Vaillant VR 52 User manual

Operating and installation instructions
GB, IE
Repeater
VR 52
Publisher/manufacturer
Vaillant GmbH
Berghauser Str. 40 D-42859 Remscheid
Tel. [phone] Fax [phone]
[e-mail] www.vaillant.de

Contents
2Operating and installation instructions 0020249211_03
Contents
1 Safety ..............................................................................4
1.1 Intended use...................................................................4
1.2 General safety information.........................................6
2 Notes on the documentation...................................11
2.1 Observing other applicable documents...................11
2.2 Storing documents........................................................11
2.3 Validity of the instructions .........................................11
3 System and product description...........................12
3.1 Component of the ambiSENSE system...................12
3.2 Design of the product .................................................13
3.3 Radio operation ............................................................14
3.4 Flashing sequence of the signal LED ......................15
3.5 Duty cycle limit.............................................................17
3.6 CE marking.....................................................................18
4 Integration into the ambiSENSE system...........19
4.1 Pairing.............................................................................19
5 Operation......................................................................22
5.1 Behaviour following a voltage recovery................22
6 Troubleshooting..........................................................23
6.1 Command not confirmed...........................................23
6.2 Resetting to factory setting......................................24
7 Decommissioning.......................................................25
7.1 Decommissioning the product.................................25
7.2 Recycling and disposal...............................................26

Contents
3
Operating and installation instructions 0020249211_03
8 Customer service ......................................................27
9 Technical data.............................................................27

4Operating and installation instructions 0020249211_03
a
Safety
a1
1 Safety
1.1 Intended use
In the event of inappropriate or improper
use, damage to the product and other
property may arise.
You can use the repeater to expand the
range of the ambiSENSE radio network.
Intended use includes the following:
– observance of accompanying operating,
installation and servicing instructions
for the product and any other system
components
– installing and fitting the product in
accordance with the product and sys-
tem approval
– compliance with all inspection and
maintenance conditions listed in the
instructions.
This product can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capa-

Operating and installation instructions 0020249211_03 5
aSafety a
1
bilities or lack of experience and knowl-
edge if they have been given supervision
or instruction concerning use of the prod-
uct in a safe way and understand the haz-
ards involved. Children must not play with
the product. Cleaning and user mainte-
nance work must not be carried out by
children unless they are supervised.
Intended use also covers installation in
accordance with the IP class.
Any other use that is not specified in these
instructions, or use beyond that specified
in this document shall be considered
improper use. Any direct commercial or
industrial use is also deemed to be
improper.
Caution.
Improper use of any kind is prohibited.

6Operating and installation instructions 0020249211_03
a
Safety
a1
1.2 General safety information
1.2.1 Risk of death from electric
shock!
Opening the product may lead to a lethal
electric shock. The product does not con-
tain any parts that need to be maintained
by the end user.
>The product must only be opened by a
competent person.
>If the product shows signs of damage
from the outside, e.g. on the housing,
on control elements, on the connection
ports, or a malfunction occurs, the
product must not be used.
>In the event of a fault, have the product
checked by a competent person.

Operating and installation instructions 0020249211_03 7
aSafety a
1
1.2.2 Danger caused by improper
operation
Improper operation may present a danger
to you and others, and cause material
damage.
>Carefully read the enclosed instructions
and all other applicable documents, par-
ticularly the “Safety” section and the
warnings.
>Only carry out the activities for which
instructions are provided in these oper-
ating instructions.
1.2.3 Risk of material damage
caused by unsuitable
environmental conditions.
The electronics may be damaged if you
install the product in an unsuitable envi-
ronment.
>Only install the product in dry, dust-free
interior rooms.

8Operating and installation instructions 0020249211_03
a
Safety
a1
>Ensure that the product is not exposed
to constant solar or heat irradiation,
vibrations or mechanical loads.
1.2.4 Risk of material damage
caused by an unsuitable plug
socket.
>Use the product only in permanently
installed earthed plug sockets, and not
in socket strips or with extension
cables.
>You cannot insert any further
intermediate plugs into the product.
1.2.5 Risk of material damage due
to lightning and overvoltage.
>Do not install the product during bad
weather.

Operating and installation instructions 0020249211_03 9
1Safety
>Disconnect the product from the power
grid during bad weather.
1.2.6 Risk of material damage
caused by a missing on/off
switch.
The product does not have an on/off
switch and therefore has to be discon-
nected from the power grid.
>Only insert the product in a plug socket
that is easy to access.
1.2.7 Risk of material damage
caused by electrical overload.
>An overload may damage the product
beyond repair, lead to a fire or lead to
an electrical accident.
>Before connecting a consumer, observe
the product’s technical data, particu-
larly the maximum power consumption

Safety
10 Operating and installation instructions 0020249211_03
1
of the consumers that are being con-
nected.
>Only load the product up to the speci-
fied power limit.
1.2.8 Regulations (directives, laws,
standards)
>Observe the national regulations, stand-
ards, directives, ordinances and laws.

Notes on the documentation
Operating and installation instructions 0020249211_03 11
2
2 Notes on the documentation
2.1 Observing other applicable
documents
>You must observe all the operating and
installation instructions included with
the system components.
2.2 Storing documents
>Keep this manual and all other applica-
ble documents safe for future use.
2.3 Validity of the instructions
These instructions apply only to:
Product article number
VR 52 Great Britain 0020253437

System and product description
12 Operating and installation instructions 0020249211_03
3
3 System and product
description
3.1 Component of the ambiSENSE
system
The product is part of the ambiSENSE
room climate solution and communicates
via a radio protocol. All products in the
ambiSENSE room climate solution can be
configured via the VRC 700 app using a
smartphone.
You can use the ambiSENSE repeater to
expand the range of the ambiSENSE radio
network in order to ensure the communi-
cation connection between the
ambiSENSE units throughout the entire
flat or house. If you are using ambiSENSE
units outside of the direct range of the
radio network, e.g. in the cellar or on the
top floor of the building, the ambiSENSE
repeater provides support when transmit-
ting radio commands. You can use up to

System and product description
Operating and installation instructions 0020249211_03 13
3
two ambiSENSE repeaters in the
ambiSENSE system. The product is easily
paired to the VR 920 Internet gateway.
3.2 Design of the product
1
2
1 Repeater
2 System button

System and product description
14 Operating and installation instructions 0020249211_03
3
3.3 Radio operation
The radio signal is transmitted on a
non-exclusive transmission path. Faults
can therefore not be ruled out. Interfer-
ences may, for example, be caused by
switching operations, electric motors or
defective electrical units.
The range inside buildings may differ con-
siderably from the range outdoors. Except
for the transmission power and the recep-
tion properties of the transceivers, envi-
ronmental influences (such as air humidity
and structural elements) play an important
role on-site.

System and product description
Operating and installation instructions 0020249211_03 15
3
3.4 Flashing sequence of the
signal LED
Flashing
sequence Meaning Explanation/
required
activity
Brief period
of flashing
orange
Radio trans-
mission/
transmission
attempt/data
transmission
Wait until the
transmission
has ended.
1 x long
period of
lighting up
green
Process con-
firmed You can con- tinue with the
operation.
1 x long
period of
lighting up
red
Process failed
or duty cycle
limit reached
Try again.
Brief period
of flashing
orange (every
10 seconds)
Pairing mode
active Enter the dig- its of the unit
number to
confirm.

System and product description
16 Operating and installation instructions 0020249211_03
3
Flashing
sequence Meaning Explanation/
required
activity
6 x long
period of
flashing red
Product
defective Note the dis- play in your
app or con-
tact your
specialist
dealer.
Lights up 1 x
orange and 1
x green (after
plugging into
the plug
socket)
Test display Once the test
display goes
out, you can
continue.

System and product description
Operating and installation instructions 0020249211_03 17
3
Flashing
sequence Meaning Explanation/
required
activity
Long and
brief period
of flashing
orange (alter-
nating)
Update to the
unit software
(OTAU = Over
the Air
Update)
New software
is trans-
ferred. (Dura-
tion: Up to 12
hrs) This
does not
affect how
the product
works during
this time.
3.5 Duty cycle limit
The duty cycle limit describes a legally
regulated limit on the transmission time of
units in the 868 MHz range. The aim of
this regulation is to guarantee that all
units that work in the 868 MHz range
work correctly. In the frequency range 868
MHz that is used by the product, the maxi-
mum transmission time for each individual

System and product description
18 Operating and installation instructions 0020249211_03
3
unit is 1% of an hour (i.e. 36 seconds in
1 hour). The product complies with this
directive.
In normal mode, the duty cycle limit is not
normally reached. In individual cases, e.g.
during start-up or the new installation of a
system, increased and radio-intensive pair-
ing processes may mean that this limit is
not reached. If the duty cycle limit is
exceeded, the signal LED lights up red for
one extended period and may indicate that
a function is temporarily missing from the
product. After a short time (max. one
hour), the product’s function is restored.
3.6 CE marking
The CE mark shows that the products
comply with the basic requirements of the

Integration into the ambiSENSE system
Operating and installation instructions 0020249211_03 19
4
applicable guidelines as stated on the data
plate.
The manufacturer hereby declares that the
type of radio equipment that is described
in these instructions complies with Direc-
tive 2014/53/EU. The complete text for the
EU Declaration of Conformity is available
at: http://www.vaillant-group.com/doc/
doc-radio-equipment-directive/.
4 Integration into the
ambiSENSE system
4.1 Pairing
To ensure that the ambiSENSE repeater is
integrated into the ambiSENSE system
and can communicate with other
ambiSENSE units, it must first be paired
to the VR 920 Internet gateway. You
should therefore first set up the VR 920
Internet gateway via the VRC 700 app in

Integration into the ambiSENSE system
20 Operating and installation instructions 0020249211_03
5
order to be able to use other ambiSENSE
units in the system.
Then pair the product via the VRC 700
app.
>Open the VRC 700 app on the smart-
phone.
>Select Settings on the bottom right.
>Select ambiSENSE.
>Select Add Repeater.
>Follow the installation assistant.
