V3 SOUND SONORITY XL User manual

TONE GENERATOR
sonority xl
midi implementation
sound list
rev.101
V3SOUND.COM

HPF High Pass Filter: Use the cutoff parameter to set the low frequency limit. When you do this,
the sound will naturally be brighter and thinner. A cutoff value over 64 usually needs to be
selected just so you notice the change.
120FX A variety of effects are stored on note 120.
Different samples are available in velocity zones in 24-step increments.
120FX ² A variety of effects are stored on note 120.
Different samples are available in velocity zones in 10-step increments.
(1) DRUM MAP - exclusive mode for percussion sounds - only one of these sounds can be
active.
velo. Velocity split
PROGRAM LIST SOLO SOUNDSPROGRAM LIST SOLO SOUNDS
PROGRAM LIST SOLO SOUNDS
PROGRAM LIST SOLO SOUNDSSAFETY PRECAUTIONS COPYRIGHT
SPECIFICATIONS
LEGEND
SAFETY INSTRUCTIONS
• Read the user manual before using the device
• Do not allow any liquid to come in contact
with the device
• Do not place anything on top of the device
• Do not handle the power supply with wet hands
• Turn off all connected devices before you
connect any new devices
Do not use or store the device where it is
exposed to:
• dampness or wetness
• extreme temperature changes
(i.e. do not store in a vehicle in winter)
• strong vibrations or jolts
HANDLING
• Use only the original cables and power supply
• Remove the cable only by pulling on the plug,
not on the cable
• Do not expose the power adapter to any
mechanical stress
CUSTOMER SERVICE
Do not carry out any repairs at home, as this may result
in permanent damage to the electronics. Any guarantee
claims are no longer valid in this case.
ACCESSORIES
Manual and power
POWER REQUIREMENT
9VDC / 1.0A
HUMIDITY
max. 80%, non-condensing
OPERATING TEMPERATURE
10 to 40 degrees Celsius

!


All the audio recordings V3SOUND uses on
the sound boards are protected by copyright.
V3SOUND alone has been given the right by all
musicians involved to use this material. Any duplica-
tion, editing or any other copy of individual sounds
by or given to a third party in any form (audio samp-
ling CD, data storage device with individual sounds,
download of any file, etc.) is strictly forbidden.
Copyright © 2018 V3SOUND - Austria
• Master Volume
• Master Reverb
• 4 GB flash memory
• 16 MIDI channels
• 4 audio out (2 stereo)
• Polyphony 256 voice
• Port available for 1 sustain foot pedal
• Dimensions: 12cm (L) x 12cm (W) x 6cm (H)
• Weight: 0,2kg
• USB Host
The CE certification is available at
http://www.v3sound.com/support/
V3SOUND GMBH
Kirchplatz 7 - 6114 Kolsass - Austria - Europe
This product conforms to the
FCC 47 CFR PART 15
SUBPART B
1

2
To avoid possible damage to the loud speakers
or other connected electronic devices, always
connect all cables before turn on the amplifier.
Turn on the V3 SONORITY first before turning on
any active loud speakers or amplifiers.
Make sure the POWER switch on the
back of the device is in the OFF position
(LED light is not on).
Plug the power adapter that came with the
device into the DC port on the back of the
unit.
 Plug the other end of the power adapter
into a power outlet. Make sure that the
adapter is compatible with the power supply.
Connect the audio outputs to an amplifier,
active loudspeakers or headphones.
Connect the MIDI or USB cable to the
V3 SONORITY.
Before you turn the device on or off, make sure that
all connected audio devices that amplify the audio
signal (mixer, amplifier, active loud speakers) have
their volumes turned down.
Press the POWER ON/OFF switch on the
back of the device.
Turn up the V3 unit MAIN VOLUME
knob to adjust the volume.
 Adjust the volume on your mixer or
active loudspeaker.
Turn the volume on the V3 SONIRITY as loud as
possible, and then adjust the volume of the sound
on your mixer.
The V3 SONORITY can be connected to any USB
Audio Class 1 compatible keyboard.
The V3 unit can supply your USB keyboard with a
maximum of 500mA.
If your keyboard requires more than 500mA, you
will need an external power supply.
Just plug in your USB keyboard here.
The polarity of the sustain foot pedal is set up
automatically when you turn on the V3 unit.
The pedal only works on MIDI channel 1.
To use the AUX OUT for any MIDI channel, you
must manually change the 4 internal switches
and send a MIDI message on the specified MIDI
channel.
The connection changes from 2 mono jacks to 2
stereo jacks.
One stereo jack gives you the MAIN in stereo; the
other one the AUX in stereo.
STEREO L + R = B A B B
STEREO + AUX = A B A A
PROGRAM LIST SOLO SOUNDSUSER INTERFACE PORTS CONNECT - USB KEYS
CONNECT - USB KEYS TURN ON FOOT PEDAL
AUX OUT - stereo
MIDI-THRU MIDI-IN
POWER ON/OFF USB-HOST
MAIN REVERB
LED - POWER ON
LED - MIDI
MAIN VOLUMEN

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSgENERAL MIDI BANK 0 gENERAL MIDI BANK 0
1 Grand Piano
2 Bright Piano
3 Electric Grand Piano
4 Honky Tonk
5 E-Piano Tines
6 E-Piano FM
7 Harpsichord
8 Clavinet
9 Celesta
10 Glockenspiel
11 Music Box
12 Vibraphon
13 Marimba
14 Xylophon
15 Tubular Bell
16 Dulcimer
17 Drawbar Organ
18 Percussive Organ
19 Rock Organ
20 Church Organ
21 Reed Organ
22 Accordion
23 Harmonica
24 Accordion Tango
25 Nylon Guitar
26 Acoustic Steel
27 Jazz Guitar
28 Guitar clean
29 Guitar mute clean
30 Overdrive Guitar
31 Distortion Guitar
32 Guitar harmonics
65 Sopran Sax
66 Alto Sax
67 Tenor Sax
68 Bariton Sax
69 Oboe
70 English Horn
71 Bassoon
72 Clarinet
73 Piccolo
74 Flute
75 Recorder
76 Pan Flute
77 Blown Bottle
78 Shakuhachi
79 Whistle
80 Ocarina
81 Square Lead
82 Saw Lead
83 Calliope
84 Chiffer Lead
85 Charang
86 Solo Vox
87 5th Saw wave
88 Bass & Lead
89 New Age
90 Warm Pad
91 Polysynth
92 Choir pad
93 Bowed
94 Metallic
95 Halo pad
96 Sweep
97 Rain
98 Soundtrack 5th
99 Crystal
100 Atmosphere
101 Brightness
102 Goblins
103 Echoes
104 Sci-fi Star
105 Sitar
106 Banjo
107 Shamisen
108 Koto
109 Kalimba
110 Bag pipe
111 Fiddle
112 Shanai
113 Tinkle Bell
114 Agogo
115 Steel Drums
116 Woodblock
117 Taiko Drum
118 Melodic Tom
119 Synth Drum
120 Reverse Cymbal
121 Guitar Noise
122 Breath Noise
123 Seashore
124 Bird
125 Telephon
126 Helicopter
127 Applaus
128 Gunshot
33 Upright Jazz Bass
34 E-Bass fingered
35 E-Bass picked
36 Fretless Bass
37 Slap Bass 1
38 Slap Bass 2
39 Synth Bass 1
40 Synth Bass 2
41 Violin
42 Viola
43 Cello
44 Contrabass
45 Tremolo Strings
46 Pizzicato Strings
47 Harp
48 Timpani
49 String Ensemble 1
50 String Ensemble 2
51 Synth Strings 1
52 Synth Strings 2
53 Choir Aahs
54 Voice Dohs
55 Synth Voice
56 Orchestra Hit
57 Trumpet
58 Trombone
59 Tuba
60 Trp. Mute
61 Horn
62 Brass Section
63 Synth Brass 1
64 Synth Brass 2
3
V3SOUND

MSB Prg.
55 1 Grand Piano
56 1 Classic Grand Piano
57 1 Rock Piano
58 1 Grand Stack 1 FM
59 1 Grand Piano Tinkle
60 1 Grand Piano and Pad
55 2 Bright Piano
56 2 Octave Piano
57 2 Bright Rock Piano
58 2 Grand Stack 2 EP
59 2 Grand Piano just Pad
60 2 Grand Piano Tremolo
55 3 Electric Grand Piano
56 3 Electric Grand Piano 2
57 3 Electric Grand Piano Trem.
58 3 Electric Grand Piano Stack
59 3 Electric Grand Piano Trem.
60 3 Electric Grand Piano hard Atk
55 4 Honky Tonk
56 4 E-Piano Wurly
57 4 E-Piano Wurly Trem. slow
58 4 E-Piano Wurly TInkle
59 4 E-Piano Wurly Trem. fast
60 4 E-Piano Wurly TInkle Trem.sl.
55 5 E-Piano Tines
56 5 E-Piano Tines Tinkle
57 5 E-Piano Tines Tremolo slow
58 5 E-Piano Tines Stack Bells
59 5 E-Piano Tines Tremolo fast
60 5 E-Piano Tines Tinkle Trem. sl.
55 6 E-Piano FM
56 6 E-Piano FM B
57 6 E-Piano FM filter
58 6 E-Piano FM detuned
59 6 E-Piano FM soft pad
60 6 E-Piano FM soft pad tremolo
MSB Prg.
55 7 Harpsichord
56 7 Harpsichord plus octave
57 7 Harpsichord octave delay
58 7 Har. Oct. delay long release
55 8 Clavinet
56 8 Clavinet filter
55 9 Celesta
56 9 Celesta Tinkle
57 9 Celesta Tinkle filter
58 9 Celesta just Attack
59 9 Celesta Tinkle and Pad
60 9 Celesta Tinkle octave delay
55 10 Glockenspiel
55 11 Music Box
56 11 Music Box oct. delay
57 11 Music Box oct. delay soft Atk.
55 12 Vibraphon
56 12 Vibraphon short release
57 12 Vibraphon soft Attack
58 12 Vibraphon no Vib.
59 12 Vibraphon no Vib. shot Rel.
60 12 Vibraphon fast Tremolo
55 13 Marimba
56 13 Marimba octave delay
57 13 Marimba & Xylo.octave delay
58 13 Marimba & Xylophon
55 14 Xylophon
56 14 Xylophon octave delay
55 15 Tubular Bell
56 15 Tubular Bell 2
55 16 Dulcimer
56 16 Dulcimer bright
57 16 Dulcimer 3
58 16 Dulcimer 3 out of tune
59 16 Dulcimer Tremolo
60 16 Dulcimer Fade in
MSB Prg.
55 17 Drawbar Organ
56 17 Ham 776555678 slow
57 17 Ham 776555678 fast
58 17 Ham 800000568 slow
59 17 Ham 800000568 fast
60 17 Ham 807800000 slow
55 18 Percussive Organ
56 18 Entertainer Organ Germany 1
57 18 Entertainer Organ Germany 2
58 18 Vintage German Organ 1
59 18 Vintage German Organ 2
60 18 Ham 807800000 fast
55 19 Rock Organ
56 19 Organ FL 1
57 19 Organ FL 2
58 19 Ham 800000000 slow
59 19 Ham 800000000 fast
55 20 Church Organ
56 20 Church Organ 2
57 20 Church Organ Flutes
55 21 Reed Organ
56 21 Theatre Organ Mighty
57 21 Theatre Organ Piston
58 21 Theatre Organ Acc
55 22 Accordion
56 22 Accordion Alpin 888
57 22 Accordion French Musette
58 22 Accordion French Celeste
59 22 Steirische Harmonika
60 22 Vox 4 Hawaii soft pad
55 23 Harmonica
55 24 Accordion Tango
56 24 Accordion Reed 16 Jazz
57 24 Accordion Reed 8 SCVI
58 24 Melodeon 8
59 24 Bandoneon
60 24 Vox 4 Hawaii fast
MSB Prg.
55 25 Nylon Guitar (120FX)
56 25 Ny. Git. soft (120FX)
57 25 Ny. Git. hard layer (120FX)
58 25 Ny. Git. death note (120FX)
59 25 Ny. Git. oct. Arp (120FX)
55 26 Acoustic Steel (120FX)
56 26 Acoustic Steel soft layers
57 26 Acoustic Steel hard (120FX)
58 26 Ac. Steel Double (120FX)
59 26 Acoustic Steel fall (120FX)
55 27 Jazz Guitar (120FX)
56 27 Jazz Guitar - note off (120FX)
57 27 Jazz Guitar Mute (120FX)
58 27 Jazz Guitar Mute DN (120FX)
59 27 Jazz Guitar Octave
55 28 Guitar clean (120FX)
56 28 Guitar clean soft EQ (120FX)
57 28 Guitar clean - PAD (120FX)
58 28 Guitar clean - stop (120FX)
59 28 Acoustic Steel Mute (120FX)
55 29 Guitar mute clean (120FX)
56 29 Guitar mute HPF (120FX)
55 30 Overdrive Guitar (120FX)²
56 30 Overdrive Guitar 8th (120FX)²
57 30 Ov. Git. Death note (120FX)²
55 31 Distortion Guitar (120FX)²
56 31 Distortion Guitar 8th (120FX)²
57 31 Dis. Gt. Death note (120FX)²
55 32 Guitar harmonics
56 32 Nylon Guitar harmonics
PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS VARIATION SOUNDS
Sound bank 55 offers the same sounds as GM sound bank 0, but all sounds have more volume and
use OSC overlapping. All sounds in this sound bank need more polyphony than bank 0.
4
V3SOUND

5
MSB Prg.
55 49 String Ensemble 1 20314
56 49 String Ensemble 1 ENV fast
57 49 String Ensemble 1 detache
58 49 String Ensemble 1 Layer
55 50 String Ensemble 2 20301ADL
56 50 String Ensemble 2 slow
57 50 String Ensemble 2 fad m3
58 50 String ENV - Filter ENV
59 50 String Ensemble 2 fad p3
55 51 Synth Strings 1
56 51 Synth Strings 1 filter up
57 51 Synth Strings 1 filter lfo
58 51 Synth Strings 1 filter
55 52 Synth Strings 2 MKS
56 52 Synth Strings 2 MKS dark
57 52 Synth Strings 2 MKS filter
58 52 Synth Strings 2 MKS rel.down
55 53 Choir Aahs
57 53 String Ens. Retro Synth. 1
58 53 String Ens. Retro Synth. 2
55 54 Voice Doo
56 54 Voice Doo
57 54 Voice Doo Double
55 55 Synth Voice
56 55 Synth Voice 2 Layer
57 55 Synth Voice 2 Layer EQ
55 56 Orchestra Hit Major
56 56 Orchestra Hit Minor
55 57 Trumpet
56 57 Trumpet soft layers
57 57 Trumpet hard layers
59 57 Trumpet legato down vel.116
60 57 Trumpet 2 Vibrato forte
55 58 Trombone
56 58 Trombone soft layers
57 58 Trombone hard layers
55 59 Tuba
58 59 Bariton Bass (note 84 up FX)
MSB Prg.
55 60 Trp. Mute
56 60 Trp Mute auto variation
55 61 Horn
55 62 Brass Section
56 62 Brass Section Sfz
57 62 Brass Section fall fast
58 62 Brass Section fall slow
55 63 Synth Brass 1
55 64 Synth Brass 2
55 65 Sopran Sax
56 65 Sopran Sax soft Layers
57 65 Sopran Sax hard Layers
58 65 Sopran Sax soft Layers noise
55 66 Alto Sax
56 66 Alto Sax soft Layers
57 66 Alto Sax hard Layers
58 66 Alto Sax soft Layers noise
55 67 Tenor Sax
56 67 Tenor Sax only soft Layers
57 67 Tenor Sax only hard Layers
58 67 Tenor Sax soft Layers & noise
59 67 Tenor Sax medium version
60 67 Tenor Sax 2 soft Jazz
55 68 Bariton Sax
55 69 Oboe
55 70 English Horn
55 71 Bassoon
55 72 Clarinet
56 72 Clarinet noise
55 73 Piccolo
55 74 Flute
56 74 Flute EQ
57 74 Flute EQ2
MSB Prg.
55 33 Upright Jazz Bass
56 33 Upright Jazz Bass more Atk.
57 33 Upright JB no finger Atk.
55 34 E-Bass fingered
56 34 E-Bass fingered EQ1
57 34 E-Bass fingered EQ2
58 34 E-Bass fingered HQ
55 35 E-Bass picked
56 35 E-Bass picked dark
55 36 Fretless Bass
55 37 Slap Bass 1 (120FX)
55 37 Slap Bass 1 (120FX)
56 38 Slap Bass 2 (120FX)
56 38 Slap Bass 2 (120FX)
55 39 Synth Bass 1
56 39 Synth Bass 1 Reso
57 39 Synth Bass 1 Reso
58 39 Synth Bass 1 filter
55 40 Synth Bass 2
56 40 Synth Bass 2 Reso
57 40 Synth Bass 2 Reso
58 40 Synth Bass 2 filter
55 41 Violin
55 42 Viola
55 43 Cello
55 44 Contrabass
55 45 Tremolo Strings
55 46 Pizzicato Strings
55 47 Harp
55 48 Timpani
MSB Prg.
55 75 Recorder
55 76 Pan Flute
55 77 Blown Bottle
56 77 Blown Bottle soft
57 77 Blown Bottle filter
58 77 Blown Bottle filter LFO
55 78 Shakuhachi
55 79 Whistle
55 80 Ocarina
55 81 Square Lead
56 81 Square Lead 1 Layer
57 81 Square Lead filter ENV
58 81 Square Lead soft Atk.
55 82 Saw Lead
56 82 Saw Lead ENV
57 82 Saw Lead HPF
58 82 Saw Lead dynamic filter
59 82 Saw Lead dynamic filter 24db
55 83 Calliope
56 83 Calliope no noise
55 84 Chiffer Lead
56 84 Chiffer Lead 2
57 84 Chiffer Lead Reso
58 84 Chiffer Lead Notch
59 84 Hook Lead
60 84 Reco Pluck
55 85 Charang
56 85 Charang Low Pass
57 85 Poly FM
55 86 Solo Vox
56 86 Solo Vox Filter
57 86 Solo Vox Filter pad
58 86 Solo Vox Filter Rise
55 87 5th Saw wave
56 87 Saw wave dynamic short
57 87 Saw wave 2
58 87 Saw wave soft
V3SOUND
PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS VARIATION SOUNDS

6
MSB Prg.
55 88 Bass & Lead
56 88 Bass & Lead tuned
57 88 Bass & Lead perc.
58 88 Bass & Lead reso
55 89 New Age
56 89 New age 2
57 89 New age 816
58 89 New age DX1
59 89 New age double
55 90 Warm Pad
56 90 Warm Pad less bass
57 90 Pad Obx
58 90 Soft Pad Obx
59 90 Dark Pad Obx
60 90 Pad Obx Rise
55 91 Polysynth
56 91 Polysynth filter
57 91 Polysynth bright
58 91 Choir pad filter
59 91 Choir pad filter up
55 92 Choir pad
56 92 Choir pad 2
57 92 Choir pad 3
55 93 Bowed
56 93 More Metal Pad
55 94 Metallic
55 95 Halo pad
55 96 Sweep
56 96 Sweep fast
57 96 Sweep fast attack
55 97 Rain
55 98 Soundtrack 5th
56 98 Soundtrack
57 98 Soundtrack soft
58 98 Soundtrack fast
60 98 Soundtrack fast fad stereo
55 99 Crystal
56 99 Crystal HPF
57 99 Crystal note off
MSB Prg.
55 100 Atmosphere
56 100 Atmosphere 2
55 101 Brightness
56 101 Brightness 1OP
57 101 Brightness Notch
55 102 Goblins
55 103 Echoes
55 104 Sci-fi Star
55 105 Sitar
57 105 Rhy. Guitar Steel CX (120FX)²
58 105 Rhy.Guitar soft CX (120FX)²
55 106 Banjo
57 106 Rhythm Guitar Folk
58 106 Rhythm Guitar Folk less Bass
55 107 Shamisen
55 108 Koto
58 108 Mandoline Tremolo
55 109 Kalimba
55 110 Bag pipe
55 111 Fiddle
56 111 Fiddle less Attack
55 112 Shanai
55 113 Tinkle Bell
55 114 Agogo
55 115 Steel Drums
55 116 Woodblock
55 117 Taiko Drum
55 118 Melodic Tom
55 119 Synth Drum
55 120 Reverse Cymbal
59 120 Bell noise motion
55 121 Guitar Noise
55 122 Breath Noise
55 123 Seashore
55 124 Bird
55 125 Telephon
55 126 Helicopter
55 127 Applaus
55 128 Gunshot
MSB Prg.
61 25 Ny. Git. slide 116 (120FX)
61 26 Ac. Steel slide 116 (120FX)
61 34 E-Bass fing. slide 116
61 57 Trumpet slide 116
61 65 Sopran Sax slide 116
61 66 Alto Sax slide 116
61 67 Tenor Sax 1 slide 116
61 72 Clarinet slide 116
61 106 Banjo slide 116
61 111 Fiddle slide up 116
V3SOUND
PROGRAM LIST SOLO SOUNDSVARIATION SOUNDS SLIDE VARIATION SOUNDS
TIP - These sounds use a special velocity mapping.
From the velocity value 116 to the top, you get a
slide-up sound.

7
Violin Ensemble
31 Marcato
32 Slow Attack
33 Detache
34 Legato 1
35 Legato 2
36 Legato up bend - small
37 Legato up bend - medium
38 Legato down bend - small
39 Legato down bend - meium
40 Pizzicato
Viola Ensemble
41 Marcato
42 Slow Attack
43 Detache
44 Legato 1
45 Legato 2
46 Legato up bend - small
47 Legato up bend - medium
48 Legato down bend - small
49 Legato down bend - medium
50 Pizzicato
Cello Ensemble
51 Marcato
52 Slow Attack
53 Detache
54 Legato 1
55 Legato 2
56 Legato up bend - small
57 Legato up bend - medium
58 Legato down bend - small
59 Legato down bend - medium
60 Pizzicato
Contrabass Ensemble
61 Marcato
62 Slow Attack
63 Detache
64 Legato 1
65 Legato 2
66 Legato up bend - small
67 Legato up bend - medium
68 Legato down bend - small
69 Legato down bend - medium
70 Pizzicato
FULL Symphonic String Orchestra
01 Dynamic Marcato/Legato fast
02 Dynamic Marcato/Legato (no note-off)
03 Dynamic Marc./Leg. slow (no note-off)
04 Marcato/Legato (no note-off samples)
05 Marcato piano (no note-off samples)
FULL Chamber Ensemble
06 Dynamic Marcato/Legato fast
07 Dynamic Marcato/Legato (no note-off)
08 Dynamic Marc. Leg. slow (no note-off)
09 Marcato/Legato (no note-off samples)
10 Marcato piano (no note-off samples)
Group Ensembles
11 Violins Marcato/Legato fast
12 Violas Marcato/Legato fast
13 Celli Marcato/Legato fast
14 Contra.Bs. Marcato/Legato fast
Just Piano Samples
15 Violins just piano Layer
16 Violins just piano Layer slow
17 Violas just piano Layer
18 Violas just piano Layer slow
Ensemble Articulations
19 Pizzicato
20 Tremolo
21 Disco Violins short
22 Disco Violins Fall
Solo Violin
71 Marcato
72 Slow Attack
73 Detache
74 Legato 1
75 Legato 2
76 Legato up bend - small
77 Legato up bend - medium
78 Legato down bend - small
79 Legato down bend - medium
80 Pizzicato
Solo Viola
81 Marcato
82 Slow Attack
83 Detache
84 Legato 1
85 Legato 2
86 Legato up bend - small
87 Legato up bend - medium
88 Legato down bend - small
89 Legato down bend - medium
90 Pizzicato
Solo Cello
91 Marcato
92 Slow Attack
93 Detache
94 Legato 1
95 Legato 2
96 Legato up bend - small
97 Legato up bend - medium
98 Legato down bend - small
99 Legato down bend - medium
100 Pizzicato
Solo Contrabass
101 Marcato
102 Slow Attack
103 Detache
104 Legato 1
105 Legato 2
106 Legato up bend - small
107 Legato up bend - medium
108 Legato down bend - small
109 Legato down bend - medium
110 Pizzicato
Solo Tremolo
111 Violin Tremolo
112 Viola Tremolo
113 Cello Tremolo
114 Contrabass Tremolo
Solo Piano Layer only
115 Violin - Piano
116 Viola - Piano
Ensembles no note-off samples
117 Violin Ens. Marcato (no note-off)
118 Violin Ens. Legato (no note-off)
119 Viola Ens. Marcato (no note-off)
120 Viola Ens. Legato (no note-off)
121 Cello Ens. Marcato (no note-off)
122 Cello Ens. Legato (no note-off)
123 Contrabass Ens. Marcato (no note-off)
124 Contrabass Ens. Legato (no note-off)
PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 62 CLASSIC ORCHESTRA BANK MSB 62
V3SOUND

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 63 CLASSIC ORCHESTRA BANK MSB 63
Trumpet Ensemble
01 Marcato (velo. spl. piano47/forte48)
02 Marcato Piano
03 Staccato
04 Sforzato
05 Legato
06 Legato up bend - small
07 Legato up bend - medium
08 Legato down bend - small
09 Legato down bend - medium
10 -
Trombone Ensemble
11 Marcato (velo. spl. piano47/forte48)
12 Marcato Piano
13 Staccato
14 Sforzato
15 Legato
16 Legato up bend - small
17 Legato up bend - medium
18 Legato down bend - small
19 Legato down bend - medium
20 -
Horn Ensemble * Note Riff up
21 Marcato (velo. spl. piano47/forte48)
22 Marcato Piano
23 Staccato
24 Sforzato
25 Legato
26 Legato up bend - small
27 Legato up bend - medium
28 Legato down bend - small
29 Legato down bend - medium
30 -
Tuben Ensemble
31 Marcato
Tenorhorn Ensemble
41 Tenorhorn Ensemble
Tenorhorn
101 Tenorhorn
Extras instument effects
121 Horn Riff up - Note 60-84
Bb Trumpet
61 Marcato (velo. spl. piano47/forte48)
62 Marcato Piano
63 Staccato
64 Sforzato
65 Legato
66 Legato up bend - small
67 Legato up bend - medium
68 Legato down bend - small
69 Legato down bend - medium
70 -
Trombone
71 Marcato (velo. spl. piano47/forte48)
72 Marcato Piano
73 Staccato
74 Sforzato
75 Legato
76 Legato up bend - small
77 Legato up bend - medium
78 Legato down bend - small
79 Legato down bend - medium
80 -
Horn
81 Marcato (velo. spl. piano47/forte48)
82 Marcato Piano
83 Staccato
84 Sforzato
85 Legato
86 Legato up bend - small
87 Legato up bend - medium
88 Legato down bend - small
89 Legato down bend - medium
90 -
Tuba
91 Marcato (velo. spl. piano47/forte48)
92 Marcato Piano
93 Staccato
94 Sforzato
95 Legato
96 Legato up bend - small
97 Legato up bend - medium
98 Legato down bend - small
99 Legato down bend - medium
100 -
8
V3SOUND

PROGRAM LIST SOLO SOUNDS PROGRAM LIST SOLO SOUNDSCLASSIC ORCHESTRA BANK MSB 64 CLASSIC ORCHESTRA BANK MSB 64
C-Flute
01 Marcato
02 Slow Attack
03 Staccato
04 Sforzato
05 Legato
06 Legato up bend - small
07 Legato up bend - medium
08 Legato down bend - small
09 Legato down bend - medium
10 -
Oboe
11 Marcato
12 Slow Attack
13 Staccato
14 Sforzato
15 Legato
16 Legato up bend - small
17 Legato up bend - medium
18 Legato down bend - small
19 Legato down bend - medium
20 -
English horn
21 Marcato
22 Slow Attack
23 Staccato
24 Sforzato
25 Legato
26 Legato up bend - small
27 Legato up bend - medium
28 Legato down bend - small
29 Legato down bend - medium
30 -
Bb Clarinet
31 Marcato
32 Slow Attack
33 Staccato
34 Sforzato
35 Legato
36 Legato up bend - small
37 Legato up bend - medium
38 Legato down bend - small
39 Legato down bend - medium
40 -
Extras
127 Percussion Map / Drumkit 62
With this program you can use the
orchestra percussion sounds
on any standard MIDI channel.
After power on it´s
MIDI Channel 1-9 and 11-16
128 Silence - no sound
101 Ensemble Flutes
102 Ensemble Clarinets
Bass Clarinet
41 Marcato
Bassoon
51 Marcato
52 Slow Attack
53 Staccato
54 Sforzato
55 Legato
56 Legato up bend - small
57 Legato up bend - medium
58 Legato down bend - small
59 Legato down bend - medium
60 -
Contra Bassoon
61 Marcato
9
V3SOUND

10
V3SOUND
ORGAN MSB 83
41 Or.Tower Mighty
42 Or.Tower Piston 2
43 Or.Tower Piston 4
44 Or.Tower Piston 5
45 Or.Tower Solo 5
46 Or.Tower Solo 6
47 Or.Tower Acc. 1
48 Or.Tower Acc. 2
49 Or.Tower Tibias
50 Or.Tower Meloton
51 Or.Tower Royal 1
52 Or.Tower Royal 2
53 Or.Tower Krumm
54 Or.Tower T. Vox
55 Or.Tower Straight
56 Or.Tower Tubas
57 Or.T. Pedals small
58 Or.T. Pedals full
59 Or.T. Pedals Dixon
60 Or.C3 Full
61 Or. Rock Organ
62 Or.Pipe Tutti 1
63 Or.Pipe Tutti 2
64 Or.Pipe Flutes
65 Or.Cordovox A
66 Or.Cordovox B
67 Or.Cordovox C
68 Or.Cordovox D
69 Or.Cordovox E
70 Or.Vox4 A
71 Or.Vox4 B
72 Or.Vox4 C
101 Or.Glocken
102 Or.Glocken short
103 Or.Glocken Reiteration
104 Or.Xylophon Hit
105 Or.Xylo Reiter A & Hit
106 Or.Xylo Reiter B
107 Or.Glo. Reiter velocity
108 Or.Xylo. Reiter velocity
109 Or.Glo. Reiter Mono
110 Or.Xylo. Reiter Mono
128 Or. Tower FX
01 Or. 776555678 slow
02 Or. 776555678 fast
03 Or. 800000568 slow
04 Or. 800000568 fast
05 Or. 008530000 slow
06 Or. 008530000 fast
07 Or. 800000000 slow
08 Or. 800000000 fast
09 Or.807800000 slow
10 Or.807800000 fast
11 Or.804708000 slow
12 Or.804708000 fast
13 Or.800008000 slow
14 Or.800008000 fast
15 Or.800000008 slow
16 Or.800000008 fast
17 Or.687600000 slow
18 Or.687600000 fast
19 Or.888000000 Perc
20 Or.Hamm full
21 Or.CD-DB slow
22 Or.CD-DB fast
23 Or.CD-FL slow
24 Or.CD-FL fast
25 Or.KW full slow
26 Or.KW full fast
27 Or.KW perc slow
28 Or.KW perc fast
29 Or.FL perc slow
30 Or.FL perc fast
31 Or.ZR soft slow
32 Or.ZR soft fast
33 Or.Klaus W. slow
34 Or.Klaus W. fast
35 Or.Klaus Musical
36 Or.Versinum
37 Or.German A
38 Or.German B
39 Or.L100 A
40 Or.L100 B
ACCORDION MSB 84
41 Acc. Reed 48
42 Acc. Reed 4816
43 Acc. Scott A
44 Acc. Scott B
45 Acc. Scott C
46 Acc. Irland 888
47 Acc. Morino
48 Acc. Morino & 16
49 Acc. Morino & 4
50 Acc. Morino Master
51 Acc. Morino (56/57)
52 Acc. Zup 88
53 Acc. Zup 8816
54 Acc. Zup 488
55 Acc. Zup Master
56 Acc. Zup 88 (56/57)
57 Steirische Harmonika 1
58 Steirische Harmonika 2
59 Steirische Harmonika 2 (56/57)
60 Steirische Helikon bass
61 Accordion Reed 4
62 Harmonium
63 Melodeon Irland
64 Bandoneon
65 Schwyzer Örgeli Nussbaumer III
66 Schwyzer Örgeli Nussbaumer IIIa
67 Schwyzer Örgeli Nussbaumer IIIb
68 Schwyzer Örgeli Nussbaumer II
01 Harmonica
02 Acc. French Musette
03 Acc. French 88816
04 Acc. French 4888
05 Acc. French Master
06 Acc. Celeste
07 Acc. Celeste+
08 Acc. Tango 8/16
09 Acc. Tango 4/8/16
10 Acc. Cav. Celeste
11 Acc. Cav. Bassoon
12 Acc. Cav. Master
13 Acc. Cav. Double Bassoon
14 Acc. Cav. Double Bassoon & 8
15 Acc. Cav. Double Bassoon Experiment
16 Acc. Super VI
17 Acc. Bassoon
18 Acc. Belgium Musette
19 Acc. Musette++
20 Melodeon 8
21 Melodeon 88a
22 Melodeon 88b
23 Melodeon 88c
24 Accordion A
25 Accordion B
26 Accordion C
27 Melodeon 888
28 Melodeon 8888
29 Melodeon 816
30 Accordina
31 Acc. Scott Gola
32 Acc. Scott Gola & 16
33 Acc. Scott Gola & 4
34 Acc. Scott Master
35 Acc. Jimmy Shand
36 Acc. Jimmy Shand & 16
37 Acc. Jimmy Shand & 4
38 Acc. Jimmy Shand Master
39 Acc. Reed 8
40 Acc. Reed 816

11
V3SOUND
GUITAR MSB 85
41 Guitar Steel mute
64 Guitar Nylon SL116
65 Guitar Steel SL116
66 Banjo SL 116
67 Guitar Pedal Steel SL 116
01 Guitar Nylon
02 Guitar Nylon soft
03 Guitar Nylon Octave
04 Guitar Steel 1
05 Guitar Steel 1 soft
06 Guitar Steel 1 hard
07 Guitar Steel 1 double
08 Guitar Steel 1 bowed
09 Guitar Steel 2
10 Guitar Steel 2 soft
11 Banjo
12 Ens. Mandolins Tremolo
13 Ens. Mandolins Tremolo+
14 Ens. Mandolins
15 Git. Jazz 1
16 Git. Jazz 2
17 Git. Jazz & Octave
18 Pedal Steel Vib.
19 Pedal Steel
20 Pedal Steel bowed
21 Git. Jazz Amp 1
22 Git. Jazz Amp 2
23 Git. Jazz Chicken Picking 1
24 Git. Jazz Chicken Picking 2
25 Git. Nylon Zupf & note off
26 Git. Nylon Zupf
27 Git. clean
28 Git. Overdrive
29 Git. Overdrive short & long velo. 64/65
30 Git. Overdrive short
31 Git. Distortion
32 Git. Distortion short & long velo. 64/65
33 Git. Distortion short
34 Guitar Feedback
35 Git. Harmonics
36 Git. Rhythm 1
37 Git. Rhythm 2
38 Guitar mute
39 Guitar mute HPF
40 Guitar mute & death
BASS MSB 86
01 Contrabass
02 Contrabass Finger Attack+
03 Contrabass soft
04 Contrabass 2
05 Contrabass 2 soft
06 Contrabass bowed
07 Contrabass bowed short
08 E-Bass 1
09 E-Bass 1 & note off
10 E-Bass 2
11 E-Bass 2 & note off
12 E-Bass 3
13 E-Bass 3 Eq
14 E-Bass 3 Filter
15 E-Bass Pick 1
16 E-Bass Pick 2
17 E-Bass Fretless
18 E-Bass Slap from note D
19 E-Bass Slap from note D & note off
20 E-Bass Slap from note G
21 E-Bass Slap from note G & note off
22 Doppelbass Bariton & E-Bass
72 Synthbass 1
73 Synthbass 2
74 Synthbass 3
75 Synthbass 4
76 Synthbass 5
77 Synthbass Jupiter 1
78 Synthbass Jupiter 2
79 Synthbass Jupiter 3
80 Synthbass Jupiter 4
81 Synthbass DX100 kurz
82 Synthbass DX100
83 Synthbass DX100 Reso
84 Synthbass DX100 HP
85 Synthbass CE25 kurz
86 Synthbass CE25
87 Synthbass CE25 Reso
88 Synthbass CE25 HP
89 Synthbass CS01 kurz
90 Synthbass CS01
91 Synthbass CS01 Reso
92 Synthbass Z3 kurz
93 Synthbass Z3
94 Synthbass Z3 long
STRINGS MSB 87
01 Violin Solo
02 Viola Solo
03 Cello Solo
04 Contrabass Solo
05 Full Strings Tremolo
06 Full Strings pizzicato
07 Strings Chamber
08 Full Strings dynamic
09 Full Strings fast
10 Full Strings detache
11 Full Strings forte
12 Full Strings Emotion
13 Full Strings 2
14 Full Strings 2 fast
15 Full Strings 2 Filter
16 Full Strings 2 LFO
17 Full Strings 2+
18 Full Strings 2 sp.
19 Full Strings special
20 Fiddle soft
21 Fiddle
22 Zillertal Geige
23 Zillertal Geige+ Arco
24 Zillertal Geige legato
25 Zillertal Geige legato up
26 Zillertal Geige legato down
27 Violin Ensemble Disco short
28 Violin Ensemble Disco fall
48 Synth. Strings PWM
49 Synth. Strings PWM+
50 Synth. Strings PWM up
51 Synth. Strings FWM
52 Synth. Strings MKS
53 Synth. Strings MKS+
54 Synth. Strings MKS24 Filter
55 Synth. Strings MKS24+
56 Retro Strings
57 Retro Stringman
64 Fiddle SL116
65 Zillertal Geige SL116

V3SOUND
12
BRASS MSB 88
01 Cornet
02 Cornet soft
03 Cornet hard
04 Cornet legato up
05 Trumpet Vibrato
06 Trombone
07 Trombone soft
08 Trombone hard
09 Trp. Miles mute
10 Trp. Miles mute AV
11 French horn
12 F-Horn
13 Trumpet Section
14 Trumpet Section staccato
15 Trumpet Section fall
16 Trumpet Section up
17 Trumpet Section sfz
18 Trumpet Section shake
19 Lead Trumpets
20 Trombone Section
21 Trombone Section staccato
22 Trombone Section fall
23 Trombone Section sfz
24 Brass sfz
25 Brass short
26 Brass staccato
27 Trumpet Ivan
28 Trumpet Ivan
29 Trumpet Ivan 1/4 note
30 Trumpet Ivan 1/4 note
31 Trumpet Ivan staccato
32 Trumpet Dixie
33 Trumpet Dixie soft
34 Trumpets
35 Trumpets HPF
36 Trumpets Filter
37 Trumpet Damper
38 Tenorhorn Vibrato
39 Bariton Sepp Accent
40 Bariton Sepp Vibrato
41 Bariton Sepp staccato mezzo
42 Bariton Sepp staccato forte
43 Tuba Jon
44 Tuba Jon soft
45 Tubas
64 Cornet SL116
65 Trumpet Dixie SL116
66 Trumpets SP116
67 Trumpet Section SP 116 fall
68 Trumpet Section SP 116 up
69 Trumpet Section SP 116 shake
SAX MSB 89
01 Sax Sopran
02 Sax Sopran soft
03 Sax Sopran hard
04 Sax Sopran noisy
05 Sax Alto
06 Sax Alto soft
07 Sax Alto hard
08 Sax Alto noisy
09 Sax Tenor 1 Jazz Vibrato smooth
10 Sax Tenor 2
11 Sax Tenor 2 soft
12 Sax Tenor 2 hard
13 Sax Tenor 2 noisy
14 Sax Tenor 2 piano
15 Sax Bariton
16 Sax Sopran Carlo
17 Sax Section Tenor 1
18 Sax Section Tenor 2
19 Sax Section Alto
20 Sax Section Alto staccato
21 Sax Section Alto fall
22 Sax Section Alto sfz
23 Sax Tenor Funk
24 Sax Tenor Growl
64 Sax Sopran SL116
65 Sax Alto SL116
66 Sax Tenor SL116
67 Sax Tenor Funky SP116 Growl
WOODWINDS MSB 90
01 Oboe
02 Englishhorn
03 Bassoon
04 Clarinet
05 Clarinet noisy
06 Piccolo
07 Flute
08 Flute EQ
09 Flute HP
10 High Whistle
11 High Whistle AV
12 Low Whistle
13 Whistle
14 Panflute
15 Bottle
16 Bottle soft
17 Bottle Q
18 Bottle LFO
19 Shakuhachi
20 Whistle GS
21 Ocarina
22 Clarinet Carlo
23 Clarinet Carlo EQ
24 Clarinet Vito
25 Clarinet Vito velo.
26 Clarinet Vito staccato
27 Clarinet Vito staccato velo.
64 Clarinet SL116
65 High Whistle SL116
66 Low Whistle SL116

13
V3SOUND
SYNTHESIZER MSB 91
41 Softpad+
42 Synth OBX
43 Synth OBX soft
44 Synth OBX warm
45 Synth OBX ENV
46 Synth Fairly
47 Synth Spacy
48 Bowed Glas
49 Bowed Glas+
50 Metal Pad
51 Halo Pad
52 Sweep Juno
53 Sweep Juno fast
54 Sweep Juno Atk.
55 Ice Rain
56 Soundtrack
57 Soundtrack+
58 Soundtrack up
59 Soundtrack fade
60 Crystal Bell
61 Crystal Bell HPF
62 Crystal Bell & off
63 Atmos
64 Atmos+
65 Brightness A
66 Brightness B
67 Brightness C
68 Goblin
69 Echo Drops
70 Star Them
71 Bell Hit
01 Square Lead 1
02 Square Lead 2
03 Square Lead 3
04 Square Lead 4
05 Square Lead 5
06 Saw Lead 1
07 Saw Lead 2
08 Saw Lead 3
09 Saw Lead 4
10 Saw Lead 5
11 Calliope 1
12 Calliope 1
13 Chiffer 1
14 Chiffer 2
15 Chiffer 3
16 Chiffer 4
17 Hook
18 FM7 Pluk
19 Charang 1
20 Charang 1
21 FM8 Brass
22 Synth Brass 1
23 Synth Brass 2
24 Prophet 8 Brass
25 Prophet 8 Brass
26 Prophet 8 Brass 24db
27 Synth 5th
28 SYizer X
29 SYizer Y
30 SYizer Z
31 SY Lead A
32 SY Lead B
33 SY Lead C
34 SY Lead D
35 Fantasia
36 Fantasia+
37 Fantasia Chor.
38 DX1 Toy Bell
39 DX1 Toy Bell+
40 Softpad
ETHNO MSB 92
01 Bag Pipe
02 Bag Pipe AV
03 Bag Pipe Drone
04 Ullian Pipe
05 Ullian Pipe AV
06 Ullian Pipe Drone
07 Pipers
08 Pipers Drone
09 Dulcimer 5 strings
10 Dulcimer 5 strings+
11 Dulcimer 5 strings Tremolo
12 Dulcimer 5 strings bowed
13 Alphorn
14 Alphorn Duo
15 Alphorn Trio
16 Alphorn Trio+
17 Alphorn Trio tune
18 Schellen Hit
19 Schellen Hit & Roll
20 Schellen Roll
21 Harp
22 Harp+
23 Dulcimer 3 strings
24 Dulcimer 3 strings+
25 Dulcimer 3 strings Tremolo
26 Dulcimer 3 strings bowed
27 Zither
28 Jew´s Harp
29 Sitar
30 Shamisen
31 Koto
32 Shanai
64 Bag Pipe SL116
65 Ullian Pipe SL116
72 Orchestra Hit Major
73 Orchestra Hit Minor
76 SFX Cymbal
77 SFX Seashore
78 SFX Bird
79 SFX Phone
80 SFX Heli
81 SFX Applause
82 SFX Gunshot
84 SFX Fret noise
85 SFX Breath
121 FX Freddy Pfister
122 SFX Nylon Guitar Perc. 31/55/79/103
123 SFX Stomp & Claps
24 - 82 Claps
84 - 107 Stomp

14
Nr. Kit 1 Kit 9 Kit 17 Kit 25 Kit 26 Kit 27 Kit 28 Kit 29 Kit 31 Kit 32 Kit 33 Kit 41 Kit 49 Kit 62
GM Electro 808/909 909 analog 2010 2011 Party Jazz Brush Orchestra Orchestra
G 7 Brush AY swirl 1 ~ ~ ~ ~ ~ Gran Casa
8 Brush AY swirl 2 ~ ~ ~ ~ ~ Gran Casa
A 9 Brush AY swirl 3 ~ ~ ~ ~ ~ Gran Casa
10 Brush MO open ~ ~ ~ ~ ~ Gran Casa
11 Brush MO ~ ~ ~ ~ ~ Gran Casa
C 12 Brush MO ~ ~ ~ ~ ~ Gran Casa
13 Brush MO o. ac ~ ~ ~ ~ ~ Gran Casa
D 14 Snare AY ~ ~ ~ ~ ~ Gran Casa
15 Snare AY ~ ~ ~ ~ ~ Gran Casa
E 16 Snare AY ~ ~ ~ ~ ~ Gran Casa
F 17 Rim AY Rim MO ~ Jz. Stick Rim ~ Rim MO Gran Casa
18 Snare AY Snare MO ~ Jazz Stick Std ~ Snare MO GC. forte
G 19 Snare AY Snare MO ~ Jz. Stick Rim ~ Rim MO GC. medium
20 Snare AY Snare MO ~ Jazz Stick Std ~ Snare MO GC. piano
A 21 Snare AY Snare MO ~
22 Sn. AY shallow Sn. MO sh ~ Jazz Stich sh ~ Snare MO
23 Snare Rim shot Sn. MO Rims ~ Jz. Stick Rim ~ Snare MO Gong
C 24 Snare Rim shall. Sn. MO RiSh ~ Jz. Stick Rsh. ~ Snare MO
25 Buzzer ~ ~ ~ ~ ~
D 26
27 High Q ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Closed HH
E 28 Slap ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Pedal Ped.
F 29 Scratch Push (7) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Open HH.
30 Scratch Pull (7) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Ride Cymbal
G31Sticks ~~~~~~~~~~~~
32 Square Click ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 33 Metronom Click ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
34 Metronom Bell ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
35 Bass Drum 1 BD 3 BD 5 Elec BD 7 909 BD 9 909 BD 11 606 BD 13 Hit BD 15 Hit BD 17 Party BD 19 Jazz BD 21 Jazz BD 21 BD 23 Gran Casa
C 36 Bass Drum 2 BD 4 BD 6 Elec BD 8 808 BD 10 909 BD 12 80 BD 14 Hit BD 16 Hit BD 18 Party BD 20 Jazz BD 22 Jazz BD 22 BD Orch. Gran Casa
37 Rim ~ ~ Rim 808 808 Rim 909 Rim 606 Rim 909 Rim 909 Rim 909 Rim Jazz Rim Sidestick ~
D 38 Snare 1 AY Snare 2 MO Snare 3 SO Elec Snare 1 808 Snare 1 909 Snare 2 Snare 80 Hit Snare 1 Hit Snare 3 Party Snare 1 Jazz Snare 1 Brush mp Snare Orch. Concert Sn.
39 Clap ~ ~ Clap 808 Clap 808 Clap 808 Clap 80 Hit Clap Hit Clap Hit Clap ~ Brush mf Castanet Castanets
E 40 Snare 1 AY Snare 2 MO Snare 3 SO Elec Snare 2 909 Snare 1 909 Snare 1 Snare 85 Hit Snare 2 Hit Snare 4 Party Snare 2 Jazz Snare 2 Brush swirl Snare Orch. Concert Sn.
F41 Tom Low Low ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
42 HiHat closed (0) ~ ~ HH elec 808 HHat cl. 909 HHat cl. HHat cl. 85 909 HHat cl. 909 HHat cl. 909 HHat cl. ~ ~ Timpani Timpani
G 43 Tom Low ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
44 HiHat Pedal (0) ~ ~ HH elec 808 HHat P. 909 HHat P. HHat cl. 85 909 HHat P. 909 HHat P. 909 HHat e. ~ ~ Timpani Timpani
A 45 Tom Medium L. ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
46 HiHat open (0) ~ ~ HH elec 808 HH. op. 909 HH. op. HHat cl. 85 909 HH. op. 909 HH. op. 909 HH. op. ~ ~ Timpani Timpani
47 Tom Medium ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
C 48 Tom High ~ ~ Elec Tom 80 808 Tom 909 Tom Tom 85 909 Tom 909 Tom 909 Tom ~Brush Tom Timpani Timpani
49 Crash Cymbal 1 ~ ~ Crash 909 808 Cym 909 Cym 808 Cym 808 Cym 808 Cym 808 Cym ~ ~ Timpani Timpani
D 50 Tom High High ~ ~ Elec Tom 80 808 Tom 90 Tom Tom 85 90 Tom 90 Tom 90 Tom ~Brush Tom Timpani Timpani
51 Ride Cymbal 1 ~ ~ Ride 909 Ride 909 Ride 909 Ride 85 Ride 909 Ride 909 Ride 909 ~ ~ Timpani Timpani
E 52 China Cymbal ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Timpani Timpani
F 53 Ride Cup ~ ~ Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 Cup 66 ~ ~ Timpani Timpani
54 Tambourin ~ ~ Tamb. 66 Tamb. 66 Tamb. 77 Tamb. 66 Tamb. 77 Tamb. 77 Tamb. 77 ~ ~ ~ Tamburin
G 55 Splash Cymbal ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
56 Cowbell ~ ~ ~ 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell 808 Cowbell Cowbell Jazz Cowbell Jazz ~ Concert Cy.
A 57 Crash Cymbal 2 ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
58 Vibraslap ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
59 Ride Cymbal 2 ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
C 60 Bongo high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
61 Bongo low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
D 62 Conga mute ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
63 Conga open ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
Drumkits are only available on DRUM
MODE parts. The MIDI-sysex message
“General MIDI reset” sets up MIDI channel
10 as the DRUM MODE part.
MIDI-Sysex can change any part to DRUM
MODE.
DRUM KITS
1 Drum - General MIDI HQ
9 Drum Hit Kit
17 Studio Kit
25 Drum Electro 80
26 Drum Computer 808/909
27 Drum 909
28 Drum Electro Vintage
29 Drum Dance Kit
31 Drum Dance Kit
32 Drum Dance Kit
33 Drum Jazz Stick Kit
41 Drum Brush Kit
49 Orchestra Kit
62 Orchestra Kit
V3SOUND

Nr. Kit 1 Kit 9 Kit 17 Kit 25 Kit 26 Kit 27 Kit 28 Kit 29 Kit 31 Kit 32 Kit 33 Kit 41 Kit 49 Kit 62
E 64 Conga low ~ ~ Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. Conga elec. ~ ~ ~ Concert Cy.
F 65 Timbale high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Concert Cy.
66 Timbale low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ C. Cy. Roll
G 67 Agogo high ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
68 Agogo low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 69 Cabasa ~ ~ Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. Cabasa elec. ~ ~ ~
70 Maracas ~ ~ Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. Maracas el. ~ ~ ~
71 Whistle (2) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
C 72 Whistle (2) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Triangle op.
73 Guiro short (3) ~ ~ Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. ~ ~ ~ Triangle mu.
D 74 Guiro long (3) ~ ~ Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. Guiro elec. ~ ~ ~ Triangle roll
75 Claves ~ ~ Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. Claves elec. ~ ~ ~
E 76 Woodblock low ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
F 77 Woodblock hi ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Wind. dwn.
78 Cuica mute (4) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Wind. up
G 79 Cuica open (4) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
80 Triangle mute(5) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
A 81 Triangle open(5) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
82 Shaker ~ ~ Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. Shaker elec. ~ ~ ~
83 Jingle Bell ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
C 84 Bell Tree ~~~~~~~~~~~~
85 Castanet ~ ~ Zap Zap Zap Zap Zap Zap Zap ~ ~ ~
D 86 Surdo mute (6) ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~
87 Surdo open (6) ~ ~ ~ ~ ~
E 88 Applaus Applaus
F 89 C. Snare pp
90 Bass Dr. 1 mp BD 3 BD 5 BD 7 BD 7 ~ C. Snare p
G 91 Bass Dr. 1 mf ~ ~ ~ ~ ~ C. Snare mp
92 Bass Dr.1 f ~ ~ ~ ~ ~ C. Snare mf
A 93 Bass Dr. 1 ff ~ ~ ~ ~ ~ C. Snare f
94 Bass Dr .1 mp ~ ~ ~ ~ ~ C. Snare ff
95 Bass Dr. 1 mf BD 4 BD 6 BD 8 BD 8 ~ C. Snare pp
C 96 Bass Dr. 1 f ~ ~ ~ ~ ~ C. Snare p
97 Bass Dr. 1 ff ~ ~ ~ ~ ~ C. Snare mp
D 98 HiHat Pedal (7) ~ ~ ~ ~ ~ C. Snare mf
99 Hi Hat cl. Tip ~ ~ ~ ~ ~ C. Snare f
E 100 Hi Hat cl. Pearl ~ ~ ~ ~ ~ C. Snare ff
F 101 Hi Hat cl. Pearl ~ ~ ~ ~ ~ Snare Roll p
102 Hi H. cl. Shaft 1 ~ ~ ~ ~ ~ Snare Roll p
G 103 Hi H. cl. Shaft 2 ~ ~ ~ ~ ~ Snare Roll m
104 Hi Hat med. 1 ~ ~ ~ ~ ~ Snare Roll m
A 105 Hi Hat med. 2 ~ ~ ~ ~ ~ Snare Roll f
106 Hi Hat Open 1 ~ ~ ~ ~ ~ Snare Roll f
107 Hi Hat Open 2 ~ ~ ~ ~ ~ Snare Ro.dyn
C 108 Hi Hat Splash ~ ~ ~ ~ ~ Snare Ro.dyn
109 Hi Hat Open 3 ~ ~ ~ ~ ~ Snare Ro.dyn
D 110 Ride Pearl ~ ~ ~ ~ ~ Snare Ro.dyn
111 Ride Pearl retrig ~ ~ ~ ~ ~ Snare Ro.dyn
E 112 Ride Cup ~ ~ ~ ~ ~ Snare Ro.dyn
F 113 Ride Cup retrig. ~ ~ ~ ~ ~ Opera Gong
114 Ride Shaft (8) ~ ~ ~ ~ ~ Opera Gong
G 115 Ride Shaft retrig. ~ ~ ~ ~ ~ Opera Gong
116 Ride Chock (8) ~ ~ ~ ~ ~ Opera Gong
A 117 Cym Crash 1 (9) ~ ~ ~ ~ ~ Opera Gong
118 Cym Splash (9) ~ ~ ~ ~ ~ Opera Gong
119 Cym Crash 2 (9) ~ ~ ~ ~ ~ Opera Gong
C 120 Cym Chock (9) ~ ~ ~ ~ ~ Opera Gong
121 Brush 1. Cym. O. s (1) Opera Gong
D 122 Brush 2. Cym. O. s Opera Gong
123 Brush 3. Cy. O. m (1) Opera Gong
E 124 Brush Rm Cy. O. m Opera Gong
F 125 Brush metal Cy. . open(1) Opera Gong
126 Brush A Cy. O. op. (1) Opera Gong
G 127 Brush B Intro Tune
V3SOUND

16
84 - Portamento control 91 - Reverb send 93 - Chorus send 120 - All sound off 121 - Reset all controllers 123 - All note off 126 - Mono-mode 127 - Poly-mode
RPN 0000H BnH 65H 00H 64H 00H 06H vv Pitch bend sensitive in semitone (default=2)
RPN 0001H Fine tune in cent BnH 65H 00H 64H 01H 06H vv vv=00 -100 vv=40H 0 vv=7FH +100
RPN 0002H Coarse tune half tone BnH 65H 00H 64H 02H 06H vv vv=00 -64 vv=40H 0 vv=7FH +64
NRPN 18rrH BnH 63H 18H 62H rr 06H vv Pitch coarse of perc. rr in semitone (vv=40H->no modif)
NRPN 1ArrH BnH 63H 1AH 62H rr 06H vv Level of perc. sound rr (vv=00 to 7FH)
NRPN 1CrrH BnH 63H 1CH 62H rr 06H vv Pan of perc. sound rr (40H = middle)
NRPN 1DrrH BnH 63H 1DH 62H rr 06H vv Reverb send level of perc rr (vv=00 to 7FH)
AUX AUDIO OUT (Reverb return is fixed in Main out)
BnH 63H 38H 62H rr 06H vv rr = MIDI channel - CH1 = 00 CH2 = 01
vv = 0 MAIN 127=AUX Example :Set CH1 to AUX - send 3 MIDI controllers: For all parts with MIDI-channel 1 cc99 value 56 + cc98 value 00 + cc06 value 127
Program Change : 0-127 * depends on sound board System Exclusive: SYSEX F0H 7EH 7FH 09H 01H F7H General MIDI Reset SYSEX F0H 7FH 7FH 04H 01H 00H II F7H Master volume (II=0 to 127, default 127) SYSEX DSP1 F0h,41h,00h,42h,12h,40h,7Fh,7Fh,xxh,00h,F7h
xxh=Effect 00h=HALL1 01h=HALL2 02h=ROOM1 03h=ROOM2 04h=ROOM3“ 05h=PLATE1 06h=PLATE2 07h=PLATE3 08h=CHORUS 09h=FLANGE 0Ah=DELAY1 0Bh=DELAY2 0Ch=CHORUS/ROOM1 0Dh=CHORUS/ROOM2 0Eh=VOCCANCEL 0Fh=ROTARY SPEAKER
SYSEX DSP2 F0h,41h,00h,42h,12h,40h,01h,38h,xxh,00h,F7h xxh=Effect
0h=CHORUS 1 02h=CHORUS 3 04h=FEEDBACK 06h=SHORT DELAY
01h= CHORUS 2 03h=CHORUS 4 05h=FLANGER 07h=FB DELAY
Recognized
Basic Default 1 - 16 Mode 3 poly mode Messages Note number * 12-109 * depends on sounds Velocity Note ON 9nH,v=1-127 o Note OFF 9nH,v=0 x Key aftertouch o Channel aftertouch o Pitch Bend 0-12 Bank Select 00 * value depends on sound board - see page 3-13 Controller 01 - Modulation
05 - Portamento time 06 - Data Entry 07 - Volume 10 - Panorama 11 - Expression 64 - Sustain 65 - Portamento 66 - Sostenuto 71 - Filter resonance 72 - ENVELOPE Release 73 - ENVELOPE Attack 74 - Filter cutoff 75 - ENVELOPE Decay 76 - Vibrato rate 77 - Vibrato depth 78 - Vibrato delay
V3SOUND - MIDI IMPLEMENTATION
