VADDIO WallVIEW 50i User manual

The Vaddio WallVIEW 50i PTZ Camera System is
designed to provide system integrators with an easy to
install wall-mounted amera system. The system
features a Canon® VC-C50i PTZ Camera mounted on
Vaddio’s thin profile wall-mount bra ket. The system
is equipped with Vaddio’s EZCamera™ Cabling System,
whi h allows the installer to use Cat. 5 abling to run power, video and amera ontrol.
Also in luded is Vaddio’s PowerRite™ Power Supply. The PowerRite system regulates
the right amount of power needed for the amera over Cat. 5 abling. An optional
VISCA ontrol interfa e an be added to allow the amera to work with any
VISCA ompatible ontrol devi e.
WallVIEW™ 50i PTZ
Pan/Tilt/Zoom Camera System
Technical Features
Canon VC-C50i PTZ Camera
A wall-mountable PTZ amera equipped with a
26X opti al and 12X digital zoom lens. The
VC-C50i delivers high quality video from far
distan es and under the dimmest lighting
onditions. Building on Canon’s long-standing
tradition as the leader in opti s and image
pro essing, it offers greater flexiblity in the most
demanding environments. Camera features
in lude: Nine amera presets, auto-fo us, auto-
iris, and one lux minimum illumination. The
motorized pan has a range of 100 degrees ea h
way and the tilt has a range of 90 degrees up
and 30 degrees down.
Thin Profile Wall-Mount Bracket
Custom PTZ amera wall-mount bra ket de-
signed ex lusively for the Canon VC-C50i
amera. Heavy duty metal onstru tion with
What’s Included
The Vaddio WallVIEW 50i PTZ in ludes the
following items:
• Canon VC-C50i PTZ Camera
• Canon Multi-Fun tion Remote Control
• Thin profile amera wall-mount bra ket
• EZCamera Camera Shoe Interfa e
• EZCamera Qui k-Conne t Box
• EZCamera Control Adapter
• 18 VDC PowerRite Power Supply
• One 12' S-Video able
• One 12' Composite video able
• All s rews and mounting hardware
able a ess openings for in-wall or exposed
wall installations. Bra ket an be mounted on a
dual gang box for new onstru tion pre-wiring.
In ludes tripod s rew and mounting hardware.
EZCamera Cabling Sy tem
Allows installer to use Cat. 5 able to run power,
video and amera ontrol. Video Balun te hnology
is used to extend the range of the video signal
and to allow it to work on Cat. 5 able. The
Vaddio PowerRite Camera Power System
in ludes a high output power supply and a
power regulator to maintain the right voltage
over Cat. 5 able.
EZCamera Shoe Interface
A plug-in shoe that intergrates the Canon VC-C50i
PTZ Camera to the EZCamera Cable System.
The shoe interfa e onverts amera outputs to
three RJ-45 ja ks. The first ja k provides power
and video. The se ond ja k provides primary
amera ontrol signaling and the third provides
daisy- hain amera ontrol to additional Canon
PTZ Cameras.
EZCamera Quick-Connect Box
This small interfa e box onverts power, S-Video
and omposite video into a single Cat. 5 able.
Vel ro® mounting square provided.
VISCA Camera Control Option
The system an be ordered with VISCA amera
ontrol. This allows you the ability to use the
amera system with ontrol systems and video
ode s that support the VISCA proto ol.
The system ships standard with the Canon
instru tion set.
A Division of Photo Control Corporation

Toll Free: 800-572-2011 • Phone: [phone] • Fax: [phone]
www.vaddio. om
©2004 Vaddio - All Rights Reserved. Reprodu tion in whole or in part without written permission is prohibited. Spe ifi ations and pri ing subje t to hange. WallVIEW, EZCamera,
ControlVIEW and PowerRite are registered trademarks of Vaddio, In . All other trademarks are property of their respe tive owners. Form Number 0129/02-09RevC.
Figure 1 – EZCamera able system with a Qui k- onne t box.
Figure 2 – EZCamera able system with a qui k- onne t dual gang wallplate.
▲
▲▲
POWER
COMPOSITE VIDEO
S-VIDEO
Monitor
WALLPLATE
Codec
PowerRite
Power Supply
CAMERA SHOE
INTER ACE
VC-C50i
CAT. 5 CABLE
Optic
Lens Configuration Nine(9) Groups of Eleven(11) Lens
Fo al Length & F Number f=3.5 to 91mm; F1.6 to F4.0
Marginal Lumination Ratio 30% Over
Zoom Ratio 26X (at infinite)
Fo us Region Wide: 0.01m to ∞; Telephoto: 1.6m to ∞;
Auto/Manual
Horizontal 42˚ Wide; 1.7˚ Telephoto
Imaging
Imaging Devi e 1/4” CCD
Number of Pixels NTSC – 630K Total (340K effe tive);
PAL – 740K Total (400K effe tive)
Color Separating System Se ondary Mosai Filter System
Ele troni Shutter Speed NTSC – 1/80,000 - 1/60 - 1/1 se ;
PAL – 1/80,000 - 1/50 - 1/1 se
Imaging Mode Visible Light Mode; Infrared Light Mode
Minimum Subje t Illumination 1 lx (visible light mode, at 1/30 ele tri
shutter speed)
Infrared Lighting GaAIAs Infrared Radiation LED;
Four Pie e
Infrared Light Power About 0.75 W x 4
Infrared Light Wavelength 970nm (peak value)
Video
Color System NTSC/PAL
(depending on the ountry of use)
Luminan e Signal S/N ratio 50dB
Resolution Horizontal: 460 TV Lines;
Verti al: 350 TV Lines
S anning System Interla e
Technical Speci ications
White Balan e Auto/Manual/One-push
Chara ter Display Setting, Clo k
Mechani m
Pan Angle Range VC-C50i – ±100˚; VC-C50iR – ±170˚
Tilt Angle Range VC-C50i – -30˚ to +90˚;
VC-C50iR – -90˚ to +10˚
Rotation Speed Pan: 1 to 90˚/s; Tilt: 1 to 70˚/s
Infared Cut Filter Motor Driven
(visible light mode/infrared light mode)
Preset Fun tion Nine(9) Positions
Cas ade Control Nine(9) Cameras
Connector
BNC Composite Video Output
Multi onne tor S-Video Output, RS-232C Control
(input, output), Other
DC Input Custom Ja k (AC adapter is used)
Regulation
Wide Converter Conne tion Diameter: 37mm; Pit h: 0.75mm
Voltage (camera only) 13VDC
Power Consumption 13 W
PowerRite Power Supply 100 - 240V, 50-60Hz, 18VDC
Other
Operating Temperature 32˚ F (0˚ C)
Dimensions Depth: 4.48”/113mm
Width: 4”/101mm
Height: 3.58”/90mm
Weight 14.3oz/405g
▲
COMPOSITE VIDEO
CAT. 5 CABLE TO SECOND CAMERA
DUAL WALLPLATE
CAMERA
SHOE
INTER ACE
VC-C50i
CAT. 5 CABLE
▲
POWER
Monitor
PowerRite
Power Supply
▲▲
Codec
ControlVIEW
S-VIDEO
RS-232
▲
Quick-Connect
RS-232
