Vantrue AngelGuard A1 User manual

Made in China
http://www.vantrue.net
EU Environmental Protection
Waste electrical products shuld
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
local authority or retailer for
recycling advice.

AngelGuard A1
2.4GHz Wireless Video Baby Monitor
User Manual

1. Safety Instructions 1
2. Product Overview
2.1 Pack Contents
2.2 Baby Monitor Overview
3.1 Powering the Camera
3.2 Power on the Monitor
3.3 Camera Pairing/Adding/Deleting
3.4 Placing the Camera
3.5 Wall Mounting Camera
4.1 Monitor Settings
4.2 Audio Alarm Settings
4.3 Temperature Alarm
4.4 Lullabies
4.5 Sleep Mode
4.6 Settings
4.7 Zoom
4.8 Pan-n-Tilt
4.9 Volume Adjustment
4.10 Brightness Adjustment
4.11 Talk Function
2
3. Getting Started 5
5
5
6
9
10
11
12
13
13
14
15
17
17
18
18
18
2
3
4. Basic Operation & Function 10
5. Specifications 19
6. Warranty & Support 20
CONTENTS

1. Safety Instructions
WARNINGS:
CAUTION:
• Keep cord out of the reach of children (more than 3ft/0.9m
away) in case of STRANGULATION.
• NEVER place camera or cords within the cot/crib.
• Secure the cord at least three feet away from crib or playpen.
• Never use extension cords with AC Adapters. Only use the AC
Adapters provided.
• Always unplug AC adapters from wall outlets and power
sources during periods of non-use.
• Do not touch the plug contacts with sharp or metal objects.
• Do not allow water damage to the monitor unit, charging port,
or charging cable which cause overheat of the charging
components.
• Do not use unofficial third party charging cables and adapters
to charge the device. This may result in overheat of the
charging port. Only use the charging cables and adapters
provided in the box.
• This product is not a toy. Do not allow children to play with them.
• This product is not intended for use as a medical monitor and its
use should not replace adult supervision.
• Before using this product, read and follow all instructions and
warnings contained in this booklet.
• Intended for indoor use only.
- 1 -
3ft

2. Product Overview
2.1 Pack Contents
A. 1x Camera Unit
C. 2x USB Power Adapter
E. 1x User Manual
A B
D EC
B. 1x Monitor Unit
D. 2x Power Cable (6.56ft)
• Adult assembly is required. Keep small parts away from children
when assembling.
• Test monitor before use and after changing camera location.
Check reception regularly. Obstacles, such as concrete walls,
may shorten the wireless signal transfer range.
• This product is not intended to replace proper adult vision of
children.
• You must check your child's activity regularly, as this product will
not alert parents to silent activities of a child.
• Microphone feedback might occur when the monitor is too
close to the camera. Please keep them at least 3m/9.8ft apart.
- 2 -
OK

A. Camera
2.2 Baby Monitor Overview
- 3 -
1. Camera Sensor
2. Lens
3. Microphone
4. Speaker
5. Temperature Sensor
6. Indicator LED
7. Set/Pair Button
8. Micro USB Port
9. Mounting Hole
9
9
9
5
6
78
1
2
3
4

- 4 -
B. Baby Monitor
1. Screen
2. Menu Button/Return
3. Power ON/OFF Button
4. Sleep Button
5. Turn UP/Brightness+
6. Confirm Button/Zoom button
7. Turn Right/ Volume+
8. Turn Down/Brightness-
9. Turn Left/Volume-
10. Shortcut Button
11. Dialogue Key-→Talking Key
12. Microphone
13. Status Indicator
14. Antenna
15. RESET Button
16. Speaker
17. Support Stand
18. Micro USB Charging Port
OK
1
4
25
8
3
67
9
10 11
12
13
14
17
15
18
16
0~90°

3. Getting Started
3.1 Powering the Camera
3.2 Powering the Camera
1) Insert one end of the included charging cable into the USB
jack on the back of the camera.
2) Insert the other end into the included power adapter. Then
insert the adapter into the socket.
After being powered on, the camera will automatically turn on.
(The green light on the base of the camera is on for a few
seconds. At this point, the camera is turned on successfully).
1) Charge the monitor via the supplied charging cable and
adapter (The monitor is provided with a lithium battery, if the
monitor has enough power, please go directly to the Step 2)
- 5 -

By default, the baby camera and monitor are paired out of the
box. When you power on the monitor and camera, the two will
automatically pair. If it fails to display on the monitor screen after
power on, please try to add new camera following below steps.
Microphone feedback(noise) might occur when the
monitor is too close to the camera. This is normal phenomenon
and can be resolved when camera is moved away from the
monitor. Please keep them at least 3m / 9.8ft apart.
NOTE:
3.3 Pairing/Adding/Deleting Camera
3.3.1 Pairing the baby monitor & camera
To add more cameras, follow the procedure below:
1) Enter menu settings, select icon and press to enter.
3.3.2 Adding a new camera
2) Press and hold the button to power on the baby monitor.
- 6 -
OK
OK
CAMERAS SOUND
DETECTION
TEMPERATURE
ALA RM
SET TI NG S
SLEEP MODE
LULLABIES

2) Select the channel to be paired, press to confirm,
select and press to confirm.
3) When the device prompts “camera is No paired”, press
to confirm.
4) When the device prompts “Start pairing, please short press the
camera SET key’’, press the SET key of the camera shortly to enter
the pairing mode.
- 7 -
Camera is No paired.
Start pairing, please short press
the camera SET key

3.3.3 Delete Cameras
5) When the monitor prompts "Pairing is OK", which indicates that
the device is successfully paired, the menu will skip to the
real-time monitoring menu, and the first indicator light of the
receiver is constantly on in green.
1) Select icon and press to enter.
2) Select the channel to be deleted, press to confirm, select
and press to confirm.
You can add up to 4 cameras per baby monitor, only one
camera can be viewed at one time. Select icon and press
to enter, press / button to select desired camera,
then press button to view the picture from that camera.
The current camera number will be shown with the camera icon
on the monitor.
Note:
- 8 -
Pairing is OK.

3.4 Placing the Camera
Place the camera unit in a convenient location (e.g. on a table
or a shelf) and point the camera lens toward the area you want
to monitor.
3) When the device prompts “Camera is paired. Can be deleted”
Press to confirm. When the device prompts “Deleting is OK”,
the camera is successfully deleted.
Do not place the camera unit within the baby's reach!
If there is interference on the picture or sound, try moving the
units to different locations, and ensure they are not close to other
electrical equipment.
Note:
- 9 -
Camera is paired. Can be deleted.
Deleting is OK.

3.5 Wall Mounting Camera
4. Basic Operation & Function
Select the spot to mount the camera, keeping it beyond your
baby's reach.
Method 1: Insert the screw (not included), pre-installed on wall
into the mounting hole of the camera.
Method 2: Choose the short screw(not included), adjusting
universal 1/4 screw length fits the baby monitor. Put the screw into
this 1/4 threaded hole and screw it.
It's strongly recommended to use a screw and screw anchor(not
included). Don't release the camera until you're sure it is firmly
mounted.
- 10 -
82
OK
MEN U SLE EP
TALK
SHO RT
CUT
202 0/0 5/2 1 11:2 4: 35 F

4.1 Monitor Settings
MONITOR SCREEN ICON
Explanation for status indicator LED
On-screen Menu Icons
No signal connection between the receiver
and the camera.
Icon Icon Description
Wireless signal strength.
Lullaby enabled.
Alarm Icon
No camera is added or the camera is
disconnected from receiver.
Icon Icon Description
Audio alarm.
Temperature alarm.
Sleep mode enabled.
Show you which camera on display.
Note: This icon will not appear on the screen
when no camera is connected to monitor.
Current time.
Displaying current room temperature.
Current battery level of the monitor unit.
When the battery is too low,this icon will
change to and flash.
- 11 -
2020/05/21 11:24:35
82 F

4.2 Sound Detection
If you need to set the warning audible alarm ON, please
enter Menu Setting, select , press to enter the warning
sound setting page, press /to turn on the audible alarm.
The audio alarm icon will be displayed in the middle of the LCD
screen. The audible alarm will last for 1 minute. The audible alarm
notification can be switched off by pressing any button on the
receiver and the notification will not be received again within 3
minutes thereafter.
Note:
The first green indicator is steady on: indicating successful
connection between the camera and the receiver.
The first to the fifth green indicators slowly flash simultaneously:
indicating power on, but camera not connected.
The second to the fifth green indicators slowly flash from low to
high: indicating the received volume.
The second to the fifth green indicators slowly flash simultaneously:
indicating that the alarm signal is received.
The sixth red indicator is steady on: indicating that the lithium
battery is being charged; (displayed whether it is turned on or off)
The sixth red indicator is off: indicating that the battery is fully
charged.
Set the sound sensitivity alarm range. This function recognizes the
intensity of the baby's crying. When your baby unit detects a
sound, which exceeds the selected sensitivity level, the sound
detection triggers the monitor unit screen to turn on automatically.
1) Enter Menu setting, go to "SOUND DETECTION", and press
to confirm.
2) Select the /// icon as needed and press to
confirm. The audible alarm setting is completed. Press to return.
- 12 -
Default
Low High
MENU
OFF
Default High
Low
OFF

4.3 Temperature Alarm
The setting of temperature alarm defaults to 15~29°C (59°F
~84°F). When the baby room temperature is outside this range,
the receiver will receive a temperature alarm. The temperature
alarm icon will be displayed on the middle of the LCD screen.
Note:
If you need to set the temperature warning audible alarm
ON, please enter Menu Setting, select , Press to enter the
warning sound setting page, press /to turn on the audible
alarm.
The audible alarm will last for 1 minute. The audible alarm
notification can be switched off by pressing any button on the
receiver and the notification will not be received again within 3
minutes thereafter.
Note:
Enter Menu Setting, select icon and press button to the
setting page.
Press /button to switch between °C & °F, and press
button to confirm.
Navigate to function by pressing the button, press /
button to turn on or off temperature alarm function.
- 13 -
CAMERAS SOUND
DETECTION
TEMPERATURE
ALARM
SETTINGS
SLEEP MODE
LULLABIES
ON
OFF
°c
°F

OFF
20s 40s 60s
4.4 Lullabies
4.5 Sleep Mode
In this screen, press / button to switch the lullaby
and press / button to adjust the volume.
Note:
The babysitter has 5 pieces of lullabies to help you sleep your
baby.
1) Enter Menu setting, select the icon and press button to
enter the setting page.
2) Select the music you want to play, press button to confirm,
the camera will play the selected lullaby, press button again
to pause the lullaby. Selecting "All" to play all the lullabies in a
loop. When the setup is complete, press to return.
You can set the receiver to auto sleep mode. This setting enables
the receiver to automatically switch to sleep mode according to
the time setting.
1) Enter Menu setting, go to and press to enter the setting
page.
2) Press / button to select 20s, 40s, 60s or OFF, press
button to confirm. Select "OFF" and press the button to
disable the sleep mode. After the setting is completed, press
to exit.
- 14 -
MENU
MENU

O S D:
DATE:
TIME:
ON
2020- 5-21
18:25:23
With the sound detection on, if the monitor is in the sleep
mode, the baby monitor will automatically turn on the screen
when it detects a sound. It will automatically turn off the screen in
a silent environment to save power.
Note:
- 15 -
4.6.1 Time Settings
4.6 Settings
This setting includes time settings, factory reset, viewing hardware
version and warning sound setting.
1) Select and press button to enter the setting page.
2) Select and press button to enter the time setting page.
3) Press / and button to set date/time;
Navigate / button to select date and time values. Press
button to confirm and proceed. To finish setup, just press the
button to exit.
MENU
CAMERAS SOUND
DETECTION
TEMPERATURE
ALARM
SETTINGS
SL EE P MO DE
LULLABIES

4.6.2 Reset default settings
1) Select and press button to enter the setting page.
2) Select and press button to enter the default setting
page.
3) At this time, the device will prompt “Restore to default
settings?”. Select YES and press button to confirm. The device
will start resetting to default settings.
4) After the default settings are restored, the receiver will
automatically switch to the monitoring interface with an icon
indicating that no camera is added.
- 16 -
YES NO
Restore to default settings?
Start restoring......
2020 /0 5/21 11:24:3 5

4.6.3 Version information
4.6.4 Warning Sound Setting
View the version information of the receiver
1) Select and press button to enter the setting page.
2) Select and press button to check the version
information.
The receiver will display corresponding version information. Press
to return after reviewing the version information.
This setting controls the sound alarm for sound detection alarm
and temperature alarm.
1) Select and press button to enter the setting page.
2) Select and press button to enter the warning sound
setting page. Press / button to turn on or off sound
detection alarm and temperature alarm.
- 17 -
MENU
ON
OFF
Rx:
Rx Date:
Tx:
Tx Date:
