the
essential requirements to EU’s Radio Equipment Directive (2014/53/EU) and the UK’s Radio
Regulations 2017 on radio systems and telecommunication equipment.
VTech Telecommunication Ltd. hereby declares that this telephone CS1500/1501/1502/1503
| CS1550/1551/1552/1553 is in compliance with the essential requirements and other relevant
provisions of EU’s Radio Equipment Directive (2014/53/EU) and the UK’s Radio Equipment
Regulations 2017.
The declaration of conformity may be viewed at https://www.vtech.com/rtte-directive.
The symbol confirms the conformity of the telephone and the above
directive.
Importer: VTech Electronics Europe Plc.
Napier Court, Abingdon Science Park, Abingdon, Oxon, OX14 3YT.
Manufacturer: VTech Telecommunications Ltd.
23/F, Tai Ping Industrial Centre, Block 1, 57 Ting Kok Road, Tai Po, Hong Kong.
Operating condition Power consumption
Off mode <1 W
Network standby mode <1 W
Customer Service and Product Warranty
IMPORTANT
Please retain this guide with your sales receipt as proof of the date of purchase.
Customer Service
Please call our Customer Services Department on 03306780149 (from the UK) or +44 3306
780149 (outside the UK) and a service representative will be happy to help you.
This warranty is valid for the UK and only. For products purchased outside
the UK and , please contact your local distributor or place of purchase.
PRODUCT WARRANTY
PRODUCT REGISTRATION
P
R
O
D
U
C
T
W
A
R
R
A
N
T
Y
ONE
YEAR Thank you for choosing this quality product from VTech.
The product detailed above is covered by a one year warranty from the date of purchase,
against any defects in materials or workmanship.
The product may be returned to the place of purchase. Alternatively the product can be
returned to VTech Electronics Europe (see address below), with proof of purchase,
without proof of purchase no replacement will be provided.
VTech Electronics Europe will examine the product and if it is found to be defective
due to faulty materials or workmanship, will replace the product at their discretion.
If the product covered by this warranty is damaged due to misuse, modification or
unauthori ed repair, or because of faulty batteries, battery discharge or incorrect
electrical connections, then this warranty becomes void.
This warranty is personal to the original purchaser and is not transferable.
Breakages to the LCD screen are not covered by the warranty.
To keep an online record of your warranty, please register your product online at
www.vtech.co.uk/
V ech Electronics E P , c/o XPO Logistics, Warehouse 350, Cat & Fiddle Lane,
West Hallam, DE7 6HE
THIS WARRANTY IS OFFERED AS AN EXTRA BENEFIT AND DOES NOT AFFECT
CONSUMERS’ STAT UTORY RIGHTS.
Visit www.vtech.co.uk/clubvtech/login
to register your VTech product
By joining the VTech Club you can also enter competitions, find
out about news and events, seek expert advice for parents and
let your kids play fun learning games and activities.
Products returned to VTech Electronics Europe Plc, should be sent to the address shown
below and packed carefully to avoid damage in transit. Please do not include batteries or
adaptors. Please include details of the fault together with your name and address,
contact phone number and/or email address.
a)
b)
a
b
c
a
bcCS1500
CS1501
CS1502
CS1503
CS1550
CS1551
CS1552
CS1553

Settings
Set language
gp/qgHS SETTINGS g
gp/qgLANGUAGE g
gp/qgEnglish | Deutsch | Français |
Italiano | Español | Nederlands g
Set date or time format
gp/qgHS SETTINGS g
gp/qgDATE & TIME g
gp/qgDATE FORMAT g
gp/qgDD-MM-YY / MM-DD-YY g
gp/qgTIME FORMAT g
gp/qg12 HR / 24 HR g
Set date & time
gp/qgHS SETTINGS g
gp/qgDATE & TIME g
gp/qgSET DATE g
gEnter the date g
gp/qgSET TIME g
gEnter the time g
Ringer - external calls
gp/qgHS SETTINGS g
gp/qgRING SETUP g
gp/qgEXT, RING g
gp/qto select melody g
Ringer - internal calls
gp/qgHS SETTINGS g
gp/qgRING SETUP g
gp/qgINT, RING g
gp/qto select melody g
Ringer - volume
gp/qgHS SETTINGS g
gp/qgRING SETUP g
gp/qgRING VOLUME g
gp/qto select volume g
Tone - set key tone on/off
gp/qgHS SETTINGS g
gp/qgTONE SETUP g
gp/qgKEY TONE g
gp/qgON / OFF g
Tone - set alert tones on/off
gp/qgHS SETTINGS g
gp/qgTONE SETUP g
gp/qgBATTERY TONE / OUT OF RANGE g
gp/qgON / OFF g
Alarm - set alarm time and activation
gp/qgHS SETTINGS g
gp/qgALARM g
gp/qgON g
gEnter alarm time in 24 hr format g
gDisplay SNOOZE g
gp/qgON / OFF g
Set the auto answer
gp/qgHS SETTINGS g
gp/qgAUTO ANSWER g
gp/qgON / OFF g
Phonebook
Store a number entry
gp/qgPHONEBOOK g
gALL CONTACTS gggADD
ggNAME ggenter name
ggNUMBER gg enter phone
number ggMELODY 1
gp/qto select melody g
Quick access keys
Call list Redial
list Phonebook Call
Blocker
Nuisance and Unwanted Call Blocker
Add a call block entry
gp/qgCALL BLOCKER g
gBLACK LIST gggADD
ggNAME ggenter name
ggNUMBER gg enter phone
number g
Block unknown calls
gp/qgCALL BLOCKER g
gp/qgSETTINGS g
gp/qgCALL TYPE g
gp/qgUNAVAILABLE g
gp/qgON / OFF g
Answering machine
(CS1550 series only)
Turn on or off with handset
gp/qgANS. MACHINE g
gp/qgTAM ON/OFF g
gp/qgON / OFF g
Play/stop, Delete, Repeat and Skip
message
To activate the handset controls during
message playback, press:-
gp/qgANS. MACHINE g
gp/qgMSG PLAYBACK g
Press these handset keys to control messages.
Stop Delete Repeat Skip
