VAC Phi Beta Triode Setup guide

TheVACPhiBeta
TriodePreamplifier
Operation&MaintenanceInformation
ValveAmplificationCompany
Manualissued02/15/2008

1
CAUTION
THEPREAMPLIFIER ANDPOWER SUPPLYCONTAINPOTENTIALLYLETHAL VOLTAGES,AND
TUBESTHAT BECOMEHOT IN USE.
NEVER OPERATETHEPREAMPLIFIER ORPOWER SUPPLYWITHTHECOVERSREMOVED.
DONOT REMOVETHECHASSISCOVERSEXCEPT TOCHANGETUBESORLIGHT BULBS.
BEFORE OPENINGACHASSISTOCHANGETUBESORLAMPS,DISCONNECTTHEPOWER
SUPPLYFROMACPOWER ANDTHEAUDIOCHASSISFROMALL OTHER COMPONENTS.
ALLOWITTOSITTURNEDOFF FOR30 MINUTESBEFORE REMOVINGTHECOVER.REPLACE
COVER ANDSECURELYATTACHBEFORE RECONNECTINGANDOPERATING
DONOT OPERATETHEUNITSIF THEYARE WET.
VACUUMTUBESBECOME HOT ENOUGHTOCAUSESERIOUSBURNS.NEVER TOUCHATUBE
WHENTHEUNITISON.ITMAYTAKESEVERAL MINUTESFORTHETUBESTOCOOLDOWN
AFTER THEUNITISSWITCHEDOFF.ITISSTRONGLYRECOMMENDEDTHAT THETUBECOVERS
BELEFT IN PLACEAT ALL TIMES.
THEAMPLIFIER ANDPOWER SUPPLYARE HEAVY.ITISADVISABLETOHAVEASSISTANCEIN
UNPACKING,MOVING,ANDSETTINGUP.BESURE TOUSEPROPER LIFTINGTECHNIQUESTO
AVOIDBACKSTRAINANDINJURY.BECERTAINTOINSTALL ITINASECURE LOCATIONFROM
WHICHIT CAN NOT FALL ORTIPOVER.
CONTENTS
Introduction
Installation
Inputs(backpanel)
Outputs& Grounding Switch(backpanel)
Operation
Fuses
Front Panel Controls
RemoteControl
Replacement ofTubes
CareofChassis
A WordAbout Tubes InGeneral /Locating aDefectiveTube
Warranty /RegistrationForm

2
INTRODUCTION
ThePhiBetaPreamplifieristheworld'sfinestaudio preamplifierand anabsolutely unique
component.Itsunusualtopology,premiumparts,and flexibilitymakeitapleasuretohear
and operate.
Thelinestageis,ineffect,asmall Class A1poweramplifier,capableofdriving loadsaslow
asafewhundredohms.Thisisastarkcontrasttonormalpreamplifiers,whichclaim alow
output impedancebut completely collapse whenaskedtodelivercurrent.ThePhicircuit
isloafingwith anormalloadinthe10,000 to200,000 ohmrange,deliveringaneffortless,
musical performance.
Thereisnoloopfeedbackand nocouplingcapacitorsinthelinesection.All active
elementsaretriodetubes,thepurest,mostlinearamplifying devices yetinvented.Output
matchingisaccomplishedbywayofsuperboutput transformers.Asasidebenefit,different
output groundingconfigurationsarepossible,optimizingperformanceintoeitherbalanced
orsingle-endedloads,and allowing ground loopsto bebroken.
Theoptionalphonostageuses triodetubes operatingwithout loopfeedback.Gainis
moderately high,with averylownoise floor.Lowoutput MC cartridges areaccommodated
bymeansofhighqualitymatchingtransformers,whichcontributevoltagegainwithout noise,
resulting indetail thatemerges from aremarkably darkand neutral background.
Remotevolumecontrol isimplementedviaamotorizedmechanicaldevice.Thisprovides
twomajoradvantages.First,thecontrol iscompletely intuitivetouse.Second,weavoidthe
sound degradationattendant with VCAs,transistorswitches,and switchedresistorarrays.
Eachchassisisfabricatedfrom non-magneticaluminum.Theseparatepowersupply allows
e.m.f.fields,switchingtransients,and mechanicalvibrationtobeisolatedfrom theaudio
circuits.
ThePhiBetaPreamplifierisdesignednotto thelatestfadbut to substance,forthehighest
possiblesound quality.Timespent familiarizingyourselfwith thismanualwill bewell
rewarded.

3
INSTALLATION
1)Provideadequateventilation.
2)Do notoperateoncarpetorany othersurfacethatmight blockairflow.
3)Thechassiswill becomewarm innormal use.
4)Do notallowthechassistotouchanymetalparts,suchastheframeofanequipment
rack.Thismight createaparallelground path thatcoulddegradethesound ofyour
system.
5)Input connectionisviasingleendedRCAjacksorXLRjacks(whichcanbefrom
balancedorunbalancedsources).Fortheinputsthatcanaccept eitherXLRorRCA
connectors,besurethattheassociatedswitchissetcorrespondingly.Connectline
levelinputs(CD, Tuner,Tape,etc.)totheappropriateRCAinput jacksontherear
panel.Note:with theexceptionofPhono (whenfitted),all inputsare"linelevel."
6)Output tothepoweramplifiercanbesingle-endedonRCAjacksorbalancedon
XLRjacks,but notboth simultaneously.Theoutput modeswitchmustbesetto
matchtheconnectionsused.IMPORTANT:READTHESECTIONON"OUTPUTS&
GROUNDINGSWITCH."
7)Output toarecordingdevice(taperecorder,CDrecorder,etc.)maybeobtained
from the“TAPEOUT”jacks.Theadjacent switchfor“TAPEOUT”mustbesetto ON.
Ifyoursystem does nothavearecorder,thisswitchshouldbesetto OFF.
8)Foroptionalphonostageonly:Connectphonocables totherearpanelMM and/or
MC inputslabeled"Phono"(both maybeusedinthesamesystem,astheyare
switchedbyacontrol onthefront panel).Connecttheground wire(s)from the
turntable(s)orphonocable(s)tothe"Ground" terminalprovidedontherearpanel.
9)Connectthepowercablefrom thepowersupply tothepreamplifier.Besureto
inserttheconnectorproperly,and fully tightenthelocking screws.
10)Connectthepowersupply tothepowersourceindicatedontherearpanel,either
100,120,220,or240 voltsAC.Thevoltageissetatthefactory.Avoidpower
conditionersthatfloattheground pin.ALWAYSconnectpowercordtocomponent
beforepluggingitintoanACoutlet.Forbestperformance,trytoroutethepower
cordaway from signal cables.

4
11)Pay close attentionto powerquality,and beawarethatdifferent powercordscan
alterthesound.Thepowersupply’sbacklitmetersshowvariationinpowerline
voltageasreflectedto theaudio circuitry.
12)12 volttriggersareprovidedforcontrol ofotheraudio components.

5
INPUTS(backpanel)
Inputs#1,#2,and Cinemamaybeeitherunbalancedorbalanced.Three connectionsare
possible:
1)Singleendedsignal onRCA connector.Setadjacent switchto “RCA.”
2)Balancedsignal onXLRconnector.Setadjacent switchto “BAL.”
3)SingleendedsignalonXLRconnector.Setswitchto“BAL.”Alternatively,youmaysetthe
switchto “RCA”ifand only ifthesourceis“pin2hot.”
OnepairofRCA jacksaccommodatethemonitorreturnfrom atapedeck.Ifyoudo not
haveatapedeck,these jackscanbeusedasanadditionallinelevelinput.Ifusingthetape
outputs,theTAPEOUT switchmustbesetto “ON.”
Twophonoinputsareprovidedfor"MC" and "MM" cartridges.Theground leadfrom the
turntableshouldbeconnectedto thebinding postlocatedby these jacks.
OUTPUTS& GROUNDINGSWITCH(backpanel)
OnepairofRCAjacksprovidelineleveloutput toataperecorder.Thelevelofsignalisnot
adjustedbythevolumecontrol.Ifusingthetapeoutputs,theTAPEOUTswitchmustbeset
to “ON.”
TwosetsofRCAoutput jacksareprovidedasmainoutputstopoweramplifiers.Inaddition,
two pairofXLRjackscanbeusedto driveapoweramplifier.The“OUTPUT MODE”switch
mustbesetaccordingly.Only onemodemaybeused,i.e., youcannotmixbalancedand
single-endedpoweramplifierconnections.

6
OPERATION
Turnthe"Volume"control fully counterclockwise.
Muteisautomatically engagedwhenswitching ontheunit.
Allowthepreamplifiertowarmup foraminutebeforeyouun-mutetheunit; failuretowait
cancause atransient tobesent throughyourpoweramplifierthatmight cause damageto
yourloudspeakers.
PLEASEREADTHESECTIONONFRONT PANELCONTROLSBEFORE USINGTHEPREAMPLIFIER.
Aswith all highfidelityproducts,thesound characteristicoftheVACchanges somewhat
asitwarmsup.Bestsound will beachievedafterabout 15 minutes ofoperation.
AnytimethatthePhiPreamplifierhasnotbeenusedforafewweeksthesound maybe
different.Thisisalsonormalforhighresolutionaudio equipment.Optimumsound should
returnafterafewhoursofoperation,preferably with anaudio signal.
NotethatalthoughyourVACSystemhasbeenrun for48 hoursatthefactory,itwill
continueto "break in" forapproximately 150 hours.Also beawarethatmany components
displaytheneedforanewbreak inperiodafterbeingtransportedinunheatedcargo
aircraft.
FUSES
Thefuse islocatedbehindinatrayabovetheACpowerconnector;thefuse carrier
containsthefuse being used,aswell asaspare.
For220 or240 voltoperation,please use a1.0amperefuse.For100 or120 voltoperation,
thefuse shouldbe2.0amperes.
Voltageconversionsmustbeaccomplishedatthefactoryorviatheimporterforyour
country.Please consultthefactory formoreinformation.

7
FRONT PANEL CONTROLS
Althoughmostofthefront panelcontrols(Volume,Power,Mute)areselfexplanatory,VAC
hasoutfittedthisunitwith several advancedfeatures whichbearfurtherdescription:
Power:Turnstheunitoff and on.
Mute:Toggles betweenthe"Mute"and "Operate"condition.Whenmuted,the
indicatorlight isilluminated.
Tape:Thisswitchselectsbetweenthesignalcomingfrom themainselector(light
out)orthesignal connectedto the“TAPEIN”jacks(light on).
Cinema:Thisswitchselectsthesourceconnectedto the“CINEMA”input jacks.
Volume(switch):
Thisswitchallowsanyinput (except Phono)tobelevelcontrolled(VARor
variable)bytherotaryVOLUMEcontrol,ortobeproducedataSET(fixed)
level.To setthisfunction,hold thetoggleswitchinthedirectionofthe
desiredsettingforfiveseconds,until theindicatorlight changes from blinking
to solidillumination.
IntheVARIABLEmode,thePhi functionsasaconventional preamplifier.
TheSETmodeallowsthecontrol ofvolumetobedeterminedentirely bythe
sourcecomponent.ThisisusefulwhenthePhiBetaPreamplifierisbeingused
asanelement ofamultichannelorhometheatersystem,with thelevelofall
5.1channelsbeing setby theplayerorthedecoder.
TheSETmodemayalsobeusedwith,forexample,aCDplayerthathasits
ownvolumecontrol.Inthisway,thePhi’svolumecontrol isbypassed.Some
audiophiles wouldconsiderthisto bea“hotrod”mode.
Note:TheTapeMonitorinput takes thesamesetting asthesourceinput.For
example,iftheSELECTORisoninput #1and #1issetup inaSETmode,
whenyouengagetheTAPEmonitoritwill alsobeintheSETmode,and the
VOLUMEcontrol will notchangethesound level.Conversely,ifinput #2isin
theVARmode,thentheTAPEmonitorwill alsobeintheVARmode,and the
volumecontrol will function. Therefore,itissuggestedthattheinput be
configuredto VARbeforerecording and monitoring isstarted.

8
Phono:SelectsbetweentheMM and MC inputs.Overall phonofunctionisselected
with themainSelectorswitch(phonoisoneclickcounterclockwise from “1”
oroneclickclockwise from “6”).
PH1 istheMC phonoinput.Ithas64 dBofgain,makingitsuitableformost
lowoutput cartridges.
PH2 istheMM input,whichprovides 44 dBofgain,suitableforuse with MM
(moving magnet)and many high-output MC (moving coil)cartridges.
Optionally,PH2 may beasecond MC input.
Both PH1 and PH2 maybeconnectedinthesamesystem,sothatinessence
therearetwo phono inputs,selectablefrom thefront panel.
Selector:ThisswitchselectsbetweenIN1throughIN6and thePHONOinputs.Rotate
counterclockwise to movedownthroughtheinputs,clockwise to moveup
throughtheinputs.
Volume:Controlstheoutput levelforthePHONOinput,and any lineinput setto the
“VAR”LEVELmode.Note:itispossiblethatoneorboth channelsmaynot
shut off completely inthefully counter-clockwise position,and thatchannel
balancemay skewatwhisperlevels.
Meters:Indicatetheoperatingvoltages withintheunit.Thiswill varysomewhatdue
to fluctuationsinpowerlinevoltage.

9
REMOTECONTROL
Theremotecontrol allowsforwireless adjustment ofPOWER,SELECTOR,TAPEMONITOR,
CINEMA,MUTE,and VOLUME.
Theremotewand ispoweredbytwo"AAA"batteries.These shouldbeofthealkalinetype.
Youwill needtoinstall theminthewand beforeusingtheremote.Sincebatteries canleak,
theyshouldberemovedfrom thewand ifitisnotgoingtobeusedforanextendedperiod
oftime.
Besureto observethepolarity diagram insideth battery compartment.

10
REPLACEMENT OFLOWLEVEL TUBES
Phono tubes aretype12AX7/ECC83;youmay wishto use lownoise testedtubes.
Linestagetubes aretype8416,no substitutetypes areacceptable.
Westrongly recommend thatyouuse only tubes specifically selectedand testedby
VACforthisapplication.
Beforereplacing tubes,all powermust
beturnedoff.Allow15 minutes forthe
tubes to cool downand voltages to
dischargebeforeremoving thetop
cover.Thevoltages insidetheunitmay
belethal innormal operation.NEVER
OPERATETHEPREAMPLIFIER WITHOUT
THECOVER INSTALLED.
Install newtubes firmlyintheirsockets,
notingthelocationofholes inthesocket
and pinsofthetubes,takingcareto
makesurethatpinpatterncorresponds
toholes intubesocket.Replacethe
coverbeforereconnectingand operating
thepreamplifier.
Intheevent thattroubleisencountered,
checkall signal,speakerand power
connections.Iftheproblempersists,
followall safety precautionsstatedearlier
inthissection,and checkthatall tubes are
correctly seatedintheirsockets.If
possible,tryanothertube.Iftheproblem
persists,please consultyourVACdealer
orcontactthefactory directly.
Tubes arelikethetires onacar;theywill eventually needreplacement.Murphy'sLaw states
thatatubewill probably fail right atthestartofalongholidayweekend.Therefore,many
audiophiles keepasparetubeofeachtypeonhand,justincase!
VACcantesttubes forconcernedcustomers.

11
TIPS & ADVICESECTION
A WordAbout Tubes inGeneral
Itistruethateachbrand oftubesoundsdifferent inaparticularhighresolutioncircuit.This
isbecause notwo manufacturersmakeatubetypeinquitethesameway,and thecentral
tendencies oftheperformanceparameterswill differslightly with eachmaker.To emphasize
thepoint,examinetheplatestructureofanytwo6SN7from differentmanufacturerswill
probably find thattheymaynoteventhesameshapeand size.(Becarefulhere,asoften
atubeismadebyafirmotherthanindicatedonitslabel.Intheheydayoftubes itwas
commontocrossbrand betweenmajorlabels,suchasGEand RCA.Todaymanylabelsdo
notmanufacturetheirtubes atall,including GoldAero and RAM.)
Thissonicvariabilitymayatfirstseemaliability,but furtherthought will revealthatitisan
advantage,justliketheabilitytoadjustVTA onatonearm.Theownerofatubeamplifier
canselectthose tubes whichsound liketherealthinginhis/herspecificsystem.Ofcourse,
ifthemanufactureryoupreferisrareyoumay want topurchase afewsparetubes forthe
future.
Howlong shouldtubes last?Ithaslong beenknowninprofessional circles (and probably
nowforgotten)thatatubesuchasthe12AX7will displaybetter performance
characteristicsaftertwo years ofcontinual operationthanwhenitwasnew.Innormal use
itisnotunusualforalowleveltubetolast5yearsorlonger.Output tubes areanotherstory,
astheyarecontinually providingsignificant amountsofcurrent.Herethesound isyourbest
guide.Certainlyatubeshouldbereplacedwhenitsemissionissignificantly downorits
transconductanceissubstantially out ofspecification.Innormaluse,outputtubes will last
atleast2yearsand perhapsmorethan5years.
Intheevent ofunusualnoiseinonechannel,oraloss ofsoundinonechannel,abadtubemay
belocatedeasily.Iftheproblemisaudible inthelinestage,exchangethetwo8416 tubes;ifthe
problemchangeschannelsthenyouhavefoundthebadtube.Iftheproblemisonly audible on
phono,swaptherearpair,thenthemiddle pair,thenthefront pair,eachtimelisteningtosee if
thesymptom followsthetube.
VACcantesttubes forconcernedcustomers.

12
CARE OFCHASSIS
VACchassisaremadefrom aluminumforsuperiorelectromagneticperformance.Themain
chassisisfinishedinadurableblackpowdercoatpaint,whilethefasciasarehand rubbed
acryliclacquer.Thelacquershouldbetreatedinmuchthesamefashionasahighquality
automotivefinish.
Neverapply anydampness orcleaningproducttoaunitthatispluggedin.Do notget
cleaning solutionsonto orinto thetubesockets.

13
WARRANTY
Your equipmentiswarranted for aperiod ofthirty(30) daysfromthe dateofpurchase.In addition,ifthe
registrationformisreceived byVACalongwithacopyofyour sales receiptfromanauthorized VACdealer
withinthisthirtydays,aservicecontractwill beextended tocover your equipmentfor two (2)years (tubes
excepted). Thiswarrantyapplies only tounitssoldinthe United States ofAmericathroughauthorized VAC
dealers andoperated withinthe United States bythe originalpurchaser.Itcovers factoryserviceand,within
the continentalU.S.,standard return shipping. For warrantyinformationoutside ofthe U.S.contactthe
importer ofVACequipmentfor your country.Unitssoldoutside ofthe U.S.shouldstill beregistered with
VAC.Itisresponsibilityofthe dealer andcustomer todetermine suitabilityofthisunitfor agiven application.
Your questions andcommentsare alwayswelcome.Contact:
ValveAmplificationCompany
1911 EastAvenue North
Sarasota, FL34234
Telephone [phone]Fax[phone]
[e-mail]
_____________________________ Detach and mail totheaddress above assoon aspossible. ____________________________
PhiBeta PreamplifierRegistrationForm
Name________________________________________________________________________
Address________________________________________________________________________
________________________________________________________________________
Telephone_______/_______-_____________e-mail __________________________________
Dealer name________________________________City________________________________
Salesperson___________________ Purchase date____________SerialNumber ________________
How didyoufirstlearn ofVACproducts?____________________________________________________
What other brands/modelsdidyouconsider?_________________________________________________
_____________________________________________________________________________________
What made youdecide onthe VAC?_______________________________________________________
_____________________________________________________________________________________
What else wouldyoulikeus toknow?_______________________________________________________
_____________________________________________________________________________________
_____________________________________________________________________________________
Optional:
What magazines do youreadregularly?________________________________________________________
What are your hobbies (besides fillinginwarrantycards)?_______________________________________
What are your favoritetypes ofmusic? ______________________________________________________
_____________________________________________________________________________________
On what format?(CD,LP,DVD,SACD,MP3,etc.) ______________________________________________
