VADDIO OneLINK HDMI User manual

Integrator's Complete Guide to the
OneLINK HDMI
Camera Extension
Document 411-0019-30 Rev. B
February 2018

ii
Contents
Overview 1
What's in this Guide 2
Features 2
Unpacking the OneLINK HDMI Camera Extension 3
OneLINK HDMI for HDBaseT Cameras 3
OneLINK HDMI For HDBaseT Cameras Used with Codecs 3
OneLINK HDMI for HDMI Cameras 4
OneLINK HDMI for HDMI Cameras Used with Codecs 5
A Quick Look at the OneLINK Device 7
Front Panel of the Receiver 7
Connector Panel of the Receiver 8
Connector Panel of the EZCamera Interface Module (EZIM) 9
Installing the OneLINK Device 10
Don’t Void Your Warranty! 10
Cabling Notes 10
Mounting the OneLINK Device 11
RS-232 Connector Pin-Outs 11
IR Forwarding Connector Pin-Out 11
Visual Conventions for Connection Diagrams 12
Connections for HDBaseT Cameras 12
Kits and Systems for HDBaseT Cameras 12
Connecting a Vaddio HDBaseT Camera 13
Connections for HDBaseT Cameras Used with Codecs 14
Kits for HDBaseT Cameras Used with Codecs 14
Connecting a Vaddio HDBaseT Camera and Polycom Codec 15
Connecting a Vaddio HDBaseT Camera and Cisco Codec 18
Connections for HDMI Cameras 22
Kits for HDMI Cameras 22
Connecting a RoboSHOT HDMI Camera 23
Connecting a Polycom EagleEye IV Camera 24
Connecting a Cisco Camera 25
Connecting a Sony or Panasonic HDMI Camera 27
Connections for HDMI Cameras Used with Codecs 29
Kits for HDMI Cameras Used with Codecs 29
Connecting a RoboSHOT HDMI Camera and Polycom Codec 30
Connecting a Polycom EagleEye IV Camera and Polycom Codec 33
Connecting a RoboSHOT HDMI Camera and Cisco Codec 36
Connecting a Cisco Camera and Codec 41
Powering Up the Equipment 46
Configuration and Administration Tasks 46

Compatible Web Browsers 46
Accessing the Web Interface 47
Web Interface Cheat Sheet 48
Configuring Network Settings 49
Assigning a Hostname 50
Specifying Time Zone and NTP Server 50
Managing Access and Passwords 51
Adding Room Information to the Web Interface 52
Viewing System Information 53
Saving (Exporting) or Restoring (Importing)a Configuration 53
Rebooting the OneLINK Device 54
Restoring Factory Settings 55
Starting a Firmware Update 56
Contacting Vaddio Technical Support and Viewing Diagnostics 57
Telnet Serial Command API 58
link power 59
network settings get 59
network ping 60
system reboot 60
system factory-reset 61
sleep 61
version 62
history 62
help 62
exit 63
Specifications 64
Troubleshooting 65
Operation, Storage, and Care 66
Compliance and Declarations of Conformity 67
FCC Part 15 Compliance 67
ICES-003 Compliance 67
European Compliance 68
Warranty Information 69
Index 70
iii
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

1
Overview
This guide covers the OneLINK™ HDMI camera extension, which is available in the following kit
configurations for use with Vaddio or third-party cameras, with or without third-party codecs.
n999-1105-043/143/943, OneLINK HDMI
n999-9520-000/001/009, OneLINK HDMI camera extension for Polycom EagleEye IV cameras with
Polycom codecs
n999-9530-000/001/009, OneLINK HDMI camera extension for Sony and Panasonic cameras
n999-9540-000/001/009, OneLINK HDMI camera extension for RoboSHOT HDMI cameras with
Polycom codecs
n999-9545-000/001/009, OneLINK HDMI camera extension for Vaddio HDBaseT cameras with Polycom
codecs
n999-9560-000/001/009, OneLINK HDMI camera extension for Cisco cameras with Cisco codecs
n999-9570-000/001/009, OneLINK HDMI camera extension for RoboSHOT HDMI cameras with Cisco
codecs
n999-9575-000/001/009, OneLINK HDMI camera extension for Vaddio HDBaseT cameras with Cisco
codecs
n999-9590-000/001, OneLINK HDMI camera extension for RoboSHOT HDMI cameras
The OneLINK HDMI camera extension is also available as a component of several Vaddio camera
systems.
Part number suffixes indicate power cord set types. Those ending in -000 include cord sets for use in North
America; -001 kits include cord sets for use in Europe and the UK; -009 kits include cord sets for use in
Australia and New Zealand.
If the camera extension is sold for use with an HDMI camera, it is shipped with a OneLINK EZCamera
Interface Module (EZIM).

What's in this Guide
This guide provides information about:
nUnpacking
nPhysical features
nInstallation
nConfiguration and system administration
nTelnet API for third-party control
nSpecifications
nTroubleshooting and maintenance
nWarranty
For your convenience, most of this information is also available in smaller, limited-purpose manuals:
nInstallation Guide for the OneLINK HDMI Camera Extension – Unpacking, physical features,
installation, and initial power-on.
nConfiguration and Administration Guide for the OneLINK HDMI Camera Extension – Physical
features, web interface for device configuration and system administration, and troubleshooting.
Download manuals, dimensional drawings, and other information from support.vaddio.com.
Features
nSimple, fast, clutter-free camera installation– power, control, video, and network connectivity on a
single Cat-5e(or better)cable
nExtends installation distance for HDMI and HDBaseT™ cameras up to 100 m (328 ft.)
nPasses uncompressed HDMI®video up to 2160p/29.97
nBidirectional control via Ethernet and RS-232
nCompatible with Vaddio HDBaseT cameras – no EZCamera Interface Module (EZIM) needed
nCompatible with RoboSHOT HDMI and other HDMI cameras
nAvailable in system configurations with Vaddio cameras
nKits available for use with Polycom and Cisco codecs and other HDMI cameras
2
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

Unpacking the OneLINK HDMI Camera Extension
Make sure you received all the items you expected. Here are the packing lists for the OneLINK HDMI kits.
Every OneLINK device ships with a power supply and at least one AC cord set. The last three digits of the
kit part number contain the regional code that specifies which cord set(s). For most OneLINK kits, the part
numbers follow this convention:
nKits with part numbers ending in -000 include one AC cord set for North America.
nKits with part numbers ending in -001 include two AC cord sets, one for Europe and one for the UK.
nKits with part numbers ending in -009 include one AC cord set for Australia and New Zealand.
Exceptions are noted case by case in the following packing lists.
OneLINK HDMI for HDBaseT Cameras
OneLINK HDMI Camera Extension for Vaddio HDBaseT Cameras, 999-1105-043/143/943
Camera not included.
nOneLINK HDMI Receiver, 998-1105-043
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
oKit 999-1105-043 includes one AC cord set for North
America.
oKit 999-1105-143 includes two AC cord sets, one for
Europe and one for the UK.
oKit 999-1105-943 includes one AC cord set for Australia and New Zealand.
nEZCamera RS-232 control adapter (998-1001-232)
nQuick-Start Guide 411-0019-01
OneLINK HDMI For HDBaseT Cameras Used with Codecs
OneLINK HDMI for Vaddio HDBaseT Cameras with Polycom Codecs, 999-9545-000/001/009
Camera and codec not included.
nOneLINK HDMI Receiver
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
n3-position Euro-style connector, 5 mm
nFan-out cable, codec side, 2 ft. (0.6 m)
nEZCamera RS-232 control adapter 998-1001-232
nQuick-Start Guide 411-0019-01
3
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

OneLINK HDMI for Vaddio HDBaseT Cameras with Cisco Codecs, 999-9575-000/001/009
Camera and codec not included.
Note
If connecting to a Cisco SX20 codec, you will need to provide
a Cisco split cable, Cisco part number CAB-PHD4XS2-
SPLIT.
nOneLINK HDMI Receiver
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nHDMI cable, 3 ft. (0.9 m)
nCustom-pinout Cat-5e cable for Cisco, 3 ft. (0.9 m)
nEZCamera RS-232 control adapter 998-1002-232
nCat-5e patch cable, 3 ft. (0.9 m)
nQuick-Start Guide 411-0019-01
OneLINK HDMI for HDMI Cameras
OneLINK HDMI for RoboSHOT HDMI Cameras, 999-9590-000/001/009
Camera not included.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM) with
mounting screws
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nPower cable EIAJ-04 to EIAJ-04, 1 ft. (0.3 m)
nCat-5e patch cable, 1 ft. (0.3 m), qty. 2
nHDMI cable, 1 ft. (0.3 m)
nEZCamera RS-232 control adapter
nQuick-Start Guide 411-0019-02
OneLINK HDMI for Sony and Panasonic Cameras, 999-9530-000/001/009
Camera not included.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM)
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nPower cable EIAJ-04 to EIAJ-04, 1 ft. (0.3 m)
nPower cable EIAJ-04 to 3x6.3mm, 1 ft (0.3 m)
nWall mount with mounting hardware for Sony and
Panasonic cameras
nHDMI cable, 1 ft. (0.3 m)
nRJ-45 to 8-pin mini-DIN cable, 1 ft. (0.3 m)
nCat-5e patch cable, 1 ft. (0.3 m)
nQuick-Start Guide 411-0019-02
4
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

OneLINK HDMI for HDMI Cameras Used with Codecs
OneLINK HDMI for Polycom Cameras with Polycom Codecs, 999-9520-000/001/009
Camera and codec not included.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM)
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nWall mount with mounting hardware for Polycom codec
and camera
nFan-out cable, EZIM side, 1 ft. (0.3 m)
nFan-out cable, codec side, 2 ft. (0.6 m)
n3-position Euro-style connector, 5 mm
nEZCamera RS-232 control adapter 998-1001-232
nQuick-Start Guide
OneLINK HDMI for RoboSHOT HDMI with Polycom
Codecs, 999-9540-000/001/009
Camera and codec not included.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM), with
mounting screws
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nFan-out cable, codec side, 2 ft. (0.6 m)
n3-position Euro-style connector, 5 mm
nHDMI cable, 1 ft. (0.3 m)
nPower cable EIAJ-04 to EIAJ-04, 1 ft. (0.3 m)
nCat-5e patch cable, 1 ft. (0.3 m), qty. 2
nQuick-Start Guide 411-0019-02
5
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

OneLINK HDMI for Cisco Cameras with Cisco Codecs, 999-9560-000/001/009
Camera and codec not included.
Note
If connecting to a Cisco SX20 codec, you will need to provide
a Cisco split cable, Cisco part number CAB-PHD4XS2-
SPLIT. This cable is also required when connecting to a Cisco
Precision 40 or Precision HD 1080p2.5x camera; you will need
two of them if connecting one of these cameras and an SX20
codec.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM)
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nPower cable EIAJ-04 to 5.5x2.1 mm, 1 ft. (0.3 m)
nWall mount with mounting hardware for Cisco codec and
camera
nHDMI cable, 3. ft. (0.9 m)
nHDMI cable, 1 ft. (0.3 m)
nCustom-pinout Cat-5e cable for Cisco, 3 ft. (0.9 m)
nCustom-pinout Cat-5e cable for Cisco, 1 ft. (0.3 m)
nCat-5e patch cable, 1 ft. (0.3 m)
nCat-5e patch cable, 3 ft. (0.9 m)
nEZCamera RS-232 control adapter 998-1002-232
nQuick-Start Guide 411-0019-02
OneLINK HDMI for RoboSHOT HDMI with Cisco Codecs, 999-9570-000
Camera and codec not included.
Note
If connecting to a Cisco SX20 codec, you will need to provide
a Cisco split cable, Cisco part number CAB-PHD4XS2-
SPLIT.
nOneLINK HDMI Receiver
nOneLINK EZCamera Interface Module (EZIM) with
mounting screws
nPower supply, 48 VDC/1.36 A, with AC cord set(s)
nPower cable EIAJ-04 to EIAJ-04, 1 ft. (0.3 m)
nHDMI cable, 3 ft. (0.9 m)
nHDMI cable, 1 ft. (0.3 m)
nCustom-pinout Cat-5e cable for Cisco, 3 ft. (0.9 m)
nCat-5e patch cable, 1 ft. (0.3 m), qty. 2
nCat-5e patch cable, 3 ft. (0.9 m)
nEZCamera RS-232 control adapter 998-1002-232
nQuick-Start Guide 411-0019-02
6
Integrator's Complete Guide to the OneLINK HDMI Camera Extension

A Quick Look at the OneLINK Device
This section covers the physical features of the OneLINK HDMI camera extension.
All OneLINK kits include a receiver, which is typically co-located with other equipment, up to 328 ft (100 m)
away from the camera. OneLINK kits for use with HDMI cameras also include an EZCamera Interface
Module (EZIM) HDBaseT converter, which is mounted adjacent to the camera.
Front Panel of the Receiver
nData Display – Shows the IP and MAC addresses for the OneLINK HDMI camera extension (not the
camera). Use the IP address to access the OneLINK HDMI web interface.
nPower System Reset button (illuminated red) – reboots the OneLINK Bridge without affecting the
connected camera.
Note
The OneLINK device does not control the camera; it passes IP and RS-232 traffic to and from the camera.
Use the camera's IP address to access the camera's web interface. The OneLINK device's IP address
only provides access to the OneLINK device, not to the connected camera.
Note
To discover the attached Vaddio camera's IP address, point the IR Remote Commander at the camera and
press the Data Screen button. The camera's IP and MAC addresses are displayed on the connected HDMI
video output.
7
Integrator's Complete Guide to the OneLINK HDMI Camera Extension
