GET MORE OUT
OF LIFE
Want more out of life? Then check out the Zafira Tourer from Vauxhall. The Zafira
Tourer combines the dramatic looks and personality of a premium MPV with the
versatility of a seven-seat people carrier* – with leisure storage and luggage space to
spare. The Zafira Tourer’s terrific to drive. Supremely comfortable. And full of
innovative features. So take a look at the stylish and flexible Zafira Tourer. It’s perfect
for your family’s active lifestyle.
This brochure covers Zafira Tourer ES, Exclusiv, Tech Line, SRi, SE and Elite models only. Some of the vehicles shown in this
brochure include options and accessories available at extra cost. And not all of the features described are available on every
model. We may also offer alternative Zafira Tourer models such as Special Editions. So for all current model or equipment
details visit the Vauxhall website: www.vauxhall.co.uk
*When all seats are occupied within the Zafira Tourer the passenger side third-row seat is only useable by a passenger up to a
maximum height of 150cm.

6
If you thought all people carriers drove the same think again. With bespoke
steering settings specifically tuned to the tough demands of UK roads and a Watt’s
link rear suspension set-up for a smoother, more stable ride, the Zafira Tourer
combines exemplary grip with serious agility – no matter how many passengers
are on board.
In addition, matching outstanding performance with impressive fuel economy and
CO2 emissions, Zafira Tourer is also highly tax efficient – a quality epitomised by
our Tech Line models. Company car drivers can experience Zafira Tourer for
themselves via our free 3 Day Test Drive programme. Please see back cover for
more details.
www.vauxhall3dtd.co.uk
THE POWER OF
SELF EXPRESSION

7

8
The best cars are designed around the driver. Slip behind the wheel of the
Zafira Tourer and you’ll have the immediate impression that everything’s been
taken care of. Strikingly styled and comfortably trimmed with premium materials
throughout, the Zafira Tourer provides conclusive proof that we wholeheartedly
support an active family’s needs, but always have the driver’s interests firmly in mind.
Thanks to the super-slim A-pillar design, visibility in the Zafira Tourer is
outstanding – particularly with the impressive panoramic windscreen. The cabin
is well-organised, thanks to the customisable FlexRail® centre console storage
system. And everything falls readily to hand. In short: the Zafira Tourer leaves
the driver comfortably in control – and passengers safely provided for.
WELCOME TO THE
CONTROL CENTRE

9

10
Don’t think of it as a travelling compartment. Think of it as a comfort zone. With
Vauxhall’s innovative Lounge Seating system, rear passengers have never felt more
relaxed. The system converts in seconds from three individual second row seats, by
sliding them rearward and inward to create two welcoming, captain-style chairs.
At the same time, the centre seat converts to an armrest, providing added comfort.
A clever rethinking of Vauxhall’s legendary Flex7® seating system adds to the
travelling experience. It means greater fore and aft adjustment. Easy-entry third
row seats. Plus a completely flat load floor once the rear seats have been folded.
CLIMB IN
CHILL OUT

11

12
Multi-tasking doesn’t get any easier than this. The Zafira Tourer has all the
versatility you need to breeze through your day. For those big, awkward loads, you
can fold all the rear seats flat to give you 1860 litres of load space. Or simply fold
single seats out of the way to make room for your passengers’ bulky luggage.
Whatever combination you need, quick-release straps ensure you’re ready in
no time at all.
VIP LOUNGE TO
CARRY-ALL IN TEN
SECONDS – FLAT

13

14

15
Looking for the ideal partner for your sporting or leisure activity? The Zafira
Tourer carries it off – in style. Inside, the Tourer’s load-carrying potential is
exceptional, with functional storage features and acres of space for all your kit.
Outside, the optional Flex-Fix® carrier – fully integrated into the rear bumper – makes
light work of transporting a couple of bikes. Need to carry an extra set of wheels or
two? Simply attach the accessory Flex-Fix® extension and hey presto: the ideal
platform for your impromptu cycling expedition, with space for up to four bikes.
PARK AND RIDE
ZAFIRA-STYLE

16
MORE FLEXIBILITY
FOR LASTING
COMFORT
Vauxhall is famous for its versatile
seating, and over the last two decades
we’ve honed flexible seating solutions
to perfection. Our benchmark Flex7®
technology allows you to fold single seats
flat or tip them up to get in and out. And
now on SE and Elite models Lounge
Seating takes Flex7® to a new level of
luxury – by letting you turn the three
individual second-row seats into two
welcoming captain-style chairs with an
armrest and extra space.
1. Third-row seating. All models come with a practical third row of seats to
make the Zafira Tourer a full-on people carrier*. Both outside second-row seats
slide forward and tilt up – so you can easily get in and out of the back.
2. Turn three seats into two. Lounge Seating is a great way of really spoiling
second-row passengers – or of keeping squabbling kids apart. The centre seat of
the second row flips down to make an armrest, and the two outside seats slide
back and away from the doors, giving you even more elbow- and legroom with
the minimum of fuss.
1
2
Please note, for illustrative purposes only. The lounge seating system is not available in the UK with the seat trim illustrated.
*When all seats are occupied within the Zafira Tourer the passenger side third-row seat is only useable by a passenger up to
a maximum height of 150cm.

17
3. Flat-folding seats. Loads come in all shapes and sizes,
and so does the luggage area in the Zafira Tourer. Each
individual rear passenger seat folds totally flat so you can
carry passengers and bulky loads at one and the same time.
4. Extra-large load space. Switch from limousine-like
comfort to all-purpose carrying ability in a matter of
seconds – so you can transport that furniture, DIY kit or
leisure equipment with ease. With rear seats folded flat, the
Zafira Tourer boasts a useful 1860 litres of luggage space.
3
4

18
SAFEGUARD YOUR
INTERESTS
Whether you’re driving alone or with your family, it’s comforting to
know the Zafira Tourer protects you all, with a full complement of
state-of-the-art active and passive safety features.
Select the innovative front camera system option available
on SE and Elite models and the Zafira Tourer will read the
speed limit signs and display a reminder on the facia,
helping you keep safe and legal. Leave your lane without a
signal and it can also warn you – just in case you’re tired or
distracted. The system also constantly indicates the distance
to the vehicle ahead, and alerts the driver if a collision is
imminent. It will even slow you down automatically should
the need arise, giving you time to apply the brakes.
The steel safety frame and airbag protection system.
It’s good to know you’re surrounded by quality safety
components. Every Zafira Tourer is built around an energy-
absorbing, high-strength steel frame, and is fitted with
front-, side- and curtain-mounted airbags that cushion your
head, pelvis and upper body in the event of an accident.

19
Traffic Sign Recognition (TSR).
Utilising the front camera function,
this clever system makes sure you’re
constantly made aware of speed limits,
even when temporary signs are put up.
TSR continually monitors road signs,
and gives you a warning if you
unintentionally stray over the limit.
It can even read and display motorway
electronic signs related to speed limits
like rain or snow warnings.
Lane Departure Warning (LDW).
LDW uses the front camera system
to recognise lane marking lines, and
emits an audible warning if your
vehicle leaves its lane unintentionally
(i.e. without you signalling), preventing
potential accidents and reminding
you of inattention or tiredness. The
LDW system can be deactivated via
a facia switch.
Adaptive Cruise Control (ACC) with
Forward Collision Alert (FCA).
ACC uses a radar sensor to
automatically maintain a gap from the
vehicle in front. It incorporates
Following Distance Indication (FDI)
which constantly shows the distance to
the leading vehicle in the instrument
panel, helping you to maintain a safe
distance. In addition, FCA – active at
speeds above walking pace – gives
visual and audible warnings if you
approach a slower-moving vehicle too
fast and uses Automatic Brake
Intervention technology to apply the
brakes, slowing the car to as little as
10mph if required.
Side Blind Spot Alert. Available as
part of the Perimeter Protection Pack
on SRi, SE and Elite models, this
ultrasonic-based system helps prevent
a potential collision with a vehicle in
the neighbouring lane by continuously
screening the blind spots on both sides
of the car and provides a visual warning
if the indicator is set to change to a lane
where another car is detected.

20
INTELLIGENT LIGHTING
FOR EVERY
ENVIRONMENT
Vauxhall’s intelligent Adaptive Forward Lighting (AFL)
technology is an invaluable optional addition to your
Zafira Tourer, especially if you do a lot of driving at night.
The headlights change their pattern to suit the location
and the weather. Sensing where you need the light
most, they help you see around corners and even dip
automatically when something is coming the other way.
You can also adjust the system for European driving.
Intelligent Light Ranging (ILR). Available in conjunction with AFL as part of
the Premium Forward Lighting Pack when the Front Camera System is specified,
ILR extends the range of both headlights up to about 350 metres at speeds over
30mph. ILR also automatically adjusts the spread to avoid dazzling oncoming
drivers. And if you’re approaching an upward gradient, it’ll even raise the beam to
give you a better view of the road.
