Preparation
Please read all of the instructions below before beginning your installation. We recommend that
you have your unit installed by a mobile video/navigation installer.
Features
• Single DIN size, all-in-one integrated entertainment system.
• Built-in DVD Player, Car specification slot-in mechanism..
• High resolution 7” (16:9) TFT color monitor, contrast and brightness adjustment.
• Built-in 40W X 4 output amplifier, 4 channel surround sound output.
• All functions can be operated by included Remote Controls.
• Powerful Graphic User Interface and software update ability.
Tools and Supplies
You will need these tools and supplies to install the unit.
• Torx type, flat-head and Philips screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screwdriver, socket wrench set or other tools)
• Electrical tape
• Crimping tool
• Multimeter
• Crimp connections
• 18 gauge wire for power connections
• 16 – 18 gauge speaker wire
• Heatshrink tubing
• Soldering iron and solder
WARNINGS
1. Only connect the unit to a 12-volt negative ground system.
2. Never install this unit where operation and viewing could interfere with safe driving conditions.
3. To reduce the risk of a traffic accident (except when using for rear view video camera) never use
the video display function while driving the vehicle. This is a violation of law.
4. To reduce the risk of a traffic accident, never driving with the sound at a level that prevents you
from hearing sounds outside around the vehicle.
5. Never disassemble or adjust the unit without the assistance of a professional. For details, please
consult your local car stereo specialty shop.
6. To prevent injury from shock or fire, never expose this unit to moisture or water.
7. Never use irregular discs.
8. To prevent damage to the mechanism inside this unit, avoid impact to the TFT monitor.
9. Do not change the fuse on the power wire without professional guidance. Using an improper fuse
may cause damage to the unit and result in a fire.
10. The monitor employs an automatic motorized mechanism. To prevent damage to the core
mechanism, please do not push, pull or swivel the monitor manually.
1 2
Disconnecting the Battery
To prevent a short circuit, be sure to turn off the ignition and remove the negative (-) battery cable
prior to installation.
NOTE: If the unit is to be installed in a car equipped with an on-board drive or navigation computer,
do not disconnect the battery cable. If the cable is disconnected, the preset memory may be
erased. Under these conditions, use extra caution during installation to avoid causing a short
circuit.
NOTE: It is especially important that you read the WARNINGS and NOTES in this manual.

Controls and Indicators
Button Operation
3410
5
2
1
678 9 11
12
15
16
17
14
3
18
19
20
21
22
13
1.POWER OFF/ VOL
Rotary encoder.
Press the encoder to turn on the unit, press and hold to turn off.
Rotate clockwise/counterclockwise to adjust the volume.
Press to enter the audio adjust menu when the unit is on.
2.MUTE
Press the button to mute the volume, and press the button again to restore the volume.
3.FAST REVERSE
4.FAST FORWARD
5.PLAY/PAUSE
6.STOP
7.PREVIOUS
8.NEXT
9.MODE
10.RESET
Use this button to restart the machine
11.SMART DIAL
Rotary encoder.
Press the encoder to access MAIN menu.
Rotate clockwise/counterclockwise to select a desired item and press to access or confirm.
23
4
12.EJECT
Press once to eject the disc.
Hold to reset loading mechanism.
13.DISK SLOT
14.INFO
Press to display playback information on the screen on DVD mode, if the TFT monitor is closed
DVD playback information will display on the LCD screen.
Press and hold to access the picture setup.
15.ANGLE+
Press the button to adjust the upward tilt angle of the screen one step at a time.
Press and hold this button to continuously adjust the upward tilt.
Press this button to adjust the picture settings in picture setup.
16.ANGLE-
Press the button to adjust the downward tilt angle of the screen one step at a time.
Press and hold this button to continuously adjust the downward tilt.
Press this button to adjust the picture settings in picture setup.
17.TFT DISPLAY
18.OPEN
Press the OPEN button to activate the motorized system and move the TFT monitor into viewing
position.
Press again to close the TFT.
19.DISP
Press to display system information on the front LCD screen when the main screen is closed
20.LCD DISPLAY
21.AS/PS (Auto store/program scan)
Press to auto store strong radio stations in the 12 preset channels in the current band
Press and hold to start to scan the preset radio station
22.BAND
Press to change among the following bands: FM1,FM2,FM3,AM
Press to change tuner mode while in other source
23.DISC INDICATOR LIGHT
It is blue when there is no disc in the unit
It is red when there is disc in the unit
LCD Display/Indicators
1. Main display area, displays the time, tuning frequency and other text information.
2. Local indicator, Indicates the local radio station seeking function is activated or not

5
3. Stereo broadcasting indicator, Indicates the radio is in stereo mode or not
4. Loudness indicator, Indicates the LOUD function is activated or not.
The key areas of touch screen
A — Return to MAIN MENU
B — Display playing information
C — Select previous chapter
D — Select next chapter
E — Display the on-screen controls, and different mode displays different menu.
F —On DVD/VCD mode, display the GOTO search menu on the screen directly.
6
Remote Control
Remote Control
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Select FM/AM band on Tuner mode
Stop playback
Power
Open
Mute
SRC
Numeric button
VOL up
VOL down
Information
GOTO search
Stop/Band
Select
ESC
Menu
Repeat A—B
OK
Direction buttons
Turn the power on/off
Open/close the motorized screen
Toggle on/off audio output
Select playing mode
Directly access certain chapter / track / preset
station in current band
Increase the volume
Decrease the volume
Display playing information
Position search function on VCD/DVD mode
Enter the audio settings
Exit the current menu
Enter the main menu of system
Adjust the picture settings
Set start point A and end point B to repeat continually
Start or pause playback, confirm the settings
Up/down/left/right to select items for setting

Repeat
Next
Previous
Fast Reverse
Fast Forward
Audio
Zoom
Angle
SUB Title
Title
Root
Also can activate and disable SCAN mode while playing CD
Repeat playback for current chapter
Select the next chapter/track for playback
Search an available radio station by increasing tuning
frequency on tuner mode
Select the previous chapter/track for playback
Search an available radio station by decreasing tuning
frequency on tuner mode
Fast reverse the disc content
Fast forward the disc content
Change the audio language for disc playback
Zooming in/out on an image
Play in different angle for a scene scene(if it is applicable)
Language selection for subtitle
Turn on PBC while playing VCD
Enter the main menu of the disc
78
TFT Monitor Operation
Open/Close TFT Monitor
Press the ( ) button on the front zone remote control or press the (OPEN) button on the front
panel to open/close the monitor.
TFT Monitor Auto Open
•If “TFT Auto Open” is “On”, when the unit is turned on, the monitor automatically open to the last
viewing position.
•If “TFT Auto Open” is ”Off” , when the unit is turned on, press the ( ) button on the remote
control or press the (OPEN) button on the front panel to open the monitor into the desired viewing
position.
•If “TFT Auto Open” is ”Manual”,when the unit is turned on or turned off, the monitor has no
movement.
See “General setting” for more instructions.
Monitor Tilt Angle Adjustment
The monitor angle can be adjusted for optimum viewing using one of the following methods:
Press the ( ) or ( ) buttons on the front panel to adjust the tilt angle of the screen one step
at a time.
Press and hold the ( ) or ( ) buttons to continuously adjust the tilt angle.
Adjust the “Screen Tilt” in the “Screen setting” to adjust the tilt of the screen to the desired degree.
Image Setting
Video Output Format
The table below shows the video output format for each source.
Adjustable Parameters
While in RGB mode, the only parameter that can be adjusted is brightness (BRIGHT). To access
“PICTURE”,“COLOR”, “CONTRAST”, and “TINT” you must be in CVBS mode.
Parameter Adjustment Procedure
1. Enter Picture Quality Setting Mode:
Press the PIC button on the remote or press and hold the INFO button on the front panel of the unit.
2. Select Items to Set:
Press the ( / ) buttons on the remote or rotate the SMART DIAL button clockwise/anticlockwise
to select an item.
3. Set Parameters:
Rotate the“ VOL” on the front panel can also adjust the selected feature.

9
4. Exit Picture Quality Setting Mode:
Press the PIC button on the remote or press and hold the INFO button on the unit.
NOTE: A video source must be connected to the AUX input and be playing to access the above
adjustments.
Parking Brake Interlock
1. When the “PARKING” lead is connected to the brake switch, the display on the TFT monitor will
display video only when the vehicle is stopped and the parking brake is applied.
2. When the “parking brake inhibit” is active, the front monitor displays a caution message with blue
background, preventing the driver from watching video while driving to reduce the risk of a traffic
accident.
Please see “INSTALLATION SECTION” for installation.
Monitor Movement Mechanism
If an obstruction occurs in the monitor path, the motion will stop automatically to prevent damage to
the mechanism or monitor.
Normal operation is resumed by pressing the (OPEN) button or disconnecting and reconnecting the
power.
10
Basic Operations
Power On / Off
Press the POWER OFF /VOL button to turn the unit on. The buttons on the front of the unit are
illuminated and start up message is briefly displayed on the LCD screen, and then displays the
current mode status. You can also turn on the unit by pressing the POWER button ( ) on the
remote control.
Press and hold the POWER OFF /VOL button on the front panel for more than 1 second or press the
POWER button ( ) on the remote to power off the unit. The monitor is drawn back into the main
compartment and the LCD screen displays “BYE BYE”.
Playing Source Selection
Press the MODE button on the front panel or the (SRC) button on the remote to change among
available playing sources: TUNER, DVD, AUX IN. The playing mode is displayed on the TFT
display.
Volume Adjustment
To increase or decrease the volume level, turn the POWER OFF /VOL on the front panel or press
the (VOL+/ VOL-) buttons on the remote control. The volume ranges from “0” to “40”. The default
volume is “10” when the unit is powered on each time. Default volume memory setup: Rotate Power
Off/VOL knob on the front panel to select volume value and then press and hold the Power Off/VOL
button until you hear a single beep. When you hear the beep, setup is completed.
Audio Control Menu
The Audio Control feature allows you to easily adjust your audio system to meet the acoustical
characteristics of your vehicle, which vary depending on the type of vehicle and its measurements.
To get the best possible sound quality from your new system, be sure to adjust the settings for the
speakers as well. Proper setting of the Fader and Balance boosts the effects of the cabin equalizer.

11
Off,On
NOTE: The Bass and Treble levels are only adjustable when EQ is on “User” mode.
The Loudness function compensates for deficiencies in sound ranges at low levels. Loudness
levels range from 1-4 or “off”. When the Loudness function is on, LOUD is displayed on the screen.
Exiting the Audio Control Menu
touch the return arrow on the top right of the display.
Press the (ESC) button on the remote control to exit the audio control menu.
Four-Channel Audio Control
System Reset
To correct a system halt or other unusual operation, use the tip of a pen to press the RESET button
located on the front bottom-right corner of the unit. After a system reset, the unit restores the
settings before last power off.
Mute
Press the MUTE button on the front panel or the MUTE button ( ) on the remote to mute the
volume from the unit.
NOTE: Press the MUTE button again to restore the volume.
Adjusting the volume or using any of the audio set-up features will cancel the mute function.
Master Volume
Front Left Channel Volume
Front Right Channel Volume
Center Channel Volume
Item
00 to 40
-10 to +10
-10 to +10
-10 to +10
4-Channel Audio Adjustments
System Setup Menu
12
MAIN Menu
There are three methods to access the MAIN menu.
•Press the MENU button on the remote control.
•Touch the A area on the touch-screen.
•Press the SMART DIAL button on the front pane
1.Touch to access setup mode.
2.Touch to access Standby mode
3.Touch to access AUX IN mode.
4. Touch to access DVD mode.
5. Touch to access Radio mode.
Note: Touch screen operations and buttons on front panel are all useable to select menu and adjust
“SETTING”. The following instructions will show the different ways to access menus and
adjustments.
Screen Setting
Accessing the Screen Setup Menu
•Press the (MENU) button on the remote control to access MAIN menu.
•Select the button on the bottom of the screen and select screen menu to access the Screen
setup.
1
4
2
35

13
General setup Menu
Accessing the General Setup Menu
•Press the (MENU) button on the remote control to access MAIN menu.
•Select the button on the bottom of the screen and select General menu to access the
General setup.
Selecting a Feature for Adjustment
Press the direction buttons on the remote control or touch the option directly on the screen to select
the feature to be adjusted.
1 to 5
Displays the software version of unit
14
Adjusting a Feature
1. Enter the option field for the feature you want to adjust by pressing the (OK) button on the
remote. A submenu appears in a second row with the selected option.
2. Select a new value by pressing the direction button.
3. Confirm your selection by pressing (OK) button. The new value setup is complete.
Adjusting the Clock
1. Access the “Clock” setting under the General Setup menu.
2. Press the direction button on the remote to move the cursor to the “Hour” or “Min” position, and
press the (OK) button. You also can touch the “Hour” or “Min” position directly.
3. The numeric keypad will pop up.
4. Press the numeric button on the remote control or touch the numeric keypad on the screen to
adjust the hour or minutes.
5. Press the (OK) button on the remote control or on the keypad of the screen to confirm setup.
Return to normal playback
The system will automatically return the previous playback mode you were in before accessing the
setup menu after setting with no operation.
Load all factory parameters to their original settling
Video out Disable
Enable Select whether to video out
The monitor does not open or close when the unit is
turned on or turned off.
Clock Mode
Clock
Load Factory
12Hr
24Hr
Clock displays 12 hour time using AM and PM.
Clock displays 24 hour time up to 23:59
00:27 present time
No/Yes

15
Language Setting
Accessing the Language Setup Menu
•Press the (MENU) button on the remote control to access MAIN menu.
•Select the button on the bottom of the screen and select language menu to access the
Language setup.
Video Setting
Accessing the Viedo Setup Menu
•Press the (MENU) button on the remote control to access MAIN menu.
•Select the button on the bottom of the screen and select viedo menu to access the viedo
setup.
Select desired disc subtitle language
Select desired disc audio language
Select desired disc menu language
Subtitle
Audio
DVD Menu
English
French
Spanish
Auto
off
English
French
Spanish
English
French
Spanish
TV Shape
View Mode
4:3
16:9
Fill
Original
Auto Fit
Pan Scan
Select desired view mode
16
Rating Setting
Accessing the Rating Setup Menu
•Press the (MENU) button on the remote control to access MAIN menu.
•Select the button on the bottom of the screen and select rating menu to access the rating
setup.
Select desired view mode
Touch to display the numeric keypad on the screen, and
then you can use the numeric keypad to set password.
Set Password
Rating
1.Kid Safe
2.G
3.PG
4.PG-13
5.PG-R
6.R
7.NC-17
8.Adult
