TECHNICAL ASSISTANCE
When trouble is reported, verify there are no broken connections to the unit.
Assistance in troubleshooting is available from the factory. When calling, you should
have a Volt-Ohm meter and a lineman's test set available and be calling from the job
site. Call (540) 563-2000 and ask for Technical Support, or visit our website at
http://www.valcom.com.
Valcom equipment is not field repairable. Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary, attach a tag to the unit clearly stating
your company name, address, phone number, contact person and the nature of the
problem. Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
WARRANTY
Warranty information may be found on our website at
www.valcom.com/warranty.
TROUBLESHOOTING CHART
INSTALLATION INSTRUCTIONS FOR
SIGNATURE SERIESTM, HIGH FIDELITY
AMPLIFIED IN-WALL SPEAKER
MODEL NO. V-1450
Issue 8 947145
SYMPTOMS
ACTIONS
No audio from
speaker
Low volume
from speaker
Loud squeal
(Feedback)
1. Verify volume control is turned up (Clockwise).
2. Using a lineman's test set, check for proper audio level on Tip/A
and Ring/B leads and if necessary at the source.
1. Verify volume control is turned up.
2. Check voltage at speaker when in use (-18 to -24VDC required).
3. Using a lineman's test set, check for proper audio level on Tip/A
and Ring/B leads. It is possible some low level audio will be
heard with only one side of Tip/A and Ring/B connected.
1. Decrease volume of speaker (Counterclockwise).
2. Increase the distance between telephone and speaker.
3. Install confidencer on telephone in severe problem areas.
VALCOM SIGNATURE SERIES HIGH FIDELITY
SELF-AMPLIFIED IN-WALL SPEAKER
The Valcom Signature Series™ In-Wall Speaker, V-1450, is a high fidelity,
self-amplified (6 Watt) speaker and may be used to provide one-way paging
and high quality music reproduction from any Valcom Page Control. This
speaker has an externally accessible volume control located behind the grille
and is screwdriver adjustable. The V-1450 will cover an area up to 600
square feet and should be spaced 20 feet apart. Good quality paging will be
heard up to 30 feet in front of the speaker. The V-1450 requires -24VDC,
200mA (4 Valcom power units). The speaker is available in white and
supplied with a trim ring and grille.
NOTE: No power amplifier required. Do not connect this speaker directly to a
25/70/100 Volt amplifier as damage to both the amplifier and speaker
may occur. (Recommended nominal input level to the V-1450 is
-10dBm).
Mounting/Connections
CAUTION: Before cutting hole, identify and locate all plumbing and
electrical wiring.
Using the enclosed cutout template, mark outline of cutout on wall. Make
sure speaker is centered between any wall studs. Using the appropriate tool,
cut a hole in the wall following the template outline.
Insert a small screwdriver tip between the grill and speaker to remove grill
from the front of the speaker assembly. Assemble speaker, mounting frame
and hardware as shown in the diagram. Do not tighten frame completely.
After assembling mounting frame, make connections to the terminal block.
Insert stripped wire into appropriate terminal and tighten with screwdriver.
Each connector accepts 18 to 24AWG wire. With the tweeter on top, place
mounting bracket into hole in the wall. Push speaker assembly flush to wall
and slide up 1/2 inch. Tighten two center screws first, then tighten the
remaining screws. Set volume control to 1/2 volume and test. Press grill into
slot around speaker assembly.
NOTE: Exercise caution when handling speaker assembly with grill removed.
Recommended Quantity of Speakers per Specific Power Run
(Standard Category 3 Twisted Pair Telephone Wire)
Mounting
Dimensions/Weight
 12.00"H x 8.65"W x 3.20"D (30.48cm H x 21.97cm W x 8.13cm D)
 3
lbs (1.36 kg)
FCC Notice
NOTE: The equipment has been tested and found to comply with the
limits for Class A digital devices, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can
radiate radio frequency energy. If not installed and used in
accordance with the instruction manual, it may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense.
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user's authority to operate the
equipment.
Speakers per
Power Run
Wire Run Length (Feet)
V-1450
24AWG
22AWG
8
4
2
125
250
500
200
400
800
