Vari Lite VL2600 Series User manual

VL2600 PROFILE
VL2600 SPOT
VL2600 WASH
VL2600 SerieS
USER MANUAL

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
2
INTRODUCTION
OUR GOAL
We are committed to providing you the highest quality in customer service. Our comprehensive resources are
available to help your business succeed and ensure you get the full benefit of being a Vari-Lite customer.
TECHNICAL SUPPORT
Our Service and Support team is tasked with online and field support, repair, demo, commissioning, mainte-
nance contracts, and technical training for fixtures and systems. In addition, this team plays a large role in a
Systems sales, responsible for administering final commissioning, record-keeping, and organizing services. Refer
to the back cover of this user manual for contacts in your region or visit WWW.VARI-LITE.COM/SUPPORT.
CUSTOMER SERVICE
Customer Service is responsible for boxed goods and spare parts quotations, order entry and fulfilment, project
delivery, lead times, and general account management. They also manage all after sales warranty fulfilment,
RGA, and repairs invoicing in tandem with our After Sales Service & Support team. Visit our website to find a
customer service agent in your region.
ADDITIONAL DOCUMENTATION
Additional product documentation, including DMX maps, software, and photometric reports, are available for
download on our website.
For more information on installing DMX512 control systems, the following publication is available for purchase
from the United States Institute for Theatre Technology (USITT), “Recommended Practice for DMX512: A Guide
for Users and Installers, 2nd edition” (ISBN: 9780955703522).
USITT Contact Information:
USITT
315 South Crouse Avenue, Suite 200
Syracuse, New York 13210-1844 USA
Phone: [phone] or [phone]
Fax: [phone] or [phone]
Website: www.usitt.org
ABOUT THIS DOCUMENT
Read all instructions before installing or using this product. Retain this user manual for future reference.
Additional product information and descriptions may be found on the product data sheet(s) which can be
downloaded from the Vari-Lite website at WWW.VARI-LITE.COM.
This user manual provides necessary information regarding safety, installation, operation and routine mainte-
nance for Vari-Lite VL2600 Series. Familiarizing yourself with this information will help you to get the most out
of your product.
WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to
the product and potential injury to yourself or others.
This user manual covers the following model(s):
• VL2600 Profile; order code(s) 88-105-7270-00, 88-105-7270-10
• VL2600 Spot; order code(s) 88-105-6950-00, 88-105-6950-10
• VL2600 Wash; order code(s) 88-105-7340-00, 88-105-7340-10

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
3
SAFETY WARNINGS AND NOTICES
Read this user manual in full before attempting to install, operate or maintain the fixture to which it relates. This
user manual is intended to provide general guidance to such suitably qualified personnel. Installation and opera-
tion of the fixture are to be performed by qualified personnel only.
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• For indoor, dry location use only. Do not use outdoors unless fixture is suitably IP rated.
• Use safety tether when mounting.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to
tampering by unauthorized personnel.
• Not for residential use. Do not use this equipment for other than intended use.
• Note distance requirement(s) from combustible materials or illuminated objects. Do not mount near gas
or electric heaters.
• Install only in locations with adequate ventilation. Ensure sure that ventilation slots are not blocked.
• Ensure that the voltage and frequency of the power supply match the power requirements of the
fixture.
• The fixture must be earthed/grounded to the appropriate conductor.
• Do not operate fixture outside the specified ambient temperature range.
• Do not connect the fixture to any dimmer pack.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition
and void warranty.
• Refer service to qualified personnel. This fixture contains no user serviceable parts.
• Prior to first use, carefully inspect fixture to ensure no damage has occurred during shipping.
• Materials used in the manufacturing process can cause strong odors when the product is new. These
odors dissipate over time.
• Prior to each use, carefully inspect power cables and replace any damaged cables.
• Exterior surfaces of the luminaire will be hot during operation. Take appropriate precautions.
• Continuous use of the fixture may shorten the lifespan. Power down the fixture when not in use.
• Do not cycle power on and o repeatedly. Disconnect mains power if the fixture is not used for an
extended period.
• Clean fixtures regularly, particularly when working in a dusty environment.
• Never touch power cables or wires while the fixture is powered on.
• Avoid entangling power wires with other cables.
• In the event of a serious operating problem, immediately discontinue using the fixture.
• It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be
changed if they have become visibly damaged to such an extent that their eectiveness is impaired, for
example, by cracks or deep scratches.
• Original packing materials can be reused for transporting the fixture.
• Do not look directly at the LED light beam while the fixture is on.
• This is a Class A product. In a domestic environment this product may cause radio interference, in which
case, the user may be required to take adequate measures.
• The light source contained in this luminaire shall only be replaced by the manufacturer or service agent
or similarly qualified person.
SAVE THESE INSTRUCTIONS.
WARNING: Refer to National Electrical Code® and local codes for cable specifications. Failure to use proper
cable can result in damage to equipment or danger to personnel.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
4
COMPLIANCE NOTICE
FCC DECLARATION OF CONFORMITY
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part
15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
this equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with Vari-Lite Strand system, service, and safety
guidelines, may cause harmful interference to radio communications.
As tested under this standard:
FCC 47CFR 15B clA*CEI
Issued:2009/10/01 Title 47 CFR Part 15 Subpart B Unintentional Radiators Class A
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user
will be required to correct the interference at his/her own expense.
EU DECLARATION OF CONFORMITY
We, Vari-Lite LLC., 10911 Petal Street, Dallas, Texas 75238, declare under our responsibility for the products
contained herein are in conformity with the essential requirements of the following European Directives and
harmonized standards:
Low Voltage Director (LVD), 2006/95/EC
EN 60589-2-17:1984+A1:1987+A2:1990 used in conjunction with 60598-1:2008/A11:2009
Electromagnetic Compatibility Directive (EMC), 2004//108/EC
EN 55022:2010, EN55024:2010

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
5
HOW TO OBTAIN WARRANTY SERVICE
A copy of the Limited Warranty card was included in the shipping package for this product.
To obtain warranty service, please contact customer service at 1-214-647-7880, or entertainment.service@
signify.com and request a Return Material Authorization (RMA) for warranty service. You will need to provide the
model and serial number of the item being returned, a description of the problem or failure and the name of the
registered user or organization. If available, you should have your sales invoice to establish the date of sale as the
beginning of the warranty period. Once you obtain the RMA, pack the unit in a secure shipping container or in its
original packing box. Be sure to clearly indicate the RMA number on all packing lists, correspondence, and ship-
ping labels. If available, please include a copy of your invoice (as proof of purchase) in the shipping container.
With the RMA number written legibly on or near the shipping address label, return the unit, freight prepaid, to:
Vari-Lite Strand
Attention: Warranty Service (RMA# ________)
10911 Petal Street
Dallas, Texas 75238
USA
As stated in the warranty, it is required that the shipment be insured and FOB our service center.
IMPORTANT! When returning products to Vari-Lite Strand for repairs (warranty or out-of-warranty) from a
country other than the USA, “Vari-Lite LLC”, must appear in the address block as the Importer of Record (IOR)
on all shipping documentation, Commercial Invoices, etc. This must be done in order to clear customs in a timely
manner and prevent returns.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
6
FEATURES
VL2600 PROFILE
1 DESCRIPTION
• Lower power consumption – approx.
820W (550W LED engine)
• High output - 19,000 lumens
• High color temperature - 7200 CCT
• Good color rendering:
– CRI 81
– TM30 Rf/80 Rg/94
• Flat, even beam
• High contrast ratio
• Wide zoom range – 7° to <48°
• Color mixing – CMY + variable CTO
• Beam shaping – Four blade framing system
• Beam reduction – Iris
• Compact design – 464 x 300 x 715mm (18 x 12 x 28in)
• Weight 32kg (70.5lb)
• Fast and accurate movement (FP=3s, FT=2s)
• Projected Image:
– 1 Rotating gobo wheel (7 + open, glass gobos)
– 1 Fixed gobo wheel (8 + open, glass gobos)
• Split-beam eects – 1 x 3-facet prism
• Beam diusion – variable frost
VL2600 SPOT
• Lower power consumption – approx.
820W (550W LED engine)
• High output - 19,000 lumens
• High color temperature - 7200 CCT
• Good color rendering:
– CRI 81
– TM30 Rf/80 Rg/94
• Flat, even beam
• High contrast ratio
• Wide zoom range – 7° to <48°
• Color mixing – CMY + variable CTO
• Fixed color wheel (7+ open)
• Beam reduction – Iris
• Compact design – 464 x 300 x 715mm (18 x 12 x 28in).
• Weight 32kg (70.5lb)
• Fast and accurate movement (FP=3s, FT=2s)
• Projected Image:
– 2 rotating gobo wheels (7+ open glass gobos)
– 1 fixed gobo wheel (8+ open glass gobos)
• Split-beam eects – 1 x 3-facet prism
• Beam diusion – variable frost
VL2600 WASH
• Lower power consumption – approx.
820W (550W LED engine)
• High output – 22,000 lumens
• High color temperature – 7200 CCT
• Good color rendering:
– CRI 81
– TM30 Rf/80 Rg/94
• Wide zoom range – 12° to 63°
• Color mixing – CMY + variable CTO
• Fixed color wheel (7 + open)
• Adjustable beam edge – PC to Fresnel
• Beam-shaping framing system
• Compact design – 465 x 300 x 705mm (18 x 12 x 28 in)
• Weight 30.2kg (66.5 lb)
• Fast and accurate movement (FP=3s, FT=2s)
Download the product datasheet(s) from the Vari-Lite website at WWW.VARI-LITE.COM for the full technical
specifications.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
7
CURRENT VERSUS VOLTAGE
TABLE 1 provides the luminaire’s current draw at specific voltages. Total luminaire current is calculated with the
lamp on and all motors sequencing.
2
INSTALLATION & SETUP
POWER AND DATA CABLING REQUIREMENTS
CONNECTING POWER
This fixture requires standard AC power distribution from 100VAC-240 VAC, 50/60 Hz.
Current required depends on the AC supply voltage and product model.
NOTE: The mating Neutrik® powerCON® True1 connector is supplied; however, you will
need to purchase or construct a cable appropriate for your application.
Depending on the application, the luminaire’s AC input cable may require a dierent
connector. If required, install a new connector meeting your requirements using the
following wire color code reference:
WARNING: DO NOT connect to three-phase service in countries with 240V power.
AC power input
WIRE* CONNECTION
Green/yellow AC ground
Blue AC neutral
Brown AC line
* International (Harmonized) Standard
AC VOLTAGE
AT 60HZ
TOTAL LUMINAIRE CURRENT
(MOTOR + LAMP CURRENT)
PROFILE SPOT WASH
100V 7.8A 7.5A 7.1A
110V 7.0A 6.7A 6.3A
120V 6.4A 6.1A 5.8A
130V 5.9A 5.6A 5.3A
200V 3.8A 3.6A 3.4A
210V 3.6A 3.5A 3.3A
220V 3.4A 3.3A 3.1A
230V 3.3A 3.2A 3.0A
240V 3.2A 3.1A 2.9A
TAbLE 1. CURRENT VS. VOLTAGE (550W LAMP)
CONNECTION PIN
AC neutral X
AC line Y
Ground (earth) G
X
Y
G
CONNECTION PIN
Phase 1 X
Phase 2 Y
Ground (earth) G
For single-phase power at 240 volts RMS: For three-phase power at 200 volts RMS:
WARNING! It is the responsibility of the user to ad-
equately protect supply source with a correct size and
type circuit breaker and not overload circuits.
WARNING! It is not recommended to power any
Vari-Lite luminaire from a dimmer - even in ‘NONDIM’
mode. Dimmer and non-dim modules are not suitable
sources of power because their output modifies the AC
wave form. This may work for a short time, but will even-
tually result in power problems, luminaire misoperation
and/or failure and may void the luminaire’s warranty.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
8
DATA CABLES
The luminaire is equipped with two, 5-pin XLR connectors for DATA IN and DATA THRU (out) applications.
DATA IN requires a 5-pin, female XLR connector and DATA THRU requires a 5-pin, male XLR connector. When
purchasing or constructing data cables, it is important that not only the correct cable type be used, but also
quality cable to ensure a reliable DMX512 system. Your cabling should meet the following USITT DMX
specification requirements:
• Suitable for use with EIA485 (RS485) operation at 250k baud
• Characteristic impedance 85-150 ohms, nominally 120 ohms
• Low capacitance
• Two twisted pairs
• Foil and braid shielded
• 24 AWG min. gauge for runs up to 1000 feet (300m)
• 22 AWG min. gauge for runs up to 1640 feet (500m)
NOTE: Microphone type cables and other general purpose, two-core audio or signal cables are not suitable for
use with DMX512.
Refer to the USITT Recommended Practice for DMX512 guide for additional information regarding DMX512
systems.
The XLR 5-pin connectors should be wired as follows:
RECOMMENDED CABLE TYPES/MANUFACTURERS
These are only a few of the suitable cable types. Any quality EIA485, twisted pair, 120 ohm, shielded cable will
also work. Refer to TABLE 2.
Pin/Wire Code to XLR Connectors
Data Thru
Cable Pinout
Male Conn.
Pin 1
Foil &
Braided
Shield
Pin 2
1st
conductor
of 1st
twisted
pair
Data (-)
Pin 3
2nd
conductor
of 1st
twisted
pair
Data (+)
Pin 4
1st
conductor
of 2nd
twisted
pair
Data (-)
Pin 5
2nd
conductor
of 2nd
twisted
pair
Data (+)
Data In
Cable Pinout
Female Conn.
1
2
3
4
51
2
3
4
5

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
9
TAbLE 2. RECOMMENDED CAbLES
TYPE PAIRS Z* JACKET AWG USE TEMP (°F) TEMP (°C)
BELDEN CABLES
1215A 2150 PVC 26 IBM Type 6 Oce 75 24
1269A 2100 PTFE 22 (solid) High Temp, Plenum 200 93
8102 2100 PVC 24 UL2919 80 27
8132 2120 PVC 28 UL2919 80 27
8162 2100 PVC 24 UL2493 60 16
82729 2100 PTFE 24 High Temp, Plenum 200 93
88102 2100 PTFE 24 High Temp, Plenum 200 93
89696 2100 PTFE 22 High Temp, Plenum 200 93
89729 2100 PTFE 24 High Temp, Plenum 200 93
89855 2100 PTFE 22 High Temp, Plenum 200 93
9729 2100 PVC 24 UL2493 60 16
9804 2100 PVC 28 UL2960 60 16
9829 2100 PVC 24 UL2919 80 27
9842 2120 PVC 24 UL2919 80 27
PROPEX CABLES
PC224P 2110 Polyurethane 22 Heavy Duty and 105 41
PC224T 2110 PVC 22 UL2464 105 41
PC226T 3110 PVC 22 UL2464
* Characteristic impedance
TERMINATION CONNECTOR
A XLR termination connector is required at the last luminaire (or “far end of the line”)
to prevent signal reflections. Signal reflections may cancel out the signal at certain line
lengths, resulting in errors. The terminator is also necessary for software downloads and
running tests on multiple luminaires. To construct your own connector, you will need the
following components:
• 5-pin, male XLR connector.
• Two 1/4W 5% 120 ohm resistors.
NOTE: A male termination connector is available as an accessory from Vari-Lite.
HANGING THE FIXTURE
The VL2600 can be hung horizontally or vertically from any structure designed to work with the type of load
created by this moving luminaire. Two mounting truss hooks or other mounting hardware are required. Many
compatible truss hooks are available from dierent manufacturers for your particular needs.
A minimum of two hooks per luminaire is required. If mounting method does not use truss hooks, two attach-
ment points, per luminaire, are required.
Solder resistors across
pins 2 & 3, and 4 & 5
1
2
3
4
5

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
10
Install mounting hardware and brackets:
Step 1. Install truss hooks (also refer to “Truss Hook Hardware (by oth-
ers)” on page 23) for additional information) on two provided
truss hook brackets as required as shown in Figure 2-7.
NOTE: Various types of truss hooks can be used. The Mega Claw truss
hook (as shown in the example above) as well as many other standard
hooks, can be ordered separately.
TRUSS HOOK HARDWARE (BY OTHERS)
When installing hanging hooks on mounting brackets, Vari-Lite strongly
recommends the use of a Belleville washer when installing a truss hook or
claw. The Belleville washer’s size should be approximately 13-25mm (0.5-
1.0 in) diameter. Belleville washers are available in various thicknesses
and any of the following thicknesses are acceptable for the application
described: 0.9.mm, 1.0mm, 1.3mm, 1.9mm (0.035-inch, 0.043-inch, 0.050-
inch, 0.073-inch).
The washer serves two purposes:
• To spread out the load. When a washer IS NOT used, the bolt
head (without a washer) concentrates the load in a smaller
area, creating focused stress on the steel bracket, making premature failure possible. A steel washer is
recommended to spread this load over a larger surface area.
• To keep the bolt in place. The recommended Belleville washer maintains tension in the bolted assembly
and prevents it from vibrating loose.
If a Belleville washer is not available, a regular flat washer measuring in diameter of 25mm (1 inch) minimum can
be used in conjunction with a suitable split lock washer situated between the bolt head and flat washer.
Step 2. Determine required configuration of bracket installation. Brackets may be installed in many dierent
orientations.
Step 3. While pulling up on locking mechanism release, fit keyed holes onto raised mounting buttons at bot-
tom of enclosure. Slide forward and release locking mechanism to lock in place. Ensure brackets are
locked securely.
WARNING: Ensure that the bracket locking mechanism is fully seated after the bracket is installed on the
luminaire.
Installing in Truss:
Step 1. Using two people, lift luminaire into mounting position.
Step 2. Secure in place with truss hook. Ensure truss hook hardware that locks hook in place (e.g. wing bolt) is
properly tightened and that luminaire is fully supported.
Mount Bracket
Mega Claw
Truss Hook
(not provided)
Truss Hook
Hardware
(not provided)
Press up to
Locked
install or release
Locking
Mechanism
Example Truss Hook and Mounting Hardware
(not included, sold separately)
Mount
Bracket
Locking
Mechanism
Keyed Hole
Mount Bracket
Fit bracket’s keyed hole and locking mechanism
over raised mounting buttons and slide forward
to lock.
BRACKET ORIENTATION

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
11
Step 3. Attach safety cable (as required) as follows:
a. Loop safety cable at least once around safety cable anchor point rod.
b. Loop safety cable at least once around truss/pipe and secure around pipe.
Step 4. Make sure tilt and pan locks are disengaged so luminaire moves freely.
Step 5. Connect power and data cables.
When hanging the luminaire in a side hang position, orient the enclosure as shown in Figure 3. Natural convec-
tion and the designed direction of the inlet and exhaust cooling fans dictate that the inlet should be closest to
the floor and the exhaust should be towards the ceiling. This eliminates the possibility of one luminaire blowing
exhaust air into the inlet of the luminaire next to it when the luminaires are side-by-side.
If the luminaires are stacked on top of one another in a side hang, a 45° enclosure orientation with the
fan inlet closest to the floor is preferred.
These two orientations in a side hang have the extra benefit of a stier pan interface in the luminaire.
FLOOR MOUNTING
All luminaires included in this manual are designed to sit directly on its base in a floor installation
application. When used in this type of application, be sure to leave enough space around the luminaire
to allow proper, uninterrupted airflow for cooling and movement.
CONNECTING DATA AND POWER
A maximum of 32 luminaires may be connected in any one DMX data link.
NOTE: This maximum limit applies to the luminaire “daisy chain” only. Your system or console may require few-
er luminaires on a single data link path. Consult your console documentation for more information.
To connect power and data:
Step 1. Connect data cable from console to first luminaire in chain at DATA IN connector.
Step 2. If required, connect additional data cables from DATA THRU connectors to DATA IN connectors of
remaining luminaires in link.
Step 3. At last luminaire in link, install male termination connector at DATA THRU connector. (Luminaires and
other devices on the same DMX chain may not function properly without termination.)
Step 4. Connect AC Input Cable connector to power input source.
Step 5. Dress AC input and data cables and secure them so that they will not interfere with luminaire head
and yoke movement.
VL2600 Profile/Spot/Wash Luminaire Channel Requirements*
DMX512
Channels Description Menu Display
23 Channels 16-Bit Mode(default) 16
**DMX terminator required for last fixture on DMX line.
Data In Data Thru Data Thru
Termination**

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
12
POWERING UP
POWER-UP PROCEDURE
When the luminaire is powered up for the first time, the default setting is enabled and the lamp will remain o.
When AC power is applied, the luminaire will immediately begin a calibration sequence that steps it through
full pan and tilt movements. The internal color and beam mechanisms will also move through a full range of
motion. After calibration, the luminaire head will either stop at its “home” position (which positions the pan
axis at mid-rotation and the head parallel to the yoke with the lens pointing away from the luminaire enclosure)
or move to its current DMX-defined position if DMX data is present. All internal mechanisms also move to their
“home” or DMX-defined positions.
CAUTION: Before applying power, be sure the luminaire is hung (or positioned), and the pan and tilt locks are
disengaged, so that the head and yoke can move freely without restriction.
To power up:
Step 1. At each luminaire, apply power connecting the power cable to the unit.
Step 2. Luminaire will automatically step through calibration and stop at “home” position (only if DMX is not
present).
ADDRESSING
PROGRAM STARTING ADDRESS
The address setting for DMX console controlled systems is entered using the Menu Display. The luminaire retains
the DMX address even if power is removed.
DMX ADDRESS
To set, edit, and save a DMX address:
Step 1. Press [ESC].
Step 2. Press [Up] / [Down] arrows until Address appears. Press [OK].
Step 3. Use [Left] and [Right] arrow buttons to scroll through all digits.
Step 4. Once at desired digit, use [Up] and [Down] arrows to change highlighted digit.
Step 5. Once digit is set, use [Left] and [Right] arrow buttons to set other digits in DMX address.
Step 6. Once all digits are set in DMX address, press [OK] to set.
Step 7. DMX will display and is saved.
PROGRAM STARTING ADDRESS WITHOUT CALIBRATION
It is possible to bypass the calibration sequence and go directly to the Menu Display programming in order to
pre-program an address setting.
Program starting address without calibrating luminaire:
• While powering up luminaire, press and hold [ESC].
• When display changes from “Starting” to the DMX address, program address as in Program Starting
Address above.
NOTE: The luminaire will require a reset to restore control.
Program starting address in Battery Mode:
• To activate menu in Battery Mode when the fixture is not connected to a power source, press [OK] and
[ESC] together. The LCD screen will come on. Address the fixture as described above. The LCD screen
will shut o after one minute of inactivity.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
13
TRANSPORTING
When shipping or transporting luminaires, Vari-Lite recommends that the luminaire(s) be suciently protected
against any (including, but not limited to) shock, vibration, drops, jarring, exposure to the environment, etc.
Failure to suciently protect any Vari-Lite luminaire during shipping or transportation will result in damage
and void the luminaire’s warranty. Vari-Lite will not be responsible for any shipping damage or breakage of any
product under any circumstances. Vari-Lite will not be responsible for any third party case manufacturer’s cases.
Note: As with all automated luminaires, proper handling and suitable protective shipping cases should be
used when transporting fixtures to reduce the risk of damage. For more information, please refer to Vari-Lite
technical notice (TN-235) “Transportation and Shipping Case Requirements” in the “Support” area of the Philips
Entertainment Lighting web site.
TRANSPORTATION AND SHIPPING CASE REQUIREMENTS
Cases to transport Vari-Lite luminaires should meet the following loading requirements:
• Luminaire head, yoke, and enclosure sub-assemblies shall be equally supported and constrained where
no one sub-assembly (head, yoke, or enclosure) fully supports the entire mass of the luminaire.
• The interior of the case shall be of high quality and uniform density foam. The foam shall be of the same
type and density throughout as to equally and uniformly support loading at every contact surface.
• The case shall, when laid on any of its six (6) surfaces, maintain the loading requirements outlined
above.
• All cases not meeting the aforementioned loading requirements, with wheels, shall have markings
on the exterior of the case that the unit is to be transported on it wheels only (e.g. “Case must be
transported and remain [at all times] on its wheels”).

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
14
COLOR CONTROL & GOBOS
COLOR WHEEL
VL2600 Profile, VL2600 Spot, VL2600 Wash
VL2600 Series fixed color wheel holds 7 color filters and has one open
space. Note that the open space will not accommodate a filter.
CAUTION: VL2600 Series accept glass gobos only. Use of metal gobos
in these luminaires may damage gobo assembly and will void the lumi-
naire warranty.
GOBO WHEELS
VL2600 Profile
This rotating gobo wheel oers seven rotatable, indexable gobo positions and one open position.
This fixed gobo wheel oers 8 gobo positions and one open position.
LUMINAIRE GOBO DIAMETER IMAGE AREA DIAMETER GLASS THICKNESS CARRIER REQUIRED?
VL2600 Profile 27mm 17.5mm 1.1mm Yes
3 OPERATION
7
1
2
3
4
5
6
8Open
slot
Red
Dark
Blue
Yellow
Kelly
Green
Congo
Blue
CTB
Amber
WHEEL 1
1 Open slot
2 Night sky
3 Circle of ovals
4 Bricked out
5 Punch card
6 Swirl
7 Honeycomb reverse
8 On the rocks*
*glass gag
1
2
3
4
5
6
7
8
WHEEL 2
1 Open slot
2 Leafy breakup
3 Medium circle
4 Lattice
5 Radial breakup
6 Dust breakup
7 Neurons
8 Grid
9 Cross bars
1
2
3
4
5
6
7
8
9

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
15
VL2600 Spot
This rotating gobo wheel oers seven rotatable, indexable gobo positions and one open position.
This rotating gobo wheel oers seven rotatable, indexable gobo positions and one open position.
This fixed gobo wheel oers 8 gobo positions and one open position.
LUMINAIRE GOBO DIAMETER IMAGE AREA DIAMETER GLASS THICKNESS CARRIER REQUIRED?
VL2600 Spot 27mm 17.5mm 1.1mm No
WHEEL 1
1 Open slot
2Night sky
3 Circle of ovals
4 Bricked out
5 Punch card
6 Swirl
7 Honeycomb reverse
8 On the rocks*
* Glass Gag
1
2
3
4
5
6
7
8
WHEEL 2
1 Open slot
2DichroFusion
3 Alpha rays
4 Circle of holes
5 Vertical bars V2
6 Tribal
7 Honeycomb
8 Droplets*
1
2
3
4
5
6
7
8
WHEEL 3
1 Open slot
2Leafy breakup
3 Medium circle
4 Lattice
5 Radial breakup
6 Dust
7 Neurons
8 Grid
1
2
3
4
5
6
7
8
9
9 Crossbars

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
16
INSTALL OR REPLACE GOBOS
WARNING: Remove power from luminaires before performing maintenance. Gobos may be HOT after oper-
tion. Allow to cool before handling.
To replace a rotating gobo:
Step 1. Remove power from luminaire.
Step 2. Remove top and bottom head cover by loosening four crossed Slot screws to access the gobo wheel.
Step 3. If removing gobos via bottom of head assembly,
undo fan tray assembly with thumb screw to
access.
Step 4. Rotate desired gobo wheel until required gobo
position is accessible.
CAUTION: Do not push on gobo glass. Press on gobo
carrier only.
CAUTION: Do not touch gobos with bare fingers. Wear
cotton gloves or other covering while replacing. To clean,
refer to CARE AND MAINTENANCE ON PAGE 53.
Step 5. Remove current gobo by carefully pressing on edges of gobo carrier with fingers, pressing gobo to-
ward front end of luminaire (toward lens), and out of wheel.
Step 6. Install new gobo as follows:
a. Place the gobo holder on a clean, flat work surface with the teeth facing upwards. The gobo is
held in place in the gobo holder by a spring. Taking care to avoid scratching or applying pressure
to the gobo, lever the end of the spring out, remove the spring and then lift the gobo out of the
gobo holder.
gobo wheel
crossed slot screw
(2 per head cover)

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
17
b. Hold the gobo with the dark side facing upwards towards the teeth in the gobo holder. Match up
the alignment marks (arrowed) in the gobo and gobo holder. Lay the new gobo flat in the gobo
holder.
c. Insert gobo carrier into wheel, ensuring that carrier snaps into place.
Step 7. Rotate desired gobo wheel until required gobo position is accessible.
DMX OPERATION
DMX MAPS
The tables assume a DMX start address of 1. When a dierent starting address is used, this address becomes
channel 1 function and other functions follow in sequence.

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
18
TAbLE 1. VL2600 PROFILE 16-bIT MODE
DMX
CHANNEL PARAMETER DEFAULTS RANGE DMX DESCRIPTION
1Intensity High 00-65535 16 Bit control of Dimming
2Intensity Low
3Pan High 32767 0-65535 540° Total Pan Rotation
4Pan Low
5Tilt High 32767 0-65535 270° Total Tilt
6Tilt Low
7Focus High 32767 0-65535 Focus control
Default value 50% Focus range
8Focus Low
9Zoom High 32767 0-65535 Zoom control
Default value 50% zoom range
10 Zoom Low
11 Cyan 00 - 255 Cyan Color Control 0-100% saturation
12 Yellow 00 - 255 Yellow Color Control 0-100% saturation
13 Magenta 00 - 255 Magenta Color Control 0-100% saturation
14 CTO 00 - 255 CTO Color correction Control 0-100% saturation
15 Color Wheel 0
0 - 255 8-bit control of Color Wheel.
(spin speed slow to fast from control channel)
0 - 15 OPEN (centred at 0)
16 - 47 Color 1 RED (centred at 32)
48 - 79 Color 2 Dark Blue (centred at 64)
80 - 111 Color 3 Yellow (centred at 96)
112 - 143 Color 4 Kelly Green (centred at 128)
144 - 175 Color 5 Amber (centred at 160)
176 - 207 Color 6 Congo Blue (centred at 192)
208 - 240 Color 7 CTB (centred at 224)
241 -255 Open
16 Color Wheel
Control 0
0 - 255
0 - 5 Linear Movement using shortest (quickest) path.
6 - 10 Linear Movement using normal (longest) path.
11 - 15 Wheel Spin CW (Forward)
16 - 20 Wheel Spin STOP
21 - 25 Wheel Spin CCW (Reverse)
26 - 56 Color Shake Quickest Path (Slow to Fast) For fastest shake
set color timing to 0
57 - 87 Color Shake Normal Path (Slow to Fast) For fastest shake set
color timing to 0
88 - 255 Reserved Values
17 Gobo Wheel 1 0
0 - 255 8-bit control of Gobo Wheel 1. See Channel 20 for control
0 - 5 Open - No Gobo
6 - 10 Gobo 1 (Night Sky) Index
11 - 15 Gobo 2 (Circle of Ovals) Index
16 - 20 Gobo 3 (Bricked Out) Index
21 - 25 Gobo 4 (Punchcard) Index
26 - 30 Gobo 5 (Swirl) Index
31 - 35 Gobo 6 (Honeycomb Reverse) Index
36 - 40 Gobo 7 (On the Rock) Index
41 - 45 Open - No Gobo

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
19
TAbLE 1. VL2600 PROFILE 16-bIT MODE
DMX
CHANNEL PARAMETER DEFAULTS RANGE DMX DESCRIPTION
17 Gobo Wheel 1
continued 0
46 - 50 Gobo 1 (Night Sky) Rotate
51 - 55 Gobo 2 (Circle of Ovals) Rotate
56 - 60 Gobo 3 (Bricked Out) Rotate
61 - 65 Gobo 4 (Punchcard) Rotate
66 - 70 Gobo 5 (Swirl) Rotate
71 - 75 Gobo 6 (Honeycomb Reverse) Rotate
76 - 80 Gobo 7 (On the Rock) Rotate
81 - 85 Open - No Gobo
86 - 90 Gobo 1 (Night Sky) Rotate with Mega Stepping
91 - 95 Gobo 2 (Circle of Ovals) Rotate with Mega Stepping
96 - 100 Gobo 3 (Bricked Out) Rotate with Mega Stepping
101 - 105 Gobo 4 (Punchcard) Rotate with Mega Stepping
106 - 110 Gobo 5 (Swirl) Rotate with Mega Stepping
111 - 115 Gobo 6 (Honeycomb Reverse) Rotate with Mega Stepping
116 - 120 Gobo 7 (On the Rock) Rotate with Mega Stepping
121 - 255 Reserved Values
18 Gobo 1 Rot/Index
High Byte
32767
0 - 65535 16-bit control of index and rotation of gobo wheel 1.
0 - 32756 Rotate Fast to Slow <<<
19 Gobo 1 Rot/Index
Low Byte
32757 - 32780 Rotation STOP
32781 - 65535 Rotate Slow to Fast >>>
20 Gobo Wheel 1
Control 0
0 - 255 Used as a control channel for dierent movement options for
Gobo Wheel 1 (Channel 17)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120 Gobo Shake Quickest Path (Slow to Fast) For fastest shake
set gobo timing to 0
121 - 150 Gobo Shake Normal Path (Slow to Fast) For fastest shake set
gobo timing to 0
151 - 180 Gobo Twist Quickest Path (Slow to Fast) For fastest twist set
gobo timing to 0
181 - 210 Gobo Twist Normal Path (Slow to Fast) For fastest twist set
gobo timing to 0
211 - 255 Reserved Values

uSer manuaL
www.Vari-Lite.com
VL2600 SerieS
20
TAbLE 1. VL2600 PROFILE 16-bIT MODE
DMX
CHANNEL PARAMETER DEFAULTS RANGE DMX DESCRIPTION
21 Gobo Wheel 2
(Fixed) 0
0-255 8-bit control of Gobo Wheel for movement options see
channel 22
0 - 5 Open - No Gobo
6 - 10 6-10 Gobo 1 (Leafy Breakup)
11 - 15 11-15 Gobo 2 (Medium Circle)
16 - 20 16-20 Gobo 3 Swirl (Lattice)
21 - 25 21-25 Gobo 4 (Radial Breakup)
26 - 30 26-30 Gobo 5 (Dust)
31 - 35 31-35 Gobo 6 (Neurons)
36 - 40 36-40 Gobo 7 (Grid)
41 - 45 41-45 Gobo 8 (Cross bars)
46 - 255 Reserved
22 Gobo Wheel 2
Control 0
0 - 255 Used as a control channel for dierent movement options for
Gobo Wheel 2 (Channel 21)
0 - 5 Gobo Selection using shortest (quickest) path.
6 - 10 Gobo Selection using normal (longest) path.
11 - 20 Reserved Values
21 - 50 Wheel Spin CW Forward (Fast to Slow)
51 - 60 Wheel Spin STOP
61 - 90 Wheel Spin CCW Reverse (Slow to Fast)
91 - 120 Gobo Shake Quickest Path (Slow to Fast) For fastest shake
set gobo timing to 0
121 - 150 Gobo Shake Normal Path (Slow to Fast) For fastest shake set
gobo timing to 0
151 - 180 Reserved Values
181 - 210 Reserved Values
211 - 255 Reserved Values
23 Iris 0
0-255 Iris size control
0 - 200 Iris beam size open to closed
201 - 255 Iris pulse slow to fast
24 Frame 1A 00 - 255 Controls Framing Shutter 1A from Open (DMX 0) to Full (DMX
255).
25 Frame 1B 00 - 255 Controls Framing Shutter 1B from Open (DMX 0) to Full (DMX
255).
26 Frame 2A 00 - 255 Controls Framing Shutter 2A from Open (DMX 0) to Full
(DMX 255).
27 Frame 2B 00 - 255 Controls Framing Shutter 2B from Open (DMX 0) to Full
(DMX 255).
28 Frame 3A 00 - 255 Controls Framing Shutter 3A from Open (DMX 0) to Full
(DMX 255).
29 Frame 3B 00 - 255 Controls Framing Shutter 3B from Open (DMX 0) to Full
(DMX 255).
30 Frame 4A 00 - 255 Controls Framing Shutter 4A from Open (DMX 0) to Full
(DMX 255).
31 Frame 4B 00 - 255 Controls Framing Shutter 4B from Open (DMX 0) to Full
(DMX 255).
32 Frame Rotate 128 0 - 255 Controls Framing Shutter mechanism from +/- 90°
