V-tech Kidi Super Star Assembly Instructions

Parent's Guide
TM
91-003251-020 US
91-003251-020.indd 1 02/28/2018 19:19:21

2
INTRODUCTION
Thank you for purchasing the VTech®Kidi Super StarTM! Grab the
microphone and sing along to eight great songs. Once you’re ready,
reduce or remove the main vocal track and sing the songs by yourself.
The disco light spins 180 degrees for a superstar effect.
PRODUCT FEATURES
PRODUCT LAYOUT AND BUTTONS
Microphone
MP3 Player
Holder
Microphone Stand
91-003251-020.indd 2 02/28/2018 19:19:22

3
BUTTONS ON MAIN UNIT
On/Off Press this button to turn the unit On and Off.
Master Volume Dial This controls the master volume of the whole
unit, including the microphone volume. Turn
this dial to adjust the whole unit’s volume at
any time.
Microphone
Volume Dial
Adjust the microphone volume at any time by
turning this dial. If the master volume is turned
Off, the microphone output cannot be heard.
On/Off Button
Microphone
On/Off Switch
Master
Volume Dial
Instant Sound
Effects Button
Microphone
Volume Dial
Selection Dial
OK Button
Games &
Tools Button
Disco Light
Effect Button
Microphone
Effects Button
Instant Sound
Effects Buttons
Playback
Button
Music Magic
Button
Record Button
Talent Show
Button
Microphone-In
Jack
AC/DC Jack
Audio-In Jack
91-003251-020.indd 3 02/28/2018 19:19:22

4
Music Magic
Button
Music Magic mode is for sing-along use only.
It reduces or removes the main vocal track
from most songs. This allows you to perform
like a super star and sing along to the music
as the lead. Press the Music Magic Button
to toggle between Music Magic mode and
Normal mode.
Music Magic Mode:
Reduces or removes the main vocal track
from sing-along songs.
Normal Mode:
Normal music playback.
Note: Music Magic mode may not work for all
songs. Its effectiveness varies depending on
the song. For the best results, studio recorded
songs are recommended. Unfortunately we
cannot guarantee Music Magic mode will work
for every song. We do not recommend using
Music Magic mode with mono recordings or live
concert performances, etc.
Record Press to start or stop recording.
Note: Records up to a maximum of 5 minutes.
Playback Press to play or pause the recording.
Note: When recording, please do not remove
the batteries or unplug the power adapter or
the recording will be erased.
Disco Light
Effect
Changing Light Effects:
In Games & Tools mode, press this button to
switch the light On and Off.
In Talent Show mode, press this button to
toggle between different disco light effects:
• Disco • Peaceful
• Voice • Dreamy
• Starry • Party
• Preset • Light Off
91-003251-020.indd 4 02/28/2018 19:19:22

5
Brightness settings:
Hold down the Disco Light Effect Button
for approximately two seconds to enter the
Brightness Settings menu. From here, turn
the Selection Dial left or right to adjust the
brightness of the unit. Press the OK button to
save when nished.
Microphone
Effects
Press this button to switch between different
microphone effects when using the microphone:
• Squeaky • Deep
• Robot • Echo
• Normal
Instant Sound
Effects
There are four Instant Sound Effects Buttons
on this unit. Press any of these buttons to add
a sound effect over your performance:
• Intro Drum • Applause
• Laughter • Cheering
Games & Tools Press this button to enter Games & Tools
mode for different activities.
Talent Show Press this button to enter Talent Show mode
for Singing Fun, Free Play and External Music
Connection.
Selection Dial Turn the Selection Dial to make a selection.
OK Button Press this button to conrm your selection.
Microphone-In Jack Used to plug in your microphone.
Note: Please ensure a rm connection.
Audio-In Jack Used to plug in an MP3 player (not included)
using the included 3.5mm jack audio cable.
Note: Please ensure a rm connection on
both ends of the audio cable.
91-003251-020.indd 5 02/28/2018 19:19:23

6
AC/DC Jack Used to plug in a VTech®7.5V AC power
adapter (sold separately).
BUTTONS ON MICROPHONE
Microphone
On/Off
Use this switch to turn the microphone On or Off.
Slide the switch up (l) for On and down (O) for Off.
Note: To avoid picking up any unnecessary harsh
sounds from the microphone, place the microphone
away from the speaker and switch the microphone
Off whenever it is not in use.
Instant Sound
Effects
Press this button to add a sound effect over your
performance.
INCLUDED IN THIS PACKAGE
• One VTech®Kidi Super StarTM
• One microphone
• One 3.5mm jack audio cable
• One microphone stand
• One parent's guide
Note: Includes three poles to adjust height. Ensure the stand is
assembled using the correct number of poles for your child's height.
STAND PARTS:
x 1 x 1
x 1
x 2 x 3
x 1 x 3
WARNING:
All packing materials such as tape, plastic sheets, packaging
locks, removable tags, cable ties and packaging screws are not
part of this toy, and should be discarded for your child’s safety.
91-003251-020.indd 6 02/28/2018 19:19:23

7
ATTENTION
Pour la sécurité de votre enfant, débarrassez-vous de tous
les produits d’emballage tels que rubans adhésifs, feuilles de
plastique, attaches, étiquettes et vis d’emballage. Ils ne font pas
partie du jouet.
NOTE:
Please keep this parent's guide as it contains important information.
This product is only to be connected to equipment of Class II (marked on
the marking plate with a symbol ).
Turn the packaging lock
counterclockwise several times.
Pull out and discard the packaging lock.
Unlock the packaging lock:
STAND ASSEMBLY
Adult assembly required. For your child’s safety, do not let your
child play with this product until it is fully assembled.
For the best stability, we recommend positioning any foot of the stand
perpendicular to the back of the Kidi Super StarTM unit. Please refer to
the illustration on the next page:
1
Stand Assembly
5
32 4
6 7
91-003251-020.indd 7 02/28/2018 19:19:27

8
GETTING STARTED
BATTERY INSTALLATION
Kidi Super StarTM uses 4 AA (AM-3/LR6) batteries or a VTech®7.5V
adapter (sold separately).
• Make sure the unit is turned OFF.
• Locate the battery cover on the bottom of the unit.
• Remove the battery cover and install 4 AA batteries as illustrated.
• Close the battery cover.
BATTERY NOTICE
• Use new alkaline batteries for maximum performance.
• Use only batteries of the same or equivalent type as recommended.
• Do not mix different types of batteries: alkaline, standard (carbon-zinc)
or rechargeable (Ni-Cd, Ni-MH), or new and used batteries.
• Do not use damaged batteries.
• Insert batteries with the correct polarity.
• Do not short-circuit the battery terminals.
• Remove exhausted batteries from the toy.
• Remove batteries during long periods of non-use.
8
91-003251-020.indd 8 02/28/2018 19:19:29

9
• Do not dispose of batteries in re.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the toy before charging (if
removable).
• Rechargeable batteries are only to be charged under adult supervision.
POWER ADAPTER CONNECTION
• Make sure the unit is turned OFF and ensure no batteries remain
inside the unit.
• Locate the AC/DC Jack on the side of the unit.
• Connect the power adapter into the unit’s AC/DC Jack.
• Insert the other end of the power adapter into a plug socket.
• Turn the unit ON.
TRANSFORMER SAFETY NOTICE
• Using a VTech®adapter (AC/DC 7.5V 400mA) is recommended
but sold separately.
• This product should only be used with a transformer for toys.
• The transformer is not a toy.
• This product is not intended for use by children under the age of three.
• Do not connect this product to more than the recommended number
of power supplies.
• Never clean this product with liquid when it is plugged into a power
supply.
• Please regularly examine the transformer, checking for damage to the
cord, plug and other areas. Do not use the transformer if there is any
damage to it.
Note: If the unit stops working or the sound becomes weak, it may be
because of a fault with the power adapter connection.
Turn the unit OFF and unplug the adapter for 15 seconds. Then plug the
adapter back in and turn the unit ON. If the problem persists, the adapter
you are using may be faulty.
91-003251-020.indd 9 02/28/2018 19:19:29

10
TO BEGIN USING KIDI SUPER STARTM
GETTING STARTED
Follow the steps below to begin using Kidi Super StarTM,
1. Connect the microphone into the Microphone-In Jack on the side of
the unit.
2. Press the On/Off Button to turn on the unit.
Low Battery Icon
When the batteries are exhausted, the low battery icon will display
and the unit will automatically shut off. Please replace the batteries with
a full set of new batteries before further use.
If the product is frequently used, the batteries will drain at a faster rate.
We recommend using a power adapter (sold separately) if this product
is to be used frequently.
Automatic Shut Off
To preserve battery life, Kidi Super StarTM will automatically power off
if there is no operation for a period of time. You can change the Auto
Power Off time in External Music Connection mode. To do this, simply
enter External Music Connection mode and press the OK Button to
bring up the Auto Power Off menu, from here use the Selection Dial
to change the time. We recommend the use of a power adapter (sold
separately) whenever possible.
ACTIVITIES
Games & Tools
• Funky Monkey
• Beat Catcher
• Silly Beat, Silly Song
• Beat Boxer
• Play That Instrument
• Tongue Twisters
Talent Show • Singing Fun
• Free Play
• External Music Connection
91-003251-020.indd 10 02/28/2018 19:19:29
