Vanco HDSP4K12 Installation instructions

4K HDMI® Splitters
with HDR
Vanco Part Number:
HDSP4K12 1x2
HDSP4K14 1x4
Technical Support
www.vanco1.com • [email protected] • 800-626-6445

www.vanco1.com 800-626-6445 2
1. Do not expose this unit to water, moisture,
or excessive humidity.
2. Do not install or place this unit in a built-in
cabinet, or other conned space without
adequate ventilation.
3. To prevent risk of electrical shock or re
hazard, due to overheating, do not obstruct
unit’s ventilation openings.
4. Do not install near any source of heat,
including other units that may produce heat.
5. Do not place unit near ames.
6. Only clean unit with a dry cloth.
7. Unplug unit during lightening storms, or
when not used for an extended period
of time. A surge protector is strongly
recommended.
8. Protect the power cord from being walked
on or pinched, particularly at the plugs.
9. Use unit only with accessories specied by
the manufacturer.
10. Refer all servicing to qualied personnel.
CAUTION
HDMI is a very complex technology requiring continuous authentication of the signal and the same
video resolution and audio settings on all electronic equipment in the system. When there are multiple
sources and displays, the video resolution and audio setting on all connected units must be adjusted
to correspond with that of the display having the lowest video and audio capability.
WARNING
DEAR CUSTOMER
Thank you for purchasing this product.
For optimum performance and safety, please
read these instructions carefully before
connecting, operating or adjusting this product.
Please keep this manual for future reference.
This product is 100% inspected and tested in the United States
to verify HDMI performance parameters.

www.vanco1.com 800-626-6445 3
FEATURES
The Vanco HDSP4K12 and HDSP4K14 with HDCP 2.2, 4K/60Hz, and 4:4:4 chroma capability, are
the most up to date HDMI splitters that are compliant with HDCP 2.2 displays and sources. Also
features EDID management, with different modes to ensure compatibility with source and display
combinations. Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio for advanced
audio setups. Take any 4K source and split the signal to multiple 4K displays to ensure the highest
quality possible with the Vanco 4K HDMI Splitters!
Note: To achieve 4K video quality, all connected displays must be able to handle 4K resolution.
Any lower resolution display connected, will affect the overall resolution the splitters output to all
ports.
1x2 4K HDMI® Splitter with HDR
Part # HDSP4K12
• Transmits audio and video from a single source to 2 HDMI outputs up to 4K2K (2160p) Ultra High
Denition resolution without any loss of quality or resolution
• Supports video formats up to 4K2K@60Hz with 12bit YCBCR 4:4:4 and HDR
• 3D frame sequential video format up to 1080p@60
• Supports high resolution VESA mode video format up to QSXGA 2560x2048@60Hz
• Compliant with HDCP 2.2 sources and backwards compatible with older versions of HDCP
• Dynamic and Manual EDID management modes to ensure compatibility during installation
• Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
• Supports Hot-plug
• High bandwidth: 18 Gbps
• Features status indicator for connection & input HDCP compliance
• Can be cascaded with other Evolution by Vanco products to create additional output options or to create
an expanded distribution system
• Power Supply: DC 5V, 1A
• Dimensions: 4.7” W x .6” H x 3” D
PACKAGE CONTENTS
• HDSP4K12 4K HDMI Splitter
• (1) DC 5V Power Supply
• Product Manual

www.vanco1.com 800-626-6445 4
1x4 4K HDMI® Splitter with HDR
Part # HDSP4K14
• Transmits audio and video from a single source to 4 HDMI outputs up to 4K2K (2160p) Ultra High
Denition resolution without any loss of quality or resolution
• Supports video formats up to 4K2K@60Hz with 12bit YCBCR 4:4:4 and HDR
• 3D frame sequential video format up to 1080p@60
• Supports high resolution VESA mode video format up to QSXGA 2560x2048@60Hz
• Compliant with HDCP 2.2 sources and backwards compatible with older versions of HDCP
• Dynamic and Manual EDID management modes to ensure compatibility during installation
• Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
• Supports Hot-plug
• High bandwidth: 18 Gbps
• Features status indicator for connection & input HDCP compliance
• Can be cascaded with other Evolution by Vanco products to create additional output options or to create
an expanded distribution system
• Power Supply: DC 5V, 1A
• Dimensions: 4.7” W x .6” H x 3” D
PACKAGE CONTENTS
• HDSP4K14 4K HDMI Splitter
• (1) DC 5V Power Supply
• Product Manual

www.vanco1.com 800-626-6445 5
SPECIFICATIONS
Video Bandwidth......................................................... 600MHz/18Gbps
Input Ports................................................................. 1 × HDMI (Female type)
Output Ports.............................................................. 2 or 4 × HDMI (Female type),
Output Resolution....................................................... 480i-1080p@50/60Hz; 2160p@24/30Hz;
2160p@60Hz; VESA Formats up to QSXGA 2560x2048@60Hz
ESD Protection........................................................... Human Body model: ±8 kV (air-gap discharge) ±4 kV
(contact discharge)
Power Supply............................................................. 1x2, 1x4: 5V/2A DC (US/EU standards, CE/FCC/UL
certied)
Dimensions................................................................ 1x2: 4.7” W x .6” H x 3” D ; 1x4: 4.7” W x .6” H x
3” D
Chassis Material......................................................... Metal
Operating Temperature................................................ 0 °C~40 °C/ 32 °F~104 °F
Storage Temperature.................................................. −20 °C ~ 60 °C/−4 °F ~140 °F
Relative Humidity........................................................ 20~90 % RH (non-condensing)
Power Consumption (Max)........................................... 1x2, 1x4: 10W

www.vanco1.com 800-626-6445 6
PANEL DESCRIPTIONS
1. POWER LED: Illuminates when the splitter is connected to power
2. IN LED: Illuminates when the source is connected and is powered on
3. OUTPUT 1/2 LED: Illuminates when a display is connected to “HDMI OUT 1/2” and is powered on
4. DC 5V IN: Connect the included power supply to power the unit
5. HDMI OUTPUT 1/2: Connect an HDMI display such as an HDTV or Projector; either port can also be used
to cascade or daisy-chain to another splitter, to create additional outputs
6. HDMI IN: Connect a source such as a Set Top Box, Game Console, or media player/streamer
7. SERVICE: Used for any future rmware updates available on the product page (downloads section) on
www.vanco1.com
8. EDID: See EDID Management section for explanation of adjustment
123
456
HDSP4K12
Front
Back
Right Side
78

www.vanco1.com 800-626-6445 7
PANEL DESCRIPTIONS
1. POWER LED: Illuminates when the splitter is connected to power
2. IN LED: Illuminates when the source is connected and is powered on
3. OUTPUT 1/2/3/4 LED: Illuminates when a display is connected to “HDMI OUT 1/2/3/4” and is powered on
4. DC 5V IN: Connect the included power supply to power the unit
5. HDMI OUTPUT 1/2/3/4: Connect an HDMI display such as an HDTV or Projector; any port can also be
used to cascade or daisy-chain to another splitter, to create additional outputs
6. HDMI IN: Connect a source such as a Set Top Box, Game Console, or media player/streamer
7. SERVICE: Used for any future rmware updates available on the product page (downloads section) on
www.vanco1.com
8. EDID: See EDID Management section for explanation of adjustment
12 3
4
HDSP4K14
Right Side Right Side
Front
Back
5
6
7
8

www.vanco1.com 800-626-6445 8
EDID MANAGEMENT
Extended Display Identication Data (EDID) is a data structure provided by a digital display to describe its
capabilities to a video source (e.g. graphics card or set-top box). In a nutshell, the display provides its EDID
info to the source to send the proper signal format, this is essential for a proper handshake to occur.
• When making any adjustments to EDID, turn off every component (splitter, source, and all displays), then
turn on splitter rst, followed by the source, then the main display (HDMI Output 1). Finally, turn on all
other displays after ensuring the correct video signal is displaying on the main display.
• When in ‘TV’ mode, the unit will read the EDID settings of the display device connected to HDMI OUT
1 (Output 1 should be the main display connected). This is an auto setting and should be set to if 4K
resolution is desired. If Output 1 detects a 4K2K capable EDID setting, the splitter will transmit the
signal in that resolution format to all outputs. If no 4K2K capable EDID is detected, then the unit will
output the best resolution that all displays can support.
• When in ‘STND’ mode, the splitter will use its own built-in EDID settings. In this mode, the EDID will
default to 1080p@60Hz and LPCM 2CH Stereo audio. Use this mode if there are display issues in TV
Mode.
Note: To achieve 4K video quality, all connected displays must be able to handle 4K resolution. Any lower
resolution display connected, will affect the overall resolution the splitters output to all ports, and the splitter
will use the highest resolution that all displays connected can handle.

www.vanco1.com 800-626-6445 9
CONNECT AND OPERATE
1. Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc.
to the HDMI input on the unit.
2. Connect a display such as an HDTV or HD Projector to the HDMI output on the unit.
3. For power, plug in the unit with the included power supply.
*NOTE: Unit must be connected to source if there are more components involved in the setup.
HDSP4K12
HDSP4K14

www.vanco1.com 800-626-6445 10
SAFETY AND NOTICE
The HDSP4K12/HDSP4K14 has been tested for conformance to safety regulations and requirements, and has
been certied for international use. However, like all electronic equipment, the HDSP4K12/HDSP4K14 should
be used with care. Please read and follow the safety instructions to protect yourself from possible injury and
to minimize the risk of damage to the unit.
• Follow all instructions and warnings marked on this unit.
• Do not attempt to service this unit yourself, except where explained in this manual.
• Provide proper ventilation and air circulation and do not use near water.
• Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.
• Use only the power adapter and power cords and connection cables designed for this unit.
• Do not use liquid or aerosol cleaners to clean this unit.
• Always unplug the power to the device before cleaning.
TROUBLE-SHOOTING
Problems Causes Solutions
Color loss or no video signal
output in HDMI display
The connecting cables may
not be connected correctly or
it may be broken.
Check whether the cables are
connected correctly and in working
condition.
The display is not compatible
with the present output
resolution.
Make sure the resolution of the
display(s) is compatible with the
present resolution.
No HDMI signal output while
local HDMI input is in normal
working state
The connecting cables may
not be connected correctly or
it may be broken.
Check whether the cables are
connected correctly and in working
condition.
Splash screen in output
devices
Poor quality of the connecting
cable
Change for another cable of good
quality.
Static becomes stronger
when connecting the video
connectors
Bad grounding Check the grounding and make
sure it is connected well.

www.vanco1.com 800-626-6445 11
TECHNICAL SUPPORT
In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445. You can also email
technical support issues to [email protected].
When calling, please have the Model Number, Serial Number (afxed to the bottom of the unit) and Invoice
available for reference during the call.
Please read this Instruction Manual prior to calling or installing this unit, since it will familiarize you with the
capabilities of this product and its proper installation.
All active electronic products are 100% inspected and tested to insure highest product quality and trouble-
free installation and operation. The testing process utilizes the types of high-denition sources and displays
typically installed for entertainment and home theater applications.
For additional information, such as helpful installation videos, glossary of terms, etc. please visit vanco1.com
LIMITED WARRANTY
With the exceptions noted in the next paragraph, Vanco warrants to the original purchaser that the equipment
it manufactures or sells will be free from defects in materials and workmanship for a period of two years from
the date of purchase. Should this product, in Vanco’s opinion, prove defective within this warranty period,
Vanco, at its option, will repair or replace this product without charge. Any defective parts replaced become
the property of Vanco. This warranty does not apply to those products which have been damaged due to
accident, unauthorized alterations, improper repair, modications, inadequate maintenance and care, or use in
any manner for which the product was not originally intended.
Items integrated into Vanco products that are made by other manufacturers, notably computer hard
drives and liquid crystal display panels, are limited to the term of the warranty offered by the respective
manufacturers. Such specic warranties are available upon request to Vanco. A surge protector, power
conditioner unit, or an uninterruptible power supply must be installed in the electrical circuit to protect against
power surges.
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales
invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco
regarding warranty repair or replacement.
LIABILITY STATEMENT
Every effort has been made to ensure that this product is free of defects. The manufacturer of this product
cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising
from its use. It is the responsibility of the user and installer of the hardware to check that it is suitable for
their requirements and that it is installed correctly. All rights are reserved. No parts of this manual may be
reproduced or transmitted by any form or means electronic or mechanical, including photocopying, recording
or by any information storage or retrieval system without the written consent of the publisher.
Manufacturer reserves the right to revise any of its hardware and software following its policy to modify and/or
improve its products where necessary or desirable. This statement does not affect the legal rights of the user
in any way.

Vanco® International
506 Kingsland Drive
Batavia, Illinois 60510
call: 800.626.6445
fax: [phone]
visit: www.vanco1.com
