VAC Vintage Line Stage Mk II User manual

ValveAmplification Company
VACStandardPreamplifierMk II
Instructions
Manual issued-3March2006
Pleasereadcarefully beforeinstalling
Copyright 2006 by ValveAmplificationCompany. All rightsreserved.

Page2
WELCOME
Congratulations on your purchase of the VACStandard MkII Preamplifier,and welcometo
the family of VACowners!
Your VACis designed not to the latest fad but to substance,providingthe highest quality of
sound. Timespent familiarizingyourself with this manual will be well rewarded.
Itis our goalto provide instruments of the highest quality,be informativeto all of our
customers, and to provide responsive, effectivecustomer service.
Please feel free to contact us if we can be of assistance. We can be reached:
Telephone[phone]
Fax[phone]
E-mail [e-mail]
Website www.vac-amps.com
We lookforward to beingof service,even as you havemany years of enjoyment fromyour
VACStandard Preamplifier.
Kevin M. Hayes
President, VAC
INTRODUCTION
The VACStandard MkII Preamplifier is an all new designderived fromthe VACPhi Beta,
and employs four twin triode vacuumtubes operatingin Class A.This unique design
providesgreat speed,detail,punch,andmusicality,allwithoutglobalfeedback.Itsmoderate
gain structure and low output impedance provides an excellent match with awide rangeof
popular power amplifiers.
The new highly shielded power transformer keepssignificant e.m.f.fields away fromthe
audio circuit,yet allows the source of power to be located close to the audio circuit’s
demands,resultingis fast,clear response to audio transients and highresolution of inner
detail.Low noise rectifiers further improvethe purity of the DC supplies,thus preserving
both the power and delicacy of the music. Heater voltageis precisely regulated to improve
tube life.
The chassis is rigid and non-magnetic.
Atriode MM phono stageor triode MC/MM phono stageare optional.

Page3
GENERAL PRECAUTIONS &SAFETY NOTES
1. DANGEROUSVOLTAGESEXISTWITHINTHE CHASSIS.DO NOT REMOVE
CHASSIS COVER UNTIL UNITHAS BEEN SWITCHED OFF AND
UNPLUGGEDFROMTHEWALLOUTLET(POWER)ANDALLCOMPONENTS
FOR15MINUTES.TUBESBECOME HOT INUSE,ANDCANCAUSEINJURY.
DO NOT EXPOSECHASSIS TO MOISTURE.DO NOT PLUG INTO ANAC
SOURCE UNTIL ALL CONNECTIONSARE COMPLETED AND ALL COVERS
ARE INSTALLED.
2.Complete all signal connections before connectingthe ACcord to the wall outlet and
turningthe unit on.Similarly,always turntheamplifier off and removethe ACpower
cord before detachingcabling.Failure to observethis sequence can result in damage
to the amplifier, speakers or associated components.
3.Atturn on,all volumecontrols should be full counter-clockwise.Allow one (1)
minute for warmup before disengagingmute and commencingplayback.Note: Mute
is automatically engaged when switchingon units equipped with the remote control
option.
4.For protection of your speakers and power amplifier, always engage“Mute” before
switchingthe power off or on.Note: Mute is automatically engaged when switching
on.
5. DO NOT OPERATE THE UNITIFITIS WET.
6. THE CHASSIS CONTAINSVACUUM TUBES.DANGEROUSVOLTAGES
EXISTWITHINTHIS CHASSIS.NEVER REMOVE THE COVER UNLESS THE
UNITHASBEENSWITCHEDOFFANDCOMPLETELYDISCONNECTEDFOR
ATLEAST15 MINUTES.THE TOP COVER MUSTALWAYSBE LEFT
SECURELYINPLACE.
7. Takecare to install your preamplifier securely in asturdy,well designed stand so that
it will not fall or tip over (this could cause serious, possibly fatal injury).

Page4
INSTALLINGTHE STANDARD MK II PREAMPLIFIER
Physical requirements:
1)Provide Adequate Ventilation.
2)The chassis cover will becomewarmduringnormal use.
3) This component must be installed in asecure, properly built (and ventilated) stand,
cabinet or enclosure. Itcould inflict serious injury or property damageif it falls,or
if the stand upon which it is placed tips over. This concern is particularly important
in households with small children who might try to climbfurniture.
Basic Hookup:
1)Connect line level inputs (CD,Tape,etc.)to the appropriate RCAinput jackson the
rear panel. With the exception of Phono (when fitted), all inputs are “line level”.
2)Connect phono cables to the rear panel RCAinput labeled “Phono.”Connect the
ground wire fromthe turntable or phono cable to the “Ground” terminal provided on
therearpanel.(See“PhonoSection”forcartridgetypesappropriateforuse.)Connect
output interconnects to your power amplifier.
3)Connect the ACpower cord to the IEC connector on the power supply.For best
performance, route the power cord away fromsignal cables.
4)Before turningthe power switch to the “on” position,set output level to zero by
rotatingthe “Volume” control fully counterclockwise.Note: Muteis automatically
engaged when switchingon.
5)Allow the preamplifier to warmup for aminute before you unmute the unit; failure
to wait can cause atransient to be sent throughyour power amplifier that might cause
damageto your loudspeakers and amplifiers.
6)Always mute the preamplifier before switchingit off.The best practice is to also turn
off your power amplifier(s) before turningoff the preamplifier.
Aswith all highperformance audio products,the sonic characteristics of all VACproducts
will continue to improveduringthe first several hundred hours of use.

Page5
OPERATINGTHE STANDARD MK II PREAMPLIFIER
Front Panel Controls:
Althoughmostofthefront panel controls (Volume,Power,Mute)areselfexplanatory,VAC
has outfitted this unit with several advanced features which bear further description:
Phono Section MM (option): When fitted, input “L6" will be connected to adiscrete, pure
tube phono preamplifier,providing40 dB of gain,suitable for use with MM (moving
magnet) and many high-output MC (movingcoil) cartridges.Your VACdealer can
recommend the proper phono cartridge(s).
Phono Section MC (option): Asabove,this will be fitted to “L6",and provides
approximately 60 dB ofgain.Itshould not be used with highoutput pickups,which may
generate excessivedistortion.Your VACdealers can recommend the proper phono
cartridge(s).AswitchonthebackpanelselectsbetweenMC(60dB) and MM (40 dB) mode.
Monitor: The small knob found at the lower left-hand corner of the faceplate switches
between“Source”,“Tape”,and“Cinema”(hometheaterpass-throughmode).Inthe“Source”
position,inputselection is determined bytheSourceSelectorSwitch.Inthe“Tape”position,
the Source Selector is overridden,and the Tape inputsare activated.[Important: The
StandardPreamplifierisoutfittedwithafull “tape loop”,includingalineleveltapeinputand
afixed level recordingoutput.Inaddition to drivingthe recordinginputs of atape deck,this
output can supply signal to any typical line level input,enablingit to control asecond zone
in multi roominstallations.]
The “Cinema” position provides access to one of the Standard MkII Preamplifier’s most
unusual feature.When set in the “Source” position,input choice is governed by the Input
Selector switch.This is the normal setting,and enables the unit to be used as atypical
preamplifier.Rotatingthecontrol clockwise to the “Cinema” position bypasses all
preamplifier controls (includingvolume) and passes the output fromyour surround sound
processor (i.e., the front left- and right-channel outputs of amultichannel processor) directly
to your power amplifier.Inthis case,the users’ analogstereo sources would be connected,
as usual,to the line,phono and tape inputs.A/V inputs (DVD,Laserdisc,DSS,etc.)would
be connected to the hometheater processor,and the processor’s main outputs would be
connected to the pair of rear panel RCAjackslabeled “HomeTheater Direct”.When the
control is set to the “Cinema” position,the Standard functions as apass-throughONLY,and
is controlled by the external processor,preamplifier,or other component connected to the
“HomeTheater Direct” inputs.
Mute: Thisknob is springloaded; movingthe control clockwise will toggle between the
“Mute” and “Operate” condition.When muted,ared glow will be observed in the LED.On
occasion the preamplifier may seemnot to haveresponded to aturn of the “Mute” knob; this
is due to “contactbounce” in the switch.Simply turn the knob again until the desired

Page6
condition is attained.
REMOTE CONTROL
The remote control allows for wireless adjustment of “Mute” and “Volume”.
The remote wand is powered by two “AAA”batteries.These should be of the alkaline type.
You will need to install themin the wand before usingthe remote.Since batteries can leak,
they should be removed fromthe wand if it is not goingto be used for an extended period
of time.
VolumeUp/Down: These buttons cause amotor to turn the volumecontrol.Motorized
controls offer superior sound,as well as direct visual indication of volumesetting.The front
panel control may also be used directly in the conventional way.
Mute: Pressingeither side of the “Mute” button will toggle between the “Mute” and
“Operate” condition.When muted,ared glow will be observed in the LED indicator.Mute
is automatically engaged when switchingon units equipped with the remote control option.
NOTE ON ABSOLUTE PHASE
Throughthemain RCAoutputs the Standard Preamplifier MkII inverts absolute phase.
There is somedebate abouttheaudibilityof absolute phase,and it generally is not controlled
for by the recordingindustry (i.e., about half of your recordingsmay haveinverted absolute
phase).
Ifyou wish to correct your playbacksystemfor absolute phase,this is easily accomplished
in the connections to your loudspeakers.Assumingthat your source component(s),power
amplifier,and loudspeakers do not invert phase,you can correct for the inversion of the
Standard Preamplifier by connectingthe positiveoutput terminals of your amplifier(s) to the
negativeterminals of your loudspeakers, and the negativeterminals of your amplifier(s) to
the positiveterminals of your loudspeakers. Sonically, this is absolutely transparent.

Page7
MAINTENANCE
Chassis Care:
Althoughyour VACchassis and faceplate are extremely durable,their finish can be
scratched,chipped or damaged if improperly treated.Cleaningwith asoft,dampcloth while
the amplifier is switchedoff andunplugged should restore the finish to its original lustre.
Never clean this component with harsh or caustic cleansingagents.
When shippingyour unit,be certain to wrap the amplifier in the cloth,tissue or plastic wrap
in which it was originally packaged.Given the highgloss of the lacquered finish,makesure
there are no ridges or sharp surfaces in those parts of the cloth which contact the faceplate.
Use of acoarser cloth or failure to otherwise protect the faceplate may result in damageto
the finish.VACis not responsible for cosmetic damageresultingfromimproper care or
packing.
InstallingNew Tubes:
Original Equipment Replacement tubes are available fromVAC.These tubes ensure your
Standard Preamplifier will meet or exceed all factory performance specifications.
DANGEROUSVOLTAGESEXISTWITH THIS COMPONENT.YOU MUSTFOLLOW
THESESTEPSTO PROTECT YOUR SAFETY. Before replacingtubes,all power must be
turned off.Unplugthe power cord fromthe wall,and removeall audio interconnect cables.
Wait 15 minutes before removingthe top cover.Install the new tubes fully firmly in their
sockets,takingcare to makesure that pin pattern corresponds to holes in tube socket.
Reinstall the top cover before reconnectingthe unit.
NEVER INSTALL OR OPERATE THIS UNITWITHOUT ALL COVERSINPLACE.
Inthe event that trouble is encountered,checkall signal,speaker and power connections.If
theproblempersists,followallsafetyprecautionsstatedearlierinthissection,andcheckthat
all tubes are correctly seated in their sockets.Ifpossible,try another tube.Ifthe problem
persists, please consult your VACdealer or contact the factory directly.

Page8
GENERAL INFORMATION ABOUT TUBES
Itis atruth that each brand of tube sounds different in aparticular highresolution circuit.
This is because no two manufacturers makeatube type in quite the sameway,and the
central tendencies of the performance parameters will differ slightly with each maker.This
sonic variability may at first seemaliability,but further thought will reveal that it is an
advantage.The owner of atube amplifier can select those tubes which sound likethe real
thingin his/her specific system. VACcan recommend the best tubes for your amplifier.
The tube types used in this component should last for 8,000 to 15,000 hours of use (two to
ten years for most users).There are always occasional exceptions,longor short.Ifyou have
to replace atube before,say,3,000 hours,just replace the single tube.Ifyou haveto replace
atube at 8,000 hours, replace themall and keep those still functioningwell as spares
VACwill be happy to test tubes for concerned customers.
WARRANTY
Your equipment is warranted for aperiod of thirty (30) days fromthe date of purchase.
Inaddition,if the registration formis received by VACalongwith acopy of your sales
receipt froman authorized VACdealer within this thirty days,aservice contract will be
extended to cover your equipment for three (3) years (tubes excepted).
This warranty applies only to units sold in the United States of America throughauthorized
VACdealers,and operated within the U.S.by the original purchaser.Itcovers factory
service,and,in the continental U.S., standard returnshipping.For warranty information
outside of the U.S.contact the importer of VACequipment for your country.Units sold
outside of the U.S.should still be registered with VAC.Itis the responsibility of the dealer
and/or customer to determine the suitability of this product for any particular application.
Your questions and comments are always welcome. Contact:
ValveAmplification Company, Inc.
1911 East Avenue North
Sarasota, FL34234
Telephone[phone]
Facsimile941 952 9691
E-mail [e-mail]

Page9
VAC STANDARD MK II PREAMPLIFIER SPECIFICATIONS (typical)
Type:Vacuumtube line stagewith external power supply and home
theater (direct power amplifier) mode.
Options:Remote control for volume&mute
Dedicated MM phono input
Dedicated MC phono input
Linestage preamplifier:
Gain:24 dB
Maximuminput signal:Essentially infinite (attenuation precedes line stage)
Main output:Invertingto RCA
Pin 2positive“hot” on XLR, pin 3negative
Tape output:Unity gain fromselector, non-inverting(archival correct)
Phono stage preamplifier (optional):
Gain:40 dB (measured at tape output)
Residual noise:3mVat output (S/N ratio approx. 69 dB)
Overload:117 mV@1kHz =8volts RMSoutput
460 mV@10 kHz
Frequency response:RIAA +/- .25 dB
Notes:Does not invert absolute phase.
Tubecompliment:
3x12AX7 (phono option) (located on circuit board at left side of chassis)
2x12AU7/6189A(line stage)
2x12AX7 (line stage)

STANDARDMKII PREAMPLIFIERREGISTRATION
mailtoVACsoon aspossible.
Name______________________________________________________________
Address______________________________________________________________
______________________________________________________________
Telephone______/______-_____________E-Mail __________________________
Dealername______________________________________________________________
"address______________________________________________________________
Purchasedate______________________SerialNumber__________________________
Salesperson______________________________________________________________
HowdidyoufirstlearnofVACproducts?
__________________________________________________________________________
Whatotherbrandsandmodelsdidyouconsider?
__________________________________________________________________________
__________________________________________________________________________
WhatmadeyoudecideontheVAC?
__________________________________________________________________________
__________________________________________________________________________
PleaseprovideanycommentsonVACproductsoryourdealer
__________________________________________________________________________
__________________________________________________________________________
Whatmagazinesdoyoureadregularly?
________________________________________________________________________
________________________________________________________________________
Whatareyourhobbies?
________________________________________________________________________
Whatareyourfavoritetypesofmusic?
________________________________________________________________________
________________________________________________________________________
