OneLINK For RoboSHOT HDMI Cameras
OneLINK For RoboSHOT HDMI Cameras Page 3 of 20
O
VERVIEW
:
Vaddio’s OneLINK System is a digital camera
extension system that extends HDMI video, power
network and control on a single Cat-5e/6 cable at
distances of up to 328’ (100m). The OneLINK
system sends and regulates power to the camera,
provides a bi-directional control channel for Ethernet
and transmits/receives uncompressed HDMI digital
video up to 1080p/60.
The system consists of the small OneLINK EZIM (EZCamera™ Interface Module) camera interface at the camera
location and the OneLINK HDMI Interface. The EZIM provides the required camera connectivity and is mounted to
the underside of the RoboSHOT HDMI camera’s Thin Profile Wall Mount with two 6-32 x .188” black mounting
screws. All the 12” (305mm) patch cables on the camera end are provided with the OneLINK system including an
HDMI cable, a power cable and two Cat-5e patch cables for network and RS-232. The Thin Profile Wall Mount can
be mounted directly to a 2-gang sized electrical box for conduit or directly to the dry wall with wall anchors.
From one end to the other, the OneLINK system provides system integrators and end users a simplified product
based on the vast experience Vaddio has in cameras and cable extension systems.
Please use this manual in conjunction with the manual for the camera attached to the OneLINK System.
Intended Use
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the
one provided or outdoor operation has not been tested and could damage the device and/or create a potentially
unsafe operating condition.
Save These Instructions
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
Important Safeguards
Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged.
In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock,
do not immerse in water or other liquids and avoid extremely humid conditions.
Important Note
OneLINK systems are not compatible with previous versions of OneLINK codec camera extenders. The
specifications are different and will not function if parts from either system are mixed. The older systems are those
with Quick-Connect part number 998-1105-019 and EZIM part number 998-6700-003. Connecting these to a new
OneLINK system may cause failure and void warranty.
Images: OneLINK HDMI Interface
(above) and the OneLINK EZIM
Camera Interface (right),
Use only the power supply provided with the system. Use of any unauthorized power supply will
void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the cause of intermittent connections. For
best results please use standard RJ-45 connectors, real crimpers and test all cables for proper
pin-outs prior to use and connection to Vaddio Cat-5e/6 products.
