Vauxhall 2013 Combo User manual

VAUXHALL Combo
Operation, Safety, Maintenance
Owner’s Manual
Model Year 2010
Edition: June 2009
TS 1649-A-10

Data specific to your vehicle
Please enter your vehicle’s data here to keep it easily accessible. This data can be found under the sections "Technical data" and "S ervice
and m aintenance" as well as on the identification plate.
Fuel
Designation
Engine oil
Grade
Viscosit y
Tyre pressure
Tyre size front rear
Sum mer tyr es
Winter tyres
Weights
Gross vehicle weight rating
– ECkerbweight
=Loading

Introduction
Your vehicle is an intelligent synthesis of
advanc ed technology, proven safety,
environmental friendlinessand economy.
It now lies with you to drive your vehicle
safely and ensure that it perform s
perfectly. This Owner’s Manual provides
you with all the necessary information to
that end.
Make sure your pa ssengers a re awa re of
the possible risk of accident and injury
which may result from improper use of the
vehic le .
You must always comply w ith the specific
laws of the country in which you are
driving. These laws may differ from the
information in this Ow ner’s Manual.
When this Manual refers to a workshop
visit, we recommend your Vauxhall
Authorised Repairer.
All Vauxhall Authorised Repairers provide
first-class service at rea sonable prices.
Ex perienced mechanics trained b y
Vauxhall work acc ording to specific
Vauxhall instructions.
The custom er literature pack, consisting of
Owner’s Manual, infotainm ent system
instructions and the Service and Warranty
Booklet should always be kept in the
vehicle: ready to hand in the glove
compartment.
Make use of the Owner’s Manu al
zThe "In brief" section will give you an
initial overview.
zThe table of contents at the beginning
of the Owner’s M anual and within the
individual chapters will show you where
everything is.
zIts index will help you find what you
want.
zYellow arrows in the illustrations serve
as points of reference or indicate som e
action to be performed.
zBlack arrows in the illustrations indicate
a reaction or a second action to b e
performed.
zThis Owner’s Manualrefers toright-hand
drive vehicles. Operation in left-hand
drive vehicles is similar.
zThe Owner’s M anual makes reference
to internal engine designations. The
associated sales desig nations are
found in the section "Technical data".
zDirectional da ta , e .g. left or right, or
front or back, in the descriptions always
relate to the direction of travel.
Symbols
6Continue reading on next page.
E quipmen t m arked with 3is not found in
all vehicles (model variants, engine range,
national variants, special equipment,
Vauxhall genuine parts and accessories).
Page references are indicated with 3,
which means "see page".
9Danger, 9Warning, Caution
Thank you for choosing a Vauxhall.
We wish you many hours of pleasurable
driving.
Your Vauxhall Team
9 Danger
Text marked 9Danger provides
inform ation on p ossible fatal injury.
Disregard of the instructions m ay
e nd an ger life.
9 Warning
Text marked 9Warning provides
information on risk of accident or injury.
Disregard of the instructions maylead to
injury .
Caution
Text marked Cautionprovides
inform ation on p ossible d amage to the
ve h icle. Disre gard o f th e in struction s
ma y lead to vehicle da mage.

Contents Commitment to custom er
satisfaction:
Our ai m: to keep you happy with your
vehicle. All Vauxhall Authorised Repairers
offer first-class service at competitive
prices. Experienced, factory-trained
technicians w ork according to factory
instructions. Your Authorised Repa irer can
supply you with GEN UINE V AU XHALL-
APPROVED PARTS, which have und ergone
stringent quality and precision chec ks, and
of course useful and attractive
VAUXHALL-APPROVED ACCESSORIES.
Our name is your guarantee!
For d eta ils of the
Va uxhall Authorised Rep airer Netw ork,
pleasering this number; 0845 090 2044
In Brie f ... ..... .... ..... .... .... ..... .... ..... .... ..... .... .... . 2
Keys, doors,
win dows .... ..... .... .... ..... .... ..... .... ..... .... .. 18
S eats , In terior ..... .... .... ..... .... ..... .... ..... .... .. 36
Instrum ents ... ..... .... .... ..... .... ..... .... ..... .... .. 63
Lighting ..... .... ..... .... .... ..... .... ..... .... ..... .... .. 8 0
Infotain ment sys tem . ..... .... ..... .... ..... .... .. 86
C lim ate c ontrol .. .... .... ..... .... ..... .... ..... .... .. 88
Driving and op eration ... .... ..... .... ..... .... .. 9 6
S elf-help, veh icle care .... .... ..... .... ..... .... 12 1
S ervice and m a inte na nce .. ..... .... ..... .... 156
Te chnical data .. .... .... ..... .... ..... .... ..... .... 17 1
Inde x . .... ..... .... ..... .... .... ..... .... ..... .... ..... .... 185

2InBrief
In Brief
Unlocking the vehicle: Turn the
key in the lock forwards or press
the qbutton on the radio remote
control 3
Pull on the door handle and open the door
or slide open the slid ing door 3.
Sliding door 3 325. Key 318,
Elec tronic imm obiliser 319 ,
Remote control 3 321 ,
Ce ntral lock in g sy ste m 3 322,
Vauxhall alarm system 3329 ,
Child locks 3325.
Unlocking the tailgate 3: Turn the
key to the horizontal position or
press the qbutton on the rem ote
control 3
Press the button to open the tailgate.
When using the remote control, the tailgate
is only unlocked if the key slot in the button
is in the horizontal position.
If the key slot is in the vertical position, the
tailgate is always locked.
Remote control 3 321,
Central locking system 3 322 ,
Vauxhall alarm system 3329,
Tailgate 3326.

3In Brief
U nloc king the rear doors 3: Turn
the key to the vertical position or
press the q button on the remote
control 3
To open the right rear door, pull on the
handle andpull open the door. Toopen the
left rear door, turn the handle on the inside.
When using the rem ote control, the rear
doors are onlyunlockedifthe key slot in the
lock is in the vertical p osition.
If the key slot is in the horizontal position,
the rear doors are a lways locked.
Remote control 3 321,
Central locking system 3 322 ,
Vauxhall alarm system 3329,
Rear doors 3 327 .
Toadjust front seat leg room 3:
Pull h and le, s lid e s eat, relea se
handle
After adjusting, move the seat until you
can f ee l it engag e.
Sea ts 336, Seat position 337.
To adjust fron t seat bac krests:
Turn handwheel
Do not lea n on seat backrest whilst
adjusting it.
Seats 336, Seat position 337 .
9 Warning
Important: Do not sit nearer than
10 in ches (2 5 c m) from th e s tee rin g
wheel, to pe rm it sa fe airbag
deploym ent.

4InBrief
Front seat height 3: Pull lev er at
side
Lift lever a nd relieve som e weight from seat
to raise it or pre ss down on se at with body
weight to low er it.
Never adjust the driver’s seat whilst driving.
It could m ov e in a n uncontrolled m anne r
when the lev er has be en pulled .
Seats 336 , S eat p os iti on 337 .
To fold front seat backrest
forwa rd 3: Raise release lever
Sea ts 336, Seat position 337.
Adjust head restraint height 3of
front and rear outbo ard sea ts: Tilt
forward to release, hold in place,
adjust height and release again
Head restraint 338, Hea d restraint
position 339, Rear, centre head res traint 3
339.

5In Brief
Pull out the seat belt and engage
it in the belt buckle
The seat belt must not b e twisted andmust
lie snugly a gainst the body. The backrest
must not be tilted back too far (maxim um
approx. 25°).
To release belt, press red button on belt
buckle.
Three-point seat belts 346,
Airbag system 3354, Seat position 337.
Adjust the exterior mirror
manually using the handle
Mirrors 332, Aspherica l exterior mirrors
332, Folding the exterior mirrors 332 .
Electrical exterior mirror
adjustment 3
Select the corresponding exterior mirror
with the rocker switch and ad just with the
four-way switch.
Mirrors 332, Aspherical exterior m irrors
332, Folding the exterior mirrors 332,
Heated exterior mirrors 333.

6InBrief
To adjust interior mirror by
swivelling
Swivel lever on underside of mirror housing
to red uce daz zle a t nig ht.
Mirrors 333.
Steering wheel adjustment 3:
Sw iv el le v er dow n, ad jus t heig ht,
swivel lever up, engage
Ad ju st s tee ring whe el only wh en ve hicle is
stationary and steering column lock is
re lea se d .
Airbag systems 3 354.
Exterior lights
Turn light switch
Press light switch
Push button
Lighting 380, Headlight warning device
378.
7=Off
8= Parking lights
9= Dipp ed b eam or main beam
0= Courtesy light
>= F ro nt fog light s 3
r= Fog tail light

7In Brief
Headlight flash, m ain beam and
dipped beam
Main beam, headlight flash 381 .
Switch turn signal on
Turn signals 381.
Hazard warning lights
Operated with the ¨button.
Hazard warning flashers 382.
Headlight flash = Pull stalk toward s
steering wheel
Main beam = Push sta lk forwards
Dippe d beam = Push sta lk forwards
again
Right = Stalk upwards
Left = Stalk downwards

8InBrief

9In Brief
Page
1Side air v ents ... ..... .... ..... .... .... ..... .. 389
2 Front pa ssenger airbag 3.... ..... .. 354
3 Infotainment system 3. .... .... ..... .. 386
4Haza rd warning lights .. .... .... ..... .... 37
LED for Vauxhall
alarm system 3.... .... ..... .... .... ..... ... 330
5Display 3for time, date,
outside tem perature,
infotainment system 3. .... .... ..... .. 373
6Ce ntre air v en ts .... .... ..... .... .... ..... ... 389
7Turn signals, headlight flash,
dipped beam, main beam .. 36, 380
8Horn .... .... ..... .... ..... .... ..... .... .... ..... ... 311
9 Steering wheel remote control 3.386
10 Instrume nts .. .... ..... .... ..... .... .... ..... .. 363
Pa ge
11 Windscreen wiper,
windscreen wash system,
re ar w in do w w ash sys tem 3.... .... 378
12 Light s witch ..... .... ..... .... .... ..... 36, 380
13 Head lig ht range adjustment 3... 383
Fog tail lig ht .... .... ..... .... .... ..... .... ... 382
Front fog lights 3 ..... .... .... ..... .... ... 382
Instrument illumination ........ .... ... 383
14 Bonn et rele ase lev er . .... .... ..... .... . 3121
15 Starter switch with
Steering colum n lock ... .... ..... .... ... 314
16 Stee ring whee l adju stm en t 3... ..... 36
17 Ac celera tor pedal .... .... .. 3102, 3104
18 Brake peda l ..... .... ..... .... .. 3102, 3111
19 Clutch ped al 3.... ..... .... .... ..... .... . 3102
Page
20 Seat heating 3... ..... .... ..... .... ..... ... 338
21 Accessory socket or
cigare tte lighte r . ..... .... ..... .... ..... ... 359
22 Ashtray 3.... .... .... ..... .... ..... .... ..... ... 360
23 Air conditioning system 3... ..... ... 392
Heated rear w indow 3.... ... 312, 335
Air recirc ulation system 3.... ..... ... 393
24 Heating and v entilation system . 388
25 Glove compartme nt ... ..... .... ..... ... 361

10 In Brief
Control indicators
>Front fog lights 3,
363, 382 .
A Engine electronics,
Immob iliser 3, E asytr oni c3,
Fault,
319, 363 , 3109.
ZExhaust gases3,
364, 3109.
vA irbag systems 3,
Belt tensioners,
364, 348 , 357.
IEngine oil pressure,
364 .
OTurn signal l ights,
365 , 381.
C
Main bea m,
365 , 381.
!Preheating 3, diesel particle
filt er 3,
365 , 3110.
TWinter programme of
Easytronic 3,
399 .
rFog tail light,
366 , 382.
pAlternator,
366.
RBrake system,
clutch system 3,
366, 3168.
u
Anti-lock brake system (ABS) 3,
3112.
SEngine oil level 3,
367, 3164.
EPS Electric power steering (EPS) 3,
367.
YFuel level,
367, 3107.

11In Brief
Op era te horn: Pres s jright or left
Airbag system 3354, Remote control on
steering wheel 3386.
Windscreen wiper: Move stalk
upwards
Windscreen wiper 378, Adjustablewiper
interval 3379, Further information 3154,
3168.
Operating windscreen wash
system: Stalk toward steering
wheel
W in dscre en w ash s ys tem 378, Further
inform ation 3169, 3182.
&=Fast
%=Slow
$= Ad justable interval switching
§=Off

12 In Brief
Rea r win dow wiper 3and
Rear window wash system 3
operation
Rear window wiper and rear wind ow wash
system 378, Further information 3168,
3169.
Heated rear window 3, heated
exterior mirrors 3
Operated with the Übutton.
Climate control system 388 , H eate d r ea r
wind ow 335 .
To clear fogged or icy windows
Turn the rotary knobs for temperature and
air flow clockwise. Set airdistribution to V.
Air conditioning system 3: Also press
button n.
Climate control 3388.
Wiper on = Push sta lk forwards
Wiper off = Stalk toward steering wheel
Washing = Push stalk forward and hold

13In Brief
Manual transmission
Reverse gear: With the vehicle sta tionary,
lift the ring under the gear-lever knob
3 s econ ds afte r de pres sin g th e clutch, a nd
then engage the gear.
If the gear does not engage, p ut the lever
into neutral, release the clutch pedal and
depress again; then repeat gear selection.
Manual transmission 3101.
Easytronic 3
To move the selector lever from Nto R
pres s th e bu t t o n o n th e lev er .
Only start in Nwith foot brak e a pplied.
Easytronic 3 396.
Before starting off, check
zTyre pressure and tyre condition 3114,
3179,
zEngine oil level a nd fluid levels in engine
compartment 3163 to 3169,
zAll windows, mirrors, exterior lighting
and number plates are free from dirt,
snow and ice a nd operational,
zSeats, seat belts and mirrors are
correctly a djusted 336 , 346, 332 ,
zCheck brake func tion at low speed ,
particula rly if the b ra kes are wet.
N= Idle speed/sta rt position
o= Drive position (centre position)
+= Higher gear
-=Lowergear
A/M = Switch between Automatic and
Manual mode
R= Reverse gear (w ith selector lever
lo c k )

14 In Brief
Steering c olum n lock a nd ig ni tion
Turn key to position 1. Move the steering
wheel slightly to release the steering
column lock.
Starting the engine
Depress the c lutch and brake ped als,
Easytronic 3in N , do not acc elerate ; for
diesel e ngine, turn ke y to p osition 2; when
control indicator !goes out turn the key
to position 3 and release it when the engine
is running.
To repea t the start procedure or switch off
the engine, turn the key b ack to 0.
To switch on the ignition, turn the key to 2.
To release the handbrake: Raise
lever s lig htly , p ress relea se
button, lower lever fully
Hand bra ke 366, 3113.
0= Ignition off
1= Steering free, ignition off
2= Ignition on,
with dies el engine: prehea ting
3=Starting

15In Brief
Parking the vehicle
zAlwa ys apply ha ndb rake firmly without
op erating the release button, and apply
as firmly as possible on a downhill or
uphill slope.
zSwitch off the engine and ignition by
turning the ignition key to 0 and
removing it. Turn the steering wheeluntil
you can feel its lock enga ge (anti-theft
protection).
On vehicles with Easytronic 3, control
in d i c a to r Rflashes for a few seconds
after the ig nition is switched off if the
handbrake has not been applied.
zIf the vehicle is parked on a level surface
or an up hill s lope, wit h a m anu al
gearbox select first gear or with
Easytronic 3mov e the selector lever to
the centre position before switching off
the ignition. Also turn the front wheels
away from the kerb if the v ehicle is on an
uphill slope.
If the vehicle is on a d ownhill slope, with
manual gearbox or Easytronic 3se lect
reverse gear before switching off the
ig nition. Also turn the front w heels
to w a rd s t h e ke rb .
zLock the vehicle with the key in the lock
or the pbutton on the remote control.
Activate the anti-theft locking system 3
and Vauxhall alarm system 3by
pressing the pbutton twice.
Advice when parkin g
zDo not park vehicle on easily ignitable
surfaces as the hot exhaust system
temperatures could cause the surface to
ignite.
zClose windows.
zThe engine cooling fans may run after
th e e ng in e ha s be en sw itch e d o ff, 3163.
Locking doors 320,Remote control 3321,
Central locking system 3322, Vauxhall
alarm system 3329, Vehicle
decomm issioning 3170.
Interesting functions
See following p ages.
6

16 In Brief
Airbag system
The airbag system consists of several
internal systems.
Front airb ag system 3
The front airbag system will be triggered in
the event of a serious ac cident involving a
frontal impact and forms safety cushions
for the driver and front passenger. The
forward movement of the driver and front
passenger is checked and the risk of
injuries to the upper body a nd head
thereby substantially reduced.
Side airb ag system 3
The side airb ag system triggers when a
side-on collision occurs a nd provides a
safety barrier for the driver and/or
passenger in the respective front door
area. This reduces the risk of injury to the
up per body considerably in case of a side
impact.
Airba g Sy ste m 354.
Operating via the information
display menus
The menu options a re s ele cted via the
menus and with the button/four-way
button or the m ulti-func tion b utton of the
infota inm ent system 3or via the buttons 3
on the steering wheel. The menu options
app ear on the displa y.
To select with four-way button:
P res s f o ur -w ay b u tt o n up , do wn , r igh t o r
left.
