VAUXHALL Astra
Owner’s Manual

0
Data specific to your vehicle
Pleas e enter you r vehicle ’s data h e re to ke ep it ea sily acces s ible.
This information is available under the section "Technical data " as well as on the identification plate.
Fuel
Designation
Engine oil
Grade
Viscosity
Tyre inflation pressure
Ty re si ze wi th up to 3 persons wi th full load
Sum mer tyres Front R ear Front R ear
Winter tyres Front R ear Front R ea r
Weights
Permissible gross vehicle weight
– ECkerbweight
=Loading
Level control
Bumper H eight see page 178

1
Your Astra
Developed to the la test findings of vehic le research, it offers technical sophistication and exceptional comfort.
Your vehicle represents an ideal synthesis of ad vanced technolog y, outsta nding safety, environm ental compatibility and economy in
operation.
It now lies with you to drive your vehicle safely and to see it performs perfectly.
This Owner's Manual provides you with all the necessary information to tha t end.
The O wner's Manual s hould a lways be ke pt in the v ehicle: ready to hand in the g lov e com partment.
Make use of the Owner's Manual:
zIts “In Brief” section will give you a n initial ov erview.
zIts index will help you find what you want.
zIt will familiarize you with the sophisticated technology.
zIt will increase your pleasure in your vehicle.
zIt will help you to handle your vehicle expertly.
The Owner's Manual is designed to be clearly laid-out and easily understood.
This symbol:
6signifies: continue reading on next page.
3The asterisk sig nifies equipment op tions not in all vehicles (model variants, engine options, models specific to one country, op tional
equipment, Genuine Vauxhall Parts and Accessories).
Yellow arrows in the illustrations serve as points of reference or ind icate some action to be performed.
Black arrow s in the illustrations indicate a reaction or a second action to be perform ed.
We wish you many hours of pleasurable driving
Your Vauxhall team
Text highlighted in yellow in p artic ular indica tes possible risk of accident and
injury. Disregard of these notes can lead to injuries which may b e fatal. Vehicle
passengers must b e informed accordingly.

2

Contents
3
Commitment to custom er
satisfaction:
Our ai m: to keep you happy with your
vehicle. All Vauxhall Authorised Repairers
offer first class service at competitive
prices. Experienced, factory-trained
technicians w ork according to factory
instructions.Your Authorised Repairer can
supply you with GEN UINE VAU XHALL-
APPROVED PARTS, which have und ergone
stringent quality and precision checks, and
of course useful and attractive
VAUXHALL-APPROVED ACCESSORIES.
Our name is your guarantee!
For d eta ils of the
Va ux hall Authorised Rep airer Netw ork
pleasering this number; 01582 - 427200
In b rie f . ..... .... ..... .... .... ..... .... ..... .... ..... .... .... . 4
Ins trum ents ... ..... .... .... ..... .... ..... .... ..... .... .. 28
K eys, doors, b onnet .. ..... .... ..... .... ..... .... .. 54
S eats , Interior ..... .... .... ..... .... ..... .... ..... .... .. 6 7
S afe ty s ystem s ... .... .... ..... .... ..... .... ..... .... .. 80
Lighting ..... .... ..... .... .... ..... .... ..... .... ..... .... 120
W indows, sun roof .... ..... .... ..... .... ..... .... 125
C onve rtible folding top . .... ..... .... ..... .... 131
He ating and v entilation ... ..... .... ..... .... 14 2
Air con ditioning sys tem . .... ..... .... ..... .... 147
E lectronic air conditioning s ystem . .... 154
Automatic transm iss ion .... ..... .... ..... .... 161
Driving hints . ..... .... .... ..... .... ..... .... ..... .... 166
Saving fuel,
prote cting the environ ment .... ..... .... 16 8
F uel cons um ption, fuel, re fu elling .. .... 17 0
C atalytic con ve rter, e xhaust gases .... 172
Drive con trol system s .... .... ..... .... ..... .... 17 6
Brake s ... ..... .... ..... .... .... ..... .... ..... .... ..... .... 181
W hee ls, tyres . ..... .... .... ..... .... ..... .... ..... .... 184
Roof racks,
caravan and tra ile r towing .... ..... .... 188
S elf-help .... .... ..... .... .... ..... .... ..... .... ..... .... 195
If y ou ha ve a problem .... .... ..... .... ..... .... 232
Mainte nan ce , Inspec tion s ystem ... .... 234
V ehicle care .. ..... .... .... ..... .... ..... .... ..... .... 245
Te chnical data . .... .... ..... .... ..... .... ..... .... 250
Inde x . .... ..... .... ..... .... .... ..... .... ..... .... ..... .... 292

4
In brief
Key num be rs,
co de n umb e rs
Remove key number from keys.
The key number is specified in the vehicle
docum ents and in the Car Pass 3.
Alloy wheels 3, towing equipment 3: make
a note of the key identifier cod es.
Elec tronic imm obilise r, radio 3: Thecode
numb ers are specified in the Car Pass and
Radio Pass 3respec tively.
Do not keep the Car Pass andRa dio Pass in
the vehicle.
6Further information – se e p ages 54, 55,
vehicle recomm issioning – see page 244.
Unlocking the vehicle:
Turnkey in
driver’s door lock
or press button qon the
remote control 3
6Door lock s, child sa fety lock 3 – see
pag e 54,
electronic immobiliser – see page 55,
radio remote control 3 – see page 56,
central loc king system 3 – see page 58,
anti-theft locking system 3– see page 60,
Vauxhall alarm system 3– see page 63,
convertible folding top 3– see page 131.

5
Unlock luggage compartment:
Tu rn key clockwis e as far as it will go
In order to av oid being locked out, the key
cannot be removed.
Position of key slot in lock:
– horizontal tailgate is loc ked
and unlocked
together with the central
locking,
– vertical tailgate is always
locked.
6Radio remote control 3 – see pa ge 56,
central locking 3 – se e p age 58,
Vauxhall alarm system 3– see page 63.
Adjusting front seats:
Pull handle,
slide seat,
rel ease handle
Never adjustthe driver’s seat whilstdriving.
It could move in an uncontrolled manner
when the handle has been pulled.
6Seat position – see page 67.
Front seat backrest adjustm ent:
Turn handwheel
Move seatbackrestto suitseating position.
Do not lea n on seat back rest whilst
adjusting it.
6Seat position – see p age 67.
Im porta nt : Do not sit nearer than 10”
(2 5cm ) from the s tee ring wh ee l, to
permit safe airbag dep loy ment.

6
Adjusting height of front
seats 3:
Leveron outboard side of seats
Pump direction of the lever
Up: Raises seat
Down: Lowers seat
6Sea t position – see pag e 67.
Front seat lumbar support 3
ad j ust m e nt :
Tu rn han dw hee l
In the 3-door hatch, the coupe and the
conv ertible, the handwhe el is on the
inboard side of the seat backrest. In the
4-door saloon and 5-door hatch and the
estate, it is on the outb oard sid e.
Ad just lumbar support to suit personal
re qu ir eme n t s.
Do not lean on seat backrest whilst
adjusting it.
6Seat position – see page 67.
Front seat thigh support 3
adjustment:
Lift and slide the front thigh support
cushion
Do not adjust the thigh sup port whilst
driving.
6Seat position – see p age 67.

7
Fo ldin g down the fr ont seat 3:
Lift the release lever,
fold the backrest down and engage,
slide the se at forward.
To reposition the seat;
slide i t back as far as it wi ll go,
lift the release leve r,
restore the backrest to an upright
position
In front se ats w ith m emory-functio n 3, the
seat engages in its original position when
pushe d bac k.
In front seats without memory function 3,
enga ge seat in required position when
pushing b ackwards.
6Seat position – see pag e 67.
Adjustin g h eigh t of fron t an d re ar
outboard se at head restraints:
Tilt forward to release,
hold and adjust height,
release
6Head restraint position – see page 68,
further informa tion, rem oval – se e page 68,
rear centre head restraint 3 –see page 68.
Adju st ing interio r mir ror:
Swivelmirror housing
Swivel lever on underside of m irror housing
to reduce d azzle at night.

8
Adjusting automatic anti-dazzle
interi or mi rror 3:
Swivel mi rror ho us ing
Dazzle at night is automatically reduced .
T h e m i rro r d oe s n ot re d u ce d az zle w h en :
zthe ignition is switched off,
zreverse gear is engaged or selector lever
is s et to R,
zinterior lighting has been switched on
Exterior mirror adjustment:
Swivel in desired direction using
interior handle
6Further information, aspherical exterior
mirror 3– se e p a ge 11 9.
El ectrically adjust able exterior
mirrors 3:
Fo ur-way s wit ch i n driver ’s doo r
Toggle sw itc h to left or right:
Four-wa y switch m ov es app ropriate m irror.
6Further information, aspherical exterior
mirror 3– see page 119,
heated exterior mirrors 3– see page 18.

9
Fi ttin g seat belt:
Draw seat belt sm oo thly fro m in ertia-
reel, guide over shoulder
and engage in belt buckle
The belt must not be twisted at any point.
The lap belt must lie snugly against the
body. The front seat backrests m ust not be
tilted back too far (recommended tilting
angle approx. 25°).
To release belt, press red button on belt
buckle.
6Seat belts – see pa ges 81 to 85,
airbag sy ste ms 3– se e p age 86,
seat p osition – see page 67.
Disen gagin g steer in g colu mn lo ck:
To re lease the lock,
move the s teering wheel slightly
and turn the key to position I
Positions:
o=Ignitionoff
I = Stee ring free , ign ition off
II = Ignition on
III = Start
6Starting – see page 21,
electronic im mobiliser – see pag e 55
re mo ve ke y a n d loc k s tee ri n g w he el –
se e p age 22.
Steering wheel adjustment 3:
Move lever down,
adjust height and distance,
move lever up,
engage
Adjust steering wheel only when vehicle is
stationary and steering colum n loc k is
released.
6Airbag systems 3– see page 86.

10

11
Page
1Side air v ents ... ..... .... ..... 144 , 1 50, 156
2Front pa ssenge r airbag 3.... ..... .... . 8 6
3Radio 3,
Infotainment system 3. .... .... ..... .... . 5 1
4 Display 3for time, date,
outside temperature,
radio 3,
Infotainment system 3,
check control 3,
trip computer 3.... .... ..... .... .... ..... .... . 3 6
5 Haza rd warn ing lights .. .... .... ..... .... . 1 5
6Ce ntre air v ents .... .... ..... 144 , 1 50, 156
7 Turn signals, headlight flash,
dippe d an d main be am ... .... ..... .... . 14
Cruise control 3.... .... ..... .... .... ..... .... 179
8Horn .... .... ..... .... ..... .... ..... .... .... ..... .... .. 16
9Ins trume nts .. .... ..... .... ..... .... .... ..... .... . 2 8
Pa ge
10 Windscreen wiper and wash system,
headlight wash system 3and
rear window wash system 3 ... ..... .. 1 6
check control, trip c om puter 3..... .. 4 6
11 Light s witch ..... .... ..... .... .... ..... ... 1 4, 1 20
12 Instrument illumination ........ .... ..... 1 22
Fog tail lig ht .... .... ..... .... .... ..... .... ..... 1 20
Fog lights 3 ..... .... ..... .... .... ..... .... ..... 1 20
Head lig ht range adjustment 3..... 12 1
13 Bonne t rele ase lev er . .... .... ..... .... ..... . 66
14 Storage compartment,
fu sebox ... .... ..... .... ..... .... .... ..... .... ..... 2 15
15 Remote control for
ra d i o an d
Infotainme nt sy ste m .... .... ..... .... ..... . 26
16 Ignition switch
with ste erin g whe el lock .. ..... .... ..... ... 9
17 Ac cele ra tor pedal .... .... .... ..... 1 66, 16 7
18 Stee ring whee l adju stm en t 3... ..... ... 9
19 Brake peda l ..... .... ..... .... .... ..... 1 66, 181
20 Clutch ped al .... .... ..... .... .... ..... .... .... 1 67
Page
21 Ashtray .. ..... .... .... ..... .... ..... .... ..... .... .. 7 8
22 Electric window operation 3,
co nve rtib le .. .... .... ..... .... ..... .... ..... .... 126
23 Storage compa rtm ent
24 Accessory socket or
cigare tte ligh te r . ..... .... ..... .... ..... .... .. 77
25 Air re circ ulation sys tem ... .... ..... .... 14 3
Air conditioning system 3... ..... .... 14 7
He ated rear w indow ... .... 18, 1 46, 157
26 Convertible folding top
operation 3... .... ..... .... ..... .... ..... .... 13 6
27 He ating and v entilation .. .... ..... .... 142
Electronic air conditioning
system 3..... .... .... ..... .... ..... .... ..... .... . 154
28 Glove compartme nt ... ..... .... ..... .... .. 7 9
CD changer 3,
Telematics 3
11

12
Control indicators
?Automat ichea dlight
range adjustment 3,
fault
se e p ag e 12 1.
v Airbag systems 3,
belt tensioners,
see pages 82, 91.
XSea t belt 3,
se e p age 28.
RBrake system,
clutch system,
se e p age 29.
@Electronic ally controlled
engi ne cooli ng 3,
se e p age 29.
!Glow plugs 3,
se e p age 29.
AEngine electronics,
immob iliser 3,
automat ic tra nsm ission 3,
fault,
see pages 29, 55, 164, 174.
pAlternator,
se e p age 30.
ZExhaust emission 3,
see pages 30, 174.
IO il pressur e,
see page 30.
>Fog light s 3,
see pages 31, 120.
P Main beam,
see pages 14, 31.
r Fog tai l light,
see pages 31, 120.
OTurn signal l ights,
see pages 15, 31.
1 Automatic transmission 3,
sporty driv ing pr og ramm e,
see page 162.
vTraction Control system (TC) 3,
E lect roni c Stab ility Progra mme
(ESP) 3,
see pages 176, 177.
u Anti-lock Brake System (ABS) 3,
see page 183.
Y Fuel level,
see pages 32, 35, 195.
g Trailer turn signa l 3,
see page 32.
y Seat occup ancy recog nition 3,
see page 91.
Lighting
Li ght switc h,
stalk positions,
see pages 14, 120,
7Ligh ts off,
8Parking lights,
9Dipped and main beam.
0Courtesy li ght,
see page 122.
>Fog lights 3,
see page 120.
r Fog tail light,
see page 120.
kInstrument il luminati on,
see page 122.
?Headlight range adjustment,
see page 121.
¨Hazard w arning lig hts,
see page 15.

13
Heating, ventilation, ai r conditioning 3,
auto matic air co nd itio nin g syst em 3
xAirflow,
see pages 142, 148, 158.
Air distri bution,
see pages 143, 148, 157,
VTo wind scre en a n d
front door windows,
JTo wind scre en , f r o n t
do or w ind ow s
and footwell,
KTo footwell,
L to head area via adjustab le air
vents and to footwell,
M to head area via adjustab le air
vents.
ÜHeated rear window,
see pages 146, 152, 157.
4Air circ ul ation system,
see pages 143, 149, 158.
n Air conditioning system 3,
se e p ag e 14 7.
AUTO Automatic mode 3,
se e p ag e 15 5.
E CO Ope rati on without c ooling 3,
se e p ag e 15 7.
ß Heated seats 3,
see pages 146, 152, 160.
Su n ro of
l Sun roof 3
opening / lowering,
see pages 128, 130.
\ Sun roof 3
closing / raising,
see pages 128, 130.
Convertible folding top
,Folding t op 3
opening,
see pages 131, 136.
/ Folding t op 3
closing,
see pages 132, 136.
Windscre en wiper
St alk p osi tions,
see page 16,
§Off,
$Timed interval wipe, or
autom atic wipe
with rain sensor 3
%Sl ow ,
&Fast.
Date, time, radio
Informa tion displa y 3,
see page 36.
ÖOn button for date and time,
;Setting b uttons for date and time.
Steering wheel remote control 3,
see page 26.
Miscellaneous
p Central l ocking sy stem 3,
loc king – see pag e 58.
q Central l ocking sy stem 3,
unlocking – see page 58.
)Cigarette lighter,
see page 77.
j Horn,
see page 16.
/Bonnet,
see page 66.
TWi nter program me ,
automa tic tr ansm issi on 3:
see page 163.
+Fir st- aid k it 3,
see pages 200, 202.
¨Wa rning tri angle 3,
see pages 200, 202.

14
Light switches:
7=Off
8= Parking lights
9= Dipped or main beam
0Pull = Courtesy light
rPush = Fog tail light
>Press = Fog lights 3
6Further inform ation – see page 120,
headlig ht warning device – see page 24.
Main and dipped beam switch:
Main beam = Pushlever forward
Dipped beam = Pull lever towards
s teering wheel
By overcoming the lever resistance the
headlight flash is operated.
Headlight flash:
Pull stalk towards s teering wheel

15
Operating turn signal lights:
Leve r in res t position
right = up
le ft = do wn
W hen th e s tee rin g wh ee l is tu rne d back, th e
lever automatically returns to its original
position. This will not hap pen when making
a m inor steering manoeuvre such as
changing lane.
When lane changing, move lever to
res is ta nce po int. W h en re leas ed , th e le ve r
will spring back.
Cruise control operation:
Press button on stalk
Switch on: Tap button I.
Switch off: Tap button §.
Resume at stored speed: Tap button R.
6Cruise control 3 – see page 179.
Hazard warning lights:
On = Press
¨
Off = Press ¨again
To aid loc ation of the pushbutton, the red
surfac e is illuminated w hen the ignition is
switched on. When the button is pressed,
its control indicator flashes in time with the
hazard warning lights.

16
Horn operation:
Press j
6Airbag sy ste ms 3– see page 86,
remote control for ra dio and Infotainment
system 3– see pa ge 26.
Windscre en wiper :
Move lever up
§= O ff
$= Timed interval wipe
%= Slow
&= Fast
Automatic wiper with rain sensor 3:
Move lever up
§= Off
$= Automatic wiper
wi th rai n s ens or
%= Slow (constant)
&= Fast (constant)
Automatic wiping $: The rain sensor
detects the amount of w ater on the
windscreen and automatically regulates
th e wind scre en wipe r.
Push lever down to switch off.
If necessary, the positions %or&can be
selected manually.

17
Operating windscreen and
headlight w ash systems 3:
Pull stalk tow ards steering wheel
The wip er will swipe for a few strokes.
The headlight wash system 3can be
operated when the lights are on.
On vehicles fitted with rain sensors 3,
operate the windscreen wash system at
regular intervals, to keep the sensor a rea
clean.
6Further inform ation – see page s 242,
246.
Operating rear window wiper and
wash systems 3:
Wi per on = Pu sh leve r f or ward
Wiper off = Pu ll le ve r towards
steering wheel
Wash = Push leve r forward
and hold
The rear window wiper works in timed
interval mode. Continuous wiping takes
place during washing.
6Further information – se e p ages 242,
246.

18
Heated rear window,
heated exteri or mi rrors 3:
On = Press
Ü
Off = Press Üagain
The rear window and exterior mirror
heating is switched off autom atically after
approx. 15 m inutes.
6Further inform ation – see page s 146,
152, 157.
To dry fogged or icy windows:
Tu rn ro tar y swi tche s f or
heater and fan clockwise,
air distribution to V,
press air conditioning switch n3
Close centre air vents, open side air vents
and direct them towards the door windows.
6Heating, ventila tion – see page 142,
air conditioning system 3– se e p age 147,
electronic air conditioning system 3– see
page 154.
Setting electronic climate control to
au to ma ti c mod e :
Press AUTO button,
se t tem pe rat ur e u sin g ro ta r y kno b
Open all air vents.
6Electronic air conditioning system 3– see
pag e 154.
