VADDIO IntelliSHOT User manual

Installation Guide for the
IntelliSHOT
Auto-Tracking Camera
Document 411-0053-31 Rev A
May 2021

Contents
Overview 1
What's in this Guide 1
Features 1
A Quick Look at the Camera 2
Front of the Camera 2
Connector Panel 3
Installation 4
Don’t Void Your Warranty! 4
Before You Install the Camera 4
Cabling Notes 4
Pre-Installation Functional Check 5
Getting the Camera's IP Address 5
If the Camera Is At 169.254.1.1 6
Status Lights 6
Installing the Wall Mount 6
Basic Connections 7
Installing the Camera and Connecting Power 7
About Inverted Installation 7
Next Steps 8
Operation, Storage, and Care 8
Photo Credits 9
Index 10
ii

Overview
This guide covers:
IntelliSHOT®auto-tracking camera:
nNorth America – 999-21100-000 (black); 999-21100-000W (white)
nEurope and UK – 999-21100-001 (black); 999-21100-001W (white)
nAustralia and New Zealand – 999-21100-009 (black); 999-21100-009W (white)
What's in this Guide
This guide covers:
nPhysical features
nTips for a successful installation
nPre-installation functional check
nInformation on connecting and mounting the camera
nCamera power-on
Complete product information is available in the Complete Manual for the IntelliSHOT Auto-Tracking
Camera.
If you are responsible for configuring the equipment after installing it, please use the Complete Manual. It
includes all the information in this guide, plus information on configuring, operating, and troubleshooting
the camera.
Features
nIntegrated camera and audio system, ideal for small to medium conference rooms
nIntelliFrameTM intelligent framing algorithm keeps participants in view reliably, without facial
recognition
n30x zoom, horizontal field of view of 70.2°
nSimultaneous HDMI, uncompressed USB 3.0 and H.264 IP streaming (RTSP or RTMP)
nUp to 1080p/30 video; up to 1080p/60 on HDMI output
nIntegrated phased microphone array
nAudio line in and line out
nUniversal Video Class (UVC) and Universal Audio Class (UAC) drivers supported in Windows®,
macOS®, and Linux operating systems, compatible with most UC conferencing applications
nIntegration-ready Telnet control
nFull administrative control via web interface; manage the camera remotely while monitoring the
stream separately
nPresenter-friendly RF remote control
1

A Quick Look at the Camera
This section covers the physical features of the camera.
Front of the Camera
The camera is available in black or white.
Camera and zoom lens – Up to 30x zoom.
Integrated microphone – No external microphone needed in typical installations. Echo-canceling
microphone picks up the voices of participants up to 10 ft. (3 m) away.
Status lights – The illuminated trim detail on the camera's face indicates the camera's current state. The
status lights can be turned off in the administrative web interface.
Pivoting head – Manually tilt the head as needed.
Note
By default, the camera's status lights are active during normal operation; however, they can be
configured to remain off when the camera is powered up. The camera may be sending video even if the
lights are off.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
2

Connector Panel
The connectors are on the underside of the camera.
PoE+ – RJ-45 connector. Connect to the network and to power via the Power and Data Out port of the
mid-span PoE+ power injector. Provides power and network access for IP streaming and camera control
via web interface or Telnet.
USB 3.0 – USBType B connector. Connect to a computer for use with soft conferencing applications.
Provides uncompressed USB 3.0 stream.
HDMI output – HDMI video and audio output connector.
IP button – Press to display the camera's IP address on video outputs.
Audio input – Line level balanced audio for an external microphone or other audio source.
Audio output – Line level balanced audio output to amplified speaker or other audio infrastructure.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
3

Installation
This section covers:
nSelecting the location for the camera
nVerifying that the camera is ready to install
nInstalling the mount
nConnection diagrams
nMounting the camera
And a required safety note here:
Note
PoE type networks connected to this equipment are for intra-building use only and should not be
connected to lines that run outside of the building in which this product is located.
Don’t Void Your Warranty!
Caution
This product is for indoor use. Do not install it outdoors or in a humid environment without the appropriate
protective enclosure. Do not allow it to come into contact with any liquid.
Do not install or operate this product if it has been dropped, damaged, or exposed to liquids. If any of
these things happen, return it to Vaddio for safety and functional testing.
Before You Install the Camera
Prepare for a successful installation:
nConsider camera viewing angles, lighting conditions, line-of-sight obstructions, and in-wall
obstructions where the camera is to be mounted.
nEnsure that the camera points away from the ceiling and lights. The camera will not perform well if it is
pointed toward a light source such as a light fixture or window.
nMounting the camera at eye level is best. If this is not feasible, mounting the camera above eye level
typically produces a better experience than mounting it below eye level.
nIf you make cables for this installation, check them for continuity.
nBe sure you can identify all cables correctly.
Cabling Notes
Use Cat-5e or better cable. Use shielded cabling if the cables will be coiled, run tightly with other cables,
or routed near sources of electromagnetic interference such as power lines or fluorescent light fixtures.
We recommend using high-quality connectors and a high-quality crimping tool.
Caution
Do not use pass-through RJ-45 connectors when making cables for this product. Poorly
crimped connectors of this type can cause intermittent connections and degraded signal
quality. They can also damage the connectors on the product, which will void your warranty.
Intact – will make reliable contact
with cable connector
Damaged – Bent contact fingers
will NOT make reliable contact
with cable connector
Installation Guide for the IntelliSHOT Auto-Tracking Camera
4

Pre-Installation Functional Check
If you're installing the camera where it's hard to reach, you may want to verify functionality before you
install it.
1. Connect the camera in its minimum functional configuration.
2. Connect power. The camera's status light turns white. If an HDMI display is connected, video is
available.
3. If not using an HDMI display:Connect the camera's USB port to your computer, then open a media
player and verify that you can select the camera as the USB video capture device. These screen
shots show how to access a camera's USB stream using VLC Media Player. In this example, the
capture device is a different camera.
If the camera turns on and sends video, continue with the installation.
Getting the Camera's IP Address
You will need the camera's IP address if you do not use the Vaddio Device Controller or Vaddio
Deployment Tool to access its web interface.
Briefly press the IP button on the connector panel. This displays the camera's IP address and MAC
address on the video outputs. Press the button again to dismiss the information.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
5

If the Camera Is At 169.254.1.1
This is the camera's default IP address. This means one of these things:
nThe camera's PoE+ power injector is not connected to the network,
OR
nThe network does not automatically assign IP addresses.
If the camera does not receive an IP address when connected to the network, you will need to configure
the camera for the network after you have done the initial device set-up.
To communicate directly with the camera for initial device set-up and network configuration, you will need
to connect a cable from your computer's network port to the DATA IN port on the PoE+ power injector.
Status Lights
The lights in the camera's head indicate its current state.
nPurple – Initializing
nWhite – Active
nRed – Audio is muted
nBlinking red – Video is muted
nYellow – Firmware update is in progress
nBlinking cyan – Remote pairing mode
nBlinking blue – Pairing error
Caution
Do not remove power or reset the camera while the status lights are yellow, showing a firmware update in
progress. Interrupting a firmware update can make the camera unusable.
Note
By default, the camera's status lights are active during normal operation; however, they can be
configured to remain off when the camera is powered up. The camera may be sending video even if the
lights are off.
Installing the Wall Mount
The camera is shipped with a wall mount. Other mounting options are available as well. Contact us if you
don’t have the camera mount you need.
You can install the camera wall mount to a display mount or directly to the drywall. If you mount it to
drywall, use wall anchors.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
6

Basic Connections
Here is an example of how the camera might be set up in a medium-size conference room. In this setup,
a PC uses a unified communications conferencing application to manage the camera and connected
microphones and speaker.
Pro Tip
Label all cables at both ends.
Installing the Camera and Connecting Power
Caution
Check your cables. Connecting a cable to the wrong port or using the wrong pin-out can result in
equipment damage and will void the warranty.
1. Connect all required cables to the camera.
2. Slide the camera into the mount.
3. Secure the cable cover to the mount.
4. Connect the mid-span power injector to mains power.
About Inverted Installation
If you use an inverted mount, you will need to select the camera's Image Flip setting when configuring
behavior and performance. Image Flip orients the video image correctly and sets the camera to respond
appropriately to tilt commands.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
7

Next Steps
The camera is now ready to configure and use. This information is available in the Complete Manual for
the IntelliSHOT Auto-Tracking Camera.
Operation, Storage, and Care
For smears or smudges on the product, wipe with a clean, soft cloth. Use a lens cleaner on the lens. Do
not use any abrasive chemicals.
Keep this device away from food and liquids.
Do not operate or store the device under any of the following conditions:
nTemperatures above 104° F (40° C) or below 32° F (0° C)
nHigh humidity, condensing or wet environments
nInclement weather
nSevere vibration
nMars or its satellites
nDry environments with an excess of static discharge
Do not attempt to take this product apart. There are no user-serviceable components inside.
Installation Guide for the IntelliSHOT Auto-Tracking Camera
8

Photo Credits
This guide may include some of these photos.
European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42,
photographs the Earth through a window in the Cupola on the International Space Station
By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats-
gender-got-to-do-with-it/, Public Domain, https://commons.wikimedia.org/w/index.php?curid=38834990
Carl Sagan, Bruce Murray, Louis Friedman (founders) and Harry Ashmore (advisor), on the occasion of
signing the papers formally incorporating The Planetary Society
By credit NASA JPL - JPL, Public Domain, https://commons.wikimedia.org/w/index.php?curid=1180927
Main Control Room / Mission Control Room of ESA at the European Space Operations Centre (ESOC) in
Darmstadt, Germany
By European Space Agency - ESOC flickr, Credit: ESA - Jürgen Mai, CC BY-SA 3.0-igo,
https://commons.wikimedia.org/w/index.php?curid=36743173
Expedition 42 on orbit crew portrait, International Space Station, Mar. 7, 2015 – Barry Wilmore
(Commander) Top, Upside down, to the right cosmonaut Elena Serova, & ESA European Space Agency
Samantha Cristoforetti. Bottom center US astronaut Terry Virts, top left cosmonauts Alexander
Samokutyaev and Anton Shkaplerov.
By NASA - https://www.flickr.com/photos/nasa2explore/16166230844/, Public Domain,
https://commons.wikimedia.org/w/index.php?curid=38931301
European Space Agency astronaut Luca Parmitano, Expedition 36 flight engineer, outside the
International Space Station
By NASA - http://spaceflight.nasa.gov/gallery/images/station/crew-36/html/iss036e016704.html, Public
Domain, https://commons.wikimedia.org/w/index.php?curid=27263573
Chris Cassidy, Luca Parmitano, and Karen Nyberg, ISS, 2013. Photo Credit: NASA
Nicolas Altobelli, Rosetta Scientist at ESA's European Space Astronomy Centre, Villanueva de la
Cañada, Madrid, Spain
By European Space Agency - Nicolas Altobelli talks to the media, CC BY-SA 3.0-igo,
https://commons.wikimedia.org/w/index.php?curid=36743144
Andrea Accomazzo, ESA Rosetta Spacecraft Operations Manager, providing a live update from the Main
Control Room at ESA's European Space Operations Centre, Darmstadt, Germany during the Rosetta
wake-up day.
By European Space Agency - Live update from the Main Control Room, CC BY-SA 3.0-igo,
https://commons.wikimedia.org/w/index.php?curid=36743150
Photo AS11-40-5948, Aldrin assembles seismic experiment, by National Aeronautics and Space
Administration, courtesy of the NASA History Office and the NASA JSC Media Services Center
Installation Guide for the IntelliSHOT Auto-Tracking Camera
9

Index
A
AEC 7
anatomy of the camera 2
C
cable connectors 3-4
camera mount 4, 6
camera placement 4
capabilities 1
ceiling-mounted cameras 7
cleaning 8
color codes for status light 6
connection diagram 7
connectors 3
D
damage, preventing 4
DHCP vs. non-DHCP networks 6
diagram, connection 7
E
echo cancellation 7
Ethernet port 3
F
functional check 5
I
Image Flip setting 7
indicator light 6
meaning of colors 6
installation 6-7
basic connections 7
camera 7
camera mount 6
inverted installation 7
IP address 6
default 6
L
light, status indicator 6
meaning of colors 6
location of the camera 4
locations of connectors 3
M
microphones 7
mount 4, 6
mounting the camera 4, 7
N
network port 3
O
operating environment 4, 8
P
pre-installation functional check 5
precautions 4
for operating the system 4
product capabilities 1
R
requirements 4
installation 4
mounting 4
RJ-45 connectors 4
S
settings 7
Image Flip 7
shelf, camera mount 6
site requirements 4
speaker 7
status light 6
meanings of colors 6
storage environment 8
T
temperature, operating and storage 8
U
USB port 3
V
visual parts identification 2-3
W
wall mount 6
warranty 4
10

Vaddio is a brand of Legrand AV Inc. · www.legrandav.com · Phone [phone] ·
Fax [phone] · Email [email protected]
Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for
identification purposes and are trademarks of their respective owners. All patents are protected under
existing designations. Other patents pending.
©2021 Legrand AV Inc.
Commercial AV Brands Chief | Da-Lite | Middle Atlantic | Projecta | Vaddio
