ValueHD VHD-V600 User manual

VHD-V600(S) Video Conference Camera
User Manual
Video Conference Solution ValueHD Technologies Co., Ltd.

VHD-V600(S) Video Conference Camera User Manual
VHD-V600(S)
Video Conference Camera
User Manual
English（V2.3）
Copyright Notice
All contents of this manual, whose copyright belongs to ValueHD Corporation cannot be cloned,
copied or translated without the permission of the company. Product specifications and information
which were referred to in this document are for reference only. We may change, delete, or update
any content at any time and without prior notice.
=============================================================================
This is class A production. Electromagnetic radiation at specific frequencies may affect the image
quality of TV in home environment.

VHD-V600(S) Video Conference Camera User Manual
Catalogue
1Note ............................................................................................................................ 1
2Packing List ................................................................................................................ 1
3Quick Start .................................................................................................................. 1
4About Product ............................................................................................................. 2
4.1Features .................................................................................................................................... 2
4.2Product Specification ................................................................................................................. 2
4.3Interfaces and Buttons .............................................................................................................. 3
4.4Dimension ................................................................................................................................. 4
4.5Remote Control ......................................................................................................................... 4
4.6RS-232 Interface ....................................................................................................................... 5
4.7VISCA Network ......................................................................................................................... 6
4.8Serial Communication Control ................................................................................................... 6
5GUI Settings ............................................................................................................... 7
5.1MENU ........................................................................................................................................ 7
5.2EXPOSURE .............................................................................................................................. 7
5.3COLOR ..................................................................................................................................... 7
5.4IMAGE ....................................................................................................................................... 8
5.5P/T/Z ......................................................................................................................................... 8
5.6NOISE REDUCTION ................................................................................................................. 9
5.7SETUP ...................................................................................................................................... 9
5.8COMMUNICATION SETUP ...................................................................................................... 9
5.9RESTORE DEFAULT ................................................................................................................ 9
6Network Function ..................................................................................................... 10
6.1Operating Environment ........................................................................................................... 10
6.2Equipment Installation ............................................................................................................. 10
6.3Internet Connection ................................................................................................................. 10
6.4IP camera controlled by LAN ................................................................................................... 10
6.4.1Setup IP address .................................................................................................................. 10
6.4.2Visit/Access IP Camera ........................................................................................................ 11
6.5IP Camera controlled by WAN ................................................................................................. 11

VHD-V600(S) Video Conference Camera User Manual
6.5.1Setup IPC controlled by dynamic DNS ................................................................................. 11
6.5.2Dynamic DNS visit camera ................................................................................................... 12
6.5.3VLC stream media player monitoring ................................................................................... 12
6.6IP Camera Parameter Setup ................................................................................................... 12
6.6.1Homepage Introduction ........................................................................................................ 12 
6.6.2Video Settings ...................................................................................................................... 14
6.6.3Image Settings ..................................................................................................................... 15
6.6.4Audio Settings ...................................................................................................................... 15
6.6.5System Settings ................................................................................................................... 16
6.6.6Network Settings .................................................................................................................. 16
6.6.7WiFi Settings ........................................................................................................................ 17
6.6.8Device Information ............................................................................................................... 17
6.7Download the Network Upgrade Program ............................................................................... 17
7Maintenance and Troubleshooting ........................................................................... 17

VHD-V600(S) Video Conference Camera User Manual
1
1 Note
 Electric Safety
Installation and operation must accord with
electric safety standard.
 Use caution to transport
Avoid stress, vibration or soakage in transport,
storage and installation.
 Polarity of power supply
The power supply of this product is +12V, the
max electrical current is 2A. Polarity of the
power supply plug drawing shows as below.
 Installation Precautions
Do not grasp the camera lens when carrying it.
Don’t touch camera lens by hand. Mechanical
damage may be caused by doing so.
Do not use in corrosive liquid, gas or solid
environment to avoid any cover (plastic
material) damage. Make sure there is no
obstacle within rotation range.
Please never power on before installation is
completed.
 Do not dismantle the camera
We are not responsible for any unauthorized
modification or dismantling.
Specific frequencies of electromagnetic field
may affect the image of the camera!
2 Packing List
When you unpack, check that all the supplied
accessories are included:
Name Quantity
Camera 1
AC Power Adaptor 1
Power Cable 1
RS232 Cable 1
Remote Control 1
Quick Start 1
3 Quick Start
1) Please check connections are correct before starting.

VHD-V600(S) Video Conference Camera User Manual
2
2) Connect the power adapter to the power
connector on the rear panel of the camera.
The power indicator on the front panel of
the camera is on.
3) After the camera is powered on, it starts to
initialize, right up to the limit position, and
then both horizontal and vertical go to the
middle position, the motor stops running,
and the initialization is completed.
(Note: If preset 0 is saved, PTZ will be
move to preset 0)
4 About Product
4.1 Features
 H.265 Encode
The world's first conference video camera
supporting H.265 encoding enables full HD
1080p/60 ultra-low bandwidth transmission.
 1080P Full HD
Adopt Panasonic's 1/2.7 inch, 2.07 million
pixels high quality HD CMOS sensor, which
can achieve maximum 1920 x 1080 high
resolution and quality image with highest
output frame rate 60 fps.
 20x Optical + 16x Digital Zoom
With the Japanese Tamron high-quality super
telephoto lens, the optical zoom is 20 times
and supports 16x digital zoom.
 Abundant & Perfect Interface
Support HDMI high-definition output, and
equipped with SDI interface, the effective
transmission distance is up to 100 meters.
 Low illumination
The application of 2D and 3D noise reduction
algorithm greatly reduces image noise. Even
under the condition of ultra-low illumination, it
still keep the picture clean and clear, and the
SNR of image is as high as 55dB.
 Remote Control
Through the RS232 and RS485 serial ports,
the camera can be controlled remotely.
4.2 Product Specification
Model VHD-V600(S)
Name Video Conference Camera
Camera
Signal System
HD: 1080P/60, 1080P/50,
1080I/60, 1080I/50,
1080P/30, 1080P/25,
720P/60, 720P/50,
720P/30, 720P/25,
720P/120 (only support by
S model), 640x480P/240
(only support by S model)
Sensor 1/2.7 inch, CMOS,
Effective pixels: 2.07M
Scanning Mode Progressive
Lens 20x, f4.42mm ~ 88.5mm,
F1.8 ~ F2.8
Digital Zoom 16x
Minimum
Illumination
0.05 Lux @
(F1.8, AGC ON)
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, One
Push, Manual, VAR
Backlight
Compensation Support
Digital Noise
Reduction
2D & 3D Digital Noise
Reduction
Signal Noise
Ratio ≥55dB
Horizontal Angle
of View 60.7° ~ 3.36°
Vertical Angle of
View 34.1° ~ 1.89°
Horizontal
Rotation Range ±170°
Vertical Rotation
Range -30° ~ +90°
Pan Speed
Range 1.7° ~ 100°/s
Tilt Speed
Range 1.7° ~ 69.9°/s
H & V Flip Support
Image Freeze Support
Local Storage Support

VHD-V600(S) Video Conference Camera User Manual
3
Number of
Preset 255
Preset Accuracy 0.1°
IPC Features
Video
Compression H.264/H.265/MJPEG
Video Stream First Stream,
Second Stream
First Stream
Resolution
1920x1080, 1280x720,
1024x576, 960x540,
640x480, 640x360
Second Stream
Resolution
1280x720, 1024x576,
720x576 (50Hz support),
720x480 (60Hz support),
720x408, 640x360,
480x270, 320x240,
320x180
Video Bit Rate 32Kbps ~ 20480Kbps
Bit Rate Type Variable Rate, Fixed Rate
Frame Rate
50Hz: 1fps ~ 25fps,
60Hz: 1fps ~ 30fps
720P/120: 120fps
(only support by S model),
640x480P/240: 240fps
(only support by S model)
Audio
Compression AAC
Audio Bit Rate 96Kbps, 128Kbps,
256Kbps
Protocols
TCP/IP, HTTP, RTSP,
RTMP, ONVIF, DHCP,
Multicast, etc.
Input/Output Interface
HD Output
1 x HDMI: Version 1.3
1 x SDI: BNC type,
800mVp-p, 75Ω, Along to
SMPTE 424M standard
Network
Interface
1 x RJ45: 10/100/1000M
Adaptive Ethernet Ports
USB 1 x USB2.0: Type A female
jack
Audio Interface 1-ch: 3.5mm Audio
Interface, Line In
Communication
Interface
1 x RS232 In: 8pin Min
DIN, Max Distance: 30m,
Protocol:
VISCA/Pelco-D/Pelco-P
1 x RS232 Out: 8pin Min
DIN, Max Distance: 30m,
Protocol: VISCA network
use only
1 x RS485: Share with
RS232 Out, Max Distance:
1200m, Protocol:
VISCA/Pelco-D/Pelco-P
Power Jack JEITA type (DC IN 12V)
Physical Parameter
Input Voltage DC 12V
Current
Consumption 1.0A (Max)
Operating
Temperature -10°C ~ 40°C
Power
Consumption -40°C ~ 60°C
Power
Consumption 12W (Max)
MTBF ＞30000h
Size 240 x 144 x 170mm
Net Weight 1.65Kg
4.3 Interfaces and Buttons

VHD-V600(S) Video Conference Camera User Manual
4
Item Name
1 System Video Format Switch
2 RS232 OUT Interface
3 RS232 IN Interface
4 Network Interface
5 LINE IN Interface
6 RS485 Interface
7 SDI Interface
8 HDMI Interface
9 USB 2.0 Interface
10 DC 12V Interface
11 Power Switch
12 Power Lamp
4.4 Dimension
4.5 Remote Control
Key Description
1. Standby Key
Press this button to enter standby mode. Press
it again to enter normal mode.
Note: Power consumption in standby mode is
approximately half of the normal mode
2. Number Key
To set preset or call preset.
3. *Key
Used with other buttons.
4. Preset Key
Set preset: Store a preset position.
[SET PRESET] + Numeric button (0-9): Setting
a corresponding numeric key preset position.

VHD-V600(S) Video Conference Camera User Manual
5
5. HOME Key
Confirm menu or the PTZ will back to the
middle position after pressed it
6. Return Key
Return back the last level menu
7. Zoom Key
Slow Zoom: Zoom In [+] or Zoom Out [-] slowly
Fast Zoom: Zoom In [+] or Zoom Out [-] fast
8. Left/Right Setting Key
Press with 1 buttons and 2 buttons setting the
direction of the Pan-Tilt.
 Simultaneously press L/R Set +1[STD]:
set the Pan-Tilt turn the same direction as
the L/R Set.
 Simultaneously press L/R Set +2[REV]:
set the Pan-Tilt turn the opposite direction
as the L/R Set.
9. Focus Key
Used for focus adjustment.
Press [AUTO] adjust the focuses on the center
of the object automatically. To adjust the focus
manually.
Press [MANUAL] adjust the focus on the
center of the object manual.
MANUAL button, and adjust it with [Far]
(Focus on far object) and [NEAR] (Focus on
near object).
10. Selection Key
Press the button corresponding to the camera
you want to operate with the remote controller.
11. #Key
Used with other buttons.
12. IR Remote Control Key
[*]+[＃]+[F1]: Address 1
[*]+[＃]+[F2]: Address 2
[*]+[＃]+[F3]: Address 3
[*]+[＃]+[F4]: Address 4
13. Reset Key
Clear preset: Erase a preset position.
[CLEAR PRESET] + Numeric button (0-9)
Or: [*]+[#]+[CLEAR PRESET]: Erase all the
preset individually.
14. PTZ Control Key
Press arrow buttons to perform panning and
tilting. Press [HOME] button to face the
camera back to front.
15. Menu Key
MENU: enter or exit OSD MENU.
16. Backlight Key
BLC ON/OFF: Press this button to enable the
backlight compensation. Press it again to
disable the backlight compensation.
NOTE:
 Effective only in auto exposure mode.
 If a light behind the subject, the subject
will become dark. In this case, press the
backlight ON/OFF button. To cancel this
function, press backli
g
ht ON/OFF button.
17. PTZ Reset Key
Preset Pan/Tilt self-test.
18. Image Freezing Function
Manually freeze: Open the freezing function
after press the remote control [F4], display
“Freeze” on the left upper corner character,
after five seconds display disappear
automatically. If you want to cancel the freeze,
press [F4] key and then can return to normal,
display “Unfreeze” on the left upper corner,
after five seconds display disappear
automatically.
Recalling the Preset image Freeze: By the
OSD Menu Setting “Recalling the Preset
image Freeze” function. After the function is
opened, the screen will stay in before
Recalling the Preset when Recalling the
Preset, the screen can be switched to the
preset position screen until the camera points
to the preset position.
19. Shortcut Set
[*]+[＃]+[1]: OSD menu default English
[*]+[＃]+[3]: OSD menu default Chinese
[*]+[＃]+[4]: Default IP address
[*]+[＃]+[5]: Save OSD
[*]+[＃]+[6]: Quickly recover the default
[*]+[＃]+[8]: Look the camera version
[*]+[＃]+[9]: Quickly set up inversion
4.6 RS-232 Interface

VHD-V600(S) Video Conference Camera User Manual
6
No. Function
1 DTR
2 DSR
3 TXD
4 GND
5 RXD
6 GND
7 IR OUT
8 NC
The correspondence between the camera and
Windows DB-9 pin:
Camera Windows DB-9
1.DTR 1.CD
2.DSR 2.RXD
3.TXD 3.TXD
4.GND 4.DTR
5.RXD 5.GND
6.GND 6.DSR
7.IR OUT 7.RTS
8.NC 8.CTS
9.RI
The correspondence between the camera and
the Mini DIN pin:
Camera Mini DIN
1.DTR 1.DTR
2.DSR 2.DSR
3.TXD 3.TXD
4.GND 4.GND
5.RXD 5.RXD
6.GND 6.GND
7.IR OUT 7.NC
8.NC 8.NC
4.7 VISCA Network
4.8 Serial Communication Control
 RS232 Communication Control
The camera is controlled via RS232. The
RS232 serial port parameters are as follows:
Baud rate: 2400/4800/9600/38400 bit/s;
Starting Position: 1 bit
Data bit: 8 bits
Stop bit: 1 bit
Check digit: None
 RS485 Communication Control
Control camera via RS485, half duplex mode:
Baud rate: 2400/4800/9600/38400 bit/s;
Starting position: 1 bit
Data bit: 8 bits
Stop bit: 1 bit
Check digit: None
After power on, the camera goes to the upper
right limit and then back to the middle position.
The zoom lens is pulled to the farthest position,
auto focus, and the aperture is adjusted to the
default value. If the camera has preset 0 saved,
the camera will be set to position 0 after the
initialization is completed. At this point, the
user can use the serial port command to
control the camera.
 List of protocols (omitted)
The serial port of the camera follows the
VISCA/Pelco-D/Pelco-P standard protocol. If
secondary development is required, the
camera can be controlled according to the
standard protocol.
For a detailed list of VISCA/Pelco-D/Pelco-P
protocols, contact the manufacturer.

VHD-V600(S) Video Conference Camera User Manual
7
5 GUI Settings
5.1 MENU
Press [MENU] button to display the main menu
on the normal screen, using arrow button to
move the cursor to the item to be set. Press
the [HOME] button to enter the corresponding
sub-menu.
MENU
Exposure
Color
P/T/Z
Noise Reduction
Setup
Communication Setup
Restore Default
[Home] Enter
[Menu] Exit
5.2 EXPOSURE
Move the main menu cursor to [EXPOSURE],
and press [HOME] key enter the exposure
page, as shown in the following figure.
EXPOSURE
Mode Auto
ExpCompMode Off
Backlight Off
Gain Limit 3
Anti-Flicker 50Hz
Meter Average
DRC 3
Select Item
Change Value
[Menu] Back
Mode: Exposure mode, optional items: Auto,
Manual, SAE, AAE, Bright.
ExpCompMode: Exposure the compensation
mode, optional items: On, Off (Effective only in
Auto mode).
ExpComp: Exposure the compensation value,
optional items: -7~7 (Effective only in
ExpCompMode item to On).
Backlight: Set the backlight compensation,
optional items: On, Off (Effective only in Auto
mode).
Bright: Intensity control, optional items: 0~17
(Effective only in Bright mode).
Gain Limit: Maximum gain limit, optional items:
0 ~ 15 (Effective only in Auto, SAE, AAE,
Bright mode).
Anti-Flicker: Anti-flicker, optional items: Off,
50Hz, 60Hz (Effective only in Auto, AAE, Bright
mode).
Meter: Optional items: Average, Center, Smart,
Top.
Iris: Aperture value, optional items: F1.8, F2.0,
F2.4, F2.8, F3.4, F4.0, F4.8, F5.6, F6.8, F8.0,
F9.6, F11.0, Close (Effective only in Manual,
AAE mode).
Shutter: Optional items: 1/30, 1/60, 1/90, 1/100,
1/125, 1/180, 1/250, 1/350, 1/500, 1/725,
1/1000, 1/1500, 1/2000, 1/3000, 1/4000,
1/6000, 1/10000 (Effective only in Manual,
SAE mode).
Gain: Optional items: 0 ~ 7 (Effective only in
Manual mode).
DRC: DRC strength, optional items: 0 ~ 8.
5.3 COLOR
Move the main menu cursor to [COLOR], and
press [HOME] key enter the color page, as
shown in the following figure.
COLOR
WB Mode Auto
RG Tuning 0
BG Tuning 0
Saturation 100%
Hue 7
AWB Sens High
Select Item
Change Value
[Menu] Back

VHD-V600(S) Video Conference Camera User Manual
8
WB-Mode: White balance mode, optional
items: Auto, Indoor, Outdoor, One Push,
Manual, VAR.
RG Tuning: Red gain fine-tuning, optional
items: -10 ~ +10 (Effective only in Auto, One
Push, VAR mode).
BG Tuning: Blue gain fine-tuning, optional
items: -10 ~ +10 (Effective only in Auto, One
Push, VAR mode).
Saturation: Optional items: 60% ~ 200%.
Hue: Optional items: 0 ~ 14.
AWB Sens: The white balance sensitivity,
optional items: Low, Middle, High.
RG: Red gain, optional items: 0~255 (Effective
only in Manual mode).
BG: Blue gain, optional items: 0~255 (Effective
only in Manual mode).
colortemp: Optional items: 2500K ~ 8000K
(Effective only in VAR mode).
5.4 IMAGE
Move the main menu cursor to [IMAGE], and
press [HOME] key enter the image page, as
shown in the following figure.
Luminance 7
Contrast 10
Sharpness 3
Flip-H Off
Flip-V Off
B&W-Mode Off
Gamma Default
Style Clarity
Select Item
Change Value
[Menu] Back
Luminance: Brightness adjustment, optional
items: 0 ~ 14.
Contrast: Contrast adjustment, optional items:
0 ~ 14.
Sharpness: Sharpness adjustment, optional
items: Auto, 0 ~ 15.
Flip-H: Image flipped horizontally, optional
items: On, Off.
Flip-V: Image Flip Vertical, optional items: On,
Off.
B&W-Mode: Optional items: On, Off.
Gamma: Optional items: Default, 0.45, 0.5,
0.56, 0.63.
Style: Optional items: Default, Norm, Clarity,
Clarity (LED), Bright, Soft, 5S.
5.5 P/T/Z
Move the main menu cursor to [P/T/Z], and
press [HOME] key enter the P/T/Z page, as
shown in the following figure.
P/T/Z
SpeedByZoom On
AF-Zone Center
AF-Sense High
L/R Set STD
Display Info On
Image Freeze Off
Digital Zoom Off
Call Preset Speed 24
Fast Zoom Off
Select Item
Change Value
[Menu] Back
SpeedByZoom: The depth of field scale switch,
optional items: On, Off.
AF-Zone: Interested in focusing area, optional
items: Top, Center, Bottom.
AF-Sense: Automatic focusing sensitivity
options, optional items: Low, Normal, High.
L/R Set: Optional items: STD, REV.
Image Freeze: Optional items: On, Off.
Display Info: Optional items: On, Off.
Digital Zoom: Optional items: Off, 2x, 4x, 8x,
16x.
Call Preset Speed: Optional items: 1 ~ 24.
Fast Zoom: Optional items: On, Off.

VHD-V600(S) Video Conference Camera User Manual
9
5.6 NOISE REDUCTION
Move the main menu cursor to [NOISE
REDUCTION], and press [HOME] key enter
the noise reduction page, as shown in the
following figure.
NOISE REDUCTION
NR2D-Level 1
NR3D-Level 3
Select Item
Change Value
[Menu] Back
NR2D Level: 2D noise reduction, optional
items: Off, Auto, 1 ~ 5.
NR3D Level: 3D noise reduction, optional
items: Off, 1 ~ 8.
5.7 SETUP
Move the main menu cursor to [SETUP], and
press [HOME] key enter the setup page, as
shown in the following figure.
SETUP
Language EN
DVI Mode DVI
Lens Type 2
auto scan shoot Off
Select Item
Change Value
[Menu] Back
Language: Optional items: EN, Chinese,
Russian.
DVI Mode: Optional items: DVI, HDMI.
Lens: Optional items: Type1, Type2.
auto scan shoot: Optional items: On, Off.
5.8 COMMUNICATION SETUP
Move the main menu cursor to
[COMMUNICATION SETUP], and press
[HOME] key enter the communication setup
page, as shown in the following figure.
COMMUNICATION SETUP
Protocol VISCA
V_Address 1
V_AddrFix Off
Net Mode Serial
Baudrate 9600
Select Item
Change Value
[Menu] Back
Protocol: Control protocol type, optional items:
Auto, VISCA, PELCO-D, PELCO-P.
V_Address: Optional items: 1 ~ 7.
(Effective only in Auto, VISCA protocol).
V_AddrFix: Optional items: On, Off (When set
to On, useless in 88 30 01 FF Command).
P_D_Address: Optional items: 0 ~ 254.
(Effective only in PELCO-D protocol).
P_P_Address: Optional items: 0 ~ 31.
(Effective only in PELCO-P protocol).
Net Mode: Set the serial port network control,
optional items: Serial, Paral.
Baudrate: Serial port baud rate, optional items:
2400, 4800, 9600, 38400.
5.9 RESTORE DEFAULT
Move the main menu cursor to [RESTORE
DEFAULT], and press [HOME] key enter the
restore default page, as shown in the following
figure.
RESTORE DEFAULT
Restore? No
Change Value
[Home] OK
[Menu] Back
Restore: Confirm restore factory settings,
optional items: Yes, No.
Note: Press [HOME] button to confirm, all
parameter restore default, include IR Remote
address and VISICA address.

VHD-V600(S) Video Conference Camera User Manual
10
6 Network Function
6.1 Operating Environment
Operating System: Windows 2000/2003/XP/
vista/7/8/10
Network Protocol: TCP/IP
Client PC: P4/128M RAM/40G HDD/ support
scaled graphics card, support DirectX 8.0 or
more advanced version.
6.2 Equipment Installation
1) Connect internet camera to your internet
or to your PC directly via internet cable.
2) Turn on DC 12V power.
3) If the network connection is normal, the
connection light (green) at the network
interface will light up within 5 seconds, and
the data indicator (orange) will flash,
indicating that the physical connection of
the camera has been completed.
6.3 Internet Connection
There are two main ways to connect network
camera.
Connect by Network Cable
Connect by Switch/Router
6.4 IP camera controlled by LAN
6.4.1 Setup IP address
If you don't know the camera IP, view as below:
Method 1: Press * and # and 4 on remote
controller one by one, the camera IP address
will be shown on screen.
Method 2: Connect camera to PC with network
cable, use “upgrade_En.exe” to search for IP
address.
Change IP address, two methods as below:
Method 1: Login the web page, select
“Network > Lan Settings”, change IP address.
Click “Apply” then restart camera.

VHD-V600(S) Video Conference Camera User Manual
11
Method 2: Open “upgrade_En.exe”, change IP
and click “Set”. After modified, IP Camera will
be restart.
IP camera default IP address “192.168.100.88”,
the username is “admin”, password is “admin”.
6.4.2 Visit/Access IP Camera
Input http://192.168.100.88 to IE (better with IE
web browser, others will cause little latency), a
login window pop up, input login name: admin,
password: admin, shown as below:
After login, shown as below:
If user first time use this camera by internet
(only for new user), must install a player
software (VLC). Please go to VLC website
http://www.videolan.org/vlc/#download and
Install VLC (player software).After installation,
login again, will show as above:
6.5 IP Camera controlled by WAN
6.5.1 Setup IPC controlled by dynamic DNS
Two dynamic DNS: Dyndns.org, 3322.org.
Router Port Mapping:
Take Tenda router for example, enter the
Router Home Page (interface page), select
“Advanced”- “Virtual Server”, add a new port
number in “Ext Port”, add a new port number in
“Int port”, put camera IP address to “Internal
IP”, then select “Save”, shown as below:

VHD-V600(S) Video Conference Camera User Manual
12
6.5.2 Dynamic DNS visit camera
Set domain name to camera, setup the
parameter, then dynamic DNS can access
camera. Access link: http://hostname: port
number. For example, setup host computer
name: youdomain.f3322.org, the camera port
number is 89, the access link should be
http://youdomain.3322.org:89.
If the camera port default is 80, then
unnecessary to input port number, use host
name can access camera directly.
6.5.3 VLC stream media player monitoring
Visit VLC media server procedure
Step 1 Open VLC media player.
Step 2 Click “Media > Open Network Stream”,
or click “Ctrl + N”; as below:
Step 3 Input URL address:
rtsp://ip: port number/1 (First stream);
rtsp://ip: port number/2 (Second
stream).
Step 4 Finish.
RTSP port number default 554.
6.6 IP Camera Parameter Setup
6.6.1 Homepage Introduction
Menu
All pages include two menu bars:
Real time monitoring: displaying video image
Parameter setup: with function buttons.
A. Video viewing window
Video viewing window must be same as video
resolution, the bigger the resolution is, the
bigger the playing area is. Double click viewing
window, will show full-screen, double click
again, will return to initialized size.
Status bar in viewing window shown as below:
1) Video playback pause button: control
real-time video pause, stop the last picture,
click recoverable video again.
2) Audio control buttons: can set silent mode.
3) Full screen switch button.

VHD-V600(S) Video Conference Camera User Manual
13
B. PTZ Setup
PTZ direction control box: Up, down, left,
right, home button as above.
Rate: Pan Speed can be chosen as 1 ~ 24,
Tilt Speed can be chosen as 1 ~ 20.
Select corresponding speed and click direction
button to realize PTZ speed up or speed down.
Zoom In/Zoom out: For zooming in or zooming
out. Focus In/Focus Out: Focusing on distant
the objects or focusing on close the objects.
Set/Call: When PTZ turn to expected position,
can set up preset that user want as below.
Method 1: Type a number into the Preset box.
Method 2: Type the name into the Presets
Information.
Click “Set” button, when PTZ turn to other
position, click “Call” button or click “No.” of the
Presets Information, PTZ will turn back to
preset position.
PTZ / MENU: When system in menu mode,
OSD menu display in the upper corner of the
image page. PTZ direction control box:
Up/down button select menu, and the home
button enter the submenu, the left/right button
modify the submenu. After the menu to be
modified, select PTZ. If in the main menu, save
the setting and exit automatically. Otherwise,
return to the previous menu.
PTZ: system in PTZ mode.
C. Language selection
Chinese/English/Russian

VHD-V600(S) Video Conference Camera User Manual
14
6.6.2 Video Settings
1) Video Format
Support 50Hz (PAL) and 60Hz (NTSC), and
Dial Priority three formats.
2) Encode Level
Support baseline, mainprofile, highprofile and
svc-t four levels.
3) Encode Protocol
Support H.264, H.265 and MJPEG three
formats.
4) Resolution
First stream support 1920x1080, 1280x720,
1024x576, 960x540, 640x480, 640x360.
Second stream support 1280x720, 1024x576,
720x576 (50Hz support), 720x480 (60Hz
support), 720x408, 640x360, 480x270,
320x240, 320x180; The bigger resolution is,
the clearer the image will be, more network
bandwidth will be taken.
5) Bit Rate
The user can specify the bit rate. Generally
speaking, the larger of the bit rate, the clearer
of the image. However, the configuration of the
bit rate needs to be combined with the network
bandwidth. When the network bandwidth is
narrow and the bit rate is configured larger, the
video stream cannot be transmitted normally,
and the visual effect is worse.
6) Frame Rate
User can specify the size of the frame rate,
generally, the frame rate greater, the image
more smooth; Frame rate is smaller, the more
sense of beating.
7) I Key Frame Interval
Set interval between 2 I frame, the bigger
interval is the response will be lower from
viewing window.
8) Bit Rate Control
Code stream control way:
Constant Bit Rate: Video coder will be coding
according to preset speed.
Variable Bit Rate: Video coder will adjust the
speed based on preset speed to gain the best
image quality.
9) Fluctuate Level
Restrain the fluctuation magnitude of variable
rate, grade 1 ~ 6.

VHD-V600(S) Video Conference Camera User Manual
15
10) Slice Split Enable
Enable or disable slice split function.
11) Split Mode
Select split mode, optional items: Fixed blocks,
Fixed bytes.
12) Slice Size
Set the size of slice.
6.6.3 Image Settings
1) Brightness
Image bright 0~14, slider control, on the right
shows the corresponding numerical.
Default value is 7.
2) Saturation
Saturation 0~14, slider control, on the right
shows the corresponding numerical.
Default value is 4.
3) Contrast
Contrast 0~14, slider control, on the right
shows the corresponding numerical.
Default value is 10.
4) Sharpness
Sharpness 0~15, slider control, on the right
shows the corresponding numerical.
Default value is 3.
5) Hue
Hue 0~14, slider control, on the right shows
the corresponding numerical.
Default value is 7.
6) Flip & Mirror
Tick Flip to realize image upside down, tick
mirror to realize image around the mirror.
Default value is not tick.
6.6.4 Audio Settings
1) Audio Switch
Enable or disable audio switch.
2) Audio Type
Audio type AAC.
3) Sample Rate
Sample rate 44.1K and 48K selectable.
4) Bit Rate
Bit rate 96K, 128K, 256K selectable.
5) Input Type
Input type line in.
6) Input Vol L
The volume of the left channel.
7) Input Vol R
The volume of the right channel.
8) ADTS Options
Optional items: On, Off.

VHD-V600(S) Video Conference Camera User Manual
16
6.6.5 System Settings
1) Work Mode
The default work mode is RTSP.
Optional items: RTSP, SDK, Multicast.
2) Reboot
Click the “Reboot” button, system restart.
3) Username and password
The user can modify the password (letters and
Numbers only).
6.6.6 Network Settings
1) Lan Settings
Default the IP address is 192.168.100.88, the
MAC address can not be modified.
2) Port Settings
A. HTTP Port
IP address identifies the network device, the
device can run multiple web applications, each
network program using network port to
transmit data, so data transmission to be
carried out between the port and port. Port
setting is to set up web server program using
which port to transmit. When port mapping,
need to be consistent with the port number
(default port: 80).
B. RTSP Port
Network camera support RTSP protocol, use
the VLC tools broadcast.
C. PTZ Port
Support PTZ protocol, default port: 5678.
3) Control Protocol Settings
Setting the camera control communication
protocol, include Visca address, Pelco-D
address and Pelco-P address.
4) RTMP Settings
Setting the MRL of RTMP, select enable or
disable video and audio. You can select control
code stream of “On”, “Off”, “Video”, “Audio”
between in the two stream.
5) RTSP Settings
Turn On/Off RTSP auth.
6) ONVIF Settings
Turn On/Off ONVIF and ONVIF auth.
7) Multicast Settings
Turn On/Off multicast. Setting the multicast
address (default value is 224.1.2.3) and port
(default value is 6688, then 6688 is the
multicast port of the first stream; 6690 is the
multicast port of the second stream).
