Valore AC154 User manual

Rechargeable Laser
Distance Meter (AC154)
Thank you for purchasing Valore Rechargeable Laser Distance Meter (AC154).
• Distance, area, volume & pythagorean measurement
• Durable & portable
• High-precision
Important: Please read the user manual thoroughly before using your distance meter.
Specifications: Package Contents:
• Battery type: Lithium battery
• Measuring range: 0.05 – 40m
• Material: Aluminium
• Dimensions (L x W x H): 100 x 32 x 18mm
• Weight: 65g
UNDERSTANDING THE PRODUCT
• Rechargeable laser distance meter x 1
• USB cable x 1
• Strap x 1
1. ON
2. Area/Volume/Pythagorean
3. Rear/Front-end unit
4. C/OFF
5. +/-/U

START USING THE LASER DISTANCE METER
Functions
1. ON
a) Power ON
b) Start single/continous measurement
2. Area/Volume/Pythagorean
a) Area measurement
Short press key until square icon is shown. Press ON, the first edge is measured. Press ON
again to finish second edge measurement. The device will calculate automatically and results
will be shown in the main displaying area.
b) Volume measuerment
Short press key until cube icon is shown. Press ON to finish the measurement on the three
edges respectively. The device will perform th volume calculation automatically and results will
be shown in the main displaying area.
c) Pyhthagorean measurement
This is mainly used to calculate target distance that cannot be directly measurerd.
Short press key until triangle appears on the display. According to the screen prompts, press
the ON key to complete the measurement from right angled edge to right-angled edge edge or
hypotenuse to right-angled edge, respectively. After the measurement is completed, the device
will automatically perform the Pythagorean calculation, and the results will be displayed in the
main display area.
3. Rear/Front-end unit
Rear/Front-end baseline
4. C/OFF
a) Power OFF
b) Clear data
5. +/-/U
a) add/minus data
b) Unit switch

Icon Detail
01
ft
60
Laser indicator
Reference Baseline indicator
Area/volume/Pythagorean
function indicator
Battery level indicator
Data storage indicator
Data storage quantity
indicator
Signal strength indicator
Unit indicator
Auxiliary display area
Main display area
Mute indicator
Sound indicator
Electronic angle
1
2
3
4
5
6
7
8
9
10
11
12
13
1
11
2
12
10
3
45 6
7
13
9
8
NB.NB.DetailDetail
Self calibration function
ON
ON
ON
/
C OFF
/
+
-
/
U
Long press onbutton canswitch the unit circularly,The lastdisplay unit
will be memorized when shut-down.
In the shutdown mode→Long press thekey until “boob” is
displayed→long press again the key until "CRL” is displayed→short
press thekey into add subtract range with-7-7mm as adjustment→short
press thekey into savesettings when the calibration is completed.
Operating
ON/OFF
OFF ON
Long press onthebut
ton will turn on the device
ON OFF
Long press onthebut
ton will turn off the device
Warm Tips
While there is no operation for 15 seconds when the laser is on, the laser
will automatically turn off
While without any operation for 30 seconds under the power-on status, the
back light of display shall be off automatically
While there is no further button operation for 45 seconds under the power-on
status, the device shall beshut down automatically.
Device Unit
ON
C/OFF
ON
ON
ON
C/OFF

Reference edge
The default reference edgeof the instrument is the rear segment of the
instrument.Short press key can switch thereference edge.
Consider self lengthNotconsider self length
Sound setting
Clear-off function
Signal strength indication
In theshutdown mode→Long press the"ON" key until
“boob” is displayed→long press the "ON" key until
"CRL.”is displayed→Long press the"ON" key until the "BP.on" is displayed→Click the
"ON" key to adjust sound On/Off→Press the"OFF" buttonto savetheoperation.
ShortPress onbutton,the last measurement will be canceled. While
using the same function or single measurement to the area or volume etc), the
clear-off button can be used to eliminate last measuring operation and arrange
the measurement once again.
C OFF
/
While all thesegment codeof signal aredisplayed, it means that there shall be
the stronger echo signal strength of measurement; while less segment code was
displayed, it shall mean the relatively reduced echo signal strength of measurement.
Measurement
Single measurement
When the laser is off,shortpress the but
ton to turn on the laser,and the
laser icon on the screen will beflashing,with short press but
ton again it shall
start measurement.The device will display the measurement result automatically.
Continuous measurement
Press the button shortly to turn on the laser. Press the butt
on for
about 2 seconds to start continuous measurement. Press the button again
shortly to stop continuous measurement During continuous measurement, the
main display area displays the real-time measured value, and the auxiliary
display area displays the max and min value during the measurement.
ON
ON
ON ON

TECHNICAL SUPPORT & WARRANTY
• For Technical Support, email us at [email protected].
• For Warranty Registration, visit www.valore.sg.
Cautions:
Read all the instructions and warnings carefully prior to using this product.
• Do not store the camera in a high temperature environment.
• Do not place the camera near a fire or other excessively hot environments.
• Do not expose this camera to moisture or submerge it in liquid. Keep camera
dry at all times.
• Do not attempt to charge the camera using any other method or connection other
than the camera’s provided charging cable.
• Do not disassemble this camera or attempt to repair or modify it in any manner.
• Be cautious of excessive drops, bumps, abrasions or other impacts to this camera. If
there is any damage to the camera such as dents, punctures, tears, deformities or
corrosion, stop using the camera and contact us immediately via email at
[email protected], or return this product to the store where you have purchased it from.
• If the product produces an abnormal smell, high temperature (low temperature during
normal use), discolours or changes shape abnormally, stop using the product and contact us
immediately via email at [email protected].
