VarTech Systems ColorVue VT190PC User manual

VT190 ColorVue User Guide 150-077
VT190 ColorVue Series
19.0” Flat Panel Series LCD Monitors
VT190PC
VT190RC
VarTech Systems Inc.
Solutions for Demanding Applications
Industrial CRT and Flat Panel Displays
User’s Guide
Read these instructions completely before attempting to operate your new Color Display.

Table Of Contents
Section Page Section Page
Section 1 Section 5
Introduction Touch screen 14
1.1 About LCD Monitors 1 5.1 Introduction 14
1.2 Product Safety Precautions 2 5.2 Installation 14
Section 2 Section 6
Display Setup Troubleshooting Tips 15
2.1 Display Features 3
2.2 Unpacking The Display 4 Section 7
2.3 Included Parts 4 Cleaning & Maintenance 16
2.4 Connecting Your Display 4
2.5 Signal Connections 4-6 Section 8
Mechanical Drawings 17
Section 3 Panel Mount Mechanical Drawings 18-19
Getting Started Rack Mount Mechanical Drawings 20
3.1 Adjusting the Display 7
3.2 Control Panel Functions 7 Section 9
3.3 OSD Adjustment 8-12 Display Specifications 21
Section 4
Display Timing 13

VT190 ColorVue User Guide 150-077
INTRODUCTION
INTRODUCTION
1
Section
About LCD Monitors
What you gain by using an LCD monitor in your industrial controls
LCDs
LCDs
LCDs
are the future of display technology. Although CRTS have dropped in
cost significantly, they do not offer the performance, reliability, and
mounting options available with LCDs. LCD monitors consist primarily of
an LCD, Video Board and a Back Light video. The LCD determines to a
large extent the viewing angle, brightness and contrast. Beyond that it is
the function of the video board which converts the analog RGB (Red, Green, Blue) signals from a
standard video card to a high quality, digital RGB that the LCD can display.
Recently the video card has taken on a new role. It is the responsibility of this device to “scale” a
particular video resolution to the “native” resolution of the LCD. Simply, consider that a computer is
putting out a VGA [640x480] resolution signal, yet the LCD that is connected is an XGA
[1024x768] display. The displayed picture would be in the center 1/3 of the LCD. With the
introduction of the scaling engine. The converter will mathematically recalculate the 640x480 to
1024x768. This may sound simple but it is in fact a complex algorithm that adjusts for different
aspect ratios and pixel alignment, essentially smoothing text and graphics to produce a picture
that is pleasant to the eye.
All Vartech displays from 12.1” (800x600) to 23.1 (1600x1200) incorporate scaling engines in the
converter card.
1.1
1

Product Safety Precautions
⇒ Ensure that sufficient space is available around the display to provide the circulation
necessary for cooling.
⇒ Ensure that the ambient air temperature will not exceed the specified maximum
temperature.
⇒ Do not attempt to service this display yourself. The rear chassis has a seal so that non
qualified personal will not expose themselves to dangerous voltages or other risks.
⇒ To protect from electrical shock, unplug the display power supply from the wall before
moving.
⇒ Do not expose the display to direct sunlight or heat.
⇒ Do not use this display near water
⇒ Do not place any heavy objects on the power cords. Damage may cause electrical shock.
⇒ Unplug the power supply from the wall or unit if one of the following conditions exists.
⇒ Power cord or plug is damaged or frayed
⇒ Liquid is spilled into the display or the display is exposed to rain or water.
⇒ The display does not operate normally when the operating instructions are
followed.
⇒ The display has been dropped or the enclosure has been damaged.
⇒ The display exhibits a distinct change in performance, indicating a need for
service.
1.1
2

VT190 ColorVue User Guide 150-077
⇒ Capable of displaying unlimited colors in a continuous spectrum. The high contrast LCD
enhances the image with no geometric distortion.
⇒ The VT190 ColorVue Series directly accepts an analog 5 wire RGB with separate H/V sync.
⇒ The VT190 ColorVue Series is auto synchronous adjusting the display to the appropriate input
between VGA, SVGA,XGA, and SXGA.
⇒ The VT190 ColorVue Series is available in Panel Mount, Rack Mount, or Wall Mount industrial
packages.
⇒ The VT190 ColorVue Series is supplied with a Anti-Reflective Screen unless equipped with an
optional Touch System.
⇒ The VT190 ColorVue Series has an integrated 115/220VAC supply as standard on all models.
Section
2
DISPLAY SETUP DISPLAY SETUP
VT190 ColorVue Series Display Features
2.1
3

⇒ VT190RC or VT190PC LCD Monitor
⇒ 5 ft Video Cable
⇒ 10-32 Mounting Hardware. (For use with Panel Mount only)
⇒ 6 ft RS232 Touch Interface Cable (Optional when touch is installed)
⇒ CD ROM with Touch Screen Drivers (Optional when touch is installed)
⇒ Users Guide (Printed or on CD)
4
2.2 Unpacking and setting up your display
Your LCD monitor package will consist of the components listed below. Open shipping
container and lay all components on a flat clean surface.
2.3 What is included with your display
2.4 Connecting the Display
1. Connect all cables to the computer first. This would include the VGA cable and the optional
RS 232 serial touch screen connection.
2. After connecting the cables between the LCD monitor and the computer, plug the power
cord into the 115/220VAC power outlet.
3. Once the 115/220VAC connection is made, the display is active.
4. If your computer was off, turn on your computer.
5. Your display should now operate as a normal computer display showing your windows or
whatever video is being sent to the flat panel.
Note: If for any reason the display goes blank and gives an “out of Range” or “No Input Signal”,
your computer or video source is putting out a signal that is out of range of the LCD’s video
board. If this happens, reboot the computer or video source and make sure you are inputting
the correct signal. If the display doesn’t work properly, it may be because:
(a) The resolution is to high or low for the LCD.
(b) The refresh rate is set to high. Refresh on an LCD is different than a CRT. Set the refresh to
60Hz. CRT’s need a high refresh rate to avoid flicker. The refresh rate has no impact on
LCD’s.
(c) The power source is incorrect.
(d) The unit is malfunctioning. If you believe this to be true, disconnect the video cable from the
rear of the LCD and connect to a known good computer CRT display. If the computer
display is working satisfactory and the video is within the appropriate range, then contact
Vartech Customer service for a RMA number at 800-223-8050.
2.5 Signal Connections
To avoid irregular operation and /or damage to the display, please insure correct video is being
supplied as shown on the following page.

VT190 ColorVue User Guide 150-077
2.5 Signal Connections Cont.
You can use an HD-15 connector cable or a BNC adapter cable to connect the flat
panel monitor to the host computer. The HD-15 video cable (supplied in the kit) you
use with this monitor is equipped with a conventional HD-15 connector at each end.
HD-15 Video Connector
The following table provides the pin numbers and
corresponding pin assignments for the HD-15 video
connector.
5
Note: The following figure is the view looking into the pin end of the male connector or
solder term end of the female connector.
Pin Signal (DVI-I) Pin Signal (DVI-I) Pin Signal (DVI-I)
1 T.M.D.S. Data2- 9 T.M.D.S. Data1- 17 T.M.D.S. Data0-
2 T.M.D.S. Data2+ 10 T.M.D.S. Data1+ 18 T.M.D.S. Data0+
3 SGND 11 SGND 19 SGND
4 Not used 12 Not used 20 Not used
5 Not used 13 Not used 21 Not used
6 DDC Clock 14 DDC Power 22 SGND
7 DDC Data 15 Ground 23 T.M.D.S. Clock+
8 Not used 16 Hot Plug Detect 24 T.M.D.S. Clock-
Pin Signal (DVI-I)
C1 Not Used
C2 Not Used
C3 Not Used
C4 Not Used
C5 Not Used
DVI-I Connector (Digital / Analog)
Pin Signal (HD15) Pin Signal (HD15) Pin Signal (HD15)
1 Red Video 6 Red Video Ground 11 Monitor Ground
2 Green Video 7 Green Video Ground 12 DDC data
3 Blue Video 8 Blue Video Ground 13 Horizontal Sync
4 Not Used 9 +5 V 14 Vertical Sync
5 Ground 10 PC detection 15 DDC clock
17
9
1 8
16
24
C5
C4C3
C2
C1

Optional BNC Adaptor Cable
An HD-15 to 5-BNC adapter cable is available. The functions of the cables are
described below.
⇒ R, B, and G: Red, Green, and Blue input connectors to establish color.
These are used for RS-343 analog signals.
⇒ HS: Separate horizontal sync signal from the video source.
⇒ VS: Separate vertical sync signal from the video source.
2.5 Signal Connections Cont.
6

VT190 ColorVue User Guide 150-077
Control Function
POWER
MENU
Use this button to enter or exit the
On Screen Display.
SEL
Use this button to enter a selection in
the On Screen Display.
Use these button to choose or adjust
items in the On Screen Display.
Use this button to turn the monitor on
and off.
4
Adjusting the display
Getting Started
3
Section
The VT190 Series display has an embedded microprocessor in the converter card.
Once you have the unit displaying the resolution you desire for your application do
the following:
In order to navigate to the appropriate adjustments, press Menu and the OSD layout
chart will appear as indicated in Fig. 1 from left to right.
If you press the “MENU” the new settings are saved and the OSM appear and your
setting will be stored in the unit’s non volatile memory.
3.1
7
Control Panel Functions
3.2
3
1
2
1 2 43

3.3 On Screen Display (OSD) Control Adjustment
Screen Adjustment Operation Procedure
1) Entering the Screen Adjustment
The setting switches are normally at stand-by. Push the MENU button once to dis-
play the main menu of the screen adjustment. The adjustable items will be dis-
played in the main menu.
2) Entering the Settings
Use the Adjust ▼and Adjust ▲buttons to select the desired setting icon and push
the SELECT button to enter sub-menu.
3) Change the Settings
After the sub-menu appears, use the Adjust ▼and Adjust ▲buttons to change the
setting values.
4) Save
After completing the adjustment, push the SELECT button to save the setting.
5) Return & Exit the Main Menu
Exit the screen adjustment, push the ‘SELECT’ button and the ‘EXIT’ of “MISC
MENU”. When no operation is done around 60 sec (default OSD timeout), it goes
back t the stand-by mode and no more switching is accepted except MENU to
restart the setting.
8

VT190 ColorVue User Guide 150-077
The following table indicates all the On Screen Display control, adjustment,
and setting menus.
9
3.3 On Screen Display (OSD) Control Adjustment Cont.
Main Menu Sub Menu A D Reference
BRIGHTNESS BRIGHTNESS  To adjust the brightness and contrast of
the screen
CONTRAST CONTRAST 
COLOR PRESET 9300K To customize the color of the screen
6500K 
R/G/B (User Color) 
POSITION V POSITION To adjust the position of the screen
H POSITION 
TRACKING CLOCK To improve the clarity and stability of the
screen
PHASE 
SETUP AUTO CONFIG 
INPUT 
INFORMATION 
RECALL 
AUDIO
OSD ADJUST 
EXIT EXIT To Exit the OSD
To customize the screen status for a
user’s operating environment
: Adjustable A: Analog Input
D-SUB
D: Digital Input
DVI-D
Legend

OSD - On Screen Display
Icon Function Description
BRIGHTNESS Adjusts the brightness of the screen.
CONTRAST Adjusts the contrast of the screen.
PRESET
COLOR 9300K / 6500K
• 9300K: Default to 9300K color temp
• 6500K: Default to 6500K color temp
• User Mode: Used to adjust RGB
RED (user mode) Adjusts the gain of red channel in ADC.
GREEN (user mode) Adjusts the gain of green channel in ADC.
BLUE (user mode) Adjusts the gain of blue channel in ADC.
VERTICAL POSITION Moves the image up and down.
HORIZONTAL POSITION Moves the image left and right.
INPUT Selects the applicable input source, analog
input (D-SUB), or Digital input (DVI-D)
INFORMATION
Provides the user with detailed information
regarding the current input format and
version.
3.3 On Screen Display (OSD) Control Adjustment Cont.
10
The OSD main menu is displayed on screen
when MENU key is pressed. The OSD menu
is a combination of graphic and text display.
The first line always shows the current
selected or active menu item. The bottom line
of main menu shows information of the input
image.
The UP and DOWN keys are used to scroll
through items within the menu. The selected
item is highlighted as the scrolling move along.
The SELECT key is used to activate the
highlighted item. During this state, the MENU
key is used to close the OSD menu from the
screen.
1024x768 70Hz

VT190 ColorVue User Guide 150-077
3.3 On Screen Display (OSD) Control Adjustment Cont.
11
OSD - On Screen Display
Icon Function Description
CLOCK Adjusts the number pixels per line
PHASE Adjusts the ADC pixel clock
AUTO CONFIG
D-SUB Input source only
Use the ▲and ▼buttons to scroll up and
down in the menu, then press the SELECT
key to start this function. If the MENU key is
pressed, the main menu is re-displayed and
nothing is changed.
Auto Adjust Performs automatic configuration of the phase,
clock, vertical position and horizontal position.
Auto Tracking Tunes the clock and phase to the best
condition automatically.
Auto Position
Centers the image automatically. Both
horizontal and vertical position are adjusted so
that the image is centered on the display.
Auto Color
Adjusts the gain and offset of the RED,
GREEN and BLUE channels on the ADC
automatically.
Return Goes back to main menu.
How to use the AUTO CONFIG Adjustment
This function tunes the parameters of PHASE, CLOCK, H-POSITION, and V-POSITION.
Suggested steps for Auto Config Adjustment:
1) Enter the “Windows” Shut-down frame.
2) Enter OSD Main menu and choose the AUTO CONFIG item, then press the SELECT key.
The picture will auto-adjust by itself. After 4 seconds, you can exit OSD and Shut-down
frame.
3) If you are not still satisfied with the picture quality, you could choose CONTRAST item in
OSD Main Menu and adjust it.
Note:
The Wallpaper color CAN NOT be black.

3.3 On Screen Display (OSD) Control Adjustment Cont.
12
OSD - On Screen Display
Icon Function Description
OSD ADJUST Adjusts miscellaneous OSD settings
OSD Position
Used to setup the OSD menu position. The
item “OSD POSITION” is used to setup the
OSD menu position. The OSD menu horizon-
tal and vertical position is adjusted separately.
Each position adjustment item will bring up
the slider window. The maximum value of the
sliders are based on the size do the OSD
menu.
Black Level Adjust Used to adjust the black level (zero level off-
set) of the AD converters.
Language Used to select the OSD menu in 5 languages:
English, German, French, Italian, Spanish
Sharpness This can adjust the video quality to be sharp or
blur.
AUDIO ADJUST Currently Not Available
Volume Increases and decreases the volume.
Mutes the audio.
Balance Adjusts the proportion of sound coming from
each speaker.
Bass Adjusts the low (bass) frequency audio output.
Treble Adjusts the high (treble) frequency audio
output.
Mute Temporarily silences audio output.
RECALL Reloads all factory default parameters.
Note:
If you don’t press any keys during 45 seconds, the OSD will disappear by itself and not
save the parameters.

VT190 ColorVue User Guide 150-077
13
Display Timing
4
Section
Applicable Video Timing
The following table lists the better display quality modes that these LCD monitors
provide. If the other video modes are input, the monitor will stop working or display
unsatisfactory picture quality.
VESA MODES
Horizontal Vertical VCLK
Mode Resolution Total
Nominal
Frequency
+/- 0.5KHz
Nominal
Frequency
+/- 1KHz
Nominal
Pixel Clock
(MHz)
DOS 720 x 400 @ 70Hz 900 x 449 31.469 70.087 28.322
VGA 640 x 480 @ 60Hz 800 x 525 31.469 59.940 25.175
640 x 480 @ 72Hz 832 x 520 37.861 72.809 31.500
640 x 480 @ 75Hz 840 x 500 37.500 75.000 31.500
SVGA 800 X 600 @ 56Hz 1024 x 625 35.156 56.250 36.000
800 X 600 @ 60Hz 1056 x 628 37.879 60.017 40.000
800 X 600 @ 72Hz 1040 x 666 48.077 72.188 50.000
800 X 600 @ 75Hz 1056 x 625 46.875 75.000 49.500
1024 x 768 @ 60Hz 1344 x 804 48.363 60.004 65.000
1024 x 768 @ 70Hz 1328 x 806 56.476 70.069 75.000
1024 x 768 @ 75Hz 1312 x 800 60.023 75.029 78.750
1152 x 864 @ 75Hz 1600 x 900 67.500 75.000 108.00
SXGA 1280 x 1024 @ 60Hz 1688 x 1066 63.981 60.020 180.00
IBM MODES
EGA 640 x 350 @ 70Hz 800 x 449 31.469 70.086 25.175
DOS 720 x 400 @ 70Hz 900 x 449 31.469 70.087 28.322
VGA 640 x 480 @ 60Hz 800 x 525 31.469 59.940 25.175
XGA 1024 x 768 @ 72Hz 57.515 72.100 75.000
MAC MODES
VGA 640 x 480 @ 60hz 800 x 525 31.469 59.940 25.175
SVGA 832 x 624 @ 75Hz 1152 x 667 49.725 74.551 57.283
XGA 1024 x 768 @ 75Hz 1328 x 804 60.241 74.927 80.000
XGA

Touch Screen
5
Section
14
Touch screens are a common means to interface operator inputs to a system. The universal
standard of Windows GUI (Graphical User Interface) has significantly increased the use of
touch screens.
There are four main touch technologies. The technologies are resistive, surface acoustic
wave (SAW), capacitive, and infrared (IR). Each touch technology has advantages and
disadvantages based on different user applications.
All Vartech Systems displays configured with a touch screen are supplied with a CDROM
which includes user manuals, application software, and drivers for various operating systems.
Insert the supplied CDROM into a CDROM drive and follow the installation instructions that
will appear on the screen.
Limited technical support is available by contacting Vartech Systems customer support at
800-223-8050.
5.1 Introduction
5.2 Installation

VT190 ColorVue User Guide 150-077
15
Problem Troubleshooting Tip
No image on display screen 1) Check that the power cord of the Computer has
been connected securely into wall outlet or
grounded extension cable or strip.
2) Check that the power switch of the Display has
been pressed and the LED on the front of the
Display is lit.
3) Check that the Video (Signal) Cable from the
Display has been securely and correctly
connected.
4) Check that the Video Card is firmly seated in
card slot of Computer motherboard.
5) Check that the Video Input from the Video Card
falls within the timing range of the Display.
(see Display Timing - Section 4)
Abnormal image 1) Check that the Video Input from the Video Card
falls within the timing range of the Display.
(see Display Timing - Section 4)
2) Check that the Video (Signal) Cable from the
Display has been securely and correctly
connected to the Video Connector at the rear
side of the Computer.
Colors of image on screen
are abnormal
1) Check that the Video (Signal) Cable from the
Display has been securely and correctly con-
nected to the 15Pin Video Connector at the rear
of the computer.
Disturbances on Screen 1) OSD adjustment is incorrect.
(See OSD screen adjustment procedures
Section 3)
Troubleshooting
6
Section

Cleaning
Occasionally clean the display panel and cabinet with a soft cloth dampened (not
soaked) with a mild (non-abrasive) glass cleaner. Keep turning a fresh side of the
cloth toward the screen surface to avoid scratching it with accumulated grit.
Do not use paper products as they may scratch the surface. To minimize the risk of
abrasion, allow the screen to stand dry.
Special care should be taken when cleaning a touch screen or polycarbonate shield
that is installed over the screen. Abrasive and certain chemical cleaners can easily
damage the surface.
Never use alcoholic or ammoniac cleaners to clean the polycarbonate shield or a
touch screen.
Replacing a Line Cord
To avoid shock and fire hazards, the monitor’s power cord should be replaced if the
insulation becomes broken or if it develops a loose internal connection.
Other Maintenance
Qualified service personnel should perform all maintenance, except for
the power cord replacement described above.
16
Cleaning and Maintenance
7
Section
Note: The solvent (a 50/50 mixture isopropyl alcohol and water) should be applied
only to the cloth, and not directly on the monitor screen.

VT190 ColorVue User Guide 150-077
17
Mechanical Drawings
8
Section
Mechanical Drawings
Model Description Page(s)
VT190PC 19.0” ColorVue Panel Mount Mechanical Drawing 18-19
VT190RC 19.0” ColorVue Rack Mount Mechanical Drawing 20
Panel Mounting Procedure
1. Cut and drill the panel (refer to panel mount drawing). Measurements are in inches.
Panel Mounting Cutout
2. If access to the side of the monitor is not available following installation, attach the power and
video cables to the side of the monitor at this time.
3. Install the monitor in the prepared cutout.
4. Install the lock nuts and washers, supplied with the monitor, behind the holes running along
the sides and top/bottom of the cutout in the panel. Extra lock nuts and washers are provided.
7.1 Panel Mount Procedure
Note:
Use #10-32 nuts for mounting.
5. Tighten all mounting nuts evenly to a torque of 24 inch-pounds.
ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide panel
seal and avoid potential damage. Vartech Systems assumes no responsibility for water or
chemical damage to the monitor or other equipment within the enclosure due to improper
installation.
6. Attach the power and video cables to the side of the monitor if you have not already done so.

Panel Size 19.0”
Type TFT Active matrix w/ Anti-Glare coating
Pixel Pitch 0.297mm
Resolution SXGA 1280 x 1024 max
Active Diagonal 19.0” Viewable
Active Screen Area 14.8” x 11.85”
376mm x 301mm
Pixel Format 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024
Viewing Angle (Up/Down) 85/85 deg.
Viewing Angle (Left/Right) 85/85 deg.
Contrast Ratio 500:1
Brightness 250 Nits
Response Time TR= 15ms
T
D= 10ms
Back Lights Cold Cathode 50,000 Hrs. Half Life
Video Connectors HD15(F)
DVI-I 29Pin connector (Digital/Analog)
Video Input RGB Analog (0.7V p-p / 75ohm), Digital
Sync TTL level, Positive/Negative, Separate H&V
Horizontal Sync 30-82kHz
Vertical Sync 56-75Hz
Colors Supported 16.7M
Power Input AC 100-240V 50/60Hz 1.0A
Power consumption 70 Watts @ 115VAC
Operating Temperature 0 to 50ºC
Storage Temperature -20 to 60ºC
Operating Humidity 10 to 95% NC
Storage Humidity 5 to 95% NC
Operating Altitude Up to 10,000 ft
Storage Altitude Up to 50,000 ft
21
Specifications
9
Section
