S108 Series Unmanaged Industrial Switches
User Manual
Version: 1.2
© Vantron Technology, Inc. All rights reserved.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual www.vantrontech.com
Revision History
No. Description Date
V1.0 First release Oct. 21, 2022
V1.1 Updated I/O description Jan. 8, 2023
V1.2 Updated the setup instructions May 17, 2023
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual www.vantrontech.com
Table of Contents
Foreword ................................................................................................................................. 1
CHAPTER 1 INTRODUCTION .............................................................................................................. 5
1.1 Product Overview............................................................................................................. 6
1.2 Features............................................................................................................................ 6
1.3 Unpacking......................................................................................................................... 7
1.4 Specifications.................................................................................................................... 8
1.5 Block Diagram................................................................................................................... 9
1.6 Product Layout ............................................................................................................... 10
1.7 Mechanical Dimensions ................................................................................................. 12
1.8Power Supply and Consumption .................................................................................... 12
CHAPTER 2GETTING STARTED .......................................................................................................... 13
2.1 Device Setup................................................................................................................... 14
2.2 Starting the Device ......................................................................................................... 15
2.3 I/Os ............................................................................................................................... 16
2.3.1 Power connector ............................................................................................................ 16
2.3.2 Relay ............................................................................................................................... 16
2.3.3 Grounding screw hole .................................................................................................... 17
2.3.4 Reset button ................................................................................................................... 17
2.3.5 Ethernet jacks................................................................................................................. 17
2.4 Definition of LED Indicators............................................................................................ 18
2.4.1 Link/activity indicator of RJ45 jacks................................................................................ 18
CHAPTER 3DEVICE CONNECTION ..................................................................................................... 20
3.1 Usage of S108 Series Unmanaged Switches................................................................... 21
3.2 Typical Connection ......................................................................................................... 22
CHAPTER 4 DISPOSAL AND WARRANTY ............................................................................................ 23
4.1 Disposal .......................................................................................................................... 24
4.2 Warranty......................................................................................................................... 25
Appendix Regulatory Compliance Statement ........................................................................... 26
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 1 www.vantrontech.com
Foreword
Thank you for purchasing Vantron Industrial Switch (“the Switch” or “the Product”). S108
series is a combination of four unmanaged switch models, including S108-B, S108-F, S108-R
and S108-FR. This manual is largely based on S108-FR for illustration, and therefore some of
the functions mentioned here may not be applicable to your product. This manual intends to
provide guidance and assistance necessary on setting up, operating and maintaining the
Product. Please read this manual and make sure you understand the structure and
functionality of the Product before putting it into use.
Intended Users
This manual is intended for:
•Network administrators
•Technical support engineers
•Other users
Copyright
Vantron Technology, Inc. (“Vantron”) reserves all rights of this manual, including the right to
change the content, form, product features, and specifications contained herein at any time
without prior notice. An up-to-date version of this manual is available at www.vantrontech.com.
The trademarks in this manual, registered or not, are properties of their respective owners.
Under no circumstances shall any part of this user manual be copied, reproduced, translated,
or sold. This manual is not intended to be altered or used for other purposes unless otherwise
permitted in writing by Vantron. Vantron reserves the right of all publicly released copies of
this manual.
Disclaimer
While all information contained herein has been carefully checked to assure its accuracy in
technical details and typography, Vantron does not assume any responsibility resulting from
any error or features of this manual, nor from improper uses of this manual or the software.
It is our practice to change part numbers when published ratings or features are changed, or
when significant structure changes are made. However, some specifications of the Product
may be changed without notice.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 2 www.vantrontech.com
Technical Support and Assistance
Should you have any question about the Product that is not covered in this manual, contact
your sales representative for solution. Please include the following information in your
question:
•Product name and PO number;
•Complete description of the problem;
•Error message you received, if any.
Vantron Technology, Inc.
Address: 48434 Milmont Drive, Fremont, CA 94538
Tel: (650) 422-3128
Email: sales@vantrontech.com
Regulatory Information
The Product is designed to comply with:
•CE
•Part 15 of the FCC Rules
•UL
Please refer to Appendix for Regulatory Compliance Statement.
Symbology
This manual uses the following signs to prompt users to pay special attention to relevant
information.
Caution for latent damage to system or human injury
Attention to important information or regulations
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 3 www.vantrontech.com
General Safety Instructions
The Product is supposed be installed by knowledgeable, skilled persons familiar with local
and/or international electrical codes and regulations. For your safety and prevention of
damage to the Product and other equipment connected to it, please read and observe
carefully the following safety instructions prior to installation and operation. Keep this manual
well for future reference.
•Do not disassemble or otherwise modify the Product. Such action may cause heat
generation, ignition, electronic shock, or other damages including human injury, and may
void your warranty.
•Keep the Product away from heat source, such as heater, heat dissipater, or engine casing.
•Do not insert foreign materials into any opening of the Product as it may cause the Product
to malfunction or burn out.
•To ensure proper functioning and prevent overheating of the Product, do not cover or
block the ventilation holes of the Product.
•Follow the installation instructions with the installation tools provided or recommended.
•The use or placement of the operation tools shall comply with the code of practice of such
tools to avoid short circuit of the Product.
•Cut off the power before inspection of the Product to avoid human injury or product
damage.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 4 www.vantrontech.com
Precautions for Power Cables and Accessories
Use proper power source only. The Product supports 5V-36V power supply. Make sure
the supply voltage falls within the specified range.
Place the cables properly at places without extrusion hazards.
Use only approved antenna(s). Non-approved antenna(s) may produce spurious or
excessive RF transmitting power which may violate FCC limits.
Cleaning instructions:
•Power off the Product before cleaning
•Do not use spray detergent
•Clean with a damp cloth
•Do not try to clean exposed electronic components unless with a dust collector
Power off and contact Vantron technical support engineer in case of the following faults:
•The Product is damaged
•The temperature is excessively high
•Fault is still not solved after troubleshooting according to this manual
Do not use in combustible and explosive environment:
•Keep away from combustible and explosive environment
•Keep away from all energized circuits
•Unauthorized removal of the enclosure from the Product is not allowed
•Do not change components unless the power cable is unplugged
•In some cases, the Product may still have residual voltage even if the power cable is
unplugged. Therefore, it is a must to remove and fully discharge the Product before
replacement of the components.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 6 www.vantrontech.com
1.1 Product Overview
As part of Vantron’s overall solution for industrial automation, Vantron S108 series is a
collection of four unmanaged industrial switches that feature 8 Gigabit Ethernet ports to
demonstrate excellent data transfer performance.
Vantron S108 series offers a Plug and Play solution that reduces users’ educational inputs
and its compact size helps to save the user space. This series supports 12V~48V wide input
voltage and -20℃~ +70℃industrial-grade extended temperature range, and implements
a fanless heat sink for device heat dissipation. Customers have the option of DIN-rail
mounting or rack mounting depending on their installation environment.
Switches are usually used in harsh environments that require stable operation and involve
data interaction between a range of devices. Vantron S108 series is particularly designed
for rail transit, smart city, intelligent mining, etc.
1.2 Features
S108 Series
Plug and play
Low power consumption
Adaptive full/half duplex Ethernet jacks
Long service time
Stringent test proof
Efficient fanless heat dissipation
Wide input voltage & temperature range
Compact size, easy to deploy
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 7 www.vantrontech.com
1.3 Unpacking
The Product has been carefully packed with special attention to quality. However, should
you find anything damaged or missing, please contact your sales representative in due time.
Standard accessories Optional accessories
1 x S108 switch 1 x 12V DC Power
adapter & power cord
1 x DIN rail
mounting bracket
(attached)
1 x DC power
connector
Actual accessories might vary slightly from the list above as the customer order might
differ from the standard configuration options.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 8 www.vantrontech.com
1.4 Specifications
Model Name
S108-B
S108-F
S108-R
S108-FR
Ethernet
Interface
8 x RJ45, 10/100/1000 Base-T (X)
NA
2 x SFP, 1000M
NA
2 x SFP, 1000M
LED Indicator
2 x LED indicator on each RJ45 port
(Green: Link/Activity; Yellow: ON—1000M, OFF—10/100M)
2 x LED indicator for each SFP port (NA for S108-B/S108-R)
Standard
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3z
Data
Transfer
Forwarding mode
Store-and-forward
MAC address table
4K
Switching capability
16Gbps
Packet forwarding
rate
11.9Mpp
Packet buffer
2.5Mb
System
Control
Alarm relay
NA
1 x 2-pin x 5.0mm (Current load: 1A @24VDC)
LED indicator
1 x Power indicator
1 x Status indicator
1 x Error indicator
Mechanical
Dimensions
170mm x 122mm x 50mm
Installation
DIN-rail mounting
MTBF
≥30,000 H
IP rating
IP40
Power Input 12V~48V DC, 1 x 4-pin x 5.0mm terminal block
(Dual redundant power supply, Over-current protection, Reverse polarity protection)
Consumption
<3W (Idle); < 7.5W (Full load)
Environment
Condition
Temperature
Operating: -20℃~ +70℃; Storage: -40℃~ +85℃
Humidity
Operating: RH 0-90% (Non-condensing)
EMC level
> EMC Level 3
Certification
CE, FCC, UL
Test
Standard Industrial Standard
EMI
FCC CFR47 Part 15, EN55032/CISPR22, Class A
EMS
IEC61000-4-2 (ESD): ±6kV (contact), ±8kV (air)
IEC61000-4-3 (RS): 10V/m (80MHz～2GHz)
IEC61000-4-4 (EFT): Power port: ±2kV, Data port: ±1kV
IEC61000-4-5 (Surge): Power port: ±1kV/DM, ±2kV/CM, Data port: ±1kV/DM, ±2kV/CM
IEC61000-4-6 (CS): 10V (150kHz～80MHz) (Mechanical)
IEC60068-2-6 (Vibration)
IEC60068-2-27 (Shock)
IEC60068-2-32 (Free fall)
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 9 www.vantrontech.com
1.5 Block Diagram
VSC7512
Temperature:
Operate: -20 ~ +70℃
Storage: -40 ~ +85℃
VT-M2M-S108 : IC Chip : Connector : PCBA
MX25L1606 PHY
VSC8514
74HC164PW
QSGMII
Console
95040-2881
IO
OQ0253510000G
2*SERDES
Serial
SI
UART
Relay
HFD3/5
GPIO
SP3222EEY
RS232
Crystal
125Mhz
8*R45
10/100/
1000M
Transformer
G4P109NM-A
Transformer
G4P109NM-A
SFP
SFP11-A0-0900
SFP
SFP11-A0-0900
DCIN
OQ0453510000G
12-48V
DC-DC
SGM61720
LEDs
WP934SA/3GD
Reset
Button
GPIO
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 10 www.vantrontech.com
1.6 Product Layout
1.6.1 Front View
8 x RJ45 port
2 x SFP port
3 x LED indicator
(Device status)
4 x LED indicator
(SFP port status)
Reset
button
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 12 www.vantrontech.com
1.7 Mechanical Dimensions
•170mm x 122mm x 50mm
1.8 Power Supply and Consumption
S108 series industrial switches work with 12V-48V DC power input supplied by a DC
connector that supports dual redundant power supply, and is reinforced by over-current
protection, reverse polarity protection. The power consumption of the device is less than
3W when idled and less than 7.5W with full load.
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 14 www.vantrontech.com
2.1 Device Setup
Before using the switch, please follow the steps below to finish the device installation.
1. Hold the switch uprightly;
2. Place the switch on the DIN rail at an angle with the clip at the top of the DIN rail bracket
fit into one side of the DIN rail;
3. Push the switch down to compress the spring of the bracket;
4. Release the switch when there is enough space for the downside of the DIN rail bracket
to fit the other side of the DIN rail;
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 15 www.vantrontech.com
5. Gently swing the switch to make sure the switch is fastened on the DIN rail;
6. Insert one end of an Ethernet cable into any RJ45 port of the switch and the other end
into a switch or server to connect the switch to the network;
7. Use another Ethernet cable to connect a client device to another RJ45 port of the
switch when necessary;
8. Insert the terminal end of the DC power connector into the power terminal of the
switch and the other end into the power cord;
9. Plug the power adapter into a power outlet that meets the supply voltage requirement
(12V to 48V DC) to turn on the device.
2.2 Starting the Device
S108 series unmanaged industrial switches offer a plug-and-play solution, and users need
only to connect the switch to a power source to start using the device. There is no
requirement for additional configurations.
If you are using the power connector supplied by Vantron
R
ed wire: +
B
lack wire: -
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 16 www.vantrontech.com
2.3 I/Os
2.3.1 Power connector
The switch implements a 4-pin 5.0mm power connector that supports dual redundant
power supply with over-current protection and reverse polarity protection to ensure
reliable operation of the device in a long term.
Pinout description:
Pin Signal Description
1 V1+ Primary power supply positive
2 V1- Primary power supply negative
3 V2+ Backup power positive
4 V2- Backup power negative
2.3.2 Relay
S108-R and S108-FR implement a relay connector that is designed to connect an alarm to
alert the user when there is a fault with any of the interface. The connector supports a load
capacity of 1A @24V DC.
Pinout description:
Pin Signal Description
1 Relay_in Relay input
2 Relay_out Relay output
Pin 1
Pin 1
Vantron | Embedded in your success, Embedded in your better life
World-leading provider of embedded/IoT products and solutions
S108 Series Industrial Switches | User Manual 17 www.vantrontech.com
2.3.3 Grounding screw hole
With the grounding screw hole, users can ground the switch using an M3 screw and a
grounding wire.
2.3.4 Reset button
The switch implements a pinhole reset button which enables the device to reboot upon a
short press.
2.3.5 Ethernet jacks
The switch offers eight RJ45 Ethernet jacks, supporting 10M/100M/1000M Base-T data
rate.
S108-F and S108-FR additionally implement two SFP ports, including SFP1 (marked as G9
on the enclosure) that supports 100M/1G data rate and SFP2 (G10) that supports
100M/1G/2.5G auto adaptive data rate.
Each Ethernet jack has two LED indicators to indicate the link/activity status of the network.
Description of the status indicator is detailed in the following section.
This manual suits for next models
4
Table of contents
Other Vantron Switch manuals
