VAUXHALL Corsa & Combo
Owner’s Manual

0
Data specific to your vehicle
Pleas e enter yo ur veh icle ’s data he re to ke ep it ea sily acces sible.
This information is available under the section "Technical data " as well as on the identification plate.
Fuel
Designation
Engine oil
Grade
Viscosity
Tyre inflation pressure
Ty re si ze wi th up to 3 pe rsons wi th full load
Sum mer tyres Front R ear Front R ea r
Winter tyres Front R ear Front R ea r
Weights
Permissible gross vehicle weight
– ECkerbweight
=Loading
Level control
Bumper H eight see page 92

1
Your Corsa
Developed to the latest findings of vehic le research, it offers technical sophistication and exceptiona l comfort.
Your vehicle represents an ideal synthesis of ad vanced technolog y, outsta nding safety, environm ental compatibility and economy in
operation.
It now lies with you to drive your vehicle safely and to see it performs perfectly.
This Owner's Manual provides you with all the necessary information to tha t end.
The O wn er's Manual s hould a lways be ke pt in the v ehicle: ready to hand in the g lov e com partment.
Make use of the Owne r's Manual:
zIts “In brief” section will give you an initial overview.
zIts index will help you find what you want.
zIt will familiarize you with the sophisticated technology.
zIt will increase your pleasure in your vehicle.
zIt will help you to handle your v ehicle expertly.
The Owner's Manual is designed to be clearly laid-out and easily understood.
This symbol:
6signifies: continue reading on next page.
3The asterisk sig nifies equipment op tions not in all vehicles (model variants, engine options, models specific to one country, op tional
equipment, Genuine Vauxhall Parts and Accessories).
Yellow arrows in the illustrations serve as points of reference or indicate some action to be performed.
Black arrows in the illustrations indicate a reaction or a second ac tion to be perform ed.
We wish you many hours of pleasurable driving
Your Vauxhall team
Text highlighted in yellow in p artic ular indica tes possible risk of accident and
injury. Disregard of these notes can lead to injuries which may b e fatal. Vehicle
passengers must b e informed accordingly.

2

Contents
3
Commitment to customer
satisfaction:
Our ai m: to keep you happy with your
vehicle. All Vauxhall Authorised Repairers
offer first class service at competitive
prices. Experienced, factory-trained
technicians w ork according to factory
instructions.Your Authorised Repairer can
supply you with GEN UINE V AU XHALL-
APPROVED PARTS, which have und ergone
stringent quality and precision chec ks, and
of course useful and attractive
VAUXHALL-APPROVED ACCESSORIES.
Our name is your guarantee!
For d eta ils of the
Va uxhall Authorised Rep airer Netw ork
pleasering this number; 01582 - 427200
In Brie f . ..... .... ..... .... .... ..... .... ..... .... ..... .... .... . 4
Instrum ents ... ..... .... .... ..... .... ..... .... ..... .... .. 29
K eys, doors, b onnet .. ..... .... ..... .... ..... .... .. 5 0
S eats , Interior ..... .... .... ..... .... ..... .... ..... .... .. 6 4
S afety sys tem s ... .... .... ..... .... ..... .... ..... .... .. 78
Lighting ..... .... ..... .... .... ..... .... ..... .... ..... .... .. 99
Windows, sun roof,
folding top ..... .... .... ..... .... ..... .... ..... .... 10 3
C lim ate c ontrol .. .... .... ..... .... ..... .... ..... .... 112
E asy tronic . .... ..... .... .... ..... .... ..... .... ..... .... 126
Automatic transm ission 3..... .... ..... .... 132
Drivin g h ints . ..... .... .... ..... .... ..... .... ..... .... 138
Saving fuel,
prote cting th e environment ... ..... .... 140
Fuel consumption,
fue l, re fue lling ... .... ..... .... ..... .... ..... .... 14 2
C atalytic con ve rte r, e xhau st gases .... 144
Drive Control Sy ste ms ... .... ..... .... ..... .... 14 8
Brake s ... ..... .... ..... .... .... ..... .... ..... .... ..... .... 15 2
W hee ls, tyres . ..... .... .... ..... .... ..... .... ..... .... 156
Roof racks , c aravan and traile r towing . ....
16 0
S elf-help .... .... ..... .... .... ..... .... ..... .... ..... .... 17 0
If y ou ha ve a problem ... .... ..... .... ..... .... 208
Maintenance,
inspe ction S ys tem . ..... .... ..... .... ..... .... 210
V ehicle care .. ..... .... .... ..... .... ..... .... ..... .... 221
Te chnical Data . .... .... ..... .... ..... .... ..... .... 226
Inde x . .... ..... .... ..... .... .... ..... .... ..... .... ..... .... 25 4

4
In Brief
Key n um be rs, code numbers
Remove key number from keys.
The key number is specified in the vehicle
docum ents and in the C ar Pass 3.
Alloy wheels 3, towing equipment 3: M ake
a note of the key identifier codes.
Elec tronic imm obiliser, infotainme nt
sy ste m 3: Th e co de numb ers are s pe cifie d
in the Ca r Pass.
Do not keep the Car Pass in the vehicle.
6Further information – see pages 50, 51.
To unlock vehicle:
Press button q 3,lift door handle
To unlock using the key in the driver’s door
lock: Turn key tow ards front of vehic le, lift
door handle.
Locking from the inside: Press lock buttons.
6Door lock s, child safety locks 3–
pag e 50,
electronic immobiliser – page 51,
radio remote control 3 – page 52,
central loc king sy ste m 3 – pag e 54,
Vauxhall alarm system 3– page 60.

5
To unlock luggage compartment:
Turn key clockwise as far
as it willgo
In order to avoid being locked out, the key
cannot be removed.
Position of key slot in lock:
– Horiz ontal Lug gage compartme nt
locked and
unloc ked tog ether
with central
locking system.
– Vertica l Lug gage compartme nt
is always locked.
Radio remote control 3 – page 52,
central lock ing system 3 – page 54,
Vauxhall alarm system 3– page 60.
Se at a d j ust men t 3:
Pull handle, slide seat,
rel ease handle,
allow seat to audibly latch into
po si ti on
Never adjustthe driver’s seat whilstdriving.
It could move in an uncontrolled manner
when the handle has been pulled.
6Seat position – see page 64.
Adjusting seat backrest:
Turn handwheel
Move seatbackrestto suitseating position.
Do not lea n on seat back rest whilst
adjusting it.
6Sea t position – see pa ge 64.
Im porta nt : Do not sit nearer than 10
in ch es ( 25c m) fro m the s tee ring wh ee l, to
permit safe airbag dep loy ment.

6
Adjusting seat height 3:
Pu ll le ver at s ide
Lift lever and remove weight from seat to
raise it or p ress d ow n on seat with body
weight to low er it.
Never adjust the driver’s seat whilst driving.
It could m ov e in a n uncontrolled m anne r
when the lever has been pulled .
6Seat position – see pag e 64.
Folding down the seat backre sts 3:
Raise release lever
To enter a nd leav e the rear sea t area, tilt
front seat back forwards.
6Seat position – see page 64.
Adjust ing head r estrai nt he ight:
T ilt f orwards to re lease ,
hold firmly and adjust height,
then release
6Head restraint position – see pag e 64,
furthe r information, remova l – see page 65,
rear head restra ints 3 – see page 65.

7
Adjusting interiormirror:
Swivel mirror ho us ing
Swivel lever on underside of mirror housing
to red uce daz zle a t nig ht.
Adjusting automatic anti-dazzle
interior mirror3:
Swivel mirror housi ng
Dazzle at night is automa tic ally red uc ed.
The mirror does not reduc e dazzle when:
zthe ig nition is sw itc hed off,
zrev erse gear is eng aged or selector lever
set to R,
zinterior lighting has been switched on.

8
Adjusting exterior mirrors:
Swivel i nterior h andle in appr opr iate
direction
6 Further information, aspherical exterior
mirror 3– page 97.
Electrically adjustable exterior
mirrors 3:
Four-way switch in driver’s door
Togg le switch to left or right: Four-way
switch m oves appropriate mirror.
6Further information, aspherical exterior
mirror 3 – see pa ge 97,
heated exterior mirrors 3– se e pag e 1 9.

9
Fi ttin g seat belt:
Draw seat belt smoothly from inertia
re el, guide over shoulder
and engage in buckle
The b elt must not be twisted at any point.
The lap belt must lie snugly against the
body. The backrest must not be tilted back
too far (recomm ended tilting angle
approx. 25°).
To release belt, press red button on belt
buckle.
6 Safety belts – see pages 79 to 83,
airbag sy ste ms 3– see p age 84,
seat p osition – see page 64.
Disengaging steer in g c olu mn lock:
To re lease th e lock, mo ve the
steering wheel slightly
and turn the key to position I
Positions:
o=Ignitionoff
I = Steering released, ignition off
II = Ignition on,
with dies el e ngin e: Pre heatin g
III = Start (transmission in neutral)
6Starting – page 23,
electronic im mobiliser – pa ge 51,
Remove key and lock steering wheel
– see page 24.
Steering whee l adjustment 3:
Swivel lever down,
adjust he ight,
swivel lever up,
engage
Adjust steering wheel only when vehicle is
stationary and steering colum n loc k is
released.
6 Airbag systems – see pag e 84.

1010

11
Page
1Side air v ents ... ..... .... ..... .... .... ..... ... 115
2 Front pa ssenger airbag 3.... ..... .... . 8 4
3 Infotainment system 3. .... .... ..... .... . 4 8
4Haza rd warn ing lights .. .... .... ..... .... . 1 7
LED for Vauxhall alarm system 3.. 6 0
5Display 3 for time, date,
outside tem perature,
infotainment system 3. .... .... ..... .... . 3 7
6Ce ntre air v ents .... .... ..... .... .... ..... .... 115
7Turn signal, headlight flash,
dippe d and main be am ... .... ..... .... . 1 5
Door-to-door
light function 3 ... .... ..... .... .... ..... .... . 16
Cruise control 3.... .... ..... .... .... ..... .... 150
8Horn .... .... ..... .... ..... .... ..... .... .... ..... .... .. 17
9 Infotainment system remote
control 3. ..... .... ..... .... ..... .... .... ..... .... . 2 6
10 Instru me nts .. .... ..... .... ..... .... .... ..... .... . 2 9
Pa ge
11 Lever for w indscreen wiper
and wash system as well as
headlight wash system 3and
rear window wash system 3.... ..... .. 1 7
12 Light switch ..... .... ..... .... .... ..... .... . 15, 9 9
13 Head lig ht range adjustment 3..... 100
Fog tail lig ht .... .... ..... .... .... ..... .... ..... 10 1
Fog lights 3 ..... .... ..... .... .... ..... .... ..... 1 01
Instrument illumination ........ .... ..... 1 01
14 Bonne t rele ase lev er . .... .... ..... .... ..... . 63
15 starte r switch
with ste erin g wh eel lock .. ..... .... ..... ... 9
16 Stee ring wh ee l adju stm en t 3... ..... ... 9
17 Ac cele ra tor pedal .... .... .... ..... 138, 1 39
18 Brake peda l ..... .... ..... .... .... ..... 13 8, 1 53
19 Clutch ped al 3.... ..... .... .... ..... .... .... 13 9
Page
20 Heated seats 3.. ..... .... ..... .... ..... .... 115
21 Accessory socket or
cigare tte lighte r . ..... .... ..... .... ..... .... .. 7 5
22 Ashtray 3.... .... .... ..... .... ..... .... ..... .... .. 7 6
23 Air conditioning system 3... ..... .... 11 4
Heated rear w indow 3 ... .... .... 1 9, 114
Air recirculation system 3.... ..... .... 114
24 Heating and ventilation system .. 112
Climate control system 3.... ..... .... . 119
25 Glove compartme nt ... ..... .... ..... .... .. 7 7

12
Control indicators
XSea t belt 3:
see p age 29.
q Headlight range adjustment 3:
se e p age 10 0.
>Fog lights 3:
see pages 29, 101.
AEngine electronics,
immob iliser 3,
automat ic tra nsm ission 3,
Easyt ronic 3,
fault:
see pages 29, 51, 146.
Z Exhaust emission 3:
see pages 30, 51, 146.
v Airbag systems 3,
belt tensioners:
see pages 80, 89.
IO il pressur e:
see page 30.
OTurn signal lights:
see pages 16, 31.
CMain beam:
see pages 15, 31.
!Preheating 3for diesel engines
see page 31.
1 E lec tronical ly cont rolled driv ing
prog ramm es for
autom atic transmission 3,
sporty driv ing pr og ramm e:
see page 134.
TAutomatic transmission 3,
Easytronic 3,
wi nter program me:
see pages 128, 134.
r Fog tai l light:
see pages 31, 101.
pAlternator:
see page 31.
RBrake system,
clutch syst em :
see page 32.
u Anti-lock brake system 3:
see page 154.
SEngine oil level 3:
see pages 32, 212.
EPS Electr oni c power steering 3:
see page 32.
v Traction Control System (TCPlus ) 3:
Electr oni c Sta bility Program
(E SP Plus )3:
see page 148.
g Trailer turn signa l 3:
see page 32.
Y Fuel level:
see pages 32, 36, 170.
ySeat occup ancy recog nition 3:
see pages 89, 90.

13
Lighting
Lig ht s witch,
st alk p o si tio n s :
see pages 15, 99,
7Lights off,
8Park ing lights,
9Dip ped and main beam.
0Courtesy lig ht:
se e p age 10 1.
CMain beam:
see p age 15.
OTurn signallights:
see p age 16.
>Fog lights 3:
se e p age 10 1.
r Fog t ail lig ht:
se e p age 10 1.
kInstrument illum ination:
se e p age 10 1.
?Headlight range adjustment 3:
se e p age 10 0.
¨Haza rd wa rning lig ht s:
see p age 17.
Clim ate co ntro l
xAir flow:
see pages 113, 122.
Air distribut ion:
see pages 113, 122,
VTo windscreen and
front door window s,
JTo windscreen, front
door windows
and footwell,
KTo footwell,
LTo hea d area and footwell,
MTo head area.
ÜHea ted rear window 3:
see pages 114, 121.
n Air conditioning system 3:
see page 114.
4Air recircul ation system 3:
see page 114.
AUTO Automatic mode 3:
see page 120.
ECO AC compressor
activ ation/de act ivat ion 3:
see page 122.
ßHeated seats 3:
see page 115.

14
Sun roof 3
lSun roof
op ening/lowering:
se e p age 10 6.
\Sun roof
closing/raising:
se e p age 10 6.
Fo ldin g sun roof 3
\Folding sun roof
op en in g:
see pages 107, 109.
lFolding sun roof
closing:
see pages 107, 109.
Windscreen wiper
Stalk positions:
see p age 17,
§Off,
$ Interval operation or
automat ic wiper
with ra in sensor 3;
% Slow,
& Fast.
Date, time, info rmatio n di splay,
Infotainment system
Inform ation d isp lay 3:
see page 37.
ÖOn button for date and time,
;Setting buttons for date and time
Infotainment system
remote contr ol 3:
see page 26.
Cruise control 3
Buttons on turn sig na l stalk :
see page 150.
IActivate, store, a ccelerate
RResume
stored speed, decelerate
§Deactivate.
Misce llaneous
p Central l ocking system 3:
loc king – see pag e 54.
q Central l ocking system 3:
unlocking – see page 54.
jHorn:
see page 17.
TWi nter program ,
automa tic tr ansm issi on 3,
Easy tronic 3:
see pages 128, 134.
+Fir st- aid k it (cushion) 3:
see page 174.
¨Wa rning tri angle 3:
see page 174.

15
Light switche s:
7=Off
8= Parking lights
9= Dipped or main beam
Press 0=Courtesylight
Press >= Fog lights 3
Press r= Fog tail light
6 Furthe r informa tion – page 99,
head light warning device – page 24,
head lig ht ra nge adjustment 3– pa ge 100,
daytime running lights – page 99.
Dipped and main beam switch:
Main beam = Push lever forward
Dipped beam = Push lever forward
again
Blue control ind ic ator Cis lit when main
beam is activated .
Headlight flash:
Pull stalk towards steering wheel

16
To activate door-to-door light
functio n:
Key to oan d r emo ve ,
open driver’s door,
pull turn signal stalk tow ard steering
wheel
The d ip ped beam remains on for a further
3 0 se cond s a fte r closing th e drive r’s door.
If the driver’s door is left open,the lights will
go out after two minutes.
Door-to-door lighting can be deactivated
by inserting the key in the starter switch or
by pulling the turn signal stalk toward the
steering wheel again.
Operating turn signal lights:
Lever in rest position
righ t = up
lef t = do wn
Whenthe steeringwheel isturnedback,the
lever automatically returns to its orig inal
position.This will not happen when mak ing
a minor steering manoeuvre such as
changing lane.
When lane changing, m ove lever to
resistance point. When released, the lever
will spring b ack.
To operate cruise control 3:
Press buttons onstalk
Switc h on: tap button I.
Switc h off: tap button §.
Resume at stored speed: tap button R.
6Cruise control 3– see p age 150.

17
Hazard warning lights:
On = Press ¨
Off = Press ¨again
To aid location of the pushbutton, the red
surface is illum ina ted when the ignition
switched on. When the button is pressed,
its c ontrol ind ic ator flashes in time with the
hazard warning lig hts.
Ho rn o perat io n:
Press j
6 Airbag systems 3– pa ge 84,
remote control for radio
and Infota inm ent syste m 3– see pag e 26.
Windscreen wiper:
Stalk up
§= Off
$= Adjus table in te rval
%= Slow
&= Fast
Setting wiper interval to a value between 2
and 15 seconds:
Stalk to interval switching $,
Stalk to §,
Wait for desired interval,
Stalk back to interval sw itc hing $.
The interval remains stored until the next
change or until the ig nition is switched off.
Switc hing the ignition off and m oving the
stalk to $ sets the interval to 7 seconds.

18
Automatic wiper with rain sensor 3:
Move lever up
§= Off
$= Automatic wiper
with rain sensor
%= Slow (constant)
&= Fast (constant)
Autom atic wiping $: The rain sensor
detects the amount of water on the
windscreen and automatically regulates
th e w inds cre en wipe r.
Pu sh le ver do wn to sw itch off.
If necessary, the positions % or &can be
selected m anually.
Operating windscreen and
headlight wash systems 3:
Pull stalk towards steering wheel
The wiper will swipe for a few strokes.
The headlight wash system 3ca n be
operated when the lights are on.
On vehicles fitted with ra in sensor 3, keep
the sensor area clean.
6Further information –
see pages 218, 224.
Operating rear window wiper and
wash sys tem s 3:
W iper o n = P ush le ver fo rward
W iper o ff = P ull l ever towards
steering wheel
wa sh = P ush le ver fo rward
and hold
The rear window wiper swipes in timed
interva l mode.
The wip er will swip e for a fe w strok es when
washing.
6Further inform ation –
see pages 218, 224.
