VARO Powerplus POWDPG7553 User manual

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 1www.varo.com
1APPLICATION..................................................................................4
2DESCRIPTION (FIG. A) ...................................................................4
3PACKAGE CONTENT LIST.............................................................4
4SYMBOLS........................................................................................5
5GENERAL POWER TOOL SAFETY WARNINGS ..........................6
5.1 Work area ................................................................................................................6
5.2 Electrical safety.......................................................................................................6
5.3 Personal safety .......................................................................................................6
5.4 Power tool use and care.........................................................................................7
5.5 Service.....................................................................................................................7
6ADDITIONAL SAFETY WARNINGS FOR BRUSH CUTTERS.......7
6.1 Brush cutter /Trimmer.............................................................................................7
6.2 Hedge trimmer.........................................................................................................8
6.3 Chain saw................................................................................................................8
6.3.1 Kickback safety precautions....................................................................................10
6.4 Check before starting ...........................................................................................10
6.5 Personal safety .....................................................................................................11
6.6 Power tool use and care.......................................................................................11
6.7 Always use common sense..................................................................................11
7ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS ...................................................................................12
7.1 Batteries ................................................................................................................12
7.2 Chargers................................................................................................................12
8CHARGING AND INSERTION OR REMOVAL OF BATTERY.....12
8.1 Charger indications ..............................................................................................12
8.2 Removal / insertion of battery..............................................................................13
8.3 Battery capacity indicator (fig. 1).........................................................................13
9ASSEMBLY....................................................................................13
9.1 Blade assembly (Fig.2) .........................................................................................13
9.2 Shaft assembly (Fig. 3).........................................................................................13
9.3 Installation protection guard (Fig. 4)....................................................................14

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 2www.varo.com
9.4 Installing the harness (Fig. 5)...............................................................................14
9.5 Mounting round handle (Fig. 6)...........................................................................14
9.6 Mounting the chain saw (Fig. 7)...........................................................................14
9.7 Replace the metal blade to spool.........................................................................14
9.7.1 Metal blade (Fig. 8).................................................................................................14
9.7.2 Spool (Fig. 9 –10)...................................................................................................15
10 OPERATION...................................................................................15
10.1 Chain lubrication...................................................................................................15
10.1.1 Filling with chain oil: ...........................................................................................15
10.2 Swivelling out the Hedge trimmer (Fig. 11) .........................................................15
10.3 Pivoting the chain saw..........................................................................................15
10.4 Starting the machine.............................................................................................15
10.5 Stopping the machine...........................................................................................16
10.6 Working with the hedge trimmer..........................................................................16
10.7 Working with the chain saw .................................................................................16
10.8 Working using the thread spool...........................................................................16
10.9 Working with the 3-tooth blade............................................................................16
10.10 Trimming procedures ...........................................................................................17
10.10.1 Trimming / mowing.............................................................................................17
10.10.2 Closer trimming..................................................................................................17
10.10.3 Fence / foundation trimming...............................................................................17
10.10.4 Trimming around trees.......................................................................................17
10.10.5 Scalping.............................................................................................................17
10.10.6 Do not sweep with trimmer.................................................................................18
10.11 Cutting with blades...............................................................................................18
10.12 Cutting techniques using the hedge trimmer......................................................18
10.12.1 Cutting Shaped Hedges: ....................................................................................18
10.13 Cutting techniques using chain saw....................................................................18
10.13.1 Sawing off small branches:.................................................................................19
10.13.2 Sawing off larger branches:................................................................................19
10.13.3 Sawing in sections: ............................................................................................19
11 CLEANING AND MAINTENANCE.................................................19

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 3www.varo.com
11.1 Cleaning the chain saw.........................................................................................19
11.2 Cleaning the hedge trimmer.................................................................................19
11.3 Cleaning the trimmer and brush cutter attachment............................................19
12 TECHNICAL DATA........................................................................20
13 NOISE.............................................................................................21
14 MAINTENANCE INTERVALS........................................................21
14.1 Chain saw..............................................................................................................21
14.2 Hedge trimmer.......................................................................................................21
15 WARRANTY...................................................................................22
16 ENVIRONMENT .............................................................................22
17 DECLARATION OF CONFORMITY ..............................................23

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 4www.varo.com
GARDEN MULTITOOL 4-IN-1 40V
POWDPG7553
1 APPLICATION
This appliance is designed for the following applications:
Brush cutter (when fitted with metal circular blade): The brush cutter is intended to cut
weed and climbing plants. Do not use it for other purposes, never use it for
cutting wood. Never cut objects with a diameter exceeding 13 mm.
Grass trimmer (when fitted with nylon line cutting head): The grass trimmer is intended for
trimming grass. Do not use it for other purposes.
Hedge trimmer (when fitted with reciprocating blade): The trimmer is intended to be used
for trimming hedges and bushes with diameter not more than 24 mm.
Chain saw: this appliance is intended for trimming branches in trees.
Do not use this appliance for other purpose than those described in this manual. Not suitable
for professional use
WARNING! For your own safety, read this manual and general safety
instructions carefully before using the appliance. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG. A)
1. Cutting disc
2. Drive shaft assembly
3. Switch trigger
4. Safety switch
5. Harness attachment/cable lock
6. Protection guard
7. Spool
8. Knob
9. Lock
10. Main switch/battery indicator
11. Round handle
12. Lever
13. Knob
Chain saw attachment
14. Socket spanner
15. Chain saw bar cover
16. Nut
17. Saw chain
18. Bar
19. Chain sprocket
20. Chain wheel
21. Chain tensioner screw
22. Oil dispenser
23. Oil filler cap
24. Oil tank
25. Oil adjusting screw
26. Oil level indicator
27. Lock
Hedge trimmer attachment
28. Lock / release
29. Handle
30. Safety lever
31. Battery pack (NOT INCLUDED)
32. Battery pack release button
33. Charger (NOT INCLUDED)
34. Battery capacity indicator
35. Button for battery capacity indicator
3 PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packing and package inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packing materials as long as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 5www.varo.com
WARNING: Packaging materials are not toys! Children must not play with
plastic bags! Danger of suffocation!
1x hedge trimmer attachment
1x chain saw attachment
1x trimmer / brush cutter attachment
1x spool
1x cutting blade
1x carrying harnas
1x bar cover
1x blade cover
Protecting guard
Socket wrench
Hex spanner
1 x chain
1 x bar
Manual
If any parts are missing or damaged, please contact your dealer.
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal
injury or damage to the tool.
Wearing of protective shoes
advised.
Read instructions carefully.
Wear gloves.
Wear safety glasses and ear
protection.
Watch out for thrown objects
and ricochets
Never operate the machine in
the rain or in damp or wet
condition. Moisture is a shock
hazard.
Keep a minimum distance of
15m between the machine and
third parties during use.
"Class II - The machine is
double insulated; Earthing
wire is therefore not
necessary (only for charger)
In accordance with essential
requirements of the European
directive(s).
Do not expose charger and
battery pack to water
Do not incinerate battery pack
or charger
Ambient temperature 40°C
max. (only for battery)
Use battery and charger only in
closed rooms
Wear a mask In dusty
conditions

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 6www.varo.com
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow all warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power
tool" in the warnings refers to your mains operated (corded) power tool or
battery operated (cordless) power tool.
5.1 Work area
Keep work area clean and well lit. Cluttered and dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used whenever conditions require
will reduce personal injuries.
Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have
the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 7www.varo.com
If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related
hazards.
5.4 Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
Maintain power tools. Check for misalignment or sticking of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to stick and are easier to control.
Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in the manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from intended could lead to a hazardous situation.
5.5 Service
Have your power tool serviced by a qualified person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
6 ADDITIONAL SAFETY WARNINGS FOR BRUSH CUTTERS
6.1 Brush cutter /Trimmer
Do not allow persons unfamiliar with the brush cutter/string trimmer or these instructions to
operate the tool. Brush cutter and string trimmers are dangerous in the hands of untrained
users.
Be sure that anyone who is to operator the brush cutter/string trimmer has first read the
instruction manual.
Never allow people unfamiliar with these instruction, people(including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge to
use the tool. Local regulations can restrict the age of the operator.
Use the tool with the utmost care and attention.
Operate the equipment only if you are in good physical condition. Perform all work calmly
and carefully. Use common sense and keep in mind that the operator or user is
responsible for accidents or hazards occurring to other people or their property.
Never use the equipment after consumption of alcohol or drugs, or if feeling tired or ill.
Avoid Unintentional Starting. Do not carry battery-installed equipment with finger on
switch. Be sure switch is off when installing a battery cartridge.
The motor is to be switched off immediately in case that the equipment shows any
problem or abnormal sign.
Switch off and remove the battery cartridge when resting and when leaving the equipment
unattended, and place it in a safe location to prevent danger to others or damage to the
equipment.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 8www.varo.com
Don't force the equipment. it will do the job better and with less likelihood of a risk of injury
at the rate for which it was designed.
Don't overreach. Keep proper footing and balance at all times.
6.2 Hedge trimmer
Caution! Notice overhead power lines.
Use of the hedge trimmer should be avoided when people, especially children, are nearby.
If the cutting unit contacts a foreign body or if the operating noises increase or the hedge
trimmer vibrates with unusually high force, turn off the motor and let the hedge trimmer
come to a standstill. Pull the mains plug or remove the battery and take the following
measures:
check for damages;
check for loose parts and fasten all loose parts;
replace damaged parts with equivalent parts or have them repaired.
Switch the appliance off and remove the mains plug or battery before:
cleaning or removing a blockage;
inspection, servicing or work on the hedge trimmer;
adjusting the working position of the cutting unit;
leaving the hedge trimmer unattended.
Always ensure that the hedge trimmer is properly placed in one of the indicated working
positions before the motor is started.
Do not use the hedge trimmer with a defective or strongly worn-out cutting unit.
To avoid the risk of fire, ensure that the motor is free from deposits and leaves.
Always ensure that all handles and safety devices are mounted when you use the hedge
trimmer. Never try to use an incomplete hedge trimmer or a hedge trimmer with
impermissible modifications.
Always use both hands when the hedge trimmer is equipped with two handles.
Always familiarise with your surroundings and pay attention to potential dangers that you
cannot hear because of the noise the hedge trimmer makes.
Keep cable away from cutting area. During operation the cable may be hidden in shrubs
and can be accidentally cut by the blade.
Keep all parts of the body away from the cutter blade. Do not remove cut material or hold
material to be cut when blades are moving. Make sure the switch is off when clearing
jammed material. A moment of inattention while operating the hedge trimmer may result in
serious personal injury.
Children must never use the hedge trimmer.
If the hedge trimmer is taken out of operation for purposes of maintenance, inspection or
storage, turn off the motor, unplug the mains plug or remove the battery and make
absolutely sure that all rotating parts have come to a standstill. Let the machine cool down
before you check or adjust it, etc.
Carry the hedge trimmer by the handle with the cutter blade stopped. When transporting
or storing the hedge trimmer always fit the cutting device cover. Proper handling of the
hedge trimmer will reduce possible personal injury from the cutter blades.
6.3 Chain saw
DO NOT operate a chain saw with one hand! Serious injury to the operator, helpers,
bystanders, or any combination of these persons may result from one-handed operation. A
chain saw is intended for two-handed use.
DO NOT operate a chain saw when you are fatigued, under the influence of drugs, alcohol
or medication.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 9www.varo.com
Use safety footwear, snug-fitting clothing, protective gloves, and eye, hearing and head
protection devices.
DO NOT allow other persons to be near when starting or cutting with the chain saw. Keep
bystanders and animals out of the work area.
DO NOT start cutting until you have a clear work area, secure footing, and a planned
retreat path from the falling tree.
Keep all parts of your body away from the saw chain when the engine is running.
Before you start the engine, make sure that the saw chain is not contacting anything.
Carry the chain saw with the engine stopped, the guide bar and saw chain to the rear, and
the muffler away from your body.
DO NOT operate a chain saw that is damaged, improperly adjusted, or not completely and
securely assembled. Be sure that the saw chain stops moving when the throttle control
trigger is released.
Shut off the engine before setting the chain saw down.
Use extreme caution when cutting small size brush and saplings because slender material
may catch the saw chain and be whipped toward you or pull you off balance.
When cutting a limb that is under tension, be alert for spring back so that you will not be
struck when the tension in the wood fibres is released.
Keep the handles dry, clean, and free of oil or fuel mixture.
Operate the chain saw only in well-ventilated areas.
DO NOT operate a chain saw in a tree unless you have been specifically trained to do so.
All chain saw service, other than the items listed in the user manual safety and
maintenance instructions, should be performed by competent chain saw service
personnel.
When transporting your chain saw, use the appropriate guide bar scabbard.
DO NOT operate your chain saw near or around flammable liquids or gases whether in or
out of doors. An explosion and/or fire may result.
USE THE RIGHT TOOL: Cut wood only. Do not use the chain saw for purposes for which
it was not intended. For example, do not use the chain saw for cutting plastic, masonry, or
non-building materials.
The first time user should have practical instruction in the use of chainsaw and the
protective equipment from an experienced operator.
Do not attempt to hold the saw with one hand only. You cannot control reactive forces
and you may lose control of the saw, which can result in the skating or bouncing of the bar
and chain along the limb or log.
Never run the chainsaw indoors. Your chainsaw produces poisonous exhaust as soon as
the combustible engine is started, which may be colourless and odourless. To use this
product can generate dust, mists and fumes containing chemicals known to cause
reproductive harm. Be aware of harmful dust, mist (such as saw dust or oil mist from chain
lubrication) and protect yourself properly.
Wear gloves and keep your hand warm. Prolonged use of chainsaws exposing the
operator to vibrations may produce whitefinger disease. In order to reduce the risk of
whitefinger disease, please wear gloves and keep your hand warm. If any of the
whitefinger symptoms appear, seek medical advice immediately.
Drive in the spiked bumper of the chainsaw directly behind the intended hinge and pivot
the saw around this point. The spiked bumper rolls against the trunk.
Only chain, guide bar and spark plug can be replaced by the user himself. Always make
sure you replace with correct material as stated in the specifications of the manual.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 10 www.varo.com
6.3.1 Kickback safety precautions
KICKBACK may occur when the NOSE or TIP of the guide bar touches an object, or when
wood closes in and pinches the saw chain in the cut.
Tip contact in some cases may cause a lightning-fast reverse reaction, kicking the guide bar
up and back toward the operator.
PINCHING the saw chain along the BOTTOM of the guide bar may PULL the saw forward
away from the operator.
PINCHING the saw chain along the TOP of the guide bar may PUSH the guide bar rapidly
back toward the operator.
Any of these reactions may cause you to lose control of the saw, which could result in serious
personal injury.
With a basic understanding of kickback, you can reduce or eliminate the element of
surprise. Sudden surprise contributes to accidents.
Keep a good firm grip on the saw with both hands, the right hand on the rear handle, and
the left hand on the front handle, when the engine is running. Use a firm grip with thumbs
and fingers encircling the chain saw handles. A firm grip will help you reduce kickback and
maintain control of the saw. Don’t let go.
Make sure that the area in which you are cutting is free from obstructions. Do not let the
nose of the guide bar contact a log, branch, or any other obstruction which could be hit
while you are operating the saw.
Cut at high engine speeds.
Do not overreach or cut above shoulder height.
Follow manufacturer’s sharpening and maintenance instructions for the saw chain.
Only use replacement bars and chains specified by the manufacturer or the equivalent.
NOTE: Low-kickback saw chain is chain that has met the kickback
performance.
WARNING: Kickback can lead to dangerous loss of control of the chain saw
and result in serious or fatal injury to the saw operator or to anyone
standing close by. Always be alert. Rotational kickback and pinch-kickback
are major chain saw operational dangers and the leading cause of most
accidents.
6.4 Check before starting
Always remove the battery to prevent the machine being started by accident. Always
disconnect the battery before any maintenance on the machine.
Before using the machine and after any impact, check for signs of wear or damage and
repair as necessary.
Inspect the working area. Remove all loose objects, such as stones, broken glass, nails,
steel wire, string, etc. that could be thrown out or become wrapped around the cutter or
cutter guard.
The machine operator must ensure that no people or animals come closer than 15 meters
while working. When several operators are working in the same area the safety distance
should be at least 15 meters.
Do an overall inspection of the machine before use, see maintenance schedule.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 11 www.varo.com
6.5 Personal safety
The cutting tool does not stop immediately after the machine is turned off.
The machine is only design for brush/trimmer . Do not use the Brush cutter/grass trimmer
for any job except that for which it is intended.
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
This appliance is not intended for use by person (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
Never allow children or other persons not trained in the use of the machine and/or the
battery to use or service it. Local laws may regulate the age of the user.
Store the equipment in a lockable area so that it is out of reach of children and
unauthorized persons.
Keep hands and feet away from the cutting area at all times and especially when switching
on the motor.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving
parts.
Never use the machine if you are tired, if you have drunk alcohol, or if you are taking
medication that could affect your vision, your judgement or your co-ordination.
Wear personal protective equipment. See instructions under the heading ”Personal
protective equipment”.
Turn off the machine when it has to be moved. Always remove the battery when passing
the machine to another person.
6.6 Power tool use and care
The only accessories you can operate with this product are the cutting attachment we
recommend in the technical data chapter.
Never use a machine that has been modified in any way from its original specification.
Never use the machine near explosive or flammable materials.
Never use a machine that is faulty. Carry out the safety checks, maintenance and service
instructions described in this manual. Some maintenance and service measures must be
carried out by trained and qualified specialists. See instructions under the heading
Maintenance.
Only use original spare parts.
Always ensure that ventilation openings are kept clear of debris.
All covers, guards and handles must be fitted before starting.
Only use the machine in daylight or in other well-lit conditions.
Never use the machine in bad weather, for instance in fog, in rain, damp or in wet
locations, strong winds, intense cold, risk of lightning, etc. Extremely hot weather may
cause overheating of the machine.
6.7 Always use common sense
It is not possible to cover every conceivable situation you can face. Always exercise care and
use your common sense. Avoid all situations which you consider to be beyond your capability.
If you still feel uncertain about operating procedures after reading these instructions, you
should consult an expert before continuing.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 12 www.varo.com
7 ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS
Use only batteries and chargers applicable for this machine.
7.1 Batteries
Never attempt to open for any reason.
Do not store in locations where the temperature may exceed 40 °C.
Charge only at ambient temperatures between 4 °C and 40 °C.
Store your batteries in a cool dry place (5 °C-20 °C). Never store batteries in discharged
state.
It is better for Li-ion batteries to discharge and reload them regularly (at least 4 times a
year). The ideal charge for long-term storage of your Li-ion battery is 40% of capacity.
When disposing of batteries, follow the instructions given in the section “Protecting the
environment”.
Do not cause short circuits. If connection is made between the positive (+) and negative (-)
terminal directly or via accidental contact with metallic objects, the battery is short circuited
and an intense current will flow causing heat generation which may lead to casing rupture
or fire.
Do not heat. If batteries are heated to above 100 °C, sealing and insulating separators
and other polymer components may be damaged resulting in electrolyte leakage and/or
internal short circuiting leading to heat generation causing rupture or file. Moreover do not
dispose of the batteries in fire, explosion and/or intense burning may result.
Under extreme conditions, battery leakage may occur. When you notice liquid on the
battery, proceed as follows:
Carefully wipe the liquid off using a cloth. Avoid skin contact.
In case of skin or eye contact, follow the instructions below:
Immediately rinse with water. Neutralize with a mild acid such as lemon juice or
vinegar.
In case of eye contact, rinse abundantly with clean water for at least 10 minutes.
Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do
not incinerate the battery.
7.2 Chargers
Never attempt to charge non-rechargeable batteries.
Have defective cords replaced immediately.
Do not expose to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.
8 CHARGING AND INSERTION OR REMOVAL OF BATTERY
8.1 Charger indications
Connect the charger to the power oulet socket
Solid green: ready to charge
Flickering red: charging
Solid green: charged
Solid green en red: battery or charger damaged

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 13 www.varo.com
Note: if the battery does not fit properly, disconnect it and confirm that the
battery pack is the correct model for this charger as shown on the
specification chart. Do not charge any other battery pack or any battery
pack that does not securely fit the charger.
1. Frequently monitor the charger and battery pack while connected
2. Unplug the charger and disconnect it from the battery pack when finished.
3. Allow the battery pack to cool completely before using it.
4. Store the charger and battery pack indoors, out of reach of children.
NOTE: If battery is hot after continuous use in the tool, allow it to cool down
to room temperature before charging. This will extend the life of your
batteries.
8.2 Removal / insertion of battery
WARNING: Before making any adjustments ensure the tool is switched off
or remove the battery pack.
Hold the tool with one hand and the battery pack (31) with the other.
To install: push and slide battery pack into battery port, make sure the release latch on the
rear side of the battery snaps into place and battery is secure before beginning operation.
To remove: Press the battery release latch and pull the battery pack out at the same time.
8.3 Battery capacity indicator (fig. 1)
There are battery capacity indicators (34) on the battery pack, you can check the capacity
status of the battery if you squeeze the button (35). Before using the machine, please press
switch trigger to check if the battery is full enough for properly working.
Those 3 LED might show the status of the capacity level of the battery:
3 LED’s are litt: Battery fully charged
2 LED’s are litt: Battery 60% charged
1 LED is litt: Battery almost discharged
9 ASSEMBLY
9.1 Blade assembly (Fig.2)
Assembling small blade on protective cover with 2pcs ST4*16 screws
9.2 Shaft assembly (Fig. 3)
Loosen the knob (8).
Pull the lock (9) outward and turn it left or right as far as it goes.
Slide the front tubular shaft onto the tubular shaft on the device housing.
Pull the lock (9) outward and turn it back to its original position.
Turn the front tubular shaft with a gentle rotating movement until the lock (9) clicks into
place in the bore on the front tubular shaft .
Fix the tubular shaft in place with the knob (8).

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 14 www.varo.com
9.3 Installation protection guard (Fig. 4)
Fit the trimmer guard for use with the motor，then tighten 2 screws so that the guard
assembly cannot move.
9.4 Installing the harness (Fig. 5)
Adjust the harness hanger in a comfortable position
Buckle the harness at the hanger
9.5 Mounting round handle (Fig. 6)
The round handle must be mounted with a spacing of at least 25 cm to the
device handle!
The leg protection must always be mounted on the operator side!
Place the round handle (11) onto the tubular shaft of the device housing (2). Choose a
position within the levelled adjustment range marked on the bottom of the tubular shaft.
Position the leg protection (12) onto the round handle (11) from below.
Fix the round handle (11) and leg protection (12) with the knob (13), tightening it.
9.6 Mounting the chain saw (Fig. 7)
Pay attention to the correct rotation direction of the saw chain. This is
indicated on the chain wheel cover (15) and above the bar bolt (20).
Tension the saw chain in accordance with the first 5-6 steps.
Place the device on a level surface.
Remove the chain wheel cover (15) by loosening the nut (16) with the mounting key (14).
Lay out the new saw chain in a loop and straighten any kinks. The cutters should face in
the direction of chain rotation. If they face backwards, turn the loop over.
Place the sawing chain (17) into the blade groove. Position the chain so there is a loop at
the back of the bar.
Hold the chain in position on the bar and place the loop around the sprocket
Place the blade bar (18) over the chain sprocket (19) and saw chain (17) onto the chain
wheel (20).
Pre-tension the saw chain (17) by turning the screw (21) in a clockwise direction with the
mounting key (14).
Put the chain wheel cover (15) back in position. Tighten the chain wheel cover nut (16).
9.7 Replace the metal blade to spool
CAUTION: NEVER use unit if blade is warped or has teeth that are chipped
or missing. Replace a damaged blade immediately.
CAUTION: Always wear heavy-duty work gloves when handling and
installing a blade.
9.7.1 Metal blade (Fig. 8)
Turn the tool upside down so that you can replace the cutter blade (2) easily.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 15 www.varo.com
To dismount the cutter blade (2), insert the hex wrench through the hole of the machine
body under the cutter blade and into the receive washer (1). rotate the cutter blade (1)
until it is locked with the hex wrench. Loosen the hex nut (5) (left-hand thread)with the hex
socket wrench and remove the nut (5), cup (4), clamp washer (3) and hex wrench.
Mount the cutter blade (2) onto the shaft so that the guide of the receive washer fits in the
arbor hole in the cutter blade . Install the clamp washer (3), cup (4), and secure the cutter
blade (2) with the hex nut (5 holding the receive washer (1) with hex wrench. Then tighten
the one nut by clockwise rotate.
9.7.2 Spool (Fig. 9 –10)
Hold the trimmer head, insert the hex wrench through the hole on the receive washer.
Screw the spool anticlockwise onto the shaft and tighten
If the line is too long when you use the equipment for the first time, the
surplus end of it will be cut by the blade on the guard hood.
10 OPERATION
10.1 Chain lubrication
The blade bar and saw chain must never be operated without oil. If the pole-mounted
pruner is used with too little oil, the cutting performance and lifespan of the saw chain will
decrease as the saw chain will become blunt more quickly. You can identify when there is
too little oil if smoke develops or the blade bar changes colour. The oil flows to the blade
bar as soon as the motor starts working.
10.1.1 Filling with chain oil:
Check the oil level indicator on the oil tank ( 24) regularly and top-up the oil if the minimum
mark „MIN“ ( 26) is reached on the oil level indicator. The oil tank holds about 100 ml of
oil.
Empty the oil tank if it will not be used for a prolonged period of time (6-8 weeks).
10.2 Swivelling out the Hedge trimmer (Fig. 11)
The hedge trimmer bar must be checked regularly for wear and reground. A blunt blade bar
causes the device to overload. Any damage that results is not covered by the warranty.
1. Hold the safety blade beam on the handle to adjust the blade beam (29).
2. Unlock the safety lever (30) and keep it pressed.
3. By simultaneously exerting pressure on the lock lever (28), you will loosen the fixation
of the cutter bar.
The safety blade beam can now be swivelled out. Use the stop stages and allow the stop
lever to click back in. You can choose 12 stop stages.
5. Then, release the safety lever (30) again and ensure that it latches back into its initial
position.
10.3 Pivoting the chain saw
1. Pull the lock (27) outward and turn it 90°.
2. Hold the pole-mounted pruner at the protective transport and turn it to the desired
position. There are five possible positions.
3. Fix the pole-mounted pruner by pulling the lock (27) outward and turning it 90° back to
the original position.
10.4 Starting the machine
To start the equipment, press the main switch than depress the safety switch and pull the
switch trigger. Release the switch trigger to stop.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 16 www.varo.com
10.5 Stopping the machine
To switch the appliance off, release the switch trigger.
10.6 Working with the hedge trimmer
While cutting, make sure that you do not touch any objects, such as wire
fences or plant supports. This can cause damage to the cutter bar.
To avoid eye injuries, always wear safety goggles while working with the hedge trimmer.
Always hold the device tightly with both hands, with one hand on the rear handle and the
other hand on the front round handle (A6). Your thumb and fingers must tightly clasp the
handles.
Check the carrying harness (A 51B) for comfortable positioning which facilitates holding
the hedge trimmer.
If the blades become jammed with solid objects, switch the device off immediately, pull the
mains plug, and remove the object.
Avoid over-stressing the device while working.
10.7 Working with the chain saw
If the saw chain gets stuck, do not attempt to pull out the pruner with force.
There is a risk of injury. Turn the motor off and use a lever arm or wedge to
release the pruner.
You will have better control over the device if you saw using the lower edge of the blade
bar (saw chain in pulling direction) and not using the upper edge of the blade bar (saw
chain in pushing direction).
The saw chain must not touch the ground or any object while sawing through the material
or thereafter.
Ensure that the saw chain does not get stuck while sawing. The log must not break or
splinter.
Please also observe the precautionary measures to protect against kickback (see the
safety information).
Remove branches hanging downwards by sawing from the top of the branch.
Twisted branches must be individually cut down to size.
10.8 Working using the thread spool
In small grass areas hold the device at an angle of about 30° and swing the cutting head
evenly to the right and left with a semi-circular movement.
The best results are obtained with a maximum grass length of 15 cm. If the grass is taller,
it is recommended to mow several times.
To cut around trees, fence posts or other obstacles, slowly move the device around the
obstacle and cut with the thread ends.
Avoid any contact with fixed obstacles (rocks, walls, picket fences, etc.). The thread would
wear out quickly. Use the edge of the protective cover to keep the device at the correct
distance.
Attention! Do not lay the cutting head on the ground during operation!
10.9 Working with the 3-tooth blade

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 17 www.varo.com
Always wear the harness and suitable protection clothing when working
with the device. Wear eye, hearing and head protection. Ensure that the
blade is installed correctly. Replace damaged or blunt tool parts. There is a
risk of injury.
Only use the blade to work on open, even areas. Carefully inspect the area to be cut and
remove all foreign bodies. Avoid hitting stones, metal or other obstacles. The blade can be
damaged and there is a risk of kickback by the machine.
When working, hold the cutter above the ground and slowly swivel the device back and
forth like a scythe in an equal arch.
Do not hold the cutting head at an angle.
Do not use the device to cut wild growth or brushwood.
Regularly check the blades for damage and replace as needed.
10.10 Trimming procedures
When properly equipped with a debris shield and stringhead, your unit will trim unsightly
weeds and tall grass in those hard-to-reach areas - along fences, walls, foundations and
around trees. It can also be used for scalping to remove vegetation down to the ground for
easier preparation of a garden or to clean out a particular area.
NOTE: Even if you are careful, trimming around foundations, brick or stone
walls, curves, etc., will result in above-normal string wear. To renew the
wire, press the lower spool knob against the ground with rotating trimmer.
10.10.1 Trimming / mowing
Swing trimmer with a sickle-like motion from side to side. Do not tilt the stringhead during the
procedure. Test area to be trimmed for proper cutting height. Keep stringhead at same level
for even depth of cut.
10.10.2 Closer trimming
Position trimmer straight ahead with a slight tilt so bottom of stringhead is above ground level
and string contact occurs at proper cutting point. Always cut away from operator. Do not pull
trimmer in towards operator.
10.10.3 Fence / foundation trimming
Approach trimming around chain link fences, picket fences, rock walls and foundations slowly
to cut close without whipping string against the barrier. If the string comes in contact with rock,
brick walls, or foundations, it will break or fray. If string hits fencing, it will snap off.
10.10.4 Trimming around trees
Trim around tree trunks slowly so string does not contact bark. Walk around the tree trimming
from left to right. Approach grass or weeds with the tip of the string and tilt stringhead slightly
forward
10.10.5 Scalping
WARNING: Use extreme caution when SCALPING. Keep a distance of 30
meters (100 feet) between operator, other people and animals during these
operations.
Scalping refers to removal of all vegetation down to the ground. To do this, tilt the stringhead
to about a 30 degree angle to the right. By adjusting the handle you will have better control

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 18 www.varo.com
during this operation. Do not attempt this procedure if there is any chance that flying debris
could injure the operator, other people, or cause damage to property
10.10.6 Do not sweep with trimmer
Sweeping refers to tilting stringhead to sweep away debris from walkways, etc. Your trimmer
is a powerful tool and small stones or other such debris may be hurled 50 feet (15 metres) or
more, causing injury or damage to nearby property such as automobiles, homes and windows.
10.11 Cutting with blades
AVOID KICKOUT
Kickout refers to the reaction of a moving blade if it contacts a strong tree, brush or a solid
object. The force that results violently pushes the blade away in an arc. Kickout may cause
loss of control resulting in injury to the operator or bystanders.
Do not use a blade near a chain link fence, metal stakes, landscape borders or building
foundations.
Do not cut with dull, cracked or damaged metal blade. Before cutting
growth, inspect for obstructions such as boulders, metal stakes or strands
of wire from broken fences. If an obstruction can not be removed, mark its
location so that you can avoid it with the blade. Rocks and metal will dull or
damage a blade. Wire can catch on the blade head and flap around or be
thrown into the air.
Do not use a brush cutter for cutting trees.
10.12 Cutting techniques using the hedge trimmer
Cut thick branches beforehand using a branch clippers.
The double-sided cutter bar enables cutting in both directions or, with a swinging action,
from one side to the other.
In case of vertical cutting, move the hedge trimmer uniformly forward or up and down in an
arc movement.
In case of horizontal cutting, move the hedge trimmer in a sickle-shaped movement to the
edge of the hedge, so that cut branches fall to the ground.
In order to achieve long straight lines, the placing of tensioned guiding cords is
recommended.
10.12.1 Cutting Shaped Hedges:
It is recommended that hedges be cut in a trapezoidal shape, in order to prevent stripping off
of the lower branches. This corresponds to the natural plant growth and allows the hedge to
thrive optimally. During cutting, only the new annual growths are reduced and thus a dense
branching and a good screen will develop.
Cut the sides of a hedge first. To do this, move the hedge trimmer in the direction of
growth from bottom to top. If you cut down from the top, the thinner branches will move
out, which may result in some areas having sparse growth or holes.
Cut the top edge, according to taste, in a flat shape, roof shape or rounded shape
Trim young plants to the required shape. The main growth should remain undamaged until
the hedge has reached the planned height. All other shoots are lopped off to half size.
Care of Free-Growing Hedges:
Free-growing hedges are not shaped when cut, although they must be regularly
maintained so the hedge does not become too high.
10.13 Cutting techniques using chain saw
Be aware of the risk of kickback as well as falling branches and branches on the ground.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 19 www.varo.com
10.13.1 Sawing off small branches:
Place the locating surface of the saw against the branch in order to prevent jerky
movements of the saw when you begin to cut it. Guide the saw with light pressure from the
top to the bottom through the branch. Watch out for premature breakage of the branch if
you have misjudged the size and weight.
10.13.2 Sawing off larger branches:
In the case of larger branches, select a relief cut first of all to ensure that the sawing
process is controlled. To do this, saw an incision into the bottom third of the branch (with
the upper side of the blade). Then saw from top to bottom towards the first cut (with the
underside of the blade)
10.13.3 Sawing in sections:
Saw off large or long branches in sections so that you have control over the place where the
branch section lands.
Saw the lower branches of the tree off first in order to make it easier for the branches that
have been cut off to fall to the ground.
After the cut is completed, the weight of the saw increases abruptly for the operator, as the
saw is no longer supported on the branch. There is a danger that you will lose control of
the device.
You should only pull the saw out of the cut with the saw chain running in order to avoid
jamming.
Do not saw with the tip of the cutting equipment.
Do not saw the bulge at the base of the branch because this will prevent the tree from
healing.
11 CLEANING AND MAINTENANCE
Your tool has been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper tool care and regular
cleaning.
Regularly clean the ventilation slot in your tool using a soft brush or dry cloth.
Regularly clean the cutting line and spool using a soft brush or dry cloth.
Regularly use a blunt scraper to remove grass and dirt from the underneath of the guard.
11.1 Cleaning the chain saw
The chain saw must be cleaned of saw dust at regular intervals.
Remove the sprocket cover.
Remove the saw chain (17) from the bar (18) and clean the guide rail.
Keep the saw chain (17) sharp and check the tension, check the oil level and the oil
supply.
11.2 Cleaning the hedge trimmer
Check the hedge trimmer for loose screws on the cutter bar and tighten these if
necessary.
Remove stuck cuttings.
Maintain the cutter bar using an oil spray or an oil can.
11.3 Cleaning the trimmer and brush cutter attachment
Remove stuck cuttings.
Keep the cutting blade (1) sharp to facilitate your work.

POWDPG7553 EN
Copyright © 2021 VARO P a g e | 20 www.varo.com
12 TECHNICAL DATA
Type
POWDPG7553
Voltage
40V
Engine type
Brushless
Shaft Ø
26 mm
Shaft type
STRAIGHT
Low vibration system
Yes
Handle type
D-HANDLE
Hedge trimmer
Cutting width
22 mm
Blade nose type
Protective
Cutting length
410 mm
Double action blade
Yes
Quick stop
Yes
Chain saw
Cutting length
175 mm
Chain speed
7 m/s
Chain type
Oregon
Bar type
Oregon
Automatic chain oiler
Yes
Brush cutter
Cutting width
255 mm
Rotation speed
7000 min-1
Number of teeth
3T
Blade dimensions
255 mm
Safety guard
Yes
Trimmer
Cutting width
320 mm
Rotation speed
7000 min-1
thread lengthening type
TAP&GO
Spool Ø
2.0 mm
Spool length
5 m
Safety guard
Yes
