CONTENTS
1Safety............................................................................................................................................ 5
1.1 Safety precautions......................................................................................................................... 5
1.2 Note on repairs .............................................................................................................................. 5
2INSTALLATION ............................................................................................................................ 6
2.1 Installation data ............................................................................................................................. 6
2.2 Dimensions of niche and appliance ............................................................................................... 7
2.3 Replacing or converting integrable door....................................................................................... 10
2.4 Adjusting integrable door ............................................................................................................. 14
2.5 Replacing or converting appliance door that can be fitted with door panel ................................... 14
2.6 Adjusting door that can be fitted with door panel.......................................................................... 15
3APPLIANCE DESCRIPTION....................................................................................................... 16
3.1 Positioning door trays .................................................................................................................. 18
3.2 Positioning glass shelves............................................................................................................. 18
4OPERATION ............................................................................................................................... 19
4.1 Operating and display elements .................................................................................................. 19
4.2 Main ON / OFF button ................................................................................................................. 20
4.3 Setting the temperature ............................................................................................................... 20
4.4 Alarm functions............................................................................................................................ 21
4.5 Special functions ......................................................................................................................... 21
4.6 Switching special operating modes - test, demo and service - on and off .................................... 22
4.7 Demo operating mode ................................................................................................................. 23
4.8 Test operating mode.................................................................................................................... 23
4.9 Service operating mode............................................................................................................... 26
5FUNCTIONS................................................................................................................................ 29
5.1 Cooling system ............................................................................................................................ 29
5.2 Electronic control unit, contact assignment .................................................................................. 34
5.3 Wiring diagram ............................................................................................................................ 38
5.4 Defrosting .................................................................................................................................... 41
6ERROR DIAGNOSTICS .............................................................................................................. 42
6.1 Error messages ........................................................................................................................... 42
6.2 General trouble-shooting ............................................................................................................. 42
7REPAIRS .................................................................................................................................... 46
7.1 Checking illumination switch ........................................................................................................ 46
7.2 Replacing light ............................................................................................................................. 48
7.3 Replacing sensor......................................................................................................................... 49
7.4 Replacing PCB ............................................................................................................................ 51
7.5 Replacing door seal..................................................................................................................... 52
7.6 Replacing fan (EK1423-EA)......................................................................................................... 52
7.7 Replace salad crisper in cold storage compartment EK1423-EA. ................................................ 53
7.8 Cooling circuit.............................................................................................................................. 55
7.9 Evacuating the refrigerant............................................................................................................ 55
7.10 Connecting solenoid valve ........................................................................................................... 56
7.11 Replacing condenser ................................................................................................................... 56
7.12 Replacing desiccant cartridge...................................................................................................... 57
7.13 Replacing compressor ................................................................................................................. 57

V-ZUG AG
Industriestrasse 66, Postfach 59, 6301 Zug
Telefon [phone], Fax [phone]
[email protected], www.vzug.com
Service manual
1036497-00-AE
1
Serial production
created
27.09.2017 waa
modified
28.09.2017 User Agent
checked
28.09.2017 asan
5 / 61
Service manual Platform 2014-2016, V-ZUG KT
1036497-00_ae gedruckt
7.14 Replacing inverter........................................................................................................................ 59
8Technical data............................................................................................................................ 61
8.1 NTC sensor ................................................................................................................................. 61
1 Safety
1.1 Safety precautions
Always disconnect the refrigerator from the mains supply before
working on the electrical system!
Electrical safety (protection against accidental contact) must be ensured
through the installation of the appliance.
The appliance must be installed and connected to the electricity supply in accordance with the
separate installation instructions.
Repair work may only be carried out by customer service experts trained by the manufacturer.
Repairs if carried out incorrectly could pose a significant hazard and cause serious injury to the user.
If the appliance is defective, the housing or frame could be live.
Do not touch any of the components in the appliance. The modules are also under mains voltage.
Disconnect the power supply to the appliance: Pull out the mains plug or switch off the fuse.
1.2 Note on repairs
Perform repair work systematically in accordance with the technical documentation.
