Var-Tec FDR-16 AR Series Quick start guide

TYPICAL WIRING DIAGRAM
Figure 1 shows the typical wiring diagram of the 4-wire
multiple-station smoke detector system.
DO NOT PLACE LINKS BETWEEN THE WIRING POSITIONS
OF TERMINALS 2 AND 5 TO PROVIDE POWER
SUPERVISION
WARNING
TO PREVENT DETECTOR CONTAMINATION AND
SUBSEQUENT WARRANTY CANCELLATION, THE
SMOKE DETECTOR MUST REMAIN COVERED UNTIL
THE AREA IS CLEAN AND DUST FREE.
INSTALLING THE BASE
1. To insure proper installation of the detector head to the
base, all the wires should be properly addressed at
installation:
(A) Position all the wires flat against terminals.
(B) Fasten the wires away from connector terminals.
2. If you use a jumper wire to connect the poles of
terminal 2 and 5 when testing the detector loop
continuity, be sure to remove the jumper wire prior to
the installation of the detector head.
3. The end-of-line device shown in Fig.1 should be
compatible with the control unit. The end-of-line
supervisory relay used should be rated for the DC
power voltage used.
4. Open area smoke detectors are intended for mounting
on a ceiling or a wall in accordance with the fire
standard in your country.
5. The base of the smoke detector can be mounted
directly onto an electrical junction box such as an
octagonal (75mm, 90mm or 100mm), a round (75mm),
or a square (100mm) box without using any type of
mechanical adapter.
INSTALLING THE HEAD
1. Align the components as shown in Figure 2.
Fig. 2 Mating detector head onto base
2. Mate the detector head onto the base and twist
clockwise to secure it.
3.Do not install the detector head until the area is
thoroughly cleaned of construction debris, dusts, etc.
The maximum number of smoke detector installed in
the same loop is 30 units.
ADJUSTING THE RELAY FOR NO/NC
The normal condition for the relay is “normally open”
(NO).To remove top cover remove two screws on back of
FDR-16/26/36 smoke detector as shown in Figure 3
1. To adjust the normal condition of the relay to
“normally closed”(NC),
2. Refer to Figure 4. There is a jumper head next to the
relay on the PCB. Remove the jumper head and reinsert
it in the NC position.
3. Carefully replace the front cover.
Relay contact rating:
1A@30VDC,
0.5A@125VAC.
TESTING
1.All the alarm signal services, releasing device and
extinguisher system should be disengaged during the
test period and must be re-engaged immediately at the
conclusion of testing.
2. After energizing the detector head for approximately
one minute, check to see the indicator green LED
flashing once every 3~5 seconds. If green LED fails to
flash, it indicates the non-functioning of the detector or
faulty wiring. Re-check the wiring or replace the
detector if necessary.
3. Allow smoke from a cotton wick or a test smoke
aerosol to enter the detector-sensing chamber for at
least 10 seconds. When sufficient smoke has entered
the chamber, the detector will signal an alarm, this
being visible by a continuous illumination of the LED.
Reset each detector and/or control unit before
attempting to test any additional detectors in the same
zone. If the alarm fails in this step, it indicates a
defective unit, which requires service.
HEAT SENSOR TESTING
The detector to be tested should be subject to a flow of
warm air at a temperature of between 56°C and 80°C.
(The requirement can be met by some domestic hair
dryers).
Proceed as follows:
FDR-16/26/36 AR/SERIES Detector
Installation Wiring Diagram
Fig. 4 Schematic of
detector Structure
When front cover is
open.
Fig. 3 Two screws on back
of FDR smoke detector
07-04-20
LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: [phone] — E-Mail: [email protected] — www.lucom.de
www.lucom.de

1. Switch on the warm airflow and check that temperature
is correct and stable.
2. From a distance of several inches, direct the airflow at
the guard protecting the thermistor. The detector
should alarm within 30 seconds.
3. Upon alarm immediately remove the heat source and
check that the red LED of the detector is illuminated.
Reset the detector from the control panel.
4.If detector fails to go into alarm mode within 30
seconds it is too insensitive and needs to be returned
to the distributor for servicing.
5. After testing, check that the system is set for normal
operation and notify the appropriate authorities that the
testing operation is complete and the system is active
again.
NOT SUITABLE FOR INSTALLATION IN AREAS
WHERE AIR VELOCITIES EXCEED 300 ft/min
MAINTENANCE
The recommended minimum requirement for detector
maintenance consists of an annual cleaning of dust from
the detector head by using a vacuum cleaner cleaning
program should be agreed to the individual environment
in conformance with NFPA-72A standard.
CAUTION: DO NOT ATTEMPT TO DISASSEMBLY OF
THE FACTORY SEALED SMOKE DETECTOR. THIS
ASSEMBLY IS SEALED FOR YOUR PROTECTION AND
IS NOT INTENDED TO BE OPENED FOR SERVICING BY
USERS. OPENING THE DETECTOR HEAD WILL VOID
THE WARRANTY.
REFERENCE TO THE TECHNICAL BULLETIN ISSUE NO.
FDRTB20041225,REV.C
SPECIFICATION
Model
2/4
wire
Ther
mal
Voltage
DC
Standby
Current
(Max.)
Alarm
Current
(Max.)
Surge
Current
(Max.)
Star-Up
Time
(Max.)
Permissible
Current
(Max.)
Frequency
Alarm
Soundlevel
Alarmcontact
Base model
FDR-16-HR
4
57°C
12V
320μA
55mA
60Seconds
80mA
3-5 Seconds
-
FormA/Auto Reset
P/N774912
FDR-26-S
4
12V
320μA
35mA
60Seconds
80mA
3-5 Seconds
-
FormA/Auto Reset
P/N774912
FDR-36-SHR
4
57°C
12V
320μA
35mA
60Seconds
80mA
3-5 Seconds
-
FormA/Auto Reset
P/N774912
Remarks: S-smoke/ H-heat/ R-rise of heat
LIMITED WARRANTY STATEMENT
VAR-TEC represents that this product is free from defects in material and workmanship. And it will repair or replace any
product or part thereof which proves to be defective in workmanship or material for a period of twelve (12) months from the
date of purchase but not to exceed eighteen (18) months after shipment by the manufacturer. For a full description of
VAR-TEC’S LIMITED WARRANTY, which, among other things, limits the duration of warranties of merchantability and
fitness for a particular purpose and excludes liability for consequential damages. Please read the entire LIMITED
WARRANTY on the VAR-TEC quotation. Acceptance of order and/or original invoice which will become part of your sales
agreement. Please contact VAR-TEC directly for a return merchandise authorization (RMA) number before returning goods
to the company. Shipment must be prepaid and VAR-TEC will repair or replace your returned detector.
FDR-00008
