Vacron VDH-NK205A User manual

VDH-NK205A
Hardware Manual
2015 JUL V1.2

VDH-NK205A Hardware Manual
i
Contents
A. CAUTION .............................................................................................................................................. 1
B. Introduction ......................................................................................................................................... 2
1. Product Overview ..................................................................................................................... 2
2. Main functions ........................................................................................................................... 2
C. Unpacking ............................................................................................................................................ 3
1. Accessories ................................................................................................................................. 3
2. Unpacking ................................................................................................................................... 3
D. Installation ............................................................................................................................................ 3
E. Product appearance ......................................................................................................................... 4
1. Front Panel .................................................................................................................................. 4
2. Rear Panel ................................................................................................................................... 5
3. Installation Illustration ............................................................................................................ 6
 Video input ....................................................................................................................... 6
 Connections for video outputs ................................................................................. 7
 Audio Inputs..................................................................................................................... 7
 Audio Output ................................................................................................................... 8
 AlarmIn/AlarmOut connections ............................................................................... 8
F. Q & A and Maintenance ................................................................................................................. 9
1. Q & A............................................................................................................................................. 9
2. Maintenance ........................................................................................................................... 11
G. Appendix : Specifications ............................................................................................................ 12
1. 8CH NVR ................................................................................................................................... 12

VDH-NK205A Hardware Manual
1
A. CAUTION
To our dear customer!
Thank you for using our products. If you encounter any problems when using,
please do not hesitate to contact our resellers. We will provide excellent services to
you via our resellers.
The software/hardware improvements of this series are subject to change without
notice to you in advance. Before using, please read this user manual carefully to
ensure that you can use the device correctly and safely.
Caution for this NVR series
After installation, never put anything heavy over this device. Owing to the use
of the harddrive(s) insides this device, check the cooling fan periodically to see
if it is in good condition. Never use this device when the cooling function is
out of order!
Do not allow any solid object or liquid fall into or penetrate into the device.
Use cleaning tools (brushes) regularly to clean circuit boards, connectors, fans,
chassis, etc. Before cleaning, turn off the power and unplug the power.
Do not attempt to disassemble the equipment, repair, or replace parts. In case
the machine does not work properly, please contact the resellers or
manufacturers. In the shortest time, we will solve the problems you have
during using.
When not using the remote control for a long time, take out the inside battery
To prevent the control from the damage coming from battery leakage!
If this equipment connects to outdoor cameras or other external alarm
devices, ground this equipment to prevent it from electrical surges.
This NVR supports remote video monitoring via Internet. Free or non-free
domain names provided by ISPs are needed for the monitoring functions.
Free domain names may sometimes have problems and nothing to do with
NVR. Non-free domain names have less problems. Choose the domain names
carefully before using the networking function.
Operating environment
Keep and use this device at places where temperature ranges 0℃~40℃. Avoid
direct sunlight or near heat sources.
Do not install this equipment in a humid environment
Do not expose this equipment in smoky, dusty environments;
Avoid strong collision, do not drop the machine
Keep the installation level, install in a stable place, avoid the product falling;
Do not block any ventilation openings. And ensure well ventilation around the
machine
Please use this equipment within rated input and output current/voltage
range.
This device is for long-time use. For safety, do not have flammable items
placed next to the device.

VDH-NK205A Hardware Manual
2
B. Introduction
1. Product Overview
This equipment is an excellent digital surveillance product designed
specifically for the security use. Using embedded LINUX operating system, it
makes the system more stable. Using standard H.264 video compression and
G.711A audio compression technology achieves audio and video functions
such as high-quality, low bit rate and single-frame playback. Using TCP / IP
and other network technologies, it provides strong network data transmission
capacity and remote control capabilities.
This equipment can be used individually or be connected to form a powerful
security monitoring network. Using professional network video surveillance
software platform, be fully experienced the powerful networking and remote
monitoring capabilities.
This equipment can be used for security in banks, telecommunications, power
stations, justice, transport, intelligence communities, factories, warehouses,
resources, water conservancy facilities and other categories.
2. Main functions
Auto detect IP camera in LAN.
Multiplex and maximize hard drive performance.
Sequence feature for easy liveview monitoring.
Motion events mark on time bar for faster event searching during
playback.
P2P functionality.
QR Code scanning for fast auto connection.
Cloud real-time monitoring.
Support SATA / SATA II hard drive up to 8TB.
Support Power Over Coaxial (PoC).

VDH-NK205A Hardware Manual
3
C. Unpacking
1. Accessories
★ Power cable and adaptor AC100-240V/DC12V 4.16A x 1PCS
AC100-240V/DC12V 4.8A x 1PCS
★ HDD screws x 8pcs
★ Operation CD x 1pcs
★ Mouse x 1pcs
2. Unpacking
When you receive the product, check first whether the packing of the
equipment has obvious damage. The protective material used for the package
during transport can cope with most of the accidental impact
Then, take out the device, remove the protective film of the digital video
recorder and check if there is any visible damage;
Finally, open the case, check the front panel data cable, power cord, power
supply fan and motherboard to see if they are connected firmly.
Front/Rare panels
The key functions of the front panel and the interfaces of the rear panel are
described in detail in the manual.
Please carefully check the plate or foil on the rear panel of the product to see
if it is the model you ordered.
Inside check
In addition to checking for visible signs of damage, be careful to check the
connections between the front panel data cable, power cord and
motherboard.
D. Installation
Steps and cautions:
1、Room temperature below 35℃
2、Reserve space for air circulation around 15 cm (6 inches)
3、Chassis installation starts from bottom to up
4、With multiple components in the chassis, take precautions to avoid
overloading to the power outlet.

VDH-NK205A Hardware Manual
4
E. Product appearance
1. Front Panel
MENU Going to Menu
ESC ESC Exit
■ /SEQ Stop Stop when Playback
INFO INFO Information Page
Backward
When playing back，there are 2*、4*、8*、
16*、32*、1/2*、1/4* backward speeds.
Under live page、2Ch and 9Ch can be
changed
Forward
When playback，there are 2*、4*、8*、
16*、32*、1/2*、and 1/4* forward speeds
Under live mode, 2Ch and 9Ch can be
changed
Play
Pause
Under Live mode, going to broadcast and
copy; however, under playback mode, going
to broadcast.
Pause
PLAY/LIVE Playback
LIVE
Under LIVE mode, going to playback.
Under playback, going to LIVE mode.
REC Record Under LIVE mode, going to manual force
recording.
Power One touch, turn on and press 3 second, turn
off.
Up
Down
Under UI mode, select UP or Down
Left
Right
Under UI mode, select right or left.

VDH-NK205A Hardware Manual
5
Confirm Confirm each operation
1 KEY_1 Preview the 1th Ch
2 KEY_2 Preview the 2th Ch
3 KEY_3 Preview the 3th Ch
4 KEY_4 Preview the 4th Ch
5 KEY_5 Preview the 5th Ch
6 KEY_6 Preview the 6th Ch
7 KEY_7 Preview the 7th Ch
8 KEY_8 Preview the 8th Ch
9 KEY_9 Preview the 9th Ch
0/+10 KEY_0/+10
Preview the 10th Ch or press the same key 3
second, then press 1 or 2, going to 11th or 12th
Ch.
Power Power Indicator Power on
LAN Network
Indicator Network on
REC Recording
Indicator NVR recording function on
PLAY Play Back
Indicator Playback
2. Rear Panel
1 DC48V
2 POC DIP SWITCH
3 IP CAMERA + POWER SUPPLY

VDH-NK205A Hardware Manual
6
4 LAN
5 E-SATA
6 AUDIO OUT
7 VGA
8 HD OUT
9 USB 3.0
10 USB 2.0
11 DC12V
POC DIP SWITCH / IP CAMERA + POWER SUPPLY / LAN
3. Installation Illustration
Video input
Input interface is RJ-45 type; input signal is IP CAM
The Video signal should comply with national standards, a higher signal to

VDH-NK205A Hardware Manual
7
noise ratio, low distortion, low-interference; clear images, no deformation,
nature color and appropriate brightness.
Make sure stable and reliable signals from cameras
Cameras should be installed in a suitable position to avoid backlighting,
low-light environment, or adopts the better BLC, low-light cameras.
Cameras and digital video recorders should be common ground, stably and
reliably, in order to ensure the normal operation of the cameras.
Make sure the transmission cables are stable and reliable
Adopt high-quality, well-shielded coaxial cables, and choose the right model
based on the transmission distance. If the distance is too far, use shielded
twisted pair, video compensation equipment, optical transmission and other
ways to ensure signal quality based on the specific circumstances.
Video cable should avoid strong electromagnetic interference with other
devices and circuits, in particular, should avoid the current of high voltage.
Make sure the connectors well-connected:
Cables and shielded cable should be well-connected firmly to avoid false,
joint welding or oxidation.
Connections for video outputs
The video outputs include VGA and HDMI interfaces.
Pay attention to the following when you select a PC display instead of a
monitor.
1. Do not remain switched on for a long time to extend the life of the
equipment;
2. Regular degaussing will help to maintain the normal operation of the
monitor.
3. Keep away from equipment with strong electromagnetic interference.
Using TV as video output device is an unreliable alternative. It is also
required to minimize the time of use and strictly control the power, the
interference caused by neighboring devices. Leakage risks of low quality TVs
may result in damage to other equipments.
Audio Inputs
Voice input impedance is high, so the microphone must be a microphone
connected to the power supply.

VDH-NK205A Hardware Manual
8
Like video input, voice transmission cables should avoid interference, fake,
poor contact, and special attention to prevent the current of the
high-voltage.
Audio Output
The audio output parameters of NVR are generally greater than 200mv 1KΩ
(BNC), you can directly connect to the low impedance headphones, powered
speakers or other sound devices through a power amplifier.
When the external speakers and microphones can not achieve spatial
segregation, it is prone to the phenomenon of whistling.
You may adopt the following actions,
1. Using better directional microphones
2. Adjust the speaker volume to make it lower than the value of the
generated howling.
3. Using sound-absorbing materials for decoration to reduce sound
reflections and improve the acoustic environment;
4. Adjusting the layout of the microphone and speakers can reduce the
whistling.
AlarmIn/AlarmOut connections
Pay attention to the following before installation.
1. AlarmIn
(a) Alarm input is grounding alarm input
(b) The alarm input signals require voltage signals to the ground
(c) When the alarm device is shared with two NVRs or connected to a
NVR and other devices, it should be isolated by relays.
2. Alarm OUT
The alarm output of the NVR can not be connected with high-power
load (no more than 1A). In the output circuit, be careful about the
excessive current that may cause damage to the relay. When using
high-power load, extra relays are needed.

VDH-NK205A Hardware Manual
9
F. Q & A and Maintenance
1. Q & A
Q 1.After power on, NVR doesn’t work.
A: The possible causes:
1. Wrong power input
2. bad connection of power cable
3. Power error
4. Firmware update error
5. Disk error or cable problem
6. Front panel error
7. Main PCB board error
Q 2.After power-on, NVR will restart after several minutes or the screen
freezes.
A: The possible causes:
1. Unstable or low input voltage
2. The hard drive has bad sectors or cable error
3. Low adaptor power
4. Front video signal not stable
5. High temperature, too much dust and the machine runs in a bad
condition
6. NVR hardware error
Q 3.HDD not found after power-on
A : The possible causes:
1. No power for the Hard Drive
2. Hard Drive cable error
3. Hard Disk error
4. Main board SATA slot error
Q 4. No output: Single, multiple or all channels
A : The possible causes:
1. Wrong firmware: Update to the right firmware
2. Brightness set to 0: set it to the default value
3. No signal input or signal too weak
4. Mask used
5. NVR hardware error
Q 5.No recorded file in local side
A : The possible causes:
1. Hard Disk error
2. Desired files are overwritten

VDH-NK205A Hardware Manual
10
3. Recording not enabled
Q 6.No audio sound
A : The possible causes:
1. Not powered-microphone
2. Not powered-speaker
3. Audio cable error
4. NVR hardware error
Q 7.Wrong time
A : The possible causes:
1. Wrong setting
2. Bad battery connection or low voltage
3. Bad frequency oscillator
Q 8.Motion detection not function
A : The possible causes:
1. Wrong schedule settings
2. Wrong area settings
3. Low sensitivity
4. Hardware limitation for different version
Q 9.Mosaic or no video when Network preview and file playback
A : The possible causes:
1. Network traffic jam
2. Bandwidth limitation in the NVR side
3. Group mode is used in the NVR networking setting. More mosaics in
group mode, not recommended.
4. Masks or channel protection in NVR side
5. No rights for the user account
6. Bad NVR output
Q 10. Networking not stable
A : The possible causes:
1. Networking not stable
2. IP conflict
3. MAC conflict
4. LAN card error (PC/NVR)
Q 11. The remote controller can not work
A : The possible causes:
1. Wrong control address
2. Long distance or poor angle
3. Battery run out

VDH-NK205A Hardware Manual
11
4. Controller or NVR front panel is out of order
Q 12. Forget the administrative password or Internet password
A : The possible solution:
1. Please contact local customer service staff or call the customer service
phone headquarters, we will guides you how to solve by the machine
type and version of the program.
2. Maintenance
Damped dust on the PCB board will cause a short circuit and will do
something wrong to the NVR or damage it. For long-term stability of the
NVR, regularly brush the circuit boards, connectors, fans and chassis to
remove dust.
Please ensure the project is well-grounded, so images, audio signal will
not be disturbed. At the same time, we can protect the NVR from static
or inductive voltage damage.
Do not remove audio/video cables and RS-484 when the NVR is
powered on, or they will be damaged.
Do not use the TV interface in the NVR video output (VOUT), or the NVR
output circuit will be damaged easily.
Do not turn off the power switch directly to shut down the NVR. Use the
menu shutdown or OFF button on the front panel (press more than three
seconds) to turn off the power automatically to avoid hard Drive crash.
Keep the NVR away from heats and hot places.
Keep the NVR chassis well-ventilated for better heat dissipation.
Have regular checks and system maintenance。

VDH-NK205A Hardware Manual
12
G. Appendix : Specifications
1. 8CH NVR
System Operating system：Linux
Storage
Device/Interface Build in SATA interface x 2, compatible SATA / SATA II / SATA
III HDD( Max. 8TB)
E-SATA *1 (Max 16T)
User Interface 25 operating buttons on Front panel controller
Video And Other
I/O Interface
Dual video：HD OUT/VGA
USB 2.0 *2
USB 3.0 *1
8CH VACRON IP-CAMERA input (RJ45 port power supply)
Headphones (speakers) sound output x 1
Ethernet x1 – 10/100(IEEE 802.3 Type 10Base-T / IEEE
802.3u Type 100Base-TX / IEEE 802.3ab Type 1000Base-T)；
Auto-MDIX
Network Protocol Ipv4 / ARP / TCP / UDP / ICMP / SMTP / HTTP / RTP / RTSP
clinet / RTCP
Video Format H.264 compression format
E-Map
Live / Playback Real-time Live View capable 8CH VGA @30fps or 4CH 1080P
@23fps
4CH 1080P @23fps Synchronous Playback
Recording Query: Time search, Event search (IP CAM
displacement, Alarm I / O triggered alarm notification)
Playback speed/ slow forward / fast forward in 5 different
speed, Play Frame by Frame mode (forward or backward)
Pentaplex operation: Live/ Record/ Playback
Event Notification Event Notification : Alarm I / O trigger, Motion detection,
Video loss, HDD error
Recording Mode Constant recording
Schedule recording
Alarm triggered recording (include motion detection
recording): Complete event video reserved 3 seconds before
and 60 minutes after event taken place.

VDH-NK205A Hardware Manual
13
Schedule alarm triggered recording (include motion
detection recording): Complete event video reserved 3
seconds before and 60 minutes after
Manual recording
Only recording without live (depending on user authority)
Backup
Management
Video output format: AVI
The USB mobile storage device or remote NAS
System
Management
Remote Client software; live, playback set up by PC (remote
side).
Authorization: Maximum 10 group accounts, Hierarchical
authority.
Support 3 users log on by Client-side software or browser.
Systems operation records, record login time, IP and
selected video.
Browser：MS IE7-IE9
Support Equipment Support megapixel IP Camera video
Support CCTV camera video via Video Server.
Power NVR : DC12V / 4.16A
IP-CAM : DC48V / 2.5A
Operating
Temperature
0-45℃
★Product specifications are subject to change without notice; please contact us for the latest
information.

Manufacturer :
FUHO TECHOLOGY CO., LTD.
No. 30 Lane 726 Sec. 3 Jinma Rd., Changhua City
Phone: [phone] Fax: [phone]
