V-TUF RUCKVAC User manual

®
CORDLESS BACKPACK VACUUM CLEANER
OPERATOR MANUAL
Please read this manual before using the RUCKVAC Cordless Vacuum Cleaner

IMPORTANT SAFETY INSTRUCTIONS
When using your Vacuum, basic safety precautions should always be observed,
Including the following:
You must read this manual before using this
product to reduce the risk of fire, electric shock, or
injury.
Failure to do so can result in serious injury or death.
1. Use only as described in this manual. Use only the recommended attachments,
battery, charger, and replacement parts.
2. DO NOT use the vacuum outdoors or on wet surfaces. DO NOT expose to rain or water.
3. DO NOT use or store vacuum in wet or moist conditions.
4. DO NOT try to recover any liquid with this vacuum. This vacuum is for DRY RECOVERY
only
5. DO NOT USE A DAMAGED VACUUM. If the unit is not working as it should be or
expected, or if it has been damaged,
left outdoors, or exposed to water, take it to an
Authorised V-TUF Repair Center for inspection and repair.
6. DO NOT allow the vacuum to be used as a toy. Pay close attention when using the
vacuum near children.
7. DO NOT handle the switch or battery pack with wet hands.
8. DO NOT put any objects into openings. Do not use with any opening blocked, keep free
of dust, lint, hair, and anything that may reduce air flow.
9. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
10. Use with extra care when cleaning on stairs.
11. DO NOT vacuum flammable or combustible materials or anything that is burning or
smoking, such as cigarettes, matches, or hot ashes.
12. Sparks inside the motor can ignite flammable vapors, to reduce the risk of fire or
explosion, do not use near combustible liquids, gases, or dusts, such as gasoline or
other fuels, lighter fluid, cleaners, oil-based paints, or natural gas.
13. To reduce the risk of inhaling toxic vapors or dust DO NOT vacuum or use near toxic
or hazardous materials.
14. DO NOT use without filter in place.
15. Disconnect battery pack before servicing vacuum.
3
VACUUM SAFETY

3
GETTING TO KNOW YOUR RUCKVAC
BATTERY POWER BACKPACK VACUUM
4

1. Main Unit 14. Dusting Brush
2. Exhaust Grill Port 15. Crevice Tool
3. On/Off Power Switch
16. Pet Hair Remover
4. Canister Lid Tabs 17. Exhaust Grill
5. Waist Band 18. Blower Port
6. Shoulder Straps 19. Combination floor
7. Back Board Panel 20. Paper Dust bag
8. Carry Handle 21. Waist Band Back Support Panel
9. Hose Inlet 22. Waist Bang Tool Carrier
10. Canister Lid 23. Cloth Dust Bag
11. Blower Attachment 24. HEPA Pre-Motor Filter
12. Flexible Hose 25. Exhaust Filter
13. Plastic Tube 26. Turbo Floor brush(optional)
5

6
IMPORTANT: Do not use the vacuum without the HEPA filter and
HEPA dust bag in place.
1. Close the power with switch and remove the flexible hose.
2. To open the canister lid press on the canister lid tabs on each side of the unit and lift
canister lid. (Fig.1)
3. Pull the tab on the HEPA dust bag holder out slightly and flip upwards.(Fig 2)
4. Holding the HEPA dust bag in your hand, slice it firmly between the slots in the bag
holder. (Fig 2)
5. The cardboard face of the new bag should rest securely in the dust bag cover
guide.(Fig 3)
6. Ensure that the shake-out bag is in place. (Fig. 4)
7. Flip the HEPA bag holder over, pressing the tab on the bag holder until it clicks then
replace the canister lid.
8. The canister lid can be replaced on the unit with the hose opening on the right or left,
as per your preference. (Fig 5)
OPERATING INSTRUCTIONS
ASSEMBLY

7
Attaching the Flexible hose to The vacuum
The flexible hose should be connected to the Vacuum before strapping the unit on.
1. To connect the flexible hose into the hose inlet, insert the threaded end of the flexible
hose into the hose inlet and turn counter-clockwise until it locks into place. (Fig 6)
2. Turn on the switch then you can operate the vacuum.

8
USING THE ATTACHMENTS
⚫Dusting Brush
The dusting brush is used for the furniture
⚫Crevice Tool
Use for radiators, crevices, corners, baseboards and between cushions. (Fig10)
⚫Pet Hair Remove Brush
The pet hair remove brush is used for upholstery. The unique surface makes it an
excellent tool for removing unwanted pet hair. (Fig11) Note: This tool is not a grooming
tool and should not be used on animals.
Caution: Do not use Pet Hair Remove Brush on delicate or woven Fabrics that may
snag. Do not use Pet Hair Remove Brush on wooden floors as this accessory might
cause mild scratching.

9
Air Driven Turbo brush (Optional)
The efficiency of your air driven turbo brush depends on the bristle brush rotating at high
speed. Strong air suction is needed to accomplish this. In order to ensure that maximum
air suction is maintained please read the following instructions:
1. Change the HEPA dust bag or empty the shake-out bag frequently.
2. Replace the pre-motor and exhaust filters as needed.
3. Ensure that the rotating brush is kept free of hair and string which may accumulate
and decrease brush performance.
4. To attach the air driven turbo brush, insert the telescopic tube into the air driven
turbo brush.
5. To adjust the suction control on the air driven turbo brush slide the suction control for
more
or less suction as desired the suction control.
Note: The driven turbo brush has a suction control on the top of the brush. Open or close
to increase or decrease the suction as desired, I, e, open for high pile or closed for low
pile carpets.

10

11

12
6. Replace the shake-out bag into the vacuum.
7. To replace the HEPA dust bag holder, flip the holder and press tab until it clicks.
8. Replace the canister lid onto the vacuum.
Warning: Never over fill the HEPA Dust bag – replace when bag is full and clean the
shake-out bag and filter each time the HEPA dust bag is replaced.
Cleaning & Replacing the Shake-Out Bag
Note:
Clean the shake-out bag out-doors when changing the HEPA
dust bag. Optimum
performance is achieved by using the HEPA dust bag with the shake-out bag decreasing
the need for washing the shake-out bag.
Cleaning the Shake-Out Bag Used with the HEPA Dust Bag:
1. Remove the shake-out bag, holding the handle at the bottom of the bag, shake out
doors vigorously over a garbage receptacle until there is no debris or dust remaining.
2. Inspect shake-out bag regularly for tears or damage. Replace shake out bags if
damage or tears are present.
Cleaning the Shake-Out Bag-
1. Remove the shake-out bag, empty trash can, and shake vigorously outdoors until there
is no more dust.
2. The shake-out bag is hand washable in lukewarm water.
3. Allow to air dry for 24 hours. The shake-out bag should be replaced when needed.
Never replace into the vacuum if still wet.
4. Replace clean shake-out bag in unit and replace the canister lid.

13
Using Your Vacuum
1. Ensure the battery pack is correctly assembled in the vacuum
2. Connect hose and telescopic tube if desired.
3. Correctly place shoulder straps on each shoulder and secure the waist band with hook
and loop strips. (Fig.16)
Caution: If the waist band and both shoulder straps are not properly and securely in
place the unit could fall off your back causing damage or injury.
4. Turn the unit on by pressing the switch located near the base of the unit to turn the
vacuum cleaner on. (Fig.17)
Removing & Replacing HEPA Dust Bag
To remove the HEPA dust bag from the vacuum:
Important: DO NOT use the vacuum without all filters, shake-out bag, and with or without
HEPA dust bag in place
1. To remove the HEPA dust bag, press on the canister lid tabs on each side of the unit
and lift canister lid. (Fig.18)
2. Pull the tab on the HEPA dust bag holder out slightly and lift upwards.(Fig.18)
3. Holding the HEPA dust bag in your hand, slide it out from the slots in the bag
holder and hold carefully in order to avoid dust falling out of HEPA dust bag. (Fig. 19)
4. Replace the HEPA dust bag with a new bag. Do not reuse the same vacuum bag.
5. The cardboard face of the new bag should rest securely in the dust bag cover
guides.

14
Cleaning the HEPA Pre-Motor Filter
Important, Please Note: The HEPA pre-motor filter will stop most of the microscopic dust
particulates and airborne allergens from re-entering the air you breathe. It has been tested
and certified up to 99.99% filtration efficiency of all particles as small as 0.3 microns- many
times smaller than a human hair! Because of this incredible filtration performance, the
HEPA pre-motor filter will accumulate many fine dust particles that are difficult to see. Be
assured that the HEPA pre-motor filter is doing the job. Clean the HEPA pre-motor filter
after each use as described in this section
1. Remove the shake-out bag from the canister. The HEPA pre-motor filter bag is located
underneath the shake-out bag. To remove the HEPA pre-contents into a motor filter, lift it
from the sides of the HEPA filter.
2. Vigorously ”TapClean” the HEPA pre-motor filter on a hard surface to remove any
residual dust that might still be on the HEPA pre-motor filter.
3. You can wash the HEPA pre-motor filter by running it under the tap and allowing the
water to run on the dirty side at least once a month or when suction appears to be
decreased.
HOW TO CHARGE THE BATTERY PACK
When using the charger, basic precautions should always be followed, including the
following:
Battery and Charging Safety
To reduce the risk of electric shock, fire, battery explosion, or injury:

15
Basic information and warning for V-TUF Battery and Charger are contained below. For
detailed usage and warning information, read the HOW TO CHARGE THE BATTERY
PACK carefully before using this unit.
1. Use only the V-TUF Charger and V-TUF Battery Pack.
2. DO NOT expose battery pack to temperatures above 122°F(50°C). Never leave
battery packs in automobiles on hot days, where temperatures can be much higher
than the outside temperature.
3. DO NOT use or store vacuum or batteries in wet or moist conditions, or with flammable
or combustible materials.
4. DO NOT charge batteries or store battery for extended periods, 1 month or more, in
temperatures above 90°F(32°C) or below 40°F(5°C).
5. When charging, make sure that the charger has at least 6 inches of clearance on all
sides. Adequate airflow is required to cool the charger when use.
6. Connect charging cord to a properly grounded outlet only. See Grounding Instructions.
7. DO NOT use a damaged cord or plug for charging.
8. DO NOT pull on charger’s cord to unplug. Grasp and pull the plug, not the cord.
9. DO NOT handle the charger’s cord plug with wet hands when inserting into electrical
outlet.
10. Keep sparks and flames away from batteries. Do not smoke near batteries or charger.
11. DO NOT
charge the unit outdoors.
12. DO NOT
attempt to repair, service, or modify the battery system or charger. Contact
the authorised V-TUF service agent or retailer with any issues.
13. DO NOT short-circuit the battery or charger terminals with conductive items such as
paper clips. This can deliver high current, resulting in heat and fire.
14. DO NOT crush, drop, incinerate or damage the battery pack. DO NOT use a battery
pack that has been damaged in any way. DO NOT incinerate the battery even if it is
severely damaged or non working. The battery can explode in a fire.

Improper connection of the equipment-grounding conductor can result in a risk of
electrical shock. Check with a Qualified electrician or service person if you are unsure
that the outlet is properly Grounded.
16
-
CHARGER GROUNDING INSTRUCTION
THE BATTERY CHARGER MUST BE GROUNGED. If the charger should malfunction or
stop working, grounding provides a path of least resistance for electrical current, thereby
reducing the risk of electrical shock. This unit is equipped with a cord that has an
equipment-grounding conductor and grounding plug. The plug must be inserted in an
appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances. Cutting of the ground wire or using a cord that is not equipped
with a ground wire will void the warranty on the unit, and V-TUF will accept NO liability
associated with the unit.

17
Charger Specification:
Charger input: 100-240V~ 50/60Hz
Charger output: 29.4V 2A
Battery Specification:
Lithium Polymer chemistry 25.2V
Approximate charge time: 4.0 hours
Approximate run time for new battery: 30 minutes.
1 2
3
1. Battery pack 2. Charger 3. charger’s cord
OPERATION
Charge in a well ventilated area. DO NOT block charger
vents. Keep them clear to allow proper ventilation.
CHARGING LITHIUM POLYMER BATTERY PACKS
Lithium Polymer batteries deliver fade-free power for their entire run time. The V-TUF
vacuum will not gradually lose power due to decreasing battery charge. The vacuum will
perform at its normal performance level until the battery has been depleted. Once this
SPECIFICATIONS AND PARTS

18
happens, recharging of the battery is required. It is not necessary to drain the battery pack
completely before recharging.
If the charger’s light is not lit at any point during the charging process, remove the battery
pack from the charger to avoid damaging the product. DO NOT insert another battery.
Contact the authorised V-TUF service agent with any issues.
BATTERY PROTECTION FEATURE
The 37-volt Lithium Polymer batteries are designed with features that protect the Lithium
Polymer cells and maximize battery life. When the battery has reached its minimum
voltage level the electronics will shut off the battery. Once the battery shuts off, it must be
recharged.
PREPARING BATTERY PACK FOR CHARGING
1. Plug the charger’s power cord into the charger (Fig 21)
2. Turn off the power switch. Confirm the switch is on the “O” position.
3. Unlock the battery pack by turning knob clockwise and take the battery pack out from
the vacuum.(Fig 22)
4. Plug the round connector on the charger’s cord into the battery pack. (Fig 23)
5. Plug the charger’s power cord into 120V wall outlet (Fig 24)
6. The indicator light will turn red when charging and turn Green when full charged. The
Battery pack may require approximately 2.5hours to full charge.
Note: Battery pack may get warm while charging.
indicate light
Fig 21

19
Fig 22
Fig 24
Fig 23

V-TUF.COM
®
