Vastex Dri-cab User manual

Utility Cart and Dri-Cab

Assembly, Operating, and Maintenance Instructions

Doc.#01‐14‐012A

 Utility Cart Assembly 2

 Dri-Cab Assembly 3-5

 Safety, Operation, and Maintenance 6

 Warranty 7

Serial Number:

(Please log your machine's serial number and date of purchase for future reference.)

Date:____/____/______

Electrical Drawing #: Rev:______

Pg #

VTX

Vastex E-mail assistance

Purchasing & Product Info:

[email protected]m

Electrical Support:

stech@vastex.com

Tech Support, Mechanical Setup, and Operation:

[email protected]om

Screen Printing Issues & Support:

[email protected]

OriginalInstrucons

YearofManufacture:2014

Vastex International, Inc.

1032 N. Irving St.

Allentown, Pa. 18109 USA

Phone# 610 434-6004 Fax# 610 434-6607

Web Site www.vastex.com

Authorized Representative in Europe:

Certification Experts BV

Nieuwstad 100 1381 CE Weesp,

The Netherlands

Tel : + 31 (0) 294 – 48 33 55

Fax : + 31 (0) 294 – 41 46 87

(Dri-Cab Shown)

Assembly

Hardware List:

A– Caster(4)

B– 3/4” Hex Nut(4)

C– 3/4” Flat Washer(4)

D– 1/4-20 x 1/2” Hex Bolt(28)

E– #8x3/8” Phillips Sht Metal Screw(16)

F– 1/4-20 Serrated Nuts(28)

Tools Needed: (1) Philips Head Screwdriver, (2) 7/16” open end wrench or socket,

(1) Adjustable wrench or 3/4” Open end/Socket Wrench

Parts List:

G– Bottom Panel (Note 4 large holes for casters)

H– Left Side Panel (Note 3 pairs of holes for OPTIONAL

Dri-Cab Hinge)

J– Right Side Panel

K– Top Panel (Note 2 Braces running side to side)

Procedure

1) Install all 4 Casters(A) onto bottom Panel(G). Tighten nuts well with adjustable wrench or 3/4” Socket.

2) Install all other hardware (refer to diagram above) Leave hardware loose for now.

3) *For DRI-CAB Assembly, do not install (4) 1/4-20 x 1/2” Hex bolts (X) yet, save for hinge install.

Assembly (Cont’d)

4) Make sure Utility Cart is

square by making these two

dimensions equal. Use a

tape measure or ruler to verify.

5) Tighten all Installed hardware.

- Use 7/16 wrenches or sockets to

tighten 1/4-20 Hardware.

- Use a Phillips head screwdriver for

Sheet metal screws

5) Utility Cart Assembly Finished.

Please continue for Dri-Cab Assembly

6) Install Screen Shelves as shown below, start from bottom

Dri-Cab Assembly

Hardware List:

A– #8x3/8” Phillips Sht Metal Screw(24)

B– 4-40 x 5/8” Phillips Pan Head Bolt(4)

C– 4-40 Hex Nut(4)

D– #4 Lock Washer(4)

E– #8 x 3/8” Sheet Metal Screw-Blunt tip(10)

Parts List:

F– Back Panel

G– Diffuser

H– Hinge Bracket– Door

J– Door

K– Deep Handle

L– Door Latch

1) Install Back Panel, Diffuser, Hinge Brackets-door as shown using a Phillips Head Screw Driver.

2) Install Deep Handle using a 1/4” nut driver or Flat blade screw driver.

3) Install Door Latch pieces using a 1/4” nut driver or Flat blade screw driver. Leave these slightly

loose until door is aligned to body.

Dri-Cab Assembly cont’d

Hardware List:

A– 1/4-20x1/2” Hex bolt(4)

B– 4-40 x 5/8” Phillips Pan Head Bolt(6)

C– 4-40 Hex Nut (6)

D– #4 Lock Washer (6)

Parts List:

E– Hinge Bracket (Body)

F– Catch

G- Seal

7) Hang Door on Hinge Brackets as shown.

8) Adjust Hinge Brackets and Catch until the

Dri-Cab Door slightly squishes the seal when

the door is closed. If needed, Latches can be

adjusted vertically.

4) Install Hinge Brackets using 1/4-20 bolts

and Serrated nuts. Leave this slightly loose un-

til door is aligned.

5) Install (3) Catches using #4 bolts, lock

washers, and nuts. Leave this slightly loose

until door is aligned.

6) Install 4 pieces of rubber seal around front

outside edge of cabinet. Overlap the seal in the

corner and cut through both, on a 45, using a

sharp knife, to create a sealing corner.

Safety Instructions

 The operator should read and understand the instruction manual before operating this equipment. Store

instruction manual and safety instructions near equipment for easy access to operators.

 VASTEX Screen Drying Cabinet is intended for the drying of emulsion on screen printing screens. Do

not use for any other purpose unless authorized by Vastex International, Inc. Use of this equipment for

any other purpose can be dangerous and may cause damage to this equipment voiding the warranty.

 It is recommended that the area around this equipment be designated as a work area and only author-

ized employees are allowed in this area.

 Children and pets must be kept clear from the work area.

 Never leave equipment unattended.

 DO NOT operate dry cabinet with any cover or guard removed.

 Operator must be familiar with controls of the dryer.

 Before starting production, the operator must check that all covers and guards are in place, no material

has been left in the cabinet, and the exhaust duct is clear of any obstructions.

 Always turn off power at the main disconnect at the end of production.

 Do Not remove any cover or guard until power at the main disconnect is switched off and locked out. No

unauthorized persons are to be allowed inside the control boxes.

 Turn off and lock out power at the main disconnect before cleaning and maintenance.

 Only qualified technicians should be allowed to make repairs on the VASTEX Screen Drying Cabinet.

 Noise and Vibraon: This noise level produced by this equipment does not exceed 70 dB(A).

Operation

1) Before using the dry cabinet, make sure the inside is thoroughly clean and dust free. Never

operate with dirty or missing intake filter.

2) Turn on the power switch, make sure fan is operating. Leave the unit on until the screens are

dry. It will take approximately 40-60 minutes to dry a fully loaded cabinet of coated screens. The

actual time with depend on the humidity level in your room. A dehumidifier is recommended for

better screen development.

4) Once the screens are dry, turn off the power switch. The screens can be stored in the cabinet

until needed.

Maintenance

1) Every week, the intake filter should be checked and cleaned as needed. A dirty filter re-

duces air flow thru the cabinet and will alter the drying process. The filter should be replaced

as necessary. Filter material can be ordered through Vastex.

2) It is important that the inside of the dry cabinet is keep clean. Periodic cleaning of the in-

side of the cabinet is recommended.

3) Check the exhaust for debris and clogging. Any restriction in the exhaust will alter the dry-

ing process.

To prevent over curing the emulsion, which

can cause premature exposure, screen

temperature should not exceed 95°F (35°C).

Vastex Warranty

Doc#01‐00‐005BRevised04/10/12

(1.)Vastex,hereinaerreferredtoas“seller”warrantsonlytoitsoriginal“purchaser”,whoholdsacopyoftheoriginalinvoiceandistheoriginalenduseroftheequipmentinqueson,

itsnewequipmentagainstdefectsinmaterialsorworkmanshiponapro‐ratedbasis.Warrantyperiodbeginsfromdateofshipmenttothebuyerandwillonlyapplytocustomerspaid

infull.Warrantyperiodsareasfollows:one(1)yearforE‐1000,three(3)yearsforallothercompletemachines(includingF‐Flash),ﬁeen(15)yearsforinfraredheaters(excludingF‐

Flash)installedbyVastexinanewdryer,three(3)yearsforreplacementinfraredheaters,andone(1)yearforreplacementparts.Rubberblankets,lightbulbsandglassonexposure

unitsareparcularlysubjecttowearwhileinuse.Wearisnotcoveredbythiswarrantybutasstatedaboveonlymanufacturersdefectsarecovered.AllsalesmadethroughVastex

dealersmustbecerﬁedbythatdealerbeforeawarrantyreplacementisissued.



(2.)This warranty is expressly conngent upon the buyer delivering to seller, at the address below, with all transportaon charges prepaid, the part or parts claimed to be defecve

within the above menoned warranty periods stated in paragraph one. The defecve part or parts will be repaired or replaced at the discreon of Vastex Internaonal, Inc. If the

equipment in queson is less than one (1) year old, it will be shipped to the customer at no charge, with an RGA issued by Vastex for the defecve part. The defecve part must be

shipped back to Vastex freight prepaid within 30 days or the account will be billed. If the equipment is more than a year old, the part will be shipped aer we receive the defecve

part. If it’s necessary to expedite the movement of parts and to minimize down me to the buyer, the replacement part shall be supplied on a C.O.D. basis. If tesng and analysis of

said part by the seller or its supplier discloses that said part is defecve, the cost of said part will be refunded to the buyer on a prorated basis.



(3.)Exceptasotherwiseprovidedherein,theequipmentisbeingsold“as‐is”.Finaldeterminaonofthesuitabilityoftheequipmentfortheusecontemplatedbythebuyer,isthesole

responsibilityofbuyer,andsellershallhavenoresponsibilityinconneconwiththesuitability.



(4.)Allwarranesimpliedbylaw,includingtheimpliedwarranesofmerchantabilityandﬁtnessareherebylimitedtoworkmanshipanddefecvepartstoawarrantyperiodstatedin

paragraphone.Theexpresswarrantyandremediescontainedhereinandsuchimpliedlimitedwarranesaremadesolelytothesolewarranesandremediesandareinlieuofallother

warranes,guarantees,agreements,andotherliabilies,whetherexpressorimplied,andallotherremediesforbreachofwarrantyoranyotherliabilityofseller,innoeventshallseller

beliableforconsequenaldamages.



Noperson,agent,distributor,orservicerepresentaveisauthorizedtochange,modifyorextendthetermshereofinanymannerwhatsoever.

Thesetermsandcondionsareanessenalpartofthetransaconbetweentheparesandconstutetheenreagreementbetweenthemwithrespecttothesame.

Somestatesdonotallowlimitaononhowlonganimpliedwarrantylastsoftheexclusionorlimitaonofincidental,orconsequenaldamages,sotheabovelimitaonmay

notapplytoyou.

Thiswarrantygivesyouspeciﬁclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.

Infraredheatersaretheonlyreplacementpartscoveredforaperiodof(3)yearsfromdateofshipmentandconngenttoreceiptofpaymentinfull.



Electricalcomponentscannotbereturnedonceinstalledunlessprovendefecve.

Pleaserefertodoc.01‐00‐015forspeciﬁctermsandcondionsofsaleandthelimitedwarranty.

Pleaserefertodoc.01‐00‐017forV‐2000HDprinterwarranty.



Updates:V1000to3yearwarranty01/09/12,Heaterwarrantyto15years01/02/2012.

‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐

TERMS AND CONDITIONS OF SALE AND LIMITED WARRANTY Doc.#01‐00‐015



1. Buyer’sorderwillconstuteanoﬀerinaccordancewiththetermshereofandsuchoﬀer,uponacknowledgmentofSeller,willconstutetheagreementbetweenBuyerand

Seller.Buyer’sorderaersuchacknowledgmentbySellerwillnotbesubjecttocancellaon,changeorreduconinamount,orsuspensionbyBuyerofdeliveries,unlesspriorto

suchaconBuyerhasobtainedSeller’swrienconsent.NotwithstandinganythingtothecontraryinBuyer’sPurchaseOrderorothercommunicaons,theparesagreetobe

boundbytheseTermsandCondions.AcceptanceoftheproductbytheBuyershallbedeemedtoconstuteuncondionalacceptanceoftheseTermsandCondions.



2. Anyoftheseterms,condionsandprovisionsofBuyer’sorderwhichareinconsistentwithSeller’sacknowledgmentandtheseTermsandCondionsofSaleshallnotbebinding

ontheSellerandshallbeconsiderednotapplicabletoanysalesomade.Nowaiver,alteraonormodiﬁcaonofanyoftheprovisionsoneithersideofthedocumentshallbe

bindinguponSellerunlessagreedtoinwringbySeller.

3. (a)AllpricesareF.O.B.Seller’sPlantandmethodofdeliveryandroungshallbeatSeller’sdiscreon,unlessspeciﬁcallyotherwisestatedherein.Notwithstandinganyagree‐

menttopayfreight,deliveryofproductspurchasedhereundertoacommoncarrierorlicensedtruckershallconstutedeliverytoBuyerandbedeterminaveofthedate

andmeofshipmentandallriskoflossordamageintransitshallbebornebyBuyer.IftheBuyerfailstoacceptthegoodsfromthecommoncarrierorlicensedtrucker,the

SellershallbeentledtoclaimpaymentfromtheBuyer.Sellershallarrangeforstorage,theriskandthecost,includinginsurancecosts,tobebornebytheBuyer(andBuyer

agreestopaysuchamountsupondemand)exceptifthefailuretoacceptdeliveryisduetoanyoftheexceponsnotedinParagraph4.

 (b)Termsofpaymentshallbeasstatedoninvoice.

4. ItisunderstoodthatdeliverieswillbemadeinaccordancewithSeller’sregularproduconschedule.EveryreasonableeﬀortwillbemadetomeettheBuyer’srequireddelivery

datesbutSellerwillnotbeliablefordamagesorbedeemedtobeindefaultbyreasonofanyfailuretodeliverordelayindeliveryduetoanypreference,priority,allocaonor

allotmentorderissuedbytheGovernment,whetherFederal,Stateorlocal,orcausesbeyonditscontrolincludingbutnotlimitedto,ActsofGodorapublicenemy,actsofGov‐

ernment,ﬁres,ﬂoods,epidemics,quarannerestricons,strikes,lockouts,freightembargoes,severeweather,unavailabilityofmaterialsorshippingspace,delaysofcarriersor

suppliersordelaysofanysubcontractors.Shoulddelayindeliverybecausedbyanyofthecircumstancesmenonedinthisparagraph,suchextensionofthedeliveryperiodshall

begrantedasisreasonableunderthecircumstancedofthecase.Shoulddelaybecausedbyaneventnotspeciﬁcallymenonedinthisparagraph,damageswillbelimitedto

cancellaonofthepurchaseorderwithoutpenalty,andrefundofanymoniesdepositedorprepaidonthepurchaseorderwithnoliabilityforanyconsequenalorincidental

damages.
