Valcom V-1094A Instruction manual

V-1094A Page Port PreAmp/Expander
Issue 1 947095-A
Input
V-1094A
Page Port
Preamp
Expander
600 Ohm page port
or zone output of a
page control unit
Power Supply
Up to 150
One-Way
Amplified
Speakers
TR(J1)
(J3)
Output
T
R
(J2)
-24V GND Input level equals output
level at position 5
Audio and Power Connections
•Note:
4.50” L
2.50” H
•Drawing goes on back side
The Amp has a 600 Ohm
input and a 8 Ohm output
with a response of 80Hz
to 10kHz +/-3dB and a
maximum gain of 8dB.
It is powered by -21 to
-26VDC at 15mA.
The V-1094A is normally
used to pre-amp audio on
long lines or provide master
volume control to all or part
of a paging zone.
Technical Assistance
540-563-2000 or
www.valcom.com
